Anova RCPHEXADA User manual

1
ASSEMBLY INSTRUCTIONS
RCPHEXADA
–
Recycled Plastic ADA Picnic Table
anovafurnishings.com
888.535.5005 tel
TOOLS NEEDED:
•Ratchet with 9/16” socket
•18 volt (or higher) drill with T-25 Torx bit
•Hammer
TABLE COMPONENTS:
ASSEMBLY HARDWARE:
All hardware is stainless steel.
ASSEMBLY:
The assembly is a two-person operation.
1. Inspect the shipping container contents for damage and to determine that all components and hardware are present.
2. Assemble the table over the shipping packaging or padded work area to avoid scratching the product.
(4) Gussets
(3) Table Legs
(3) Cross Braces
(9) 3/8”
Flat Washers
(9) 3/8-16 x 5”
Carriage Bolts
(20) #9 x 2 1/2”
Torx Screws
Torx Screws
(33) #9 x 3”
Hex Nuts
(9) 3/8
-16
(1
) Tabletop with Frame
(1)
Full Seat Base
(2) Half Seat Bases
(4) Seat Legs
(2) Short Seats
(2) Long Seats

2
3. Locate the three cross braces and arrange them as shown
with the outside chamfered edge oriented downward.
Slide the three pieces together so they interlock and
screw them together using two #9 x 2 1/2” Torx screws
and one #9 x 3” Torx screw into the predrilled pilot holes
in each unit. Hold the cross braces flat to the work surface
when driving the screws to assure the assembly is flat and
snug.
Note:
Make sure the angled end of each cross brace is
oriented downward.
4. Place the tabletop upside down on the padded work area and place the cross brace assembly on the tabletop assembly. Orient the cross
brace so the arms of the cross brace match up with the arms on the tabletop frame.
Note:
Make sure the angled end of the cross brace is oriented downward.
5. Place the table legs through the cross brace
assembly slots, into the corresponding slot in the
tabletop frame. Attach the legs to the tabletop
using a 3/8” x 5” carriage bolt inserted through
the predrilled holes and into the table leg and the
tabletop frame. Place a 3/8” flat washer and 3/8”
hex nut on the end of each of the carriage bolts.
Use the hammer to set the carriage bolt and
expose the threads before adding the washers and
nut.
Note:
Leave the nut finger tight so the legs can be
adjusted in Step 5.

3
6. Raise the cross brace assembly until the mounting holes in the cross brace are aligned with the holes in the legs. Attach the cross
braces to the table legs using two 3/8” x 5” carriage bolts inserted through each leg and cross brace along with a 3/8” flat washer
and 3/8” hex nut on the end of each of the carriage bolts.
Use the hammer to set the carriage bolt and expose the threads before adding the washers and nut.
Insert two #9 x 2 1/2” Torx screws through the tabletop frame and into each leg.
7. Build the seat support units using two #9 x 3” Torx screws to attach the seat leg on each end for the full seat base and two #9 x 3” Torx
screws to attach the seat leg to one end of the half seat bases.

4
8/19/2014 Copyright 2014 ANOVA®Made in U.S.A
8. Attach a seat support unit to the bottom of each leg using two #9 x 3” Torx screws through the predrilled holes.
Note:
When attaching the half seat support units, make sure the seat leg is oriented to be nearer the full seat support unit.
9. Turn the table right side up. It is best to use at least three
people to turn the table. Be careful when turning the table
that the seat support units land flat and don’t get twisted
or rolled. Attach the seats to the seat support units. Install
#9 x 3” Torx screws in the predrilled pilot holes on the
outside of each seat and through the seat into the seat leg.
Note:
The two short seats must be attached over the full
size seat base and the two long seats attach over the two
half seat bases.
Then align the inside edges of the seats together over the
cross brace and install the inside pairs of #9 x 3” Torx
screws through each seat into the cross brace.
10. Attach the gussets using two #9 x 2 1/2” Torx screws in
each gusset as shown.
Drive the bottom screws through the gusset and into the
seat base first. When inserting the side screws into the
gusset and seat leg, be sure to hold the leg vertical.
Note:
Table is Federally ADA-compliant.
