ENGLISH 7
Using Timer
•Timerstartswhenpump
is on. Timer displays
pumping duration in
minutes : seconds.
•Timercanberesetby
pressing Timer Reset
button.
•Timerandpump
automaticallyturnOFF
after 60 minutes.
Turning Pump OFF
•Whennishedpumping,
press and hold Power
button to turn pump and
timer functions OFF.
Removing Ameda HygieniKit Milk Collection System
from Breast(s)
•AfterpumpisOFF,ifnecessary,insertangerbetween
breast(s)andbreastanges(s)tobreaksuction.
•Removebreastanges(s)frombreast(s).
Cleaning the Ameda Platinum Breast Pump
For At-Home/End-Users
After each pumping, wipe the Ameda Platinum Breast Pump
with clean, damp cloth.
For Hospitals/Rental Stations
Clean between users. Wearing disposable gloves, wipe
the Ameda Platinum Breast Pump with damp disposable
cloth using hospital approved antibacterial cleaner, such as
CaviCideTM.
Troubleshooting
Pump does not turn ON
•Ensureproperpowercordconnectiontopump.
•Ensuregroundedplugconnectiontoelectricaloutlet.
•Ensureoutlethaspower.
Unable to adjust speed
•EnsurepumpfunctionisON.
•Ensure“CheckKit”isnotshowninsuctiondisplay
window.
Unable to adjust suction
•EnsurepumpfunctionisON.
•Ensure“CheckKit”isnotshowninsuctiondisplay
window.
Low or no suction
•Ensure“CheckKit”isnotshowninsuctiondisplay
window.
•Checkbreastangeforadequatesealagainstbreast.
•CheckthattheAmedaHygieniKitMilkCollectionSystem
is properly assembled.
•Checkthatadaptercapisrmlysnappedontotopof
breast flange.
•Ensuresiliconediaphragmisinplaceinsidetopofbreast
flange.
•Ensuretubingadapterisproperlyttedintotubing
adapter port on pump.
•Inspectvalveforstretchingortears.Ifseen,replace
valve.
•Ensurevalveispushedrmlyintoplaceinlowerportion
of breast flange.
•Ensureonesideoftubingadapterisclosedwhensingle
pumping.
“Check Kit” error message appears
•Ensuretubingadapterisproperlyttedintotubingadapter
port on pump.
•Ensureonesideoftubingadapterisclosedwhensingle
pumping.
•Checkthatadaptercapisrmlysnappedontotopof
breast flange.
•Ensuresiliconediaphragmisinplaceinsidetopofbreast
flange.
•Checktubingandsiliconediaphragmtoensurethatparts
are free of defects.
•Checktubingisrmlyattachedtoadaptercap.
“Service Required” error message appears
•Callyourlocaldistributor.Forlistingofdistributors
worldwide, visit www.ameda.com.
The Ameda Platinum Breast Pump should be serviced only
by Ameda, Inc. or authorized Service Centers approved by
Ameda, Inc.
Maintenance
It is recommended the Ameda Platinum Breast Pump be
inspected at least once every year to include the following:
•Visuallycheckpumphousingforcracks,breakage,or
damage and ensure Pump Feet are present.
•Visuallycheckforpowercorddamage.
•Checkforproperoperationofcontrolsandbuttons.
•Checktherearenomissingscrews.
•CheckcoverispresentonServicePortDoor.
•CheckTubingAdapterPortisfreefromobstruction.
Quick Functional Check
Thefollowingchecks/testsshouldbeperformedpriortouse
by a new user:
•Visualchecksforpowercorddamage.
•Checkforabnormalnoise.
•Checkforproperoperationofcontrolsandbuttons.
Service Port
•DonotopenServicePortDooronbottomofthePump.
•Donotconnectanyequipmenttotheserviceportwhen
operating the pump.
•ServiceportistobeaccessedonlybyauthorizedService
Centers approved by Ameda, Inc.
Replacing Detachable Power Cord:
•Powercordisdetachablefrompowerinlet.
•Ifpowercordconditionisindoubt,onlyreplacewith
Amedasupplied3-conductorcordequippedwith
protective ground conductor.
Technical Information
Protection Class 1, Type B
Power Supply:
OperatingInputVoltage100VACto240VAC
OperatingFrequency50/60Hz
Input Power 80VA
FuseRatingQuickActing(F),2.5A,250V,5x20mm
Power Cord: Use only Ameda supplied power cord
For North America, use Ameda 24502059
Minimum Voltage Rating: 125V
Minimum Current Rating: 10A
PlugType:IEC60320C13(HospitalGrade)
MaximumLength:10feet(3.05m)
Cord Type: 3x18AWG, rated VW-1, 105C
Jacket Type: SJT or SJTW
Certication:ULListed(ELBZ)
Operation: Continuous
ISO10079-1,IntermittentSuction,MediumVacuum
Suction: Showninpercentageoffullscalesuction1%-100%;
(approximately30mmHg to 250mmHg/4.0kPa to 33.3kPa)
Speed: 30to80cyclesperminute(cpm)
