Amana DigiSmart PTC models User manual

MC-DPTAC www.amana-ptac.com 2/13
Amana® is a trademark of Maytag Corporation or its related companies and used under license to Goodman Company, L.P. All rights reserved. Supersedes 9/12
Packaged Terminal air condiTioners and HeaT PumPs
wiTH our digismarT®conTrol Board & ems
PTac sPecificaTions and accessories caTalog
Assembled in the USA for 30 years:
Units are 100% run-tested and
triple-tested for leakage.
• First-Year Warranty: Parts & Labor
• Second through Fifth Year: Parts & Labor on certain sealed
system components
• Second through Fifth Year: on certain functional parts only
* Complete warranty details available from your local dealer or
at www.amana-ptac.com.

2 www.amana-ptac.com MC-DPTAC
• EnergyEfciencies:WithEERsupto11.7andCOPsupto3.4,ourunit’shighefcienciesmayqualifyyouformanyoftherebates
offered by electrical power companies.
• QuietOperation:OurPTAChasbeenredesignedtobethequietestPTACwe’veeverbuilt.Theunit’sstate-of-the-artdesignand
constructionprovideaquietenvironment,allowinggueststoenjoypeaceful,sleep-llednights.
• Two fan motors (indoor/outdoor)
• Indoortangentialfanforquietoperation
• STC of 28
• AssembledintheUSAfor30years: assembled at our plant in Fayetteville, TN, using Goodman resources including
engineering, production, and testing.
• IncreasedDehumidicationCapacity: Maintain lower humidity levels in rooms while cooling them without the need
for expensive add-ons. As a result, guests feel more comfortable at higher temperatures, thus reducing cooling costs.
• Seven-ButtonTouchPad:Providescompletecontroltoguestsforin-roomcomfortwhilemaintainingenergyefciency.
• Five-YearLimitedWarranty:Enjoyoneofthemostcomprehensivewarrantiesintheindustry:FirstYear:parts&labor;Second
throughfthyears:parts&laboroncertainsealedsystemcomponents;secondthroughfthyears:oncertainfunctional
parts only. For complete warranty details, visit www.amana-ptac.com.
• 100%RunTested: All units are 100% run tested at our plant in Fayetteville, TN, including leak checks during manufacturing and
again prior to shipment at the warehouse.
• 7”UnitFrontDepth: Enhance valuable room space with our slim unit front, which has a sleek 7” depth, one of the shallow-
est silhouettes in the industry today. In addition, to inhibit guest-tampering, the front can be secured to the chassis with a
hidden screw.
• RemovableCondenserShroud:Allowseasyaccesstoenableregularcleaningofcoils,whichisessentialtomaintainunitefciency
and protect the compressor for long unit life.
• EasyPull-OutFilters:Ourltersarewashableandeasytomaintain.
• FilterDryerforSealedSystemRefrigerant: Standard in all units to protect the compressor and lengthen the life of the unit by remov-
ing moisture and preventing acid formation.
Removable/Cleanable ShRoud foR eaSy Cleaning
filteR dRyeR
eaSy Pull-uP filteRS

sTandard feaTures

MC-DPTAC www.amana-ptac.com 3
sTandard feaTures (conT.)
• CondensateDispersionSystem: Our condensate dispersion system removes condensate from indoor cooling operation by throwing
waterdirectlyontotheoutdoorcoilforrapidevaporationandincreasedcoolingefciencies.Theslingerringonthenew,
enhanced fan draws water up and into the fan blades. This water is then atomized and evaporated into the atmosphere
through the condenser. Increased surface area from the coil allows more water to be evaporated on the sides of the coils and
helps to minimize condensate run-off.
• FrontDeskControl:EachunitcomesequippedwiththeDigiSmart™controlandenergymanagementsoftware.WithDigi-Smart™
using the optional RF Antennae, all units can be wirelessly connected to a central hub for enhanced energy savings and
diagnostics.AmanabrandPTACsalsohavealow-voltageinterfacecapabilitywithaeld-suppliedfront-deskON/OFFswitch.
(See Page 4.)
• RoomFreezeProtection: When the unit senses temperatures of 40°F or below, the unit activates the fan motor and either the
electric resistance heater or the hydronic heater.
• Easy-to-useControls: No complex controls to confuse your guests and create phone calls for your manager. Controls are easy to
read, understand, and activate. Our new 7-button control panel provides guests with complete control of the unit for their
in-roomcomfortwhilemaintainingoverallenergyefciency.
• EasytoServicewithOn-BoardLEDDiagnostics: The main components are easily serviced and there is no guessing to determine the
problem with our easy-to-read diagnostics.
• StonewoodRoomFront:OurStonewoodroomfrontstrikesthebalancebetweenattractivestylingandpracticaldesign.Distinc-
tive contours and a modern appearance enhance the character of even the most luxurious room, while the sleek 7” depth
maximizes usable space for your guests.
• RemoteThermostatControl:WhentheDigiSmart™wirelessremotethermostat(DS01E,soldseparately)issetup,boththeremote
thermostatandunitcontrolpanelcontinuetocontroltheunit,providingexibilityandhome-likesystemcontrol.Installa-
tionrequiresnomorethanpressingtwobuttons.Noneedtorunwiresormakeelectricalconnections.
• RemoteTemperatureSensing:Guestsenjoyultimatecomfortwithconsistentclimatecontrol.Whentheeld-installedthermistor
(RTS03) is used, the unit-mounted thermostat is overridden to allow more accurate, internal wall-sensing of room ambient
temperature.
• ExtendedHeatPumpHeating: Heat pump models will operate in the heating mode down to as low as 24°F outdoor ambient tem-
perature.
• ZeroFloorClearance:Theunitcanbeinstalledushtoanishedoor,ifdesired.(Someaccessoriesdonothavezeroclearance).
• 30-SecondFan-OffDelay: The fan continues to run 30 seconds after the compressor has stopped in either cooling or heat pump
modeandafterelectricheathasbeenturnedoff.Thisimprovesefciencybydispersingtheconditionedaironthecoilsinto
the room.
• CompressorLock-In: This feature helps prolong the life of the compressor by preventing short-cycling. When the compressor is
switchedfromOfftoOnbecauseroomtemperaturehasrisenorfallenbelowthespeciedlimit,itwillremainonforatleast
4 minutes. If the temperature set-point is changed during this 4 minutes, the lock-in feature is overridden.
• AutomaticEmergencyHeat: No more “my unit is not heating” complaints during the middle of the night. Heat pump units will
automatically switch over to electric resistance heat if the heat pump compressor system fails or if the heating load is greater
than the unit capacity.
• ConstantFanMode: Take advantage of each unit’s dual options — select continuous fan operation or cycle the fan ON and OFF
with the thermostat. Our new 7-button design allows guests to select fan performance while allowing the owner to have the
unit revert to the desired program of continuous fan or cycle with conditioning.
• HiddenVentilationControl: The ventilation control lever is hidden from the occupant's view to allow you to manage ventilation
requirements.
• High-PressureSwitch: Protects the unit from high pressure and damage to the unit, helping to ensure long unit life.

4 www.amana-ptac.com MC-DPTAC
brings together our best PTAC ever with our best Energy Management Software and now integration with
PropertyManagementand FrontDeskManagement Software.ReducePTACenergy consumptionby 35%OR MORE*through
the power of the in-unit Energy Management System, programmable temperature set-back and limits combined. Reduce PTAC
maintenancecostthroughourautomatedmaintenancenoticationsystem.Improvedmaintenancesustainsenergyefciency
(EER)andprolongsPTAClife,keepingequipmentrunningatitsdesignedefciencylevelandroomguestsmorecomfortable.
THe amana Brand digismarT soluTion
in-room: “self-insTallaBle” wireless PeriPHerals
TheDigiSmartOccupancySensorcompletesthein-roomequipment.Thisinfraredsensorcan
determineiftheroomisoccupiedorempty,andwhenemptysignalsthePTACtoadjustthe
temperature to save energy based on programmable setbacks.
TheDigiSmartWirelessRemoteThermostatcanmountonthewallanywhereintheguestroom.
Battery powered and with its own wireless ability to communicate with the PTAC to maintain
room temperature. Best of all, no wires to run. The PTAC and Thermostat connect at the press of
a button and are permanently linked. The thermostat and PTAC work in-sync to display accurate
temperature.
TheDigiSmart WirelessAntennainstalls insidethe PTAC witha snap-inconnector. Installingthe antennaallows thePTACto
communicatewirelesslywithotherdevicesintheroomandtotheDigiSmartnetwork.
>45,000+roomshavehadwirelessinstallationssince2005
>Totalwirelessdevicesdeployedtodate:120,000+
TheAmanabrandDigiSmartPTACwithantenna,combinedwiththeself-installable,wirelessThermostatandOccupancySensor
givethepropertyownercompletecontrolovertheequipmentsettingsandcanreducePTACenergyusageby35%ORMORE.*
siTe-level —
cenTral wireless conTroller
>Site-widePTACConguration
>Site-widePTACDiagnostics
>FrontDeskSystemInterface
> Email Reporting
> Internet Accessible Web User
Interface Enterprise
*ThesesavingsrepresentestimatedsavingsovertimeascomparedtothesamePTACmodelwithouttheDigiSmartEMSSysteminstalledandweregenerated
using general assumptions including energy loads, local weather averages and use of occupancy controls. Actual savings will vary according to actual use
habits,roomsquarefootage,andhowtheunitisinstalled.

MC-DPTAC www.amana-ptac.com 5
enTerPrise — mulTiPle wireless conTrollers
CentRal monitoRing and
ContRol of multiPle PRoPeRtieS
>DataWarehousing
> Savings Analysis
> Email Reporting
> Virtual Metering
> Load Shedding
weB-Based, real-Time moniToring
amana® Brand digismarT™ conTroller:
All of the PTACs in the building can be managed through a single interface on a PC.
FEATURES INCLUDE: Full unit details for every PTAC, visible from the front desk or home ofce, automatic emails for PTAC
maintenance, ability to change all settings on the unit, and enhanced diagnostics. Monitor up to 170 PTACs, WIRELESSLY, with one
controller. Additional controllers can expand the network for additional rooms/properties.
>SystemVerication
> Global Setbacks
>EMSConguration
> Site Statistics
> Battery Notices
> Email Reporting
> Unit Health
> Unit Code Alerts
Temp Limiting – Each PTAC
can be congured with a heat-
ing and cooling temperature
set-point limit.
Setbacks – Once a room is
declaredunoccupiedbytheoccupancysensor,thePTACprogressesthroughthreedifferenttemperaturesetbacks,conguredas
threedegreeandtimepairs(Anexamplecongurationislistedbelow).
1st: 2°, 30 mins – Setback the temp 2 degrees after 30 minutes
2nd: 4°, 1 hr – Setback the temp 2 more degrees after 30 more minutes
3rd: 8°, 3 hrs – Setback the temp 4 more degrees after 2 more hours
UnrentedSet-Points–Byintegratingwithyourproperty'sFrontDeskSystem,thePTACswilladjusttospecicset-pointswhenno
longeridentiedasrentedinthesystem.

6 www.amana-ptac.com MC-DPTAC
nomenclaTure

BasicModelType Engineering
PTC StandardCoolerPTAC Major&MinorRevisions
PTH
StandardHeatPumpPTHP
DRY DehumidCoolerPTAC FeaturesCode
A StandardModel
CoolingCapacity C CorrosionProtec>on(Seacoast)
07 7000BTU/h
60Hz
D PowerDoor
09 9000BTU/h
60Hz
F FuseHolder(230/208Only)
10 10000BTU/h
50Hz
H HydronicHeatCapable
12 12000BTU/h 50or60Hz P CondensatePump(PTHOnly)
15 14000BTU/h
60Hz
Q QuietSTC31Chassis
RatedVoltage R RFAntenna
2 115V,60Hz,1Ph V PowerVent
3 230/208V,60Hz,1Ph X placeholder
4 265V,60Hz,1Ph W HardWired(PTQC)
5 240/220V,50Hz,1Ph
Useupto4asneededinalphabe>calorder
DesignSeries Examples:
G R410A PTC123E50AXXX PTC073E35CRXX
PTC123E50CXXX PTC073E25CQRW
HeaterSize
00 NoElectricHeat 3.5kW(230/208V)
15 1.5kW 3.7kW(265V)
25 2.5kW 5.0kW
PTC 07 3 G 35 AXXX
50
35
AA
1,2,3 4 5 6 7,8,9
10,11,12,13
14
Power cord configuraTion
277VRatingPowerCordPlugs
NEMA7Conguration
G
W
20 amp
G
W
30amp
250VRatingPowerCordPlugswithLCDIDevice
NEMA6Conguration
PowerCordPlugs
15 amp 20 amp
30amp
PowerReceptacleConguration
NEMA6-15R; 250V
receptacle used on
230/208V units
NEMA6-20R; 250V
receptacle used on
230/208V units
NEMA6-30R; 250V
receptacle used on
230/208V units
NEMA7-20R; 277V receptacle
used on 265V units
NEMA7-30R; 277V receptacle
used on 265V units
All units come with factory-installed power cords.
Allunitslessthan250voltscomewithLCDIdevice.

MC-DPTAC www.amana-ptac.com 7
ProducT sPecificaTions: PTc models — cooling/elecTric HeaT
230/208 voltS
, , PTC
073G***XXX
PTC
093G***XXX
PTC
123G***XXX
PTC
153G***XXX
Voltage ³ 230 / 208 230 / 208 230 / 208 230 / 208
Capacity (BTU/h) 7,700 9,000 11,700 / 11,500 15,000 / 14,700
Amps  3.5 4.1 5.6 7.0
  670/660 805/785 1135/1105 1500/1470
EER 11.5 11.2/11.5 10.3/10.4 10.0/10.0

Min. Circuit Amps ²,, 4.2 4.9 6.8 8.5
CFM (Cool/Wet Coil) High 290 290 290 340
Low 264 264 264 314
CFM (Dry Coil) High 310 310 310 360
Low 282 282 282 332
    
 1.7 2.2 3.6 4.4
Net Weight (lbs.) 98 102 102 113
Ship Weight (lbs.) 113 117 119 130
265/277 voltS
 PTC
074G***XXX
PTC
094G***XXX
PTC
124G***XXX
PTC
154G***XXX
Voltage ¹, ³265 265 265 265
Capacity (BTU/h) 7,700 9,000 12,000 14,800
Amps  3.0 3.6 4.8 6.0
  670 795 1,165 1,480
EER 11.5 11.3 10.3 10.0

Min. Circuit Amps ²,, 3.6 4.4 5.9 7.4
CFM (Cool/Wet Coil) High 290 290 290 340
Low 264 264 264 314
CFM (Dry Coil) High 310 310 310 360
Low 282 282 282 332
    
 1.7 2.2 3.6 4.4
Net Weight (lbs.) 98 102 102 113
Ship Weight (lbs.) 113 117 119 130


 
 
 
 

 
 
 
 
 


8 www.amana-ptac.com MC-DPTAC
ProducT sPecificaTions: PTH models — cooling/HeaT PumP/elecTric HeaT
,,,9
**AXXX

**AXXX

**AXXX

**AXXX

**AXXX

**AXXX

**AXXX

**AXXX
Voltage ¹,³ 230 / 208 230 / 208 230 / 208 230 / 208 265 265 265 265
Capacity (BTU/h) 7,600 9,000 12,000 14,200 7,600 9,100 12,000 14,200
 3.9 4.2 5.8 7.0 3.1 3.7 5.0 6.1
 650 785 1,125 / 1,100 1,465 / 1,445 650 790 1,120 1,465
EER 11.7 11.5 10.7 9.7 11.7 11.5 10.7 9.7

Min. Circuit Amps ²,, 4.7 5.1 7.1 8.5 3.8 4.5 6.1 7.4
CFM (Cool/Wet Coil)
High 340 330 340 390 340 330 340 390
Low 245 245 245 340 245 245 245 340
CFM (Dry Coil)
High 370 360 370 410 370 360 370 410
Low 270 270 270 370 270 270 270 370
        
        
 1.7 2.2 3.6 4.4 1.7 2.2 3.6 4.4
Net Weight (lbs.) 108 112 115 126 108 112 115 125
Ship Weight (lbs.) 123 127 132 143 123 127 132 142









outdoor ambient.






MC-DPTAC www.amana-ptac.com 9
ProducT sPecificaTions: PTH models — reverse-cycle HeaTing Performance
ProducT sPecificaTions: PTc / PTH models — elecTric HeaT Performance
(PrimaryHeatingforPTCModels;AuxiliaryHeatingforPTHModels;SeebelowforPowerCordConguration)



**AXXX

**AXXX

**AXXX

**AXXX

**AXXX

**AXXX

**AXXX

**AXXX
Voltage ¹, ³ 230 / 208 230 / 208 230 / 208 230 / 208 265 265 265 265
 6,800 8,300 / 8,100 11,500 / 11,300 13,800 / 13,600 6,800 8,300 11,400 13,700
 3.9 4.2 5.8 7.0 3.1 3.7 5.0 6.1
 585 / 570 715 / 700 1085 /1035 1350 / 1330 570 715 1080 1340
 3.4 / 3.5 3.4 3.1 / 3.2 3.0 3.5 3.4 3.1 3.0
CFM (Dry) 370 360 370 410 370 360 370 410









outdoor ambient.











 









  
230/208V 2.5 1 8,500 6,800 - - 2,570 / 2,115 11.2 / 10.1 14.1 15 
230/208V 3.5 1 12,000 9,900 - - 3,570 / 2,935 15.5 / 14.1 19.5 20 
230/208V 5 1 17,100 14,000 - - 5,070 / 4,160 22.1 / 20.0 27.6 30 
265V 2.5 1 - - - - 8,500 2,570 9.7 12.2 15 
265V 3.7 1 - - - - 12,600 3,770 14.2 17.9 20 
265V 5 1 - - - - 17,100 5,070 19.2 23.9 25 







outdoor ambient.






10 www.amana-ptac.com MC-DPTAC
accessories


16
1
/
16

StandaRd outdooR gRille
SGK01B Single Pack
SGK01TB Stonewood Beige
aRChiteCtuRal outdooR gRille
AGK01CB Anodized Aluminum (Silver)
AGK01DB DarkBronze/Brown
AGK01TB Stonewood Beige
AGK01WB Amana White
AGK01SB Custom Colors
PGK01DB DarkBronze/Brown
PGK01TB Stonewood Beige
PGK01TB Amana White
 
Wall SleeveS
All our wall sleeves have industry standard dimensions of 42” wide x 16”
high. All Stonewood Beige G-90 metal wall sleeves are thermally insulated
and include a weather board for use during construction. The WS900D, SC
and INTERNAL 14” depth is the industry standard. Sleeves may be shipped
separately to allow for installation during construction.
outdooR gRilleS
Available in stamped-aluminum or architecturally louvered for application with
anAmanabrandWS900Dwallsleeve.
AGK—Extruded aluminum architectural grille available with anodized alu-
minumnishorabaked-onpaintnishfordurability.Choosefrom
3 stock colors or a custom color to blend with your building’s exterior
color scheme. Colors include:
CB(ClearAnodized),DB(DarkBrown/Bronze),
TB (Stonewood Beige), WB (White), SB (Special/Custom Colors)
PGK—One-pieceinjectionmoldedgrilleusingapolymerblendofengi-
neered thermoplastic high-impact strength material with chemical
resistance and an exterior UV protective coating.
Choose from 3 stock colors:
DB(DarkBrown/Bronze),TB(StonewoodBeige),WB(White)
Skirting Skirting
Leveling Legs
Optional
Fuse Holder
Location
Optional
Power Switch and Circuit Breaker
Location
Power Receptacle
Subbase Box Assembly
 230/208V 15/20A
 230/208V 30A
 265V 15/20A
 265V 25A
 Non-electrical
Sub-baSe Kit
The fully skirted sub-base conceals wiring while providing strong support, if
needed.Plug-inreceptacleandeld-wiringaccessspeedsinstallation.Electrical
accessories, such as fuse holders, circuit breakers and disconnect switches, meet
N.E.C.requirements.
loW-voltage WiRe haRneSS Kit
Forquickconnectionsoftheremote,orwired,thermostats,wiredEMS,orfront
deskwithjumpersandconnectors.
 
Remote eSCutCheon Kit (not ShoWn)
Optional kit for use with units controlled via a wired, remote thermostat. Covers
control touch-pad for wired thermostat installations.
Each kit contains 80 wires and wire nuts, enough to
attach a thermostat and one additional accessory
to 10 PTAC units. Wires come in assorted colors for
easy attachment.
 
(use with WS900E)
 
CondenSate dRain Kit
Attaches to the wall sleeve base pan for controlled internal or external disposal
of condensate. 
StandaRd dePth SleeveS
WS900E Standard PTAC sleeve
WS900SC Seacoast triple protected
WS900D-
INTERNAL
Internal drain only for
window-wall installations
(DK900Dsoldseparately)
extRa deeP SleeveS
We offer sleeves in several depths for thicker wall
installationsorspecialroomcongurations
WS9xxD1 16” to 24” in 1” increments
WS928D1 Extra deep 28”
WS930D1 Extra deep 30”
WS936D1 Extra deep 36”

or


 
 
 
haRd-WiRe KitS
Used to permanently wire to the chassis when a standard sub-base and power
cord are not used.
LL2B 

leveling legS
Gives wall sleeve front support and helps to level the unit for installation.

MC-DPTAC www.amana-ptac.com 11
accessories (conT.)
 230/208V 15A
FHK315E 230/208V 15A (R-410A)
 230/208V 20A
FHK320E 230/208V 20A (R-410A)
 230/208V 30A
FHK330E 230/208V 30A (R-410A)
fuSe holdeR Kit
Cartridge-style fuses can be installed in the fuse holder for use in the sub-base or
chassis.Availablein15,20and30amp(includedon265-voltunit).
 
CiRCuit bReaKeR Kit (230/208v only)
Thecircuitbreakerkit,availablein15,20or30amp,canbeusedwithAmana
brand sub-bases. It gives overcurrent protection, and its location allows you to
turn the unit on or off without tools.
Basepan
Condenser
Condenser Baffles
 
CondenSeR baffle Kit
For use on non-bafed grilles. These deectors direct the air in toward the
center and away from the inlet to prevent recirculation of the hot condenser air.
 230/208V
 265V
PoWeR diSConneCt SWitCh
ThePSHW**Apowerdisconnectswitchcanbeusedfor265-voltor230/208-volt
physicaldisconnect,whererequiredbylocalcodes.Theswitchisratedat30-
amp capacity. The switch is for use with and Amana® brand standard sub-bases
or PTPWHWK4 Hard Wire Kit.
 Main Duct – R-22
 Main Duct – R-410A
 
duCt extenSion Kit
Extendsairdistributiontoanadjoiningroom.Consistsofamainductfortheroom
oforiginandanextensionducttoreachtheadjoiningroomandterminalduct.
PTDK01Aallowsforthenew“B”seriesunittoworkwiththe“A”seriesductkits.

TRANSITION BAFFLES


 Terminal Duct
 
 
 230/208V – R-22
 265V – R-22
PoWeR vent Kit
InstallationofPowerVentincreasesCFMuptoapproximately95.Ventdoorwill
automatically close when unit fan is off.
R-410A models must have these kits installed at the factory.
 230/208V – R-22
 265V – R-22
 230/208V – R-410A
CondenSate Removal PumP
Canbeeld-installed.Assistsinremovingcondensatedevelopedbyheatpump
operation and transfers it to indoor coil to dissipate into room while adding
humidity to the room.
Sub-baSe extenSion CoveR Kit
Converts older 30-amp sub-bases to allow for installation of the larger 30-amp
LCDIpowercordandplugs.
SBEC10A 

12 www.amana-ptac.com MC-DPTAC
accessories (conT.)
theRmoStatS
The following thermostats offer remote control. Any thermostat other than those listed must be submitted to Goodman Company, L.P., for approval prior to use.
 230/208V – R-22
 265V – R-22
 230/208V – R-410A
 265V – R-410A
PoWeR dooR Kit
Vent door will automatically open when unit fan is on.
 
 
 
 
hydRoniC heat Kit
Add-on kits t all units allowing the addition of hydronic water or hydronic
steam heat to cooling and heating units. The kits feature left- or right-hand
piping. Unit retains complete service access with a kit installed. Unit must be
connected to and operated by a wall thermostat.



 2-way/24V/NC/Steam
 
 2-way/24V/NC/End Switch
 
 

hydRoniC valveS
Water and steam valves are available for use with the HWK03 (water) and HVK03
(steam) heat kits.
 
 
SeCuRity Key loCKS
Inconjunctionwiththetamper-resistantfront,theinstallationofAmana®brand
security key locks prevents tampering of the controls used to set temperature,
heating and cooling functions. UL approved for institutional use only.
RTS03 Remote wall-mounted sensor
Remote temPeRatuRe SenSoR
Unit can be wired to sense room temperature away from the PTAC to have
accurate readings.
DS01E 
DD01E 
DT01A Antennae / Router
GT01A Generic Radio Antenna / Router
DD01F 
 
DL01E 
WiReleSS Rf (Radio fRequenCy) ContRolS
AllDigiSmartPTACscomefactory-readytobecontrolledviawirelessRFdevices.
2.4Ghz80215.4protocolassuresrobustcommunicationsandresponse.
 








      
2246002 1 1 1 5 No Yes Digital Manual  Wired
2246003 2 2 2 7 Yes Yes Digital Manual  Wired
2246007 2 2 2 7 Yes Yes Digital Auto-Change  Wired
2246008 2 2 2 7 Yes Yes Digital   Wired
DS01E 2 2 2 0 Yes Yes Digital Manual  Wireless

MC-DPTAC www.amana-ptac.com 13
accessories (conT.)
WEMR01W Recess-mounted door switch
WEMS01B 
WEMS01W 
WiRed eneRgy management ContRol
Includes PIR occupancy sensor power from the DigiSmart control and door
switch;cannotbeusedwitharemotewiredthermostat.
SECM1001A 

SEZA0501A 

Wall Sleeve extenSion adaPteR KitS
Room-side extension kits to increase the depth of the existing sleeve to allow for
an industry-standard PTAC to be installed.
 
 
CuRtain baffle Kit
Thecolor-matchedpolymercurtainbafeshelptopreventcurtainsfromfalling
into the discharge air stream and causing recirculation, reducing efciencies
and shortening compressor life.
inTake air filTers
Itisextremelyimportanttocleanthe inlet airltersoncea month(ormoreoftenifoperatedindustyordirtylocationsor
conditions)toproperlymaintaintheoperationalperformanceofthePTACunit.Thetwointakeairlters(constructedofdurable
polypropylene)canbeeasilyinsertedintothecabinetfrontusingthecabinetlterguides.Beforecleaningtheintakelters,turn
theunitoffbysettingthemodeswitchtotheOFFposition.Filtersshouldbecleanedasrequired.Thefollowingprocedureisused
toremovetheintakelters:
1.Facingtheunit,pulluponthelterhandleslocatedatthefronttopoftheunit.
2.Pulleachlterupwardandremove.
3.Cleanlterswithvacuumorwithrunningwater.Reversethisproceduretoreinstallthelters.
Note:Accessorylterkitsareavailablefromyoursalesperson.Allltersarepermanentandcleanable.Consultyour
I&O Manual for other monthly cleaning instructions.
monTHly mainTenance
sPare filTers
Helps keep dirt and lint out of the air and off the coil,
thus increasing the unit's efciency. Amana® brand
ltersareeasytoremove,washandreplace.
 
 
 


rePlacemenT cHarcoal filTer kiT
Absorbs airborne odors caused by cigarette, pipe
or cigar smoke and odors caused by mold, mildew,
etc. Filters are made of polyester bers coated with
activated charcoal and are individually wrapped. These
lters are permanent and can be washed or cleaned.
Call your Amana® brand PTAC sales person for details.
10ltersperpack.
 
 

14 www.amana-ptac.com MC-DPTAC
uniT wiTH accessory wall sleeve and suB-Base accessory
3 "
1"
1"
6-1/8" 9 - 9 / 16" 24 - 5 / 16"
40"
42"
Location of external drain holes
on bottom flange of Wall Sleeve
3" Clearance
to side walls
Air
Flow
Air
Flow
Air
Flow
Air Discharge Grille Control
Door
ToP view
11-3/8"
40°
21-1/2"
1 -3 /8"
13/16"
14-1/8"
4"
2-3/4"
15°
7-3/8"
1/2" O.D.
COPPER
DRAIN TUBE
AIR DISCHARGE GRILLE IS
REVERSIBLE TO PROVIDE EITHER
15° OR 40° DISCHARGE ANGLE
HINGED
CONTROL
DOOR
OPTIONAL
SUBBASE
13/16"
7/8"
STAMPED GRILLE
1-3/8"
ARCH GRILLE
WALL SLEEVE
16-1/16"
rigHT view
fronT view
58” lcdi cord seT — 230v/208v uniT*
58" CORD SET 230V/208V UNIT*
18" CORD SET 265V UNIT*
3-1/4"
MIN
2"
MAX
2-5/8"
42"
16-1/16"
R IGHT
LEFT
1" AND 3/4" CONCENTRIC KNOCKOUTS BACK
& BOTTOM OF SUBBASE (ELECTRICAL ONLY)

MC-DPTAC www.amana-ptac.com 15
FINISHED FLOOR
42 1/4"
16 1/4"
MIN
MAIN STUD
JACK STUDS
HEADER - 4" x 4" OR
DOUBLE 2"x 4" ON EDGE
SUB-FLOOR
CRIPPLE
JACK STUD
ADJUST FRAMING TO
SECURE THIS DIMENSION
framing for accessory wall sleeve (ws9XX)





 to the outside.
(

 
See Note 4 if using hydronic units.
2. 

 ®brand ®brand 
®
 ®brand

mounted thermostat.
5.
Mounting
Holes
(Drilled by
Installer)
Plastic
Anchor
Screws
Expansion
Anchor Bolt
Toggle Bolt
Wood Screw
Alternative
Fastening Method
(Field Supplied)



16 www.amana-ptac.com MC-DPTAC
Amana®is a trademark of Maytag Corporation or its related companies and used under license to Goodman Company, L.P. All rights reserved. Our continuing commit-
ment to quality products may mean a change in specications without notice. © 2013 • Goodman Company, L.P. • Houston, Texas • Printed in the USA.
Packaged Terminal air condiTioners
and HeaT PumPs
wiTH conTrol Board
7-ButtonControlPad
• One-Touch Activation
• Total Fan Control
• Easy-to-ReadDisplay
Assembled in the USA for 30 years:
Units are 100% run-tested and
triple-tested for leakage.
First-Year Warranty: Parts & Labor
Second through Fifth Year: Parts & Labor on certain sealed system components
Second through Fifth Year: on certain functional parts only
* Complete warranty details available from your local dealer or
at www.amana-ptac.com.
