OWNERS MANUAL
Elevate™Shower Bases
A8014T RHO / A8014T LHO/ A8016T-CO
A8017 T- CO / A8015T-CO
INSTALLATION INSTRUCTIONS
Thank you for selecting American Standard – the benchmark of fine quality for over 150 years. To ensure this
product is installed properly, please read these instructions carefully before you begin. Certain installations may
require professional help.
INSTALLATION PREPARATION
• Please unpack carefully and identify all parts needed for installation by using the Box Contents as a reference.
Inspect the product and report any damages or missing parts immediately to customer care by calling 800-
442-1902. Follow the prompts for consumer/bathing.
NOTE: Take extra care in handling edges and surfaces of bases. Use only non-abrasive cloths to
avoid scratching.
• The Elevate Base dimensions are nominal and meant for a standard alcove. Please measure your alcove to
determine if the Elevate Base will work in your alcove prior to installation.
• Ensure adequate wall support is provided to area where base is to be installed.
• Wear protective equipment during installation to avoid injury.
• Please keep these instructions for after care and customer service details.
BOX CONTENTS
A8014T RHO/LHO 60 X 30 A8017T-CO.011 38 X 38 Corner
A8016T-CO.011 36 X 36 Corner A8015T-CO 48 X 30 Alcove
60 X 30 RHO/LHO A8014T 10 Clips
36 X 36 Corner A8016T-CO 6 Clips
38 X 38 Neo Angle A8017T-CO 6 Clips
48 X 30 Alcove A8015T-CO 8 Clips
Trench/Drain Plate

BEFORE YOU BEGIN
Inspect your product thoroughly before installing. Take extra care in handling surfaces
of the base and use only non-abrasive cloths to avoid scratching. Observe all local plumbing
and building codes.
RECOMMENDED TOOLS AND MATERIALS
Level Tape Measure Square
Pipe Wrench
Standard Woodworking Tools
MATERIALS
Exterior Rated Screws
Silicone Sealant
Drop Cloth
OPTIONAL: Mortar Mix or Grout
Caulking Gun
Pencil
Slip Joint Pliers Personal Safety
Equipment
Screwdriver
A B C
E
I
F
F
G H
D
1234567891 01 1
1234567891 0 11 12 13 14 15 16 17 18 19 20 21 22 23 24
INSTALLATION INSTRUCTIONS
IMPORTANT GENERAL INFORMATION
This unit is best installed by two people.
Cover drain with tape prior to installation to prevent the loss of small parts.
Unpack your unit carefully and inspect for freight damage. Lay out and identify all parts using Box
Contents as a reference. Before discarding the carton check to see that no small hardware parts have
fallen to the bottom of the box. If any parts are damaged or missing refer to the description noted in the
instructions when inquiring about replacements.
When installing coordinating bath walls, additional studs may be required.
Refer to those installation instructions prior to installing base.
Take extra care when driving nails or screws to avoid damaging the base.

1
2
INSTALLATION AND FRAMING INSTRUCTIONS
INSTALLATION OF DRAIN ASSEMBLY
1a. Ensure that the floor and stud walls are square and plumb on a level floor as shown in Figure A.
Provide a 7" x 7" (178 x 178 mm) opening in the floor for the drain and refer to the product rough-in
on the specification page for actual drain location.
2a. All of the shower bases require purchasing a round drain for use with a standard 2” (51 mm) plastic
schedule 40 waste pipe. Figure B shows the typical drain assembly. Before installing drain into the
shower base, remove strainer. (Ref. Figure B) This will be installed after shower base is in its final position.
Cut the waste pipe height so that the drain body will fit snug in the shower base. Apply silicone sealant
between the drain body and shower base.
NOTE: Drain not included and must be purchased separately.
The alcove opening dimensions should be at least 1/8"(3mm) larger than dimensions shown on
spec page for the model being installed.
For the best t, the opening measurements should be veried against the actual
shower base received.
FIGURE A
90° 90°
2" (51 mm)
PVC Waste Pipe
Opening 6" x 6"
(152 x152 mm)
C/L
(See Product Rough-In on specification page for Drain Location)
DRAIN ASSEMBLY
Strainer
Drain
Body
Shower
Base
Silicone
Sealant
Rubber
Gasket Fiber
Gasket
Locking
Nut
Rubber
Caulking
Gasket
FIGURE B

FIGURE D
Clip Locations
3
4
BASE INSTALLATION
INSTALLATION OF BASE CLIPS
3a. Place base into position and check for level in several directions. (Figure C)
NOTE: If base is not level, shim or level sub floor using optional mortar.
NOTE: Rectangle base shown.
4a. Once base is in place and level in several directions, attach supplied plastic clips evenly around
the perimeter of alcove studs to the base flange and screw clip into stud. (Fig. D)
NOTE: Reference “Box Contents” by model to determine how many clips are required.
FIGURE C
Level base in two directions.
Level
Level
TUB
FLANGE
STUD
FIGURE D
