Ambiano EA-1295 Professional User manual

INSTRUCTION MANUAL
Model Number EA-1295
Induction Cooker
INSTRUCTION MANUAL
AFTER SALES SUPPORT
MODEL: EA-1295 PRODUCT CODE: 53816 06/2016
Version: 5
1800 898 750
AUS
[email protected]
Professional

AFTER SALES SUPPORT
MODEL: EA-1295 PRODUCT CODE: 53816 06/2016
1800 898 750
AUS
[email protected]
Contents
1 Warranty Details
2 Welcome
3 General Safety Instructions
5 Product Overview
6 Product Operating Instructions
10 Maintenance / Disposal
11 Troubleshooting
12 Product Specifications
13 Repair and Refurbished

Induction Cooker
The product is guaranteed to be free from defects in workmanship and parts for a period
of 36 months from date of purchase. Defects that occur within this warranty period,
under normal use and care, will be repaired, replaced or refunded at our discretion,
solely at our option with no charge for parts and labour. The benefits conferred by this
warranty are in addition to all rights and remedies in respect of the product that the
consumer has under the Competition and Consumer Act 2010 and similar state and
territory laws.
Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure and for
compensation for any other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
MODEL: EA-1295 PRODUCT CODE: 53816 06/2016
[email protected]
AFTER SALES SUPPORT
YEAR WARRANTY
3
1800 898 750
AUS
1

AFTER SALES SUPPORT
MODEL: EA-1295 PRODUCT CODE: 53816 06/2016
1800 898 750
AUS
[email protected]
Congratulations on choosing to buy a Ambiano product.
All products brought to you by Ambiano are manufactured to the highest
standards of performance and safety and, as part of our philosophy of customer
service and satisfaction, are backed by our comprehensive 3 Year Warranty. We
hope you will enjoy using your purchase for many years to come.
Welcome
2

Read this manual thoroughly before first use, even if you are familiar with this type
of product. The safety precautions enclosed herein reduce the risk of fire, electric
shock and injury when correctly adhered to. The induction cooker is for private
indoor domestic use only.
Keep the manual in a safe place for future reference, along with the completed
warranty card, purchase receipt and carton. If applicable, pass these instructions
on to the next owner of the appliance.
Always follow basic safety precautions and accident prevention measures when
using an electrical appliance, including the following:
Warning :
DO NOT switch on the induction cooker if the cooktop has been damaged or
cracked.
1. Do not place the unit near gas or other hot elements in order to avoid
damage or malfunction.
2. To reduce the risk of damage use a dedicated electrical circuit. The rated
electrical current should not be less than 16A.
3. Place the unit on a level surface allowing a 10cm space between the cooktop
and the wall.
4. To protect against an electric shock do not immerse the unit, the cord or the
plug in or near water or other liquids.
5. Do not block the exhaust vent. Blocking may overheat the unit.
6. When heating tinned food ensure the lid is removed.
7. When replacing the power cord ensure that the replacement is recommended
by the appliance manufacturer.
8. Do not heat an empty pot.
9. To avoid being burned, do not touch the cooktop when it is turned on.
10. Close supervision is necessary when the induction cooktop is used near
children.
11. Users with pacemakers, should check with their doctor before using the
induction cooktop.
12. During cooking do not remove the cookware from the glass plate as this will
interfere with the cooking process.
AFTER SALES SUPPORT
MODEL: EA-1295 PRODUCT CODE: 53816 06/2016
1800 898 750
AUS
[email protected]
3
General Safety Instructions

AFTER SALES SUPPORT
MODEL: EA-1295 PRODUCT CODE: 53816 06/2016
1800 898 750
AUS
[email protected]
4
General Safety Instructions
Cont...
13. Children less than 8 years of age shall be kept away unless continuously
supervised.
14. Keep the appliance and its cord out of reach of children less than 8 years.
15. WARNING: The appliance and its accessible parts become hot during use.
16. Case should be taken to avoid touching heating elements.
17. Warning: If the surface is cracked, switch off the appliance to avoid the
possibility of electric shock.
18. The outer surface may get hot when the appliance is operating.
19. Metallic objects such as knives, forks, spoons and lids should not be placed
on the hot surface since they can get hot.
20. The appliance is not intended for use by persons (including children under 8
years old) with reduced physical, sensory or mental capabilities or lack of
experience and knowledge unless they have been given supervision or
instruction concerning use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children without supervision.
21. The appliance is not intended to be operated by means of an external timer or
separate remote-control system.
WARNING:
To avoid getting burned, do not touch the glass plate during use or
immediately after the induction cooker has been turned off.
CAUTION: Hot surface, please do not touch with your hand.
!

Control Panel
1 Preset-set switch-on time
2 Decrease power/temperature/time
3 Indicator lights:
- 8 power setting: 300W, 600W, 900W, 1200W,
1400W, 1600W, 1800W and 2100W
- 8 temperature setting: 60˚C, 90˚C, 120˚C,
150˚C, 180˚C, 220˚C and 240˚C
4 Increase power/temperature/time
5 Timer-set switch-off time
6 Warm milk
7 Soup
8 Stir-Fry
9 Display
10 Fry
11 Hot pot
12 On/Off
13 Cooking zone
14 Glass plate
15 Exhaust vent
Not shown:
• Instruction manual
• Quick start guide
• Warranty card
AFTER SALES SUPPORT
MODEL: EA-1295 PRODUCT CODE: 53816 06/2016
1800 898 750
AUS
[email protected]
Product Overview
5
15
1
14
678
10 11 12
2
4
5
3
9
13

AFTER SALES SUPPORT
MODEL: EA-1295 PRODUCT CODE: 53816 06/2016
1800 898 750
AUS
[email protected]
An introduction to induction cooking
Induction cooking is based on an electro-magnetic field creating energy which
heats the base of a pan positioned on the cooktop. The electro-magnetic field is
activated when material containing iron (ferrous material) comes within range of the
inductors beneath the cooktop surface. Induction cooking is generally about twice
as fast as traditional gas cooking and ideal for fast cooking such as stir-frying. On
the other end of the spectrum, induction is also very slow and gentle and ideal for
melting chocolate or making a bernaise sauce. The induction cooktop is also easy
to clean. Since there are no elements heating the glass, spill-overs are less likely to
get baked onto the surface. Finally, because the cooktop is not heated directly,
induction cooking is much safer to use.
Before first use
1. Remove all packaging materials from the induction cooker.
2. Place the appliance on a dry, stable and level surface.
3. Make sure there is at least 10cm free space around the appliance to prevent
overheating.
4. There is a over heat protection in the production, please refer to page 11 for E2
and E7 code.
5. Always place the cookware on the cooking zone during cooking.
6. Make sure you use cookware of the correct types and sizes (see the table
below).
Product Operating Instructions
6
Material Cookware with a bottom made of iron or magnetic stainless steel
Shape Cookware with a flat bottom
Size Cookware with a bottom diameter of 12-26 cm, depending on the
cooking mode
Recommended types and sizes of cookware

WARNING:
To use only one pot at a time on the cooking zone.
To avoid getting burned, do not touch the glass plate during use or
immediately after the induction cooker has been turned off.
Using the induction cooker
1. Follow the steps in “Before first use”.
2. Press the On/Off button ( ), the On/Off indicator lights up.
3. Press the cooking mode key to choose the desired cooking mode. The
corresponding indicator lights up and the induction cooker starts working in the
selected mode.
4. When the cooking is finished, press the On/Off button ( ) to switch off the
appliance.
5. Unplug the induction cooker after the fan stops working.
6. Do not remove cookware during cooking.
Note:
• During cooking, you can change the power level by pressing the increase (+)
or decrease (-) button.
• For Soup and Milk modes the power adjusts automatically.
• There is overheat protection in the Induction Cooktop. Error codes E2 and E7
(see page 11) will indicate an overheat issue.
Default cooking times and temperatures
Refer to below table for the times and temperatures of different cooking modes.
Cooking mode Default cooking time
(hour)
Default cooking
temperature/power
02:00 200°C/1600W
Fry ( ) 02:00 220°C/1800W
Stir Fry ( )
Hot pot ( ) 02:00 180°C/1400W
00:30 60°C (fixed temperature)Warm Milk ( )
02:00 auto adjusts (200˚C - 60˚C)Soup ( )
AFTER SALES SUPPORT
MODEL: EA-1295 PRODUCT CODE: 53816 06/2016
1800 898 750
AUS
[email protected]
Product Operating Instructions
Cont...
7

AFTER SALES SUPPORT
MODEL: EA-1295 PRODUCT CODE: 53816 06/2016
1800 898 750
AUS
[email protected]
Product Operating Instructions
Cont...
8
There are 8 power levels in total (300W, 600W, 900W, 1200W, 1400W, 1600W,
1800W and 2100W) and 8 temperature levels in total (60˚C, 90˚C, 120˚C, 150˚C,
180˚C, 200˚C, 220˚C and 240˚C). These can be adjusted by pressing the (+) or (-)
key to set the desired power level. For Soup and Milk modes the power adjusts
automatically. To cancel this mode, press other keys to switch to other cooking
modes or press the On/Off ( ) key to stop the operation.
Using the timer
You can use the Timer button ( ) to decide how much time you want to set for
the different cooking modes (not applicable for Warm Milk and Soup modes).
1. Follow the steps in “Before first use”.
2. Press the On/Off ( ) button, the On/Off ( ) indicator lights up.
3. Choose the desired cooking mode.
4. Press the Timer button ( ) once or more times until the timer indicator lights
up.
5. Press the Increase (+) or Decrease (-) button to adjust the time.
6. When the time has elapsed, the induction cooker turns off automatically.
Note:
• After you have selected the cooking time, wait for a few seconds before the
induction cooker automatically confirms it with a “Beep” sound the indicator
flashes. After that the indicator above On/Off ( ) key will start to flash.
• After the timer is set, you can press the Timer button ( ) again to cancel the
timer.

AFTER SALES SUPPORT
MODEL: EA-1295 PRODUCT CODE: 53816 06/2016
1800 898 750
AUS
[email protected]
Product Operating Instructions
Cont...
9
WARNING:
• For food safety reasons, do not leave easily spoilt foods on the induction
cooker for too long when using the timer.
Preset time for delayed cooking
You can use the Preset button ( ) to set the time that you want the appliance to
start cooking. The preset timer is available up to 24 hours.
1. Press the On/Off button ( ). The On/Off indicator lights up.
2. Choose the desired cooking mode.
3. Press the Preset button ( ) once or more times until the preset indicator
lights up.
4. Press the Increase (+) or the Decrease (-) button to choose the desired preset
time.
5. When the preset time has elapsed, you will hear a few beeps and the
induction cooker will start working automatically.
Note:
• The preset timer can not be used for Hotpot, Fry and Stir Fry cooking modes.
• After you have selected the preset time, wait for a few seconds before the induction
cooker automatically conrms it.
• When the induction cooker is at preset mode, you can press the Preset button ( )
again to cancel the preset time.

AFTER SALES SUPPORT
MODEL: EA-1295 PRODUCT CODE: 53816 06/2016
1800 898 750
AUS
[email protected]
1. Clean the glass surfaces with a soft, damp cloth
or sponge. You can use washing-up liquid for stubborn stains.
2. Wipe the glass surfaces dry with a soft, dry cloth.
3. Do not use any abrasive or harsh cleaning agents that may scratch the
surface of the hotplate or the glass panel.
4. Clean the exhaust vent using a soft brush.
5. Do not immerse the unit in water.
6. When not in regular use, it is important to store your hotplate in a safe,
dry location. We strongly recommend that you store the hotplate in its
original carton to keep it dust-free.
7. When using transportation to move your hotplate to another location,
we recommend that it is safely packed in its original carton or similar
packaging materials to avoid damage.
Maintenance
10
CAUTION:
Before cleaning or moving the appliance, or when it is not in
use, switch off the appliance and unplug the power plug.
Grip by the plug, do not pull by the cord.
WARNING:
Allow the Induction Cooker to cool down completely before cleaning or
maintenance to avoid risk of burns or injury.
Disposal
Packaging
Your device has been packaged to protect it against transportation
damage. The packaging constituents are raw materials and can be
reused or recycled.
Device
At the end of its life, the device should not be disposed of in
household rubbish. Contact your municipal authorities about the
options for environmentally friendly disposal.

AFTER SALES SUPPORT
MODEL: EA-1295 PRODUCT CODE: 53816 06/2016
1800 898 750
AUS
[email protected]
11
Troubleshooting
Error codes E0 Internal circuit error
E1 Without cookware or Incompatible
cookware used
E2 Internal overheat
E3 Over-voltage
E4 Under-voltage
E5 Top plate sensor open/short circuit
E6 IGBT sensor open circuit/ short circuit
E7 Top plate overheat
When showing error
codes E1, E2 and
E7, check whether
suitable cookware is
being used.
When showing error
codes E0, E3-E6,
contact the Service
Centre.
During operation, if any problems or errors occur, please check the following table
before calling for service. Below are common errors and the checks to perform.
NOTE: To avoid any danger and damage to the appliance, do not attempt to
disassemble or repair it yourself.
Problem Solution
The On/Off button
( ) does not respond.
There is a connection problem. Check if the induction
cooker is connected to the mains and if the plug is
inserted firmly into the wall socket.
You may have put unsuitable cookware on the cooking
plate or you may removed the cookware from the
cooking plate during cooking. Make sure the cookware
is made of steel, iron or aluminum with stainless steel
cladding base and has a base diameter larger than 12cm.
The bottom of the cookware may not be flat. Use
cookware with a flat bottom.
The appliance beeps
continuously and then
stops working.
You may have placed the cookware outside of the
cooking zone.
The cookware does
not heat up to the
required temperature.
During cooking you can change the power level by
pressing the Increase (+) or Decrease (-) button.
The cooking
temperature of the
preset mode is too
high or too low.

AFTER SALES SUPPORT
MODEL: EA-1295 PRODUCT CODE: 53816 06/2016
1800 898 750
AUS
[email protected]
Model EA-1295
Rated Voltage 220-240V~50/60Hz
Power 2100W
Temperature Range 60 - 240˚C
Unit Dimensions 298*376*60mm
Net Weight 2.565kg
Product Specifications
12
IM Version No: V5 Issue Date: 04/2016
You may contact us at [email protected]
for an electronic file of the Instruction Manual.
IEC 60335-2-9
AS/NZ S 60335.1 & AS/NZS 60335-2-9

MODEL: EA-1295 PRODUCT CODE: 53816 06/2016
[email protected]
AFTER SALES SUPPORT
YEAR WARRANTY
3
1800 898 750
AUS
Repair and Refurbished Goods
or Parts Notice
Induction Cooker
Unfortunately, from time to time, faulty products are manufactured which need to be returned
to the Supplier for repair.
Please be aware that if your product is capable of retaining user-generated data (such as files
stored on a computer hard drive, telephone numbers stored onamobile telephone, songs
stored on a portable media player, games saved onagames console or files stored ona USB
memory stick) during the process of repair, some or all of your stored data may be lost.
We recommend you save this data elsewhere prior to sending the product for repair.
You should alsobe aware that rather than repairing goods, we may replace them with
refurbished goods of the same type or use refurbished parts in the repair process.
Please be assured though, refurbished parts or replacements are only used where they
meet ALDI’s stringent quality specications.
If at any time you feel your repair is being handled unsatisfactorily, you may escalate your
complaint. Please telephone us on 1800 898 750 or write to us at:
Install + Fix Solutions
7/210 Robinson Road East, Geebung, QLD, Australia 4034
1800 898 750
8:30am - 6pm AEST
[email protected]
13
