American Standard AquaWash 8033A65G.020 User manual

8033A65G.020
AquaWash®Slim Bidet Seat
Installation and User Manual
8033A65G.020
Warranty information included
Thank you for purchasing the BIDET. Please read through
the manual carefully for appropriate use of the product.
After you read through the manual, keep it at a proper place
for further reference.
1 Names of Parts --------------------------------
2 Installation -------------------------------------- 3-5
1-2
Pre-installation
Installation Procedures
Connecting water hose
3 Operation ---------------------------------------- 6
4 Care and Cleaning ---------------------------- 7
5 Product maintenance ------------------------ 8
6 Self Diagnosis and Specifications ------ 9
Self Diagnosis and Trouble Shooting
Specifications
Warranty
760416-100EN Rev. 1 6/22
Product names listed herein are trademarks of AS America Inc.
© AS America, Inc. 2022

Seat
Lever
Front Cleansing
Nozzle
Back Cleansing
Nozzle
Seat cover
Quick release button
Water supply hose
T-shaped
Adapter
Water inlet hose
1
Bidet Water Supply Connection
760416-100EN Rev. 1 6/22
Names of parts
Product

1. Bidet Seat
2. Mounting Kit
3. T-shaped adapter 4. Water inlet hose 5. Installation and User Manual
2
nuts(2)
Sliding plates(2)
Bolts(2)
Seat Mounting Plate
760416-100EN Rev. 1 6/22
Components

1. Insert the bolts in sliding plates
Please make sure you read the instructions carefully and install it properly.
Pre-installation
1. The water pressure limit is from 0.07 to 0.6 MPa(10-87PSI). Please use as instructed.
2. The water shut-off valve should be near to where the product can be installed and dismantled.
2. Press the release button and remove
the seat mounting plate.
3. Insert bolts with sliding plates into the Seat Mounting Plate.
3
760416-100EN Rev. 1 6/22
Cautions
Product Installation Procedures
Installation

4
1. Install the nuts into the holes in the toilet bowl.
3.
Screw the bolts into the nuts. Do not fully tighten.
5. Adjust the bidet seat evenly over the toilet bowl. 6. Press the quick release button to release
the seat.
4. After mounting the mounting plate, slide the bidet
seat fully into position until it clicks into place.
2. Place the Mounting plate with bolts and sliding
plates onto the toilet bowl. Align the bolts and
sliding plate with the seat post hole.
760416-100EN Rev. 1 6/22
Installation Procedure

5
7. Fully tighten the bolts once the bidet seat is in
correct position.
8. Reinstall the bidet seat until it fully clicks into
position.
1. Close the water supply shut off valve to shut
off water into the tank. Remove as much water
from the tank as is possible so it doesn't spill
out when removing the supply line hose and
remove the hose to the tank. Connect the
T-Shaped adapter to the inlet valve of the tank.
2. Reconnect water supply hose to T-Adapter
and fully tighten.
1. Do not lift the product with seat cover and seat open.
2. Cannot use with hot water where temperature is higher
than 104˚F. This may cause operational issues.
Water supply hose from Shut
Off valve to toilets tank.
T-Shaped Adaptor
Water Shut
Off Valve
Prohibited
760416-100EN Rev. 1 6/22
Installation Procedure
Connecting water hose

6
4 separate positions 20º upwards or 20º downwards:
for nozzle self-cleaning.
0º - OFF45˚upwards - Back Cleansing
45˚downwards - Front Cleansing
760416-100EN Rev. 1 6/22
Operation

7
1. Cleaning Seat and Lid.
2. Clean the nozzle.
4. To release the whole Bidet Seat.3. Seat & Cover release.
Press the button, pull the seat forward.Open the seat and cover to 90˚and lift
the seat & cover upwards to release.
After cleaning, insert the seat & cover
into the holes perpendicularly to install
the seat.
Use a smooth sponge/cloth with a mild cleanser
to clean the product. Do not use the following:
hydrogen chloride detergent, paint thinner,
benzene, abrasive paper, polishing agent,
fragrances and insecticide, etc.
Pull out the nozzle softly and use smooth
cloth/sponge or toothbrush with a mild
cleanser to clean the nozzle.
Care and Cleaning
Paint thinner
Insecticide
Abrasive paper
760416-100EN Rev. 1 6/22

8
2. Nozzle tip replacement1. Lever replacement.
As per figure A, remove the old lever along
the axis direction.
Aa per figure B, insert the new lever rib into
the corresponding control valve slot. The
installation is completed with a “click” sound.
3. Water hose leakage
As per figure A, pull out the nozzle and
remove the nozzle tip along the axis
direction as per figure B, insert the
new nozzle tip into the nozzle along the
corresponding slot.
If water leakage is detected from the water
hose, re-tighten the hose connection.
Nozzle Tip
760416-100EN Rev. 1 6/22
Product maintenance

1. Please recheck the user's manual.
2. If failure or damage occurs after refering the manual,stop using the product and contact the
retailer or local service center.
9
8033A65G.020Model No.
Backflow Prevention
Water Supply
Water Pressure Range
Dimensions
Weight
0.4 - 1.8 L/min
0.4 - 1.8 L/min
Backflow Prevention
Direct from water pipes
490X405X63mm
2.1 KG
Static pressure: 0.14-0.86MPa, Dynamic pressure:above 0.07Mpa
Water flow to pressure is too
low during Cleansing/Bidet
Water dripping into the
bowl when using the unit
No water comes out
during Cleansing/Bidet 3. Nozzle tip is stuck
2. Filter net of T-shaped connector is stuck
1. Water shut-off valve is turned off
2.Low water pressure of water supply
1.Low water pressure of the unit
Take off and clean the nozzle tip
External water pressure is too high
1. Adjust the water pressure volume by the lever.
Turn on the water shut-off valve
Clean the filter net of T-shaped connector
The maximum water pressure of the unit is 0.8MPa.
Increase external water pressure.
4. External water pressure is low
2. Assure the nozzle tips are clean.
1.Check if the water pressure is above 10 psi.
2. Fully open the shut-off valve
3. Check if there are any kinks on the water supply hose.
Do not disassemble, repair or modify the unit.
Back Cleansing water flow volume
Front Cleansing water flow volume
760416-100EN Rev. 1 6/22
Self Diagnosis and Specifications
Self Diagnosis and Trouble shooting
Specifications
Description
SolutionCauseStatus
Classification
Caution
To request service:
