Andatech Sentry User manual

USER’S MANUAL
Baton Breathalyser
ANDATECH

3
Thank you for purchasing the Andatech Sentry baton breathalyser.
We hope you enjoy owning your Andatech Sentry breathalyser. If you
have any questions regarding the unit or want to speak with us further,
please visit andatech.com.au or call 1300 800 200 (between 9am and
5:30pm Monday to Friday).
Table of Contents
Components 4
Contents 4
Operating Instructions 5
Troubleshooting / Warning Display 6
Menu 8
Specifications 13
Safety Information 14
Disclaimers 15
Measurements & Conditions for Test 16
Warranty Details 17
Recalibration and Service 19
Andatech Guarantee 20

4
Components
Contents
1 x Andatech Sentry
1 x Blow cap
3 x Blow caps (additional)
1 x Micro USB cable
1. Blow cap
2. LED Lighting
3. Magnet installed (Rear side)
4. Micro USB port
5. Lighting / Up button
6. White FND display
7. Power / Confirmation / Passive test
button
8. Setting / Down button
9. Battery cover & handle
10.Slotted screw
1 x Handstrap
1 x User manual
6 x AA batteries
1 x Hard case
16
7
8
9
10
2
3
4
5

5
Operating Instructions
1. Press the power button . The screen will light up
2. The device will then indicate the battery level as High , Medium or
Low
3. The device will then proceed to warm up
4. The device is ready to take a test when it shows “go”
5. Get the subject to blow into the device blow cap from a distance of 2 to 3 cm
away from the sampling hole.
6. The test result will be displayed in two modes:
• Passive mode: Results will be displayed as Zero , Low or High
• Normal mode: Results will be displayed in 2 decimal format from 0.00 to
0.10 %BAC
(equivalent to 0.50mg/L or 0.10%BAC or 100mg/100mL)
*Results higher than 0.10% BAC will be displayed as “HI” without the
3-digit result display.
Note: In normal mode testing, results may be affected by sampling distance,
angle, flow rate, and strength.
Press and hold the power button from switched off mode, to see the last test “L”
result e.g.
When switched on, press and hold power button to switch off the unit. It will show
OUT.
Manual mode testing
This mode can be used if the subject is unable to breathe out hard enough, or to
check the alcohol content of a drink. To use this mode:
1. Place the unit sampling hole as close as possible to the subject’s mouth or
the drink’s contents without touching.
2. Press the power button once when the unit is in “go” status .
3. Results will be displayed as Zero , Low or High

6
LED Light Options
1. Press and hold the left button to enter the LED light options. Continue
pressing to change the light colour.
2. Hold down the left button to revert to the default white LED light option.
Troubleshooting / Warning Display
Escape to “go” (ready to blow) mode from the setting menu.
Shortcut key: hold the buttons together
The unit is running out of batteries. Replace with new batteries now
(Replace all batteries at the same time. Do not mix old and new
batteries)
Appears when the surrounding temperature is below -5*C when it is too
low to operate the device.
Appears when the surrounding temperature is above 50*C when it is too
high to operate the device.
Number of DAYS before calibration is required. For example, d.30
means 30 days left before calibration is required.
Number of test COUNTS before calibration is required.
For example, t.99 means 990 test counts before calibration is required.
This warning will only appear before the warming up status when the
device is switched on.
Number of DAYS that the calibration grace period has been activated.
The CA.d and specific number of DAYS left until calibration lock will be
displayed alternatingly.
Device must be calibrated before this number counts down to zero.
Number of test COUNTS that the calibration grace period has been
activated.
The CA.t and specific number of test COUNTS left until calibration lock
will be displayed alternatingly.
(001 = 10 COUNTS left)
Device must be calibrated before this number counts down to zero.

7
Device is in calibration lock status and cannot be used.
Contact technical service provider to get the unit calibrated.
Battery level indication
This indication will only appear before the warming up status when the
device is switched on.
Low battery level indication while device is in ready to blow status.
The batteries need to be replaced immediately.
* Low battery level indication could be displayed under WHITE LED
status as the power consumption of the WHITE LED is much higher than
that of other LED colours.
Device is under calibration grace period (DAYS or COUNTS)
Device needs to be calibrated before it enters calibration lock status.
Flow error: The breath sample was not strong enough.
Get the subject to blow strong and steady during sampling.
USB cable is connected to the device.
PC software is connected to device.
Err1 error: Pressure sensor is damaged. Contact your technical service
provider.
Err2 error: Alcohol sensor is damaged. Contact your technical service
provider.
Err3 error: Timer or timer battery is damaged. Contact your technical
service provider.
Err5 error: Memory damaged. Contact your technical service provider.
Err8 or Err9 error: Alcohol sensor damaged. Contact your technical
service provider.
Device is ready to switch off. Press power button once to switch off the
device.
Device is switching off.

8
Menu
The Menu mode can be accessed to change the device settings. To enter Menu
mode (Some devices may have the menu disabled at the request of the owner):
When the device is in “go” status, press and hold the down button until
the screen shows .
Use the up and down buttons to scroll through the Menu Options.
Press the power button to enter any Menu setting option.
Press the up and down buttons to scroll through the setting options
available, then press the power button to select and save. After saving, the
device will return to the main menu options.
Continue scrolling, or press and hold the buttons to return to warm up
and testing mode .
Menu Options
0. Last Result Check
1. Count of Test Numbers
*The dot on the display indicates a thousand.

9
2. Display Mode Setting
3. LED Light Setting
4. Automatic Switch Off Setting

10
5. Test Result Display Time Setting
6. Calibration Reminder Setting
Note: If device has passed the calibration DAYS or COUNTS, the grace period will
be activated, and the “remaining DAYS or COUNTS” to the calibration lock will be
displayed whenever the device is turned on.
If the device has passed the grace period of the calibration DAYS or COUNTS,
the device will be locked and cannot be operated on anymore. Contact your local
authorised agent to get it calibrated.
LED Operation Chart

11
Replacing Batteries
1. Loosen the slotted screw by turning it anticlockwise using a coin or
appropriate tools. Remove the Battery cover.
2. Replace the old batteries with six new 1.5V Alkaline Batteries (LR06,
AA) or rechargeable batteries. Please make sure that the batteries are
inserted in the correct direction (follow the batteries diagram on the
rear label).

12
3. Put the battery cover back into position, with the arrow facing
upwards. Align the protrusion with the slow on the device and tighten
the slotted screw by turning it clockwise using a coin or appropriate
tools.
Battery Safety Information
• Do not disassemble the batteries!
• Only replace with batteries of the same type. Never use different types of
batteries together or combine used batteries with new ones.
• Replace all the batteries at the same time. Do not continue re-using the old
batteries.
• Keep batteries out of children’s reach.
• Do not use manganese batteries.
• Do not attempt to recharge Alkaline batteries as this may cause an
explosion.
• Do not insert the battery into the opposite electrode (refer to the diagram on
the rear side label whenever replacing batteries).
• Please remove all the batteries if not using the device for a long time.
• If batteries show any sign of leakage, please remove them immediately and
avoid contact with eyes or skin. If battery liquid comes in contact with any of
these body parts, rinse the affected region with a sufficient amount of clean
water and seek medical attention immediately.

13
Specifications
Sensor Type SuracellTM sensor (Fuel Cell sensor)
Battery AA Size Alkaline Battery
Or Rechargeable Battery 6EA
Weight 370g (Including batteries)
Size (mm) 276(Height) x 44.5(Width) x 44.5(Thickness)
Test
result
LED Alert Zero : Green / Low : Red / High : Blinking Red
FND display 0.00/Lo/Hi or Numerical result
(Display “HI” in Numerical result mode means more
than 0.10% BAC)
Buzzer alarm Zero : 1 Beep sound
Low : Repeating short Beep sound
High : long Beep sound
Warming up time Within 10 seconds
Time for analysis Within 2 seconds (at 0.00 BAC)
Maximum test 12 times / 1 minute
Working temperature -5°C ~ 50°C
Storage -10°C ~ 60°C
Mouthpiece Blow cap (Replaceable & washable passive cone type)
Auto power OFF Adjustable 30 to 900 seconds
Duration time for
display
Adjustable 1 to 9 seconds
Calibration period Every 5,000 tests or 12 months whichever comes first
(Factory Default) *Changeable by request
Additional Function Built-in Magnet
Calibration reminder & Grace period
Calibration protection by Web-server connecting
Manual LED lighting: White, Red blinking, Red, Red &
blue

14
Safety Information
• Always use genuine Andatech parts and accessories. Using non-genuine parts and
accessories for the device will not only risk providing inaccurate results, but may also
damage the device.
• Calibrate and service the device hardware and software only with authorised Andatech
service centres to avoid damage and voiding your product warranty.
• Wait at least 20 minutes after eating or drinking before testing. Alcohol remaining in the
mouth, or even excess saliva, may interfere with testing. This includes alcohol-based
mouthwash or similar products, which include any alcohol ingredient.
• Avoid testing in high wind or enclosed spaces. Poor ventilation may also lengthen the
time required for warm up between tests.
• Do not blow smoke, saliva or other contaminants into the sampling hole, as the sensor
may become damaged.
• Hold the device directly to the subject for accurate results. Other positions may not give
you accurate results.
• Handle the device with care. Poor handling, physical impact, or electrical shock can
cause premature device failures.
• Do not store the device in environments with extreme temperatures, direct sunlight, dirt
and dust.
• Store the device beyond children’s reach.
• Any service in regard to the device should be performed by authorized service partners
only.

15
Disclaimers
•Thisproductmustbeusedstrictlyinaccordancewiththeinstructionsinthis
manual.
•Thisproductisintendedtoprovidetheuserwithanindicationofalcoholonthe
breath. However, neither the manufacturer nor the supplier gives any warranty
(express or implied) that the product can give any indication of blood alcohol level.
•Aperson’sBAC(BloodAlcoholConcentration)canonlybeaccuratelymeasured
by the administration of a blood test. This product only measures breath alcohol
content which, in turn, only gives an approximate indication of blood alcohol
concentration.
•Inthesecircumstancestheuserofthisproductshouldnotrelyontheinformation
provided thereby as an accurate indication of their blood alcohol concentration or
of their level of intoxication or of their fitness to drive and in particular should not
take any action in reliance on such information as the product can provide no more
than an indication of alcohol on the breath.
•Iftheuserofthisproductmakesanydecisionortakesanyactionbasedontheuse
of the product such decision or such action shall be at the sole risk of the user and
neither the manufacturer nor the supplier assumes any responsibility for such
decision or action.
•Inparticular,neitherthemanufacturernorthesuppliershallbeinanywayliableif
the user of the product asserts that the product led them to believe they were fit to
operate a motor vehicle and are subsequently found not to be so fit.

16
Measurements & Conditions for Test
•Useacleanmouthpieceforeachtest.
•Donotallowsamplescontainingsmoke,tobaccoorotherchemical
products to enter the unit, as damage to the fuel cell can occur.
•Theremustbeanintervalofatleast15minutesafteralcohol
consumption as alcohol residue in the mouth may give a false reading.
Such residue may also be left by aromatic drinks, mouthwash,
medicines and drops, as well as by belching and vomiting. Rinsing your
mouth with water or non-alcoholic drinks does not substitute for an
interval.
•Aperson’sbloodalcoholconcentration(BAC)cancontinuetoriseforup
to 2 hours after drinking alcohol. If a caution results or a result is close
to the designated BAC, it is recommended to wait and retest after 20
minutes.
•Itcantake10hoursormoreforaperson’sBACtoreturntozeroaftera
high BAC has been reached. A further test should be carried out later in
the day or the following morning.
LIABILITY FOR PROPER FUNCTION OR DAMAGE
The liability for proper functioning of the instrument is
irrevocably transferred to the owner or operator in the event the
instrument is serviced or repaired by personnel not employed
or authorised by Andatech. In such an event, the warranty will
be void.

17
Warranty Details
It is our aim to provide you with quality products that you
can trust. Our products come with guarantees that cannot
be excluded under the Australian Consumer Law. You are
entitled to a replacement or a refund for a major failure and
for compensation for any other reasonably foreseeable loss
or damage.
You are also entitled to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major failure.
The Guarantee
The product is guaranteed to be free from defects in workmanship and parts for a
period of 1 year from the date of purchase. Defects that occur within this warranty
period, under normal use and care, will be repaired, replaced or refunded at our
discretion, solely at our option with no charge for parts and labour. The benefits
conferred by this warranty are in addition to all rights and remedies in respect of the
product that the consumer has under the Trade Practices Act and similar state laws.
Proof of Purchase
This warranty is valid for the original purchase and is not transferable. Please
keep your purchase docket or receipt as proof of purchase and as proof of date on
which the purchase was made. The purchase docket (or a copy) or receipt must be
presented with the warranty when making a claim under this warranty.
Service during the Warranty Period
To claim for warranty, contact us on 1300 800 200 or send and email to
[email protected] to get an RA# (Return Authorisation Number). Ensure
that the RA# is clearly stated on the outside of the packaging and that the product is
properly packaged so that no damage occurs to the product during transit. Shipping
of the product back to us for warranty will be at your cost. A product return without
the RA# or proof of purchase will not be accepted.
Extent of Warranty
This warranty is limited to defects in workmanship or parts. All defective products
or parts will be repaired or replaced. This warranty does not cover manuals and
packaging.
Normal Wear and Tear
This warranty does not cover normal wear and tear to the product or parts.

18
Exclusions
This warranty does not cover:
•Calibrationcosts.
•Anydefectcausedbyanaccident,misuse,abuse,improperoperation,lackof
reasonable care, unauthorised modification, loss of parts, tampering or attempted
repair by a person not authorised by the distributor.
•Anyproductthathasbeendamagedbyalightningstrikeeitherdirectlyor
indirectly or a main power surge or liquid ingress.
•TheproductifitislocatedoutsideofAustralia.
•Anydamagecausedbyimproperpowerinputorimpropercableconnection.

19
WARRANTY
The manufacturer warrants for 1 year from the date
of purchase, the product to be free from defects in
workmanship or material (excluding recalibration) under
normal use. The manufacturer’s obligation under this
warranty is limited to replacing, adjusting or repairing
the unit if returned along with proof of purchase. This
warranty is void if the unit has been tampered with,
damaged or abused in any way.
Visit my.andatech.com.au to register your warranty
online and receive calibration reminders.
CALIBRATION AND SERVICE
Andatech recommends the Andatech® Sentry to be
calibrated every 5000 tests or 12 months, whichever
comes first.
To register your product and book in a calibration, please
go to my.andatech.com.au or contact:
Andatech Pty Ltd
Hotline: [phone]
Website: www.andatech.com.au

20
Andatech Guarantee
We take pride in the quality and integrity of our breathalysers,
and it’s important to us that you get the most out of using our
products.
With this commitment in mind, we will extend the warranty of
your Andatech Breathalyser for up to 5 years from the original
purchase date as long as you keep it calibrated every 6 months
from the date of purchase.
Go to andatech.com.au/alcosense-guarantee for more information and for terms
and conditions.
Set and “forget”
Save costs
Priority calibration
EASY WAY TO EXTEND YOUR WARRANTY
Sign up for a Breathalyser Management
Plan and save time and money each
year. It’s the easiest way to get your
breathalyser calibrated every 6 months,
and saves you the hassle of booking it in
each time.
Go to andatech.com.au/breathalyser-management
or call 1300 800 200 for more information.

Andatech Pty Ltd
www.andatech.com.au
1300 800 200 V2.1. Updated 11.10.2017
