Amana RCE Prestige User manual

www.amana-hac.com
Specification Sheet
14 SEER
RCE Prestige™
Split System Air Conditioner
High-efficiency Copeland Scroll Compressor with Factory-
installed Sound Blanket. Compressor is hermetically sealed and
features safeguards to protect it from excessive temperatures,
pressure and abnormal electrical currents. In addition,
energy-saving design reduces internal resistance and friction
and increases operating efficiency. The entire compressor is
mounted on rubber cushions to help absorb vibrations.
Economy and Performance. Simplicity of design and
construction make this unit economical to own as well as
operate. The balance of economy and efficiency makes RCE
units ideal for replacement or new construction. The RCE line
delivers SEERs of up to 15 when paired with high-efficiency
blower coils, which can help reduce your cooling costs.
Refrigerant line connections and service valves are easy to
reach. Embossments in the bottom allow drainage and air flow
under the unit to reduce corrosion. Heavy vinyl-coated grilles
protect the fan, motor and coil. Controls and service valves can
be serviced without interrupting unit operation.
Copper and Aluminum Coils. The RCE condenser features
enhanced fins. Our condenser and evaporator coils are made
from copper tubing and aluminum fins. Tubing life is extended
and fewer leaks experienced because we use only refrigeration-
grade copper tubing.
Optional “A” Coils are shipped with leak-proof plastic drain pans
attached. All coils have sweat connections and are fully leak
tested before leaving the factory.
Pressure Controls and Time Delay provide additional protection
to the compressor upon a loss of charge to the system. The time
delay prevents short cycling. A 3-minute delay occurs when the
power supply or the indoor thermostat’s signal is interrupted.
Field-Piped Refrigerant System. Sweat style service valves are
used for a more positive connection. Installers can size the
tubing to fit the job with a neat application and no waste for
better control. Unit is shipped charged with refrigerant for a 15’
liquid line and matching indoor coil.
Service Valves and Gauge Ports are angled at 30° with enough
clearance to allow quick and easy servicing of the unit. Service
panel swings open at the corner for effective service from two
directions. Inside, a pre-wired control panel speeds installation.
Minimal quantity of numbered and color-coded wires to assure
fast field wiring. Compressor and tubing access from the side
and top give plenty of internal room for installation and removal
of parts.
Factory-installed Liquid Line Filter Drier. Standard protection
adds to reliability by helping to keep refrigerant clean and dry.
Clean and dry refrigerant ensures longer life for the compressor
and expansion devices.
Quiet Condenser Fan with Vertical Air Discharge. Quiet, efficient
fan and motor reduce operating sounds and large blades
move high volumes of air with lower power requirement. Draw
through air flow directs operating sound and hot air away from
neighbors, shrubs and buildings. Adds to installation versatility.
Cabinets. Painted sheet metal cabinet maintains its attractive
finish for many years. Cabinet and screws resist rust and fading
due to UV rays. When properly anchored, meets the 2001 Florida
Building Code unit integrity requirements for hurricane-type
winds.
LIMITED WARRANTY
• Lifetime—Compressor
• 10-Year Limited—Parts
Cooling Capacity:
24,000 - 60,000 BTUH
U
RL
C
U
RL
The Amana®brand RCE Prestige™ Air Conditioners
offer economy, dependable cooling comfort,
high-efficiency performance, application flexibility
and installation and service ease. Cost-effective
engineering, low operating costs, reliable
components and quality manufacturing make RCE
units perfect for the value-minded homeowner or
cost-conscious builder.

Specification Sheet
www.amana-hac.com
2
Nomenclature
C
Revision
(C Indicates Two-Tone
Color Scheme)
Voltage
2: 208/230-60-1
Marketing Designator
C: Current Series
Nominal
Capacity
System Type
C: Cooling
Product Family
E: 14 SEER
Product Type
R: Remote Condensing
Unit or Heat Pump
36: 36,000 Btuh
48: 48,000 Btuh
60: 60,000 Btuh
42: 42,000 Btuh
30: 30,000 Btuh
24: 24,000 Btuh

R E 24 C 2

Specification Sheet
www.amana-hac.com 3
Specifications for C2A Models
Dimensions
RCE24C2A RCE30C2A RCE36C2A RCE42C2A RCE48C2A RCE60C2A
Cooling Capacities
Nominal Cooling Capacity (Btuh) 24,000 30,000 36,000 42,000 48,000 60,000
Compressor
R.L. AMPS 10.8 12.2 14.7 16.5 18.3 25.0
L.R. AMPS 54.0 67.0 83.0 95.0 109.0 169.0
Condenser Fan Motor
Horsepower 1/12 1/4
R.L. AMPS 0.6 1.70
L.R. AMPS 1.0 3.30
Sound Levels (Db) 7.2 7.2 7.4 7.6 7.6 7.8
Refrigerant Lines
Liquid Line (“O.D.) 3/8
Suction Line (“O.D.) 3/4 7/8 1-1/8
Refrigerant Charge 155.0 oz. 160.0 oz. 225.0 oz. 225.0 oz. 235.0 oz. 245.0 oz.
Design Subcooling Cooling Mode 11° ± 3° 11° ± 3° 11° ± 3° 11° ± 3° 11° ± 3° 11° ± 3°
Electrical
Power Supply 208/230-60-1
Minimum Circuit Ampacity 14.22 16.0 20.5 22.7 25.0 33.4
Maximum Overcurrent Device 20 25 35 35 40 55
Electrical Conduit Size
Power Supply 1/2” or 3/4”
Low Voltage 1/2”
Approximate Shipping Weights (pounds)
Weight 208 209 270 272 274 314
Square Base Height
RCE24C2A 29½” 29”
RCE30C2A 29½” 29”
RCE36C2A 35⅝” 33”
RCE42C2A 35⅝” 33”
RCE48C2A 35⅝” 33”
RCE60C2A 35⅝” 37”

Specification Sheet
www.amana-hac.com
4
Specifications for C2C Models
Dimensions
RCE24C2C RCE30C2C RCE36C2C RCE42C2C RCE48C2C RCE60C2C
Cooling Capacities
Nominal Cooling Capacity (Btuh) 24,000 30,000 36,000 42,000 48,000 60,000
Compressor
R.L. AMPS 10.90 12.18 13.46 16.54 17.95 19.87
L.R. AMPS 54.0 63.0 73.0 95.0 104.0 137.0
Condenser Fan Motor
Horsepower 1/12 1/6
R.L. AMPS 0.6 1.10
L.R. AMPS 1.0 1.90
Sound Levels (Db) 7.2 7.2 7.4 7.6 7.6 7.8
Refrigerant Lines
Liquid Line (“O.D.) 3/8
Suction Line (“O.D.) 3/4 7/8 1-1/8
Refrigerant Charge 120.0 oz. 125.0 oz. 160.0 oz. 175.0 oz. 175.0 oz. 235.0 oz.
Design Subcooling Cooling Mode 11° ± 3° 11° ± 3° 11° ± 3° 11° ± 3° 11° ± 3° 11° ± 3°
Electrical
Power Supply 208/230-60-1
Minimum Circuit Ampacity 14.22 15.82 17.93 21.77 23.54 26.54
Maximum Overcurrent Device 25 25 30 35 40 45
Electrical Conduit Size
Power Supply 1/2” or 3/4”
Low Voltage 1/2”
Approximate Shipping Weights (pounds)
Weight 175 175 230 230 235 260
Square Base Height
RCE24C2C 29½” 37”
RCE30C2C 29½” 37”
RCE36C2C 35⅝” 37”
RCE42C2C 35⅝” 37”
RCE48C2C 35⅝” 37”
RCE60C2C 35⅝” 37”

Specification Sheet
www.amana-hac.com 5
Cooling Specifications for C2A Models
RCE36C2A with CHA36T*C
Conditions: 80° ID DB, 67° ID WB @ 1,200 CFM
Outdoor
Ambient °F
Total
Btuh
Sensible
Btuh
Latent
Btuh
Total
Outdoor
Watts
75° 37,800 26,080 11,720 2,230
80° 38,350 26,140 11,210 2,305
85° 36,900 26,200 1,070 2,380
90° 36,450 26,240 10,210 2,450
95° 36,000 26,280 9,720 2,520
100° 35,100 26,135 8,965 2,575
105° 34,200 25,990 8,210 2,630
110° 32,950 25,040 7,910 2,680
115° 31,700 24,090 7,610 2,730
TVA Conditions @ 95° OD DB, 75° ID DB, 63° ID WB
95° 33,400 26,050 7,350 2,410
RCE60C2A with CHA60T*C
Conditions: 80° ID DB, 67° ID WB @ 1,800 CFM
Outdoor
Ambient °F
Total
Btuh
Sensible
Btuh
Latent
Btuh
Total
Outdoor
Watts
75° 62,000 42,780 19,220 3,830
80° 61,250 42,865 18,385 3,970
85° 60,500 42,950 17,550 4,110
90° 59,750 43,010 16,740 4,230
95° 59,000 43,070 15,930 4,360
100° 57,550 42,850 14,700 4,465
105° 56,100 42,630 13,470 4,570
110° 54,000 41,035 12,965 4,660
115° 51,900 39,440 12,460 4,750
TVA Conditions @ 95° OD DB, 75° ID DB, 63° ID WB
95° 54,700 42,660 12,040 4,160
RCE24C2A with CHA24T*C
Conditions: 80° ID DB, 67° ID WB @ 800 CFM
Outdoor
Ambient °F
Total
Btuh
Sensible
Btuh
Latent
Btuh
Total
Outdoor
Watts
75° 25,600 171,509 8,450 1,550
80° 25,300 17,200 8,100 1,600
85° 25,000 17,250 7,750 1,660
90° 24,700 17,290 7,410 1,710
95° 24,400 17,325 7,075 1,760
100° 23,800 17,250 6,550 1,800
105° 23,200 17,170 6,030 1,840
110° 22,350 16,540 5,810 1,875
115° 21,500 15,910 5,590 1,910
TVA Conditions @ 95° OD DB, 75° ID DB, 63° ID WB
95° 23,900 18,400 5,500 1,600
RCE30C2A with CHA30T*C
Conditions: 80° ID DB, 67° ID WB @ 1,000 CFM
Outdoor
Ambient °F
Total
Btuh
Sensible
Btuh
Latent
Btuh
Total
Outdoor
Watts
75° 30,200 20,840 9,360 1,850
80° 29,850 20,890 8,960 1,910
85° 29,500 20,945 8,555 1,980
90° 29,150 20,985 8,165 2,040
95° 28,400 21,025 7,775 2,100
100° 28,100 20,925 7,175 2,150
105° 27,400 20,825 6,575 2,200
110° 26,350 20,020 6,330 2,245
115° 25,300 19,230 6,070 2,290
TVA Conditions @ 95° OD DB, 75° ID DB, 63° ID WB
95° 27,500 22,550 4,950 2,100
RCE42C2A with CHA42T*C
Conditions: 80° ID DB, 67° ID WB @ 1,400 CFM
Outdoor
Ambient °F
Total
Btuh
Sensible
Btuh
Latent
Btuh
Total
Outdoor
Watts
75° 42,000 29,400 12,600 2,520
80° 41,500 29,460 12,040 2,610
85° 41,000 29,520 11,480 2,700
90° 40,500 29,560 10,940 2,775
95° 40,000 29,600 10,400 2,850
100° 39,000 29,430 9,570 2,915
105° 38,000 29,260 8,740 2,980
110° 36,600 29,180 8,420 3,040
115° 35,200 27,100 8,100 3,100
TVA Conditions @ 95° OD DB, 75° ID DB, 63° ID WB
95° 37,100 29,300 7,800 2,730
RCE48C2A with CHA54T*C
Conditions: 80° ID DB, 67° ID WB @ 1,600 CFM
Outdoor
Ambient °F
Total
Btuh
Sensible
Btuh
Latent
Btuh
Total
Outdoor
Watts
75° 49,400 34,580 14,820 2,930
80° 48,800 34,640 14,160 3,035
85° 48,200 34,700 13,500 3,140
90° 47,600 34,740 12,860 3,235
95° 47,000 34,780 12,220 3,330
100° 45,850 34,590 11,260 3,400
105° 44,700 34,400 10,300 3,480
110° 43,050 33,140 9,910 3,620
115° 41,400 31,880 9,520 3,620
TVA Conditions @ 95° OD DB, 75° ID DB, 63° ID WB
95° 43,600 34,400 9,200 3,180

Specification Sheet
www.amana-hac.com
6
RCE24C2C / CA*025*2A + TVX
Conditions: 80° ID DB, 67° ID WB @ 800 CFM
Outdoor
Temp. ° F.
Total
Btuh
Sensible
Btuh
Latent
Btuh
Total
Watts
75° 24,990 17,688 7,302 1,843
80° 24,693 17,989 6,704 1,898
85° 24,395 18,277 6,118 1,953
90° 24,098 18,054 6,044 2,002
95° 23,800 17,831 5,969 2,050
100° 23,205 17,715 5,490 2,091
105° 22,610 17,581 5,029 2,950
110° 21,777 17,005 4,772 2,168
115° 20,944 16,422 4,522 2,203
TVA Conditions @ 95° OD DB, 75° ID DB, 63 ID WB
95 22,054 4,401 17,653 1,973
RCE30C2C / CAX*037*2A + TXV
Conditions: 80° ID DB, 67° ID WB @ 1,000 CFM
Outdoor
Temp. ° F.
Total
Btuh
Sensible
Btuh
Latent
Btuh
Total
Watts
75° 29,610 20,421 9,189 2,060
80° 29,258 20,435 8,823 2,121
85° 28,905 20,442 8,463 2,182
90° 28,553 20,518 8,035 2,236
95° 28,200 20,586 7,614 2,290
100° 27,495 20,452 7,043 2,336
105° 26,790 20,298 6,492 3,600
110° 25,803 19,632 6,171 2,421
115° 24,816 18,960 5,856 2,461
TVA Conditions @ 95° OD DB, 75° ID DB, 63 ID WB
95 26,131 5,751 20,380 2,204
RCE36C2C / CAX*042*2A + TXV
Conditions: 80° ID DB, 67° ID WB @ 1,150 CFM
Outdoor
Temp. ° F.
Total
Btuh
Sensible
Btuh
Latent
Btuh
Total
Watts
75° 36,540 24,510 12,030 2,648
80° 36,105 24,526 11,579 2,726
85° 35,670 24,535 11,135 2,803
90° 35,235 24,626 10,609 2,872
95° 34,800 24,708 10,092 2,940
100° 33,930 24,547 9,383 2,998
105° 33,060 24,362 8,698 3,600
110° 31,842 23,563 8,279 3,106
115° 30,624 22,756 7,868 3,157
TVA Conditions @ 95° OD DB, 75° ID DB, 63 ID WB
95 32,247 7,786 24,461 2,831
RCE42C2C/CA*X049*2A + TXV
Conditions 80° ID DB, 67° ID WB @ 1,000 CFM
Outdoor
Temp. ° F.
Total
Btuh
Sensible
Btuh
Latent
Btuh
Total
Watts
75° 43,050 34,980 8,070 3,104
80° 42,538 31,705 10,833 3,194
85° 42,025 28,499 13,526 3,284
90° 41,513 28,605 12,907 3,363
95° 41,000 28,700 12,300 3,442
100° 39,975 28,513 11,462 3,509
105° 38,950 28,298 10,652 5,040
110° 37,515 27,370 10,145 3,635
115° 36,080 26,433 9,647 3,693
TVA Conditions @ 95° OD DB, 75° ID DB, 63 ID WB
95 37,992 9,579 28,413 3,316
RCE48C2C / CA*X061*2A + TXV
Conditions: 80° ID DB, 67° ID WB @ 1500 CFM
Outdoor
Temp. ° F.
Total
Btuh
Sensible
Btuh
Latent
Btuh
Total
Watts
75° 49,350 33,569 15,781 3,441
80° 48,763 33,591 15,171 3,601
85° 48,175 33,603 14,572 3,760
90° 47,588 33,728 13,859 3,855
95° 47,000 33,840 13,160 3,950
100° 45,825 33,619 12,206 4,031
105° 44,650 33,366 11,284 6,360
110° 43,005 32,272 10,733 4,181
115° 41,360 31,167 10,193 4,250
TVA Conditions @ 95° OD DB, 75° ID DB, 63 ID WB
95 43,552 10,050 33,502 3,800
RCE60C2C/ CAX*061*2A + TXV
Conditions: 80° ID DB, 67° ID WB @ 1750 CFM
Outdoor
Temp. ° F.
Total
Btuh
Sensible
Btuh
Latent
Btuh
Total
Watts
75° 59,850 40,712 19,138 4,347
80° 59,138 40,738 18,399 4,553
85° 58,425 40,753 17,672 4,760
90° 57,713 40,904 16,808 4,882
95° 57,000 41,040 15,960 5,005
100° 55,575 40,772 14,803 5,109
105° 54,150 40,465 13,685 2,607
110° 52,155 39,138 13,017 5,303
115° 50,160 37,798 12,362 5,393
TVA Conditions @ 95° OD DB, 75° ID DB, 63 ID WB
95 52,818 12,189 40,630 48,10
Cooling Specifications for C2C Models

Specification Sheet
www.amana-hac.com 7
Performance Ratings
Model Evaporator Model Total BTUH Sensible BTUH SEER EER ARI Ref. # Decibel
RCE24C2*
ARPT032-00A-1
CHH24TCD+BDK
CHH30TCD+BDK
AEPT030-00A-1
ARUF032-00A-1
ARPF036-00B-1
CA*X025*2*+A*V90453B**
CA*X025*2*+MBR800****
CA*X025*2*+BDK
CA*X030*2*+A*V90453B**
CA*X030*2*+A*V90704C**
CA*X030*2*+MBR800****
CA*X030*2*+BDK
CA*X037*2*+A*V90453B**
CA*X037*2*+A*V90704C**
CA*X037*2*+MBR800****
CA*X037*2*+MBE1200****
CA*X037*2*+BDK
CH*X024*2*+A*V90704C**
CH*X024*2*+MBR800****
CH*X024*2*+BDK
CH*X030*2*+A*V90453B**
CH*X030*2*+MBR800****
CH*X030*2*+BDK
CH*X037*2*+A*V90453B**
CH*X037*2*+A*V90704C**
CH*X037*2*+MBR800****
CH*X037*2*+MBE1200****
CH*X037*2*+BDK
23,000
23,200
24,200
23,600
23,000
23,000
24,000
24,400
23,800
24,000
24,400
23,800
23,200
24,600
24,800
24,800
24,800
24,200
24,600
24,600
23,400
24,000
24,200
24,000
24,000
24,800
23,800
24,200
23,600
16,300
16,500
17,200
16,800
16,300
16,300
17,000
17,300
16,900
17,000
17,300
16,900
16,500
17,500
17,600
17,600
17,600
17,200
17,500
17,500
16,600
17,000
17,200
17,000
17,000
17,600
16,900
17,200
16,800
14.0
14.0
14.0
15.0
14.0
14.0
15.0
15.0
14.0
15.0
15.0
15.0
14.0
16.0
16.0
15.0
16.0
14.0
15.0
14.0
14.0
15.0
15.0
14.0
15.0
15.0
15.0
15.0
14.0
12.7
12.3
12.3
14.0
12.7
12.7
12.8
12.8
12.3
12.8
12.8
12.8
12.3
13.5
13.5
12.8
13.5
12.3
12.8
12.3
12.3
12.8
12.8
12.3
12.8
12.8
12.8
12.8
12.3
410056
411353
411402
462893
468210
468755
504540
504541
504542
504543
504544
504545
504546
504547
504548
504549
504550
504551
504552
504553
504554
504555
504556
504557
504558
504559
504560
504561
504562
71
RCE30C2*
ARPT042-00A-1
CCH36FCD+TXV+BDK
CHH36TCD+BDK
CHH30TCD+BDK
AEPT030-00A-1
ARUF042-00A-1
ARPF036-00B-1
CA*X030*2*+A*V90704C**
CA*X037*2*+A*V90453B**
CA*X037*2*+A*V90704C**
CA*X037*2*+A*V90905D**
CA*X037*2*+MBR1200****
CA*X037*2*MBE1200****
CA*X037*2*+BDK
CA*X042*2*+A*V90453B**
CA*X042*2*+MBR1200****
CA*X042*2*+MBE1200****
CA*X042*2*+BDK
CA*X049*2*+BDK
CH*X030*2*+A*V90453B**
CH*X037*2*+A*V90453B**
CH*X037*2*+MBE1200****
CH*X042*2*+A*V90453B**
CH*X042*2*+A*V90704C**
CH*X042*2*+BDK
27,000
27,600
27,600
27,600
28,800
27,000
27,000
27,200
28,000
27,200
28,600
28,400
28,800
28,800
28,000
28,600
29,000
28,800
26,600
27,000
27,000
27,400
28,000
28,000
27,400
20,000
20,400
20,400
20,400
21,300
20,000
20,000
20,100
20,700
20,100
21,200
21,000
21,300
21,300
20,700
21,200
21,500
21,300
19,700
20,000
20,000
20,300
20,700
20,700
20,300
14.0
14.0
14.0
13.0
15.0
14.0
13.0
14.0
15.0
15.0
15.0
14.0
15.0
14.0
15.0
14.0
15.0
14.0
14.0
14.0
14.0
14.0
15.0
15.0
14.0
12.7
12.3
12.3
11.7
14.0
12.7
11.7
12.3
12.8
12.8
12.8
12.3
12.8
12.3
12.8
12.3
12.8
12.3
12.3
12.3
12.3
12.3
12.8
12.8
12.3
410048
411383
411391
462467
462894
468204
469096
504563
504564
504565
504566
504567
504568
504569
504570
504571
504572
504573
504574
504575
504576
504577
504578
504579
504580
71

Specification Sheet
www.amana-hac.com
8
Performance Ratings (cont.)
Model Evaporator Model Total BTUH Sensible BTUH SEER EER ARI Ref. # Decibel
RCE36C2*
ARPT049-00A-1
CHH36TCD+BDK
CCH48FCD+TXV+BDK
CCH36FCD+TXV+BDK
AEPT036-00A-1
ARUF042-00A-1
ARPF048-00B-1
CA*X037*2*+A*V90905D**
CA*X037*2*+A*V91155D**
CA*X037*2*+MBR1200****
CA*X037*2*+MBE1200****
CA*X037*2*+BDK
CA*X042*2*+A*V90453B**
CA*X042*2*+MBR1200****
CA*X042*2*+MBE1200****
CA*X042*2*+MBE1600****
CA*X042*2*+BDK
CA*X049*2*+A*V90704C**
CA*X049*2*+A*V90905D**
CA*X049*2*+A*V91155D**
CA*X049*2*+MBR1600****
CA*X049*2*+MBE1600****
CA*X049*2*+MBE2000****
CA*X049*2*+BDK
CA*X049*2*+BDK
CH*X030*2*+A*V90453B**
CH*X037*2*+A*V90453B**
CH*X037*2*+MBR1200****
CH*X037*2*+BDK
CH*X042*2*+A*V90453B**
CH*X042*2*+A*V90704C**
CH*X042*2*+MBR1600****
CH*X042*2*+MBE1600****
CH*X042*2*+BDK
CH*X048*2*+A*V90905D**
CH*X048*2*+A*V91155D**
CH*X048*2*+MBE2000****
CH*X048*2*+BDK
35,000
34,800
36,000
34,800
34,800
35,000
35,000
35,000
35,200
35,200
35,200
34,600
35,200
35,200
35,400
36,000
34,800
35,600
35,800
35,800
35,600
36,200
36,200
35,800
35,000
33,200
33,200
34,000
34,600
34,200
34,800
35,000
35,200
35,000
35,000
35,200
36,000
35,000
25,600
25,400
26,300
25,400
25,400
25,600
25,600
25,600
25,700
25,700
25,700
25,300
25,700
25,700
25,700
26,300
25,400
25,000
26,100
26,100
26,000
26,400
26,400
26,100
25,600
24,200
24,800
24,800
25,300
25,000
25,400
25,700
25,700
25,700
25,700
25,700
26,300
25,600
14.0
14.0
14.0
14.0
15.0
14.0
14.0
15.0
15.0
14.0
15.0
14.0
15.0
14.0
15.0
15.0
14.0
15.0
16.0
16.0
14.0
15.0
16.0
14.0
14.0
14.0
14.0
14.0
14.0
15.0
15.0
14.0
15.0
14.0
15.0
15.0
16.0
14.0
12.7
12.3
12.3
12.3
14.0
12.7
12.7
12.8
12.8
12.3
12.8
12.3
12.8
12.3
12.8
12.8
12.3
12.8
13.5
13.5
12.3
12.8
13.5
12.3
12.3
12.3
12.3
12.3
12.3
12.8
12.8
12.3
12.8
12.3
12.8
12.8
13.5
12.3
410045
411434
411465
411467
462895
468211
469094
504581
504582
504583
504584
504585
504586
504587
504588
504589
504590
504591
504592
504593
504594
504595
504596
504597
504598
504599
504600
504601
504602
504603
504604
504605
504606
504607
504608
504609
504610
504611
73
RCE42C2*
ARPT049-00A-1
CHH60TCD+BDK
CCH60FCD+TXV+BDK
AEPT060-00A-1
ARUF049-00A-1
ARPF048-00B-1
CA*X042*2*+A*V90453B**
CA*X042*2*+A*V90704C**
CA*X042*2*+MBR1200****
CA*X042*2*+MBE1200****
CA*X042*2*+BDK
CA*X049*2*+A*V90704C**
CA*X049*2*+A*V90905D**
CA*X049*2*+A*V91155D**
CA*X049*2*+MBR1600****
CA*X049*2*+MBE1600****
CA*X049*2*+MBR2000****
CA*X049*2*+BDK
CA*X060*2*+A*V90905D**
CA*X060*2*+A*V91155D**
CA*X060*2*+MBR2000****
CA*X060*2*+MBE2000****
CA*X060*2*+BDK
CH*X042*2*+A*V90704C**
CH*X042*2*+BDK
CH*X048*2*+A*V90704C**
CH*X048*2*+A*V90905D**
CH*X048*2*+A*V91155D**
CH*X048*2*+MBR1600****
CH*X048*2*+MBE1600****
CH*X048*2*+MBR2000****
CH*X048*2*+MBE2000****
CH*X048*2*+BDK
40,000
41,500
41,500
38,500
40,000
40,000
39,000
39,000
39,500
40,000
39,000
40,000
40,000
40,500
40,500
40,500
39,500
38,500
40,500
40,500
40,000
40,500
40,500
38,500
39,000
38,500
39,500
40,000
39,000
39,500
38,500
40,000
39,000
29,600
30,700
30,700
28,500
29,600
29,600
28,900
28,900
29,200
29,600
28,900
29,600
29,600
30,000
30,000
30,000
29,300
28,500
30,000
30,000
29,600
30,000
30,000
28,500
28,900
28,500
29,200
29,600
28,900
29,200
28,500
29,600
28,900
14.0
14.0
14.0
15.0
14.0
14.0
14.0
15.0
14.0
14.0
14.0
15.0
15.0
15.0
14.0
15.0
14.0
14.0
16.0
16.0
14.0
16.0
14.0
14.0
14.0
14.0
15.0
15.0
14.0
15.0
14.0
15.0
14.0
12.6
12.3
12.3
14.0
12.6
12.6
12.3
12.8
12.3
12.3
12.3
12.8
12.8
12.8
12.3
12.8
12.3
12.3
13.5
13.5
12.3
13.5
12.3
12.3
12.3
12.3
12.8
12.8
12.3
12.8
12.3
12.8
12.3
410057
411533
411545
462896
468208
468788
504612
504613
504614
504615
504616
504617
504618
504619
504620
504621
504622
504623
504624
504625
504626
504627
504628
504629
504630
504631
504632
504633
504634
504635
504636
504637
504638
73

Specification Sheet
www.amana-hac.com 9
Performance Ratings (cont.)
Model Evaporator Model Total BTUH Sensible BTUH SEER EER ARI Ref. # Decibel
RCE48C2*
ARPT049-00A-1
CHH60TCD+BDK
CCH60FCD+TXV+BDK
CCF61FCC+TXV+BDK
CHH48TCD+BDK
AEPT060-00A-1
ARUF048-00A-1
ARPF060-00B-1
CA*X049*2*+A*V90905D**
CA*X049*2*+A*V91155D**
CA*X049*2*+MBE1600****
CA*X049*2*+BDK
CA*X060*2*+A*V90905D**
CA*X060*2*+A*V91155D**
CA*X060*2*+MBR2000****
CA*X060*2*+MBE2000****
CA*X061*2*+MBR2000****
CA*X061*2*+MBE2000****
CA*X061*2*+BDK
CH*X048*2*+A*V90905D**
CH*X048*2*+A*V91155D**
CH*X048*2*+MBE1600****
CH*X048*2*+MBR2000****
CH*X048*2*+MBE2000****
CH*X048*2*+BDK
CH*X060*2*+MBR2000****
CH*X060*2*+MBE2000****
CH*X060*2*+BDK
45,000
47,000
47,000
46,500
46,000
46,500
45,000
45,000
44,000
44,000
46,000
45,000
46,000
46,000
45,500
46,000
46,500
47,500
46,500
45,000
45,000
44,500
45,500
46,000
45,000
46,500
47,500
46,500
33,300
34,800
34,800
34,400
34,000
34,400
33,300
33,300
32,600
32,600
34,000
33,300
34,000
34,000
33,700
34,000
34,500
35,200
34,400
33,300
33,300
32,900
33,700
34,000
33,300
34,400
35,200
34,400
14.0
14.0
14.0
14.0
13.0
15.0
14.0
14.0
14.0
14.0
14.0
13.0
14.0
14.0
14.0
14.0
14.0
15.0
14.0
14.0
14.0
14.0
14.0
15.0
14.0
14.0
15.0
14.0
12.0
12.3
12.3
12.3
12.1
14.0
12.0
12.0
12.3
12.3
12.3
11.9
12.3
12.3
12.3
12.3
12.3
12.8
12.3
12.3
12.3
12.3
12.3
12.8
12.3
12.3
12.8
12.3
410049
411582
411585
411586
435969
462898
468216
469098
504639
504640
504641
504642
504643
504644
504645
504646
504647
504648
504649
504650
504651
504652
504653
504654
504655
504656
504657
504658
74
RCE60C2*
ARPT061-00A-1
CHH60TCD+BDK
AEPT060-00A-1
ARUF061-00A-1
ARPF060-00B-1
CA*X060*2*+A*V91155D**
CA*X060*2*+MBE2000****
CA*X061*2*+A*V90905D**
CA*X061*2*+A*V91155D**
CA*X061*2*+MBR2000****
CA*X061*2*+BDK
CH*X048*2*+MBE2000****
CH*X048*2*+BDK
CH*X060*2*+A*V91155D**
CH*X060*2*+MBE2000****
CH*X060*2*+BDK
57,000
57,000
56,000
57,000
57,000
56,500
56,000
57,000
57,500
59,000
57,000
56,000
55,500
57,000
58,000
57,000
41,600
41,600
40,900
41,600
41,600
41,200
40,900
41,600
42,000
43,100
41,600
40,900
40,500
41,600
42,300
41,600
14.0
14.0
14.5
14.0
14.0
14.0
14.0
14.0
14.0
14.0
14.0
14.0
13.0
14.0
14.0
14.0
12.7
12.3
13.5
12.7
12.7
12.3
12.3
12.3
12.3
12.3
12.3
12.3
11.6
12.3
12.3
12.3
410055
411672
462897
468213
468789
504659
504660
504661
504662
504663
504664
504665
504666
504667
504668
504669
76

Specification Sheet
www.amana-hac.com
10
Model Description RCE24C2* RCE30C2* RCE36C2* RCE42C2* RCE48C2* RCE60C2*
ASAS Electronic Air Cleaner X X X X X X
FSK01A** Freeze Thermostat Kit X X X X X X
AMU Media Air Cleaner X X X X X X
PCK01A Pressure Control Kit X X X X X X
ASC01A Anti-short Cycle Kit X X X X X X
LSK01A Liquid Line Solenoid Kit X X X X X X
** Factory-installed
Accessories

Specification Sheet
www.amana-hac.com 11
Model M038101 1213402 1213401 1213408
Manual/Auto Manual Manual Manual Manual or Auto
Programmable No No Yes Yes
Cool 1 1 1 1
Heat 1 1 1 1
Emergency Electric Heat No No No Yes
Shape Rect. / Vertical Rectangular Rectangular Rectangular
Battery Powered No Yes Yes No
24V Powered w/Battery Back-up No No No Yes
For Use With Gas Heat, Electric Heat, Electric Cool
Color Beige White White White
Thermostats

Specification Sheet
www.amana-hac.com
12
Amana®is a trademark of Maytag Corporation and used under license to Goodman Company, L.P. All rights reserved.
Our continuing commitment to quality products may mean a change in specifications without notice.
Copyright © 2004 Goodman Company, L.P. · Houston, Texas · Printed in U.S.A. Form: PDB-RCE
Date: 8/04
Supercedes 2/04
