Amana P1212701R Assembly instructions

Service
Room Air Conditioners
Service Manual for
Amana
RS4110001
Revision 0
February 1997
Models and manufacturing
numbers in this manual
8V2S P1212701R
10V2S P1212702R
This manual is to be used by qualified appliance
technicians only. Amana does not assume any
responsibility for property damage or personal
injury for improper service procedures done by
an unqualified person.
RaytheonAppliances

Table of Contents
RS4110001 Rev. 0 2
Important Information..................................................3
Important Safety Information
Safety Precautions ...............................................4
Replacement Parts...............................................4
Specifications..............................................................5
Installation Instructions
Installing Your Air Conditioner..............................5
Electrical Requirements........................................5
Grounding Instructions .........................................5
Electrical Connection............................................5
Preparing for Installation.......................................7
Installing Unit in a Sliding Window........................8
Installing Unit in a Casement Window..................12
Operating Instructions
Using Air Conditioner............................................14
Air Conditioner Features.......................................14
Fan Control Knob .................................................14
Temperature Control Knob...................................14
Vent Control Knob................................................14
Air Directional Louvers .........................................15
Night Time Cooling...............................................15
Care and Cleaning Instructions
Winter Storage .....................................................16
Air Filter Cleaning.................................................16
Cabinet Cleaning..................................................16
Troubleshooting Procedures
Air Conditioning Voltage Limits.............................17
Low Voltage..........................................................17
High Voltage.........................................................17
Electronic Control.................................................17
Troubleshooting Chart ................................................18
Disassembly Procedures
Front Panel Removal............................................19
Wrapper Removal ................................................19
Control Box Access..............................................19
Fan Motor Removal..............................................19
Evaporator Blower and/or
Condenser Fan Removal......................................19
Compressor Mounting Pedestal Removal............19
Component Location Illustrations.........................20
Wiring Diagram...........................................................22

Important Information
RS4110001 Rev. 0 3
Great pride and workmanship go into every product to provide our Customers with the highest possible quality. We
realize, however, that during its lifetime the product may require service. The information contained in this manual is
intended for use by a qualified service technician who is familiar with the safety procedures required in the repair and
who is equipped with the proper tools and testing instruments.
!
WARNING
Repairs covered in this manual that are made by unqualified personal can result in hazards due to improper
assembly or adjustments subjecting inexperienced persons making such repairs to the risk of injury or electrical
shock which can be serious or even fatal.
Important Note to Consumer
CAUTION
!
If performing service on your own product, you must assume responsibility for any personal injury or property
damage which may result. Amana will not be responsible for any injury or property damage arising from improper
service and/or service procedures.
In order to locate an authorized service agency, please consult your telephone book or the dealer from whom you
purchased this product. If you require further assistance, please contact:
CONSUMER AFFAIRS DEPT. OR 1-319-622-5511
AMANA call and ask for the
AMANA, IOWA 52204 Consumer Affairs
Users of products outside of the United States and Canada should contact:
AMANA
ATTN: CONSUMER AFFAIRS DEPARTMENT
AMANA, IOWA 52204, USA
Telephone: [phone]
Facsimile: [phone]
RECOGNIZE SAFETY SYMBOLS, WORDS AND LABELS
DANGER
!
Immediate hazards which WILL result in severe personal injury or death.
WARNING
!
Hazards or unsafe practices which COULD result in severe personal injury or death.
CAUTION
!
Hazards or unsafe practices which COULD result in minor personal injury or product or property damage.

Important Safety Information
RS4110001 Rev. 0 4
Safety Precautions
!
WARNING
To reduce risk of fire, electrical shock, or personal injury, observe the following:
• Use this unit only in the manner intended by manufacturer. If any questions arise, contact the manufacturer, at
the address or telephone number listed in “Important Information” section.
• Before servicing or cleaning unit, switch power off at service panel and lock service panel to prevent power from
being switched on accidentally.
• Installation work and electrical wiring must be done by a qualified person in accordance with all applicable
codes and standards, including fire-rated construction codes and standards.
• When cutting or drilling into walls, do not damage electrical wiring and other hidden utilities.
• This unit must be grounded.
Prior to returning product to service, ensure that the following is adhered to.
• All electrical connections are correct and secure.
• All electrical leads are properly dressed and secured away from sharp edges, high temperature components,
moving parts.
• All uninsulated electrical terminals, connectors, heaters, ect. are adequately spaced away from all metal parts
and panels.
• All safety grounds are correctly and securely connected.
• All panels are properly and securely reassembled.
!
WARNING
To avoid risk of electrical shock, property damage, personal injury, or death: when installing a grounded appliance
in a home that does not have a three-prong grounded receptacle, under no conditions is the grounding prong to
be cut off or removed. It is the personal responsibility of the consumer to contact a qualified electrician and have a
properly grounded three-prong wall receptacle installed in accordance with the appropriate electrical code.
Servicing of Grounding Products
The standard accepted color coding for ground wires is green or green with yellow stripe. These ground leads are
NOT to be used as current carrying conductors. It is extremely important that the servicer replaces any all grounds
prior to completion of service. Under no condition should a ground wire be left disconnected causing a potential
hazard to the servicer or consumer.
Replacement Parts
Use only replacement parts cataloged for this appliance. Substitutions may defeat compliance with safety standards
set for home appliances.

Specifications
RS4110001 Rev. 0 5
Amana Model Specifications
Model 8V2S1 10V2S1
Chassis Type Slider Casement Slider Casement
Capacity Features
Cooling Btu’s 8,000 10,000
EER (Energy Efficiency Ratio) 10.5 9.5
Moisture Removal −Pints/Hour 2.0 2.5
Electrical Information
Volts 60 Hz 1 PH 115 115
Amps Cooling 6.7 8.8
Watts Cooling 760 1050
Fuse Breaker (Delay) 15 Amps 15 Amps
Receptacle (Code) A 15
Air Flow System
Capacitor (MFD / Volts) 5 / 370 15 / 370
RPM / CFM (EVAP) High 1100 / 235 1375 / 305
RPM / CFM (EVAP) Medium 900 / 185 1140 / 245
RPM / CFM (EVAP) 700 / 135 940 / 195
Refrigeration System
Compressor Tecumseh Tecumseh
Compressor Number RG5472E RG5490E
Compressor Type Rotary Rotary
Capacitor (MFD / Volts) 35 / 370 25 / 370
Refrigerant Charge R22 in oz. 24.25 22.00
Restrictor Tube
I.D. (in.) / length (in.) .0541 x 45.0 .046 x 45.0
Thermostat Type Bulb Bulb

Installation Instructions
RS4110001 Rev. 0 6
Installing Your Air Conditioner
NOTE: These instructions describe installation in a
typical wood framed window with a wood SLIDE-
BY sash, or installation in a metal CASEMENT
window. Modification may be necessary when
installing in windows constructed differently than
those illustrated herein.
High window accessory kit is available for window
heights up to 62” (1575mm).
Electrical Requirements
WARNING
!
To avoid risk of electrical shock, personal injury, or
death follow the following.
• Electrical ground is required on this appliance.
• DO NOT ground to a gas line.
• If cold water pipe is interrupted by plastic, non-
metallic gaskets, or other insulating materials, DO
NOT use for grounding.
• Check with a qualified electrician if you are in doubt
as to whether the appliance is properly grounded.
• DO NOT modify the power supply cord plug. If it
does not fit the outlet, have a proper outlet installed
by a qualified electrician.
• DO NOT have a fuse in the neutral or grounding
circuit. A fuse in the neutral, or grounding circuit
could result in an electrical shock.
• DO NOT use an extension cord with this appliance.
Observe all local codes and ordinances.
Grounding Instructions
NOTE: Do not under any circumstances cut or remove
grounding prong from the plug or bend power
prongs to fit receptacle other than one for the
equipment. Such abuse of the plug can result in
electrical shock or overheating.
For your personal safety, this appliance must be
grounded. This air conditioner includes a power supply
cord with a three-prong grounding plug. To minimize
possible electrical shock hazard, the cord must be
plugged into a mating three-prong grounding wall
receptacle; and grounded in accordance with the
National Electrical Code (ANSI/NFPA 70-latest version)
and all local codes and ordinances. If a mating
three-prong grounding-type wall receptacle is not
available, it is the responsibility of the consumer to have
a properly grounded three-prong wall receptacle installed
by a qualified electrician.
If codes permit, and a separate grounding wire is used; it
is recommended that a qualified electrician determine
that the grounding path is adequate and not interrupted
by plastic, non-metallic gaskets, or other insulating
materials.
Do not use an extension cord. If product power cord is
too short, have a qualified electrician install an
appropriate receptacle.
Receptacle Wiring
Receptacle wiring should be a minimum of 14 gauge.
Use copper wire only. It is the responsibility of the
consumer to provide proper and adequate receptacle
wiring, installed by a qualified electrician.
Electrical Connection
Electrical ground is required on this appliance.
Electrical Requirements
A 115 volt (103.5 minimum, 126.5 maximum), 60 Hertz,
AC only, 15 ampere fused electrical supply is required. A
time delay fuse or time delay circuit breaker is also
required. A separate circuit, serving only this appliance,
MUST be provided.

Installation Instructions
RS4110001 Rev. 0 7
Preparing for Installation
Installation Tips
For wood-frame casement windows: It may be
necessary to construct a frame, using at least 1-inch
thick wood, with a 15 1/2-inch wide opening.
For brick or cement building construction: It may be
necessary to provide a wood stool strip under the air
conditioner for mounting purposes.
Tools Required
• Flat-head screwdriver
• Phillips-head screwdriver
• Carpenter’s level
• Tape measure
• Fine tooth saw
• Electric or hand drill
• 1/8-inch drill bit
• 9/64-inch drill bit
WARNING
!
To avoid risk of personal injury or product damage
follow the following precautions.
• Because this air conditioner weighs about 88 to 105
pounds, it is recommended that you have someone
help you when you install your new unit, and that
you both use proper lifting techniques. Inspect the
condition of the window where the unit will be
installed. Be sure it will support the weight of the
unit.
• This appliance must be installed according to all
applicable codes and ordinances.
• Handle the air conditioner with care. AVOID the
sharp metal fins on the front and rear coils.
• Make sure your air conditioner does not fall during
installation.
• Do not use the water collected in the unit for
drinking purposes. It is not sanitary.
Installation Kit Contents:
Verify all parts are present.
1 Platform (1)
2 Support brace (1)
3 Adjustment bolt (1)
4 Hex flange nut1/4  (1)
5 Track seal (1)
6 Side channel seal (1)
7 Foam seal strip/Sash seal
8 Safety bracket (1)
9 Screw#10x2 1/2  flat-head (2),
10 Screw#10x1 3/4  pan-head (2),
11 Screw#10x1  pan-head (2)
12 Screw#8x3/4  pan-head (6)
13 Screw#8-32x3/4  self-threading (7)
14 Window locking bracket (1)
15 Plastic window panel (1)
16 Side channel (2)
17 Screw - #8x3/8  truss-head (6)
39, 10, 11
8
13
5
7
6
15
14
16
17
122
1
4
NOTE: Use the scale below to measure the length of
screws. The scale will come in handy when
separating screws for installation.

Installation Instructions
RS4110001 Rev. 0 8
Determining the proper sized of the window.
• 15 1/2-inches minimum width
• 16 1/4-inches maximum width (for casement
windows)
• 21 1/4-inches minimum height (with window panel
retainer)
• 20 5/16-inches minimum height (window panel
retainer removed)
• 39 7/16-inches maximum height
20 5/16"
minimum
height
39 7/16"
maximum
height
15 1/2"
minimum
width
16 1/4"
maximum
width
NOTE: The height measurement must be of an
unobstructed opening above the mounting
platform. In some cases, due to a variety of stop
and track arrangements, the above dimensions
may vary slightly. If necessary, the installation
can be made by altering the window jambs.
Alternate Window Jamb Applications
To install in windows having no flanges or wood stops on
the top and side jambs, the channels and panel frame
must fit against a mating flange (or 1/16-inch max. thick
angle) attached to the window jambs. Figure A shows
this angle installed. Figures B & C show alternate
treatments. On the sash side of the opening, the leading
corner of the inner sash becomes the flange. You can
purchase the angle strip locally.
Flush
1"x1" or
3/4"x3/4"
angle
3/4"x1"
3/4"x1"
Room Room
Room
A
Add angle to
wood stop
BC
Add wood
as shown Add 16 or 18 gauge angle
Choosing a proper window location.
• Choose a window that allows the cooled air to flow
freely and directly into the room(s) wishing to cool.
Remember, it is difficult to move air around corners.
Also, choose a window that is within 6 feet of an
electrical outlet.
6 foot
power cord
reach
Installing Unit in a Sliding Window
1. Attach support brace to platform. Use adjustment bolt
and hex flange nut to complete the assembly.
Choose the slot and adjustment bolt hole locations
that will create a 45°angle between the platform and
support brace.
• Place assembly in the window to determine
platform will rest properly, allow for proper sloping (
3/16-inch lower on outside).
NOTE: If planning to use a siding-protection board on
the outside of your house, hold the board in
place while testing assembly in the window.

Installation Instructions
RS4110001 Rev. 0 9
2. Measure, and lightly mark a line 8 11/16-inches from
window jamb.
81116
NOTE: If any sash stop protrudes more than 1 inch from
side window jambs, 8 11/16-inch measurement
must be increased accordingly. Screen and
storm window frames may also require
adjustments to the measurement.
3. Center platform assembly on the line with inside
platform tab pressed against inside edge of window
track. Use holes provided in the platform as a guide,
mark and drill two 9/64-inch diameter holes. Drill
holes in either track or stool.
Alternate screw location
Platform tab
Window track Window seal
CAUTION
!
To avoid risk of property damage be sure the wood
stool or window track is securely attached to the
building construction. Use longer screws in the sub-
framing if necessary.
4. Remove protective backing from the track seal. Apply
seal to room side of the window track. Center of the
seal strip should coincide with the line marked in Step
3. Two screw holes drilled in Step 4 should be directly
above the seal strip in the inner track.
Apply track seal
to window side
of track.
5. Securely attach siding-protection board to the side of
the house.
Inside
wall of
house Siding
protection
board
NOTE: Siding-protection board should be long enough
to reach 2 wall studs.

Installation Instructions
RS4110001 Rev. 0 10
6. Place platform assembly, with platform tab against
inside of window track, and attach it to the window
jamb. Use appropriate length screws.
7. Adjust platform assembly so that the outside edge is
3/16-inch lower than the inside. This will ensure
proper water drainage from the air conditioner.
Outside edge is
lower than inside
Platform tab
against inside
of track
8. Level platform assembly from side-to-side. Verify
window track is level. Use leveling shims as
necessary to ensure unit is level from side-to-side.
9. Measure distance from the top of platform assembly
to top of window opening. Subtract 20 1/2 to
20 5/8-inches. Mark this measurement on the plastic
window panel, along the longer side.
10.Clamp plastic window panel between a board and
work table, cut along the line with a fine tooth saw.
Remove any burrs with a file.
11.Fasten side channels to unit using 3 screws per
channel. Start with the first screw at the top of the
channel. Verify hook ends of the channels face
toward back of the unit.
12.Slide plastic window panel into panel frame, with
smooth side to the room. Slide panel frame assembly
into side channels of the air conditioner cabinet.
Verify plastic window panel is firmly enclosed on all
sides by retainer grooves.
Plastic
window
panel
Panel
frame
13.Cut side channel seal into 2 equal lengths. Remove
protective backing and apply to rear side of cabinet
side channels, starting just below panel frame
assembly. Pinch off excess length so the seal is even
with the bottom of cabinet side channel.
Weather
seal

Installation Instructions
RS4110001 Rev. 0 11
14.Remove front panel frame and filter. Remove 2
screws securing front panel frame in place. Press
down on top edge of front panel frame, tilt forward,
and lift up off the bottom spring clips. Remove filter.
NOTE: DO NOT push or pull the air direction louvers.
15.Place unit into the window opening on platform
assembly. Place window panel frame, and cabinet
side channels against the top and side window
jambs.
Slide inner
window sash
frimly against
cabinet
16.Slide inner window sash firmly against side of
cabinet. Make sure not to peel seal strips from
window track and cabinet side channels. If panel
frame does not fit snugly to inner window sash,
secure panel frame to the sash with #8x3/4-inch
screws, or #8-32x3/4-inch self-threading screws. Use
partially plugged holes in panel frame to drill 1/8-inch
pilot holes for screws.
17.Hook safety bracket over base of the unit and fasten
to the front of platform assembly. Use a #8-32x3/4
inch self-threading screw.
Safety bracket
NOTE: Bracket prevents movement of air conditioner
(either in or out) after completing installation.
18.Stuff foam seal strip/sash seal between vertical sash
and window glass.
19.Use window locking bracket to lock inner window
sash to base of outer window sash. Use a
#8x3/4-inch screw, or #8-32x3/4-inch self-threading
screw. (Drill 1/8-inch pilot hole.)
20.Replace air conditioner filter and front panel frame.
Make sure to replace screws that secure front panel
frame in place.

Installation Instructions
RS4110001 Rev. 0 12
Installing the Unit in a Casement Window
NOTE: Open window to maximum amount allowed for
clearance of the cabinet. Crank handle should
be removed to allow platform to be fastened to
the jamb. If window cannot open far enough
(more than 15 1/2-inches) for cabinet to clear
the window, remove window entirely by drilling
out the rivets. Bolts can serve as the pivots in
the future.
To avoid crank handle and window clearance problems,
the unit can be installed in a stationary sash section.
However, the horizontal mullion and the 2 glass panels
must be removed before installation.
1. Attach support brace to platform. Use adjustment bolt
and hex flange nut to complete assembly. Choose
the slot and adjustment bolt hole locations that will
create a 45°angle between the platform and support
brace. Try assembly in window to determine if
platform will rest properly, and allow proper sloping
(3/16-inch lower on outside).
Platform
Adjustment
bolt
Support
brace
1/4"
hex
flange
nut
NOTE: If planning to use siding-protection on the
outside of the house, hold the board in place
when testing assembly in the window.
2. Drill a 9/64-inch diameter pilot hole in window jamb
equal distance from each side of jamb, and 3/16-inch
up from the window sill. If the hole coincides with the
window lever slot in the jamb bottom, an additional
hole will have to be drilled through the platform edge
and window jamb to miss this slot.
81116
3. Peel off protective backing from track seal, and stick
the seal to the window sill on the outside of bottom
jamb.
Apply track seal
to window side
of track.
4. Screw platform assembly to window jamb through
pilot hole drilled in Step 2. Use #8x3/4-inch self-
threading screw.
Track seal
Screw
Window
jamb
5. Adjust platform assembly so that rear until be
3/16-inch lower than the front. This will ensures
proper water drainage from the air conditioner.
Outside edge is
lower than inside
Platform tab
against inside
of track
NOTE: Projection below the base of air conditioner will
require the rear of platform to be 7/16-inches
lower than the front to create the 3/16-inch slant
from front to rear.

Installation Instructions
RS4110001 Rev. 0 13
6. Securely attach siding-protection board to the side of
the house.
Inside
wall of
house Siding
protection
board
NOTE: Siding-protection board should be long enough
to span 2 wall studs.
7. Measure distance from the top of platform assembly
to top of window opening. Subtract 20 1/2 to
20 5/8-inches. Mark this measurement on the plastic
window panel, along the longer side.
8. Clamp plastic window panel between a board and
work table, cut along the line with a fine tooth saw.
Remove any burrs with a file.
9. Fasten side channels to unit using 3 screws per
channel. Start with the first screw at the top of the
channel. Verify hook ends of the channels face
toward back of the unit.
10.Slide plastic window panel into panel frame, with
smooth side to the room. Slide panel frame assembly
into side channels of the air conditioner cabinet.
Verify plastic window panel is firmly enclosed on all
sides by retainer grooves.
11.Cut side channel seal into 2 equal lengths. Remove
protective backing and apply to rear side of cabinet
side channels, starting just below panel frame
assembly. Pinch off excess length so the seal is even
with the bottom of cabinet side channel.
12.Remove front panel frame and filter. Remove 2
screws securing front panel frame in place. Press
down on top edge of front panel frame, tilt forward,
and lift up off the bottom spring clips. Remove filter.
Clips
Filter
NOTE: DO NOT push or pull the air direction louvers.
13.Place unit into the window opening on platform
assembly. Place window panel frame, and cabinet
side channels against the top and side window
jambs.
Slide inner
window sash
frimly against
cabinet
14.Drill two 9/64-inch diameter pilot holes in top of
window jamb in line with the partially plugged holes in
panel frame. Secure panel frame to window jamb
with two #8-32x3/4-inch self-threading screws. If
additional holding is necessary, two screws may be
used on the sides of panel frame.
15.Drill two screw-clearance holes in cabinet side
channels (near bottom) and two 9/64-inch diameter
pilot holes in side window jambs. Secure cabinet side
channels to window jambs with two #8-32x3/4-inch
self-threading screws.
NOTE: Be careful not to twist side channel seals.
Inserting screws will prevent unit from being
pushed into the room.
16.Replace unit front panel frame and filter. Replace
screws that hold the panel in place. Do not push or
pull front panel louvers.

Operating Instructions
RS4110001 Rev. 0 14
Using Air Conditioner
NOTE: If unit is turned off, wait 3 minutes before
restarting. This will allows pressure inside the
compressor to equalize. Failure to follow these
instructions may cause inefficient operation.
WARNING
!
To avoid risk of fire, electric shock, or personal injury,
read IMPORTANT SAFETY INSTRUCTIONS before
operating this appliance.
To begin operating air conditioner, follow these
steps:
1. Plug in air conditioner.
NOTE: To avoid electrical hazards, do not use an
extension cord or adapter plug.
2. Place exhaust vent to
CLOSED position.
3. Turn TEMPERATURE CONTROL knob to highest
number setting or
COLDER setting.
4. Turn FAN CONTROL knob to
COOL MODE HIGH
setting.
5. Adjust louvers for comfortable air circulation.
6. Once room has cooled, turn temperature control knob
to setting more comfortable.
Air Conditioner Features
Controls featured in this manual represent 82VS and
102VS models.
Fan Control Knob
Turns unit on, off, and allows you to select either cooling
air, or allows air to circulating at existing temperature.
Operate FAN ONLY and COOL MODE according to the
following suggestions:
Mode Function
OFF Turns unit off.
HIGH COOL Maximum cooling speed, start unit in
this mode.
MED COOL Moderate cooling speed.
LOW COOL Minimum cooling speed.
HIGH FAN Maximum air circulation speed.
MED FAN Moderate air circulation speed.
LOW FAN Minimum Air circulation speed.
LOW
MED
HIGH
FAN CONTROL
HIGH
MED
LOW
OFF
FAN
ONLY COOL MODE
Temperature Control Knob
When any COOL MODE setting is selected, thermostat
controls the amount of cooling by automatically turning
cooling compressor on and off in response to room
temperature.
Turn TEMPERATURE CONTROL knob to highest
number for the coldest cooling setting. Once room
reaches desired temperature, adjust TEMPERATURE
CONTROL knob to desired number comfortable for
cooling room.
ECONOMY
SETTINGS
1
2
3456
7
8
COLDER
TEMPERATURE CONTROL
NOTE: Higher numbers provide lower room
temperatures. Lower numbers provide higher
room temperatures.
Vent Control Knob
Allows unit to either recirculate inside air CLOSED , or
exhaust air to the outside
EXHAUST .
•
CLOSED position is used when maximum cooling is
desired. It may also be used for air recirculation
without cooling when air conditioner is turned to FAN
ONLY position.
•
EXHAUST position removes stale air from the room,
and exhausts it to the outside. Fresh air is drawn into
the room through normal air passages found in
homes.
• The
EXHAUST or CLOSED position can be used with
any fan selection.
VENT CONTROL
CLOSED
EXHAUST

Operating Instructions
RS4110001 Rev. 0 15
Air Directional Louvers
Controls air flow direction. Louvers at the top front of unit
permit side-to-side adjustment of air flow direction. Move
lever to direct airflow either to the left or right.
Night Time Cooling
When outside temperatures drop below 70° F (21° C)
and unit is cooling, frost may form on coils and block air
flow into room. If this occurs, operate unit on FAN ONLY
setting to defrost coil.
If cooling while outside temperature is low, set
thermostat to middle position. Make sure louvers are
open. This will prevent frost build-up.

Care and Cleaning Instructions
RS4110001 Rev. 0 16
Winter Storage
If you plan to store air conditioner during the winter,
remove it carefully from window according to the
installation instructions. Cover it with plastic, or return it
to the original carton.
NOTE: To prevent rust or electrical connections from
being damaged, store unit in a dry place in an
upright position.
A winter cover can be purchased from your dealer.
Cover will protect unit if left in place through the winter.
Air Filter Cleaning
Air filter needs to be checked at least once a month to
verify if cleaning is necessary. Trapped particles in filter
can build up and cause frost accumulation on cooling
coils.
Screw
Clips
Filter
Front Panel
NOTE: To avoid reducing cooling capacity clean air filter
monthly.
1. Remove front retaining screw on each side of
cabinet.
2. Push front panel down, and pull toward forward to
release front panel from retaining lock.
3. Gently pull filter forward off of clips.
4. Wash filter using a liquid detergent and warm water.
Rinse filter thoroughly.
5. Gently shake excess water from filter and dry filter
thoroughly.
6. Reassemble in reverse order.
Clips
Filter
Cabinet Cleaning
WARNING
!
To avoid risk of to electrical shock or fire hazard
unplug unit.
• Cabinet and front may be dusted with an oil-free
cloth, or washed with a cloth dampened using a
mild liquid detergent and warm water. Rinse
thoroughly and wipe dry.
• Never use harsh cleaners, wax, or polish on cabinet
front.
• Be sure to squeeze excess water from cloth before
wiping around controls. Excess water in or around
controls may cause damage to unit.
• Cabinet front can be removed for more thorough
cleaning. See “Air Filter Cleaning” section.
• Clean front panel in a sink, using a mild liquid
detergent and warm water. Rinse thoroughly and
dry. Be careful not to disturb soft seals on the front
panel.

Troubleshooting Procedures
!
WARNING
To avoid electrical shock, personal injury, or death, disconnect power before servicing unless testing requires it.
RS4110001 Rev. 0 17
Air Conditioning Voltage Limits
This unit operates on a 115 VAC, 60 Hz power source.
Minimum voltage required to operate this unit is 103.5
VAC and maximum voltage is 126.5 VAC.
Low Voltage
Low voltage is a common cause of trouble during
operation of any room air conditioner
Improper voltage can result in one or more of the
following:
1. Unit will not operate.
2. Compressor motor cycling on motor protector.
3. Premature failure of motor protector.
4. Blown fuses.
5. Premature failure of compressor or fan motor.
6. Noticeable dimming of lights when unit is operating.
7. Evaporator icing, caused by low voltage reducing fan
speed resulting in an inadequate air flow over the
evaporator.
Low voltage will result from inadequately wired circuit,
extension cords, and loose fuses or connections in the
power supply. Voltage supplied by the electrical
company can also result in low power, (responsibility of
local power company.
All units will operate and run on minimum voltage stated
in "Air Conditioning Voltage Limits", and will perform
satisfactorily if voltage remains constant. Low voltage
caused by defective wiring will not remain constant under
load.
Testing for low voltage, use a reliable voltmeter with
sufficient capacity to measure the required voltage.
Verify voltage at electric power entry point and at
electrical outlet serving the unit Verify readings with the
unit off, while the unit is starting, and again while the unit
is operating. Lowest reading should not drop below the
lowest minimum value.
High Voltage
High voltage can be equally troublesome, causing motor
to overheat, cycle on their protectors, or break down
electrically. This problem can only be solved by the local
power company.
Electronic Control
Control is not repairable. If any component in the control
is defective, entire control must be replaced.
NOTE: Repair or replace any malfunctioning line voltage
component before testing or replacing the
electronic control. Do not assume service
problem is directly caused by the electronic
control system. A line voltage component
(including power cord and wiring) that has
opened, shorted, grounded or otherwise
malfunctioned, may have created a service
problem.

Troubleshooting Chart
RS4110001 Rev. 0 18
Problems Possible Causes
Fan motor will not operate. No power supplied to unit.
Power supply cord faulty.
Selector switch faulty.
Energy saving switch faulty.
Energy control system faulty.
Wire disconnected or loose.
Capacitor is faulty.
Faulty fan motor windings.
Fan blade will not rotate. Fan blade hitting shroud or blower wheel hitting scroll.
Fan motor operates intermittently. Cycles on motor protector.
Fan motor operates noisy. Condenser fan blade or evaporator blower wheel.
Loose blower clamp or set screw.
Worn bearings.
Grommets (if applicable).
Compressor will not run, but the fan motor
runs. Voltage. Wiring.
Selector switch.
Temperature Control.
Capacitor. (Discharge capacitor before testing.)
Compressor.
Motor protector (external).
Motor protector (internal).
Electronic Control (if applicable).
Hard Starting.
Compressor cycles on motor protector. Voltage.
Motor protector (external).
Motor protector (internal).
Fan Motor.
Condenser air flow restriction.
Condenser fins damaged.
Capacitor.
Wiring.
Refrigerant system.
Insufficient cooling. Low Capacity.
Air filter.
Exhaust door open.
Unit undersized
Excessive noise. Evaporator Blower wheel.
Condenser fan.
Copper tubing.
Compressor internal noise.
Fan motor.
Excessive water or condensation. Unit operating under extremely high humidity conditions.
No cooling. Refrigerant leak.
Unit is cooling but room is not cool. Amps and watts.
Sealed Refrigeration System.
Wattage decreases slowly until abnormally low. Undercharged, restricted strainer or plugged restrictor tube.
Wattage decreases immediately. No Refrigerant.
Compressor defective.
Wattage continuously high. Overcharged of refrigerant.
Evaporator coil partially frosted. System low on refrigerant.
Evaporator completely iced. Low outside temperature.
No Heat. (Heat/Cool models only.) No Power.
Selector switch position.
Temperature control position.
Fan Motor.
Heating element.
Selector switch.
Temperature control.
Terminals and connectors.
Fan motor will not rotate during a heat cycle.
(Heat/Cool models only.) Thermostatic drain valve. (Water level control, if applicable.)

Disassembly Procedures
!
WARNING
To avoid electrical shock, personal injury, or death, disconnect power before servicing unless testing requires it.
RS4110001 Rev. 0 19
Front Panel Removal
1. Disconnect power supply from unit.
2. Remove screw securing each side of front panel.
3. Slide panel downward, pull top of panel forward, then
lift panel up and off tabs located at the bottom.
Wrapper Removal
1. Disconnect power supply from unit.
2. Remove front panel, see "Front Panel Removal".
3. Remove screws securing wrapper to bottom of unit.
4. Remove screws on top of unit. One on each end of
the top mounting rail (leave the middle screw in) and
the screw in the middle of the unit itself.
5. Lift wrapper up and off the base of the unit.
Control Box Access
1. Disconnect power supply from unit.
2. Remove front panel, see "Front Panel Removal".
3. Remove control knobs and dial plate.
4. Disconnect thermostat bulb from evaporator coil.
5. Remove screws securing top of control panel to
control box.
6. Remove screws securing front bottom of control
panel to control box.
7. Raise control panel up to gain access to switch,
thermostat, and capacitor.
Fan Motor Removal
1. Disconnect power supply from unit.
2. Remove front panel, see "Front Panel Removal".
3. Remove wrapper see "Wrapper Removal".
4. Lift and remove expanded metal rear panel.
5. Disconnect thermostat bulb from evaporator coil.
6. Remove screws securing control panel to control box
and lift panel back.
7. Disconnect compressor and fan motor leads from
thermostat, selector switch, and capacitor.
8. Remove control panel.
9. Remove vent door actuator arm.
10.Remove screws securing control box to bulkhead.
11.Remove compressor and fan motor leads from
control box and remove control box.
12.Remove screws securing evaporator coil to bulkhead.
13.Lift evaporator coil upward and swing evaporator coil
out and away to the left.
NOTE: Do not bend tubing any more than necessary.
14.Remove blower scroll, bending bulkhead sides
outward while pulling blower scroll up and out of unit.
15.Squeeze hub clamp and remove. Remove blower
wheel.
NOTE: Position blower wheel for reassembly.
16.Remove screws securing condenser end brackets to
compressor pedestal.
17.Remove tape from top of condenser shroud to
condenser end bracket. Hinge top of shroud back.
18.Remove screw securing condenser mounting
bracket.
19.Release plastic tabs from condenser shroud of
condenser end brackets.
20.Lift condenser coil upward and swing coil away.
NOTE: Do not bend tubing any more than necessary.
21.Loosen condenser blade hub screw and remove
blade.
NOTE: Position blades for reassembly.
22.Remove fan motor mount screws located behind
evaporator coil.
23.Reverse procedures to reinstall.
NOTE: Verify wires and tubing holes through bulkhead
are properly sealed.
Evaporator Blower and/or Condenser Fan
Removal
• To replace evaporator blower and/or condenser fan,
see " Fan Motor Removal". Follow the appropriate
disassembly procedures necessary for repair.
Compressor Mounting Pedestal Removal
1. Disconnect power supply from unit.
2. Remove motor, see "Fan Motor Removal".
3. Remove screws securing pedestal to bulkhead.
4. Remove plastic nuts securing compressor to
mounting studs.
5. Support compressor and remove pedestal.
6. Reverse procedures to install.

Disassembly Procedures
RS4110001 Rev. 0 20
Component Location Illustrations
Cabinet
front
panel
Rear grille
Cabinet wrapper
Vertical
louver
Dial
plate
Control knobs
Filter
Control
box
Door vent
Capacitor
Capillary tube
Fan
control Temperature
control
Vent
control
