Anova RCPSC6 User manual

anovafurnishings.com
888.535.5005 tel
TOOLS NEEDED:
• 18 Volt (or higher) drill
• T30 Torx Bit
Assembly Instructions
Recycled
RCPSC6 - Recycled Plastic 6' Traditional Bench
BENCH COMPONENTS: ASSEMBLY HARDWARE:
(8) 2" X 4" Planks (3) Bench Supports
ASSEMBLY:
Inspect the shipping container contents for damage and to determine
that all components and hardware are present.
1.
2. Lay all parts on a so work surface or on the shipping packaging to
prevent damage to nish.
3. Locate one of the 2” x 4” planks and position the plank over the
innermost sets of predrilled holes in the bench supports. Mount
the 2" X 4" plank to the bench support by driving three of the
1/4" X 3" torx washer head screws with the 18 volt drill and the
T30 torx bit into the clearance holes of the planks and the pilot
holes of the bench supports.
NOTE: When installing the screws start from one end of the
bench and nish on the opposite end.
4. Align the clearance holes in another plank with the uppermost
pair of pilot holes in the bench supports and install three 1/4" X
3" torx washer head screws.
5. Align the clearance holes in another plank with the front pair of
pilot holes in the bench supports and install three 1/4" X 3" torx
washer head screws.
1
Recycled Plastic 6' Traditional Bench
(24) 1/4" X 3" Torx Washer Head Screws
1/4" X 3" Torx
Washer Head Screw
1/4" X 3" Torx
Washer Head Screw
2" X 4" Plank
Bench Support
Install the screws
in this direction
The assembly is a two-person operation.

2
Note: Please contact Customer Care at 1-866-797-1761 when ordering replacement parts.
Copyright 2019 ANOVA® Manufactured in the U.S.10/25/2018
6. Attach the rest of the planks in the same manner, starting from the outside of the
bench supports and working inward, and from the top working down.
A A B B
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A A
B B
C C
D D
SHEET 1 OF 1
DRAWN
CHECKED
QA
MFG
APPROVED
dmetz 1/24/2018
DWG NO
TITLE
SIZE
D
SCALE
REV
0.12 : 1
9.66"
26.00"
.50"
9.66"
28.00"
.50"
FOOT MOUNT
Bench Support
2" X4" Plank
Assembly and Replacement Parts
