Anova Signature L1501 User manual

anovafurnishings.com
888.535.5005 tel
TOOLS NEEDED:
• Ratchet with 1/2" socket
• 1/2" Box-end or open-end wrench
Unpacking Instructions
Signature
L1501 - Signature 5 1/2' Flat Bench
INSTRUCTIONS:
Inspect the shipping container contents for damage. The bench is packed with the seat facing down and with wooden runners
across the feet. This protects the seat and allows the boxes to be stacked while in storage or in transit.
1.
Li the bench out of the box and place it on a padded workspace.
Or, cut or tear down the packaging cardboard to allow access to
the bolts and nuts that attach the wooden runners to the feet.
2.
Use the ratchet with 1/2” socket and the wrench to remove the
5/16” bolt, washer, and nut from each foot.
3.
1
Signature 5 1/2' Flat Bench
This is a two-person operation.
2" x 4" Wood Runners
5/16" Bolts
The box is shown shorter to
show contents more clearly.
Remove the wooden runners. Turn the bench upright.
The bench is already completely assembled. Move the bench to
the desired location for use.
4.
16.50"
62.65"
4 X O.40"
L1501 - 5 1/2' Flat Bench Foot Mount

Copyright 2018 ANOVA® Made in USA. 2
Note: Please contact Customer Care at 1-866-797-1761 when ordering replacement parts.
01/31/2018
Assembly and Replacement Parts
Bench Seat
Foot
