Andatech PRODIGY User manual

USER MANUAL
Andatech®
PRODIGY

INTRODUCTION
Thank you for purchasing an Andatech®ProdigyS.
The Andatech®ProdigySis a state-of-the-art instrument used
to detect ethyl alcohol from a valid breath sample.
It uses an electrochemical fuel cell to measure the
concentration of alcohol in the breath sample expelled from a
human subject. If alcohol is present, a corresponding voltage is
generated from the fuel cell, which is proportional to the alcohol
content of the sample provided by the human subject. This
voltage is then sent to the CPU and converted to the subject’s
BAC (blood alcohol concentration) which is then displayed.
PREPARATION
Gently pull down the battery compartment cover to remove it.
Insert fresh alkaline batteries (4 x AA), checking that the + and
- on each battery are aligned according to the polarity diagram
inside.
Carefully replace the battery compartment cover.
CONTENTS
DEVICE FEATURES
OPERATING INSTRUCTIONS
TEST RECORDS
SETTINGS
CONDITIONS FOR TESTING
PRINTER
TROUBLESHOOTING
DISCLAIMERS
WARRANTY DETAILS
PRODUCT REGISTRATION
.............................................3
..............................4
...................................................8
.............................................................9
.............................11
.............................................................12
........................................15
....................................................16
........................................17
...............................19

3
DEVICE FEATURES
Passive Test
Specic Test
Settings
Records
8
DIAGRAM EXPLANATION
Disposable mouthpiece
Button to remove mouthpiece
Touch screen display
On/Off button
External power connectors
Stylus pen
Function button

4
OPERATING INSTRUCTIONS
ATTACHING A MOUTHPIECE
• Tear the perforated section from the wrapper of a new
mouthpiece.
• Pull back the wrapper to expose half the mouthpiece.
• Ensuring the two small holes in the bottom of the mouthpiece
are aligned with the sensor, insert the notched end of the
mouthpiece into the slot on the right of the screen (refer to
Image 1).
• Lower the other end of the mouthpiece until it snaps into place
(refer to image 2).
• Remove remainder of wrapper from mouthpiece and discard.
• To discard the mouthpiece after a test, slide the remove
mouthpiece button upwards (refer to image 3). This will eject
the mouthpiece from the unit.
• Use a new mouthpiece for each test.
ATTACHING A SAMPLING CUP
• Tear the perforated section from the wrapper of a new
sampling cup.
• Pull back the wrapper to expose the bottom half of the
sampling cup.
• Ensuring the two small holes in the bottom of the sampling
cup are aligned with the sensor, insert the notched end of the
sampling cup into the slot on the right of the screen.
• Lower the other end of the sampling cup until it locks into
place.
• Remove remainder of wrapper from sampling cup and
discard.
• To discard the sampling cup, pull it out in the direction of the
arrow shown on the sampling cup.

5
PASSIVE TEST
Refer to "Conditions for Testing" on page 11 before conducting
a test.
Attach a sampling cup to the sample port and select the
"PASSIVE" button.
When the screen displays “Please Blow”, take a deep breath and
blow towards the sampling cup until the BEEP tone stops.
“Alcohol Detected” or “No Alcohol” displays on the screen.
Select "NEXT" to start another test.
If the screen shows “Alcohol Detected”, use a mouthpiece to
perform a standard test so that an accurate BAC reading can be
obtained.
NOTE: A “passive test” is only used for screening; it checks
for the presence of alcohol in a breath sample. An accurate
test result can only be obtained via a “specic test” using a
mouthpiece.
NOTE: Test records of passive tests cannot be printed or stored.

6
SPECIFIC TEST WITH INPUT
Refer to "Conditions for Testing" on page 11 before
conducting a test.
Use the stylus pen to input information.
Note: 16 characters maximum for each
input.
Select "NEXT" or "BACK" to move to the
next or previous eld.
If no data elds are selected, the unit will
proceed directly to test mode.
(See page 10 to enable/disable data
elds.)
When the screen displays “Please
Blow”, take a deep breath and blow
into the mouthpiece with a slow and
steady breath. Blow until the progress
bar reaches 100%, then stop blowing.
A click will be heard indicating a sample
has been taken.
Attach a mouthpiece to the sample
port and select "SPECIFIC".
The breathalyser will take a clean air
sample to ensure the mouthpiece and
sensor are clear of alcohol from any
previous tests.
If no alcohol is detected, the unit
will proceed to test mode (skip to
image ).
If alcohol is detected, verify that a
clean mouthpiece is being used and
select "RETEST".
1
2
3
4
3

7
The test result will display.
Select "NEXT" to start another test.
If the subject does not blow into the unit
within 30 seconds, the operator can
either select “Refuse” to conrm the
subject refused to take the test, or “Test
Again” to allow the subject to retry.
If the subject stops blowing too early
or blows with insufcient force, select
"Discontinue" to abandon the test, or
"Test Again" to retry .
5
6
7

8
Up to 10,000 test records can be stored, depending on the
length of the records.
Once the memory is full, new records will overwrite existing
records beginning with the oldest.
Use "NEXT" or "BACK" to move to the next or previous record.
It is recommended to upload device records using "Andalink"
software on a regular basis to prevent loss of records.
After uploading records, device memory can be cleared.
In order to download your data to a PC you must have the
Andalink for Prodigy software, available from
www.andatech.com.au
TEST RECORDS

9
DATE & TIME
Set correct Date and Time.
Select “UPDATE” to conrm.
SETTINGS
Settings menu for standard ProdigyS.
For devices with a bluetooth printer,
refer to page 14 for additional settings.
SETTINGS
STATISTICS
The number of tests includes both
passive and specic tests. This count
will not reset if records are deleted
before calibration.

10
Unselect all tick boxes to disable data
collection during a test.
FIELD
Use the tick boxes on the left to select
which data will be collected for each
"specic" test. Clicking a eld name
allows editing of the eld name.
AUTO OFF
Select time limit to turn off the device
automatically. Select "NEXT" to conrm.

11
MEASUREMENTS & CONDITIONS FOR TEST
• Use a clean mouthpiece for each test.
• The optimum temperature range for operating the unit
is -10°C to 50°C. Use within this temperature range will
limit condensation from the subject’s breath and ensure
an accurate reading is taken.
• Do not allow samples containing smoke, tobacco or
other chemical products to enter the unit, as damage to
the fuel cell can occur.
• It is recommended that the operator observes
the subject for approximately 20 minutes before
administering the breath test. This is to ensure the
subject does not consume anything. Following this
procedure will ensure the subject’s saliva is clear of
alcohol so that it does not alter the outcome of the
breath sample test.
• There must be an interval of at least 15 minutes after
alcohol consumption as alcohol residue in the mouth
may give a false reading. Such residue may also be left
by aromatic drinks, mouthwash, medicines and drops,
as well as by belching and vomiting. Mouth rinsing with
water or non-alcoholic drinks does not substitute for an
interval.
Working temperature range of Andatech® ProdigyS:-10°C to 50°C
Storage temperature range of Andatech® ProdigyS:-15°C to 65°C
LIABILITY FOR PROPER FUNCTION OR DAMAGE
The liability for proper functioning of the instrument is
irrevocably transferred to the owner or operator in the
event the instrument is serviced or repaired by personnel
not employed or authorised by Andatech. In such an event,
the warranty will be void.
CONDITIONS FOR TESTING
• A person’s blood alcohol concentration (BAC) can
continue to rise for up to 2 hours after drinking alcohol.
If a caution results or a result is close to the designated
BAC, it is recommended to wait and retest after 20
minutes.
• It can take 10 hours or more for a person’s BAC to return
to zero after a high BAC has been reached. A further test
should be carried out later in the day or the following
morning.

12
PRINTER
Ensure that the serial number on the printer matches the serial
number on the breathalyser.
Press and hold the ON/OFF button on the printer for 2 seconds to
switch on the printer. The indication light will turn green.
VERIFY CONNECTION
When the printer is successfully connected to the ProdigyS, the
indication light on the printer will show a steady green and a
bluetooth icon will appear on the ProdigyShomescreen.
To turn off the printer, press and hold the ON/OFF button on the
printer for 3 seconds.
Release
lever
On/Off
button /
Indication
light
Connection
Icon

13
FIELDS
Fields selected under Field Settings (refer to page 10) will be
printed on the receipt. Data entered during the test will print on
the receipt.
BATTERY LIFE
High Capacity Lithium rechargeable batteries can print around
30m of paper.
BATTERY CHARGER
Use only the supplied charger to charge the printer battery.
Caution: Use only the Lithium battery provided.
STANDARD THERMAL PAPER SIZE
6cm x 1000cm
A wireless thermal printer can be used with the device.
INSERT / REPLACE PAPER
Pull the handle. When inserting a new roll of paper, make sure
the glossy/outer side of the paper is facing the serrated tear strip
once the door is closed.
PRINTING
Records can be printed from the Test Result screen and Test
Record screen for specic tests only.
Passive test results cannot be printed.

14
SETTINGS
In addition to the settings on page 8,
devices compatible with a bluetooth printer
will display PRINT and BLUETOOTH
settings.
PRINT
a Set the number of copies to
automatically print after each test if
"Auto Print" is enabled.
b Select this box to automatically print
all test results.

15
TROUBLESHOOTING
'CALIBRATION NEEDED' WARNING
When the unit starts up and shows the "Calibration Needed"
warning and alarm, it means the unit has passed its calibration
due date. The unit can continue to be used by touching the
screen, however it is strongly recommended that it be sent to
us for calibration.
BATTERY LIFE TOO SHORT
Use only alkaline batteries, and if using rechargeable batteries,
use either NiMH or rechargeable alkaline batteries.
TOUCH SCREEN NOT RESPONDING
If the touchscreen is not sensitive enough, calibrate the screen
by pressing and holding the On/Off button (right button)
immediately followed by the Function button (left button). Then
follow the on-screen instructions.
CLEAN AIR TEST CONTINUES TO DETECT
ALCOHOL
Let the device sit for 5 minutes to clear out any possible
residue. If the problem persists, contact Andatech.
BLUETOOTH
Check the bluetooth printer status. If the printer is switched
on and connected, the State will display "Working". If the
State displays "None", ensure the printer is on and press
"MATCH" .
Note: It may take several seconds for the connection to
complete.

16
THINGS TO REMEMBER
• Always wait a minimum of 15 minutes after your last
drink before testing.
• NEVER take a sip of alcohol and blow immediately
into the device.
• Ignoring these two points WILL cause damage to the
unit that is NOT covered by warranty.
DISCLAIMERS
This product must be used strictly in accordance with the
instructions in this manual.
This product is intended to provide the user with an indication
of alcohol on the breath. However, neither the manufacturer
nor the supplier gives any warranty (express or implied) that
the product can give any indication of blood alcohol level.
A person's BAC (Blood Alcohol Concentration) can only be
accurately measured by the administration of a blood test.
This product only measures breath alcohol content which, in
turn, only gives an approximate indication of blood alcohol
concentration.
In these circumstances the user of this product should not
rely on the information provided thereby as an accurate
indication of their blood alcohol concentration or of their level
of intoxication or of their tness to drive and in particular
should not take any action in reliance on such information as
the product can provide no more than an indication of alcohol
on the breath.
If the user of this product makes any decision or takes any
action based on the use of the product such decision or such
action shall be at the sole risk of the user and neither the
manufacturer nor the supplier assumes any responsibility for
such decision or action.
In particular, neither the manufacturer nor the supplier shall
be in any way liable if the user of the product asserts that the
product led them to believe they were t to operate a motor
vehicle and are subsequently found not to be so t.
If the subject fails to give a valid breath sample, the operator
can either select “Discontinue” to conrm; or can select “Test
Again” to allow the subject to re-test. A passive test can be
performed by selecting “Passive” whilst the user is blowing.
Slide up the button underneath the mouthpiece to remove the
mouthpiece.

17
Proof of Purchase
This warranty is valid for the original purchase and is not
transferable. Please keep your purchase docket or receipt as proof
of purchase and as proof of date on which the purchase was made.
The purchase docket (or a copy) or receipt must be presented with
the warranty when making a claim under this warranty.
Service during the Warranty Period
To claim for warranty, contact us on 1300 800 200 or
[email protected] to get an RA# (Return Authorisation
Number). Ensure that the RA# is clearly stated on the outside of
the packaging and that the product is properly packaged so that
no damage occurs to the product during transit. Shipping of the
product back to us for warranty will be at your cost. A product
return without the RA# or proof of purchase will not be accepted.
Extent of Warranty
This warranty is limited to defects in workmanship or parts. All
defective products or parts will be repaired or replaced. This
warranty does not cover manuals and packaging.
WARRANTY DETAILS
It is our aim to provide you with quality products that you
can trust. Our products come with guarantees that cannot
be excluded under the Australian Consumer Law. You are
entitled to a replacement or a refund for a major failure and
for compensation for any other reasonably foreseeable loss
or damage.
You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and
the failure does not amount to a major failure.
The Guarantee
The product is guaranteed to be free from defects in
workmanship and parts for a period of 1 year from the date
of purchase. Defects that occur within this warranty period,
under normal use and care, will be repaired, replaced or
refunded at our discretion, solely at our option with no
charge for parts and labour. The benets conferred by
this warranty are in addition to all rights and remedies in
respect of the product that the consumer has under the
Trade Practices Act and similar state laws.

18
Normal Wear and Tear
This warranty does not cover normal wear and tear to
the product or parts.
Exclusions
This warranty does not cover:
• Calibration costs.
• Any defect caused by an accident, misuse, abuse,
improper operation, lack of reasonable care,
unauthorised modication, loss of parts, tampering
or attempted repair by a person not authorised by
the distributor.
• Any product that has been damaged by a lightning
strike either directly or indirectly or a main power
surge or liquid ingress.
• The product if it is located outside of Australia.
• Any damage caused by improper power input or
improper cable connection.

WARRANTY
The manufacturer warrants for 1 year from the date
of purchase, the product to be free from defects in
workmanship or material (excluding recalibration) under
normal use. The manufacturer’s obligation under this
warranty is limited to replacing, adjusting or repairing
the unit if returned along with proof of purchase. This
warranty is void if the unit has been tampered with,
damaged or abused in any way.
To register your warranty online, go to
my.andatech.com.au
RECALIBRATION AND SERVICE
Andatech recommends the Andatech®ProdigySbe
calibrated every 6 months (unlimited tests) to maintain
Australian Standards.
For recalibration and technical support, please go to
my.andatech.com.au or contact:
Andatech
Hotline: [phone] (Within Australia)
[phone] (International)
Website: www.andatech.com.au
PRODUCT REGISTRATION
Visit my.andatech.com.au to register your warranty online and
receive calibration reminders. Alternatively, complete this form
and forward to the address below with a copy of your proof of
purchase:
Andatech, PO BOX 3038, Nunawading VIC 3131 Australia.
Product Andatech® ProdigyS
Date of purchase
Place of purchase
Surname
Given name
Address
Suburb
Postcode State
Contact no.
Email

Andatech
PO Box 3038
Nunawading VIC 3131
1300 800 200
www.andatech.com.au
Version 4. Updated 28.04.2016.
Calibration Centre
