APG PT-510 Series User manual

APG
R
Doc #9005031
Rev A, 02/2017
PT-510 and PT-510W Series
User Manual
4-20 mA

ii Tel: [phone] • Fax: [phone] • www.apgsensors.com • [email protected]
Table of Contents
Introduction ................................................................................................................ iii
Warranty and Warranty Restrictions.................................................................... iv
Chapter 1: Specications and Options..................................................................... 1
Dimensions ........................................................................................................................................1
Specications ................................................................................................................................... 2
Model Number Congurator...................................................................................................... 3-4
Electrical Pinout Table and Supply Power Table...................................................................... 5
Chapter 2: Installation and Removal Procedures and Notes..............................5
Tools Needed..................................................................................................................................... 5
Mounting Instructions ................................................................................................................... 5
Electrical Installation ..................................................................................................................... 5
Removal Instructions ..................................................................................................................... 6
Chapter 3: Maintenance .............................................................................................6
General Care...................................................................................................................................... 6
Vent Tube Drying............................................................................................................................. 7
Repair and Returns.......................................................................................................................... 8

iii
Tel: [phone] • Fax: [phone] • www.apgsensors.com • [email protected]
Introduction
Thank you for purchasing a PT-510/PT-510W series submersible pressure transmitter from APG. We
appreciate your business! Please take a few minutes to familiarize yourself with your PT-510 and this
manual.
PT-510/PT-510W series submersible pressure transmitters oer reliability in harsh industrial conditions. The
small size, and all welded, all stainless steel body make the durable PT-510/PT-510W the perfect instrument
for static and dynamic pressure measurement. The PT-510 comes with a Delrin nose cone, suitable for clean
water use, while the PT-510W has a stainless steel cage for additional transducer protection in wastewater
environments.
Reading your label
Every APG instrument comes with a label that includes the instrument’s model number, part number, serial
number, and a wiring pinout table. Please ensure that the part number and pinout table on your label
match your order.

iv Tel: [phone] • Fax: [phone] • www.apgsensors.com • [email protected]
Warranty and Warranty Restrictions
This product is covered by APG’s waranty to be free from defects in material and workmanship under
normal use and service of the product for 24 months. For a full explanation of our Warranty, please visit
https://www.apgsensors.com/about-us/terms-conditions. Contact Technical Support to recieve a Return
Material Authorization before shipping your product back.
Scan the QR code below to read the full explanation of our Warranty on your tablet or smartphone.

1
Tel: [phone] • Fax: [phone] • www.apgsensors.com • [email protected]
Chapter 1: Specications and Options
• Dimensions
PT-510 with Removable Plastic
Nose Cone
PT-510W with Welded Cage
4.7"
[119.8mm]
3.7"
[94.2mm]
1.0"
[25.7mm]
[21.9mm]
ø 0.9"
[18.8mm]
ø 0.7"
ø 0.1"
[2.6mm]
4.8"
[121.4mm]
3.1"
[79.0mm]
1.7"
[42.4mm]
1.0"
[25.4mm]
ø 3.5"
[88.9mm]
ø 3.6"
[91.4mm]
0.4"
[9.4mm]
0.3"
[7.6mm]
ø 0.9"
[21.9mm]

2Tel: [phone] • Fax: [phone] • www.apgsensors.com • [email protected]
Performance
Pressure Ranges 0 to 20 PSIG
Analog Output 4-20mA
Over Pressure 2X FS
Burst Pressure 3X FS
Accuracy
Overall ±0.5% of Full Scale (BFSL)
Linearity ±0.25% of Full Scale (BFSL)
Hysteresis ±0.15% of Full Scale
Repeatability ±0.20% of Full Scale
Span ±1% of Full Scale
Zero ±1% of Full Scale
Environmental
Operating Temperature -4 to 185°F (-20 to 85°C)
Maximum Submersible Depth 46 ft / 14 m / 20 psig
Electrical
Supply Voltage (at sensor) 11-30 VDC
Current Draw 3-30 mA
Materials of Construction
Wetted Materials 18-8 Stainless Steel, Stycast
Cable PVC, Hytrel, or Polyurethane
Seal Neoprene Rubber
Nose Cone (PT-510 only) PVC
Cage (PT-510W only) 18-8 Stainless steel
Mechanical
Cable Tensile Strength Up to 200 pounds
• Specications

3
Tel: [phone] • Fax: [phone] • www.apgsensors.com • [email protected]
• Model Number Congurators
Part Number: PT-510 - _____ - _____ - _____ - _____
A B C D
A. Cable Type
□B Hytrel 0.31” Ø - Black (with vent tube)
□ C▲PVC - Black (with vent tube
□E Polyurethane - Black (with vent tube)
B. Pressure Range - PSI
□5
□10
□15
□20
C. Output
□L01▲ 4-20 mA, 2-wire (+ ground)
D. Cable Length
□XXX (specify length of cable needed in feet)
040▲40 foot length standard for 5 & 10 PSI
060▲60 foot length standard for 15 & 20 PSI
Note: ▲Indicates this option is standard.

4Tel: [phone] • Fax: [phone] • www.apgsensors.com • [email protected]
Part Number: PT-510W - _____ - _____ - _____ - _____
A B C D
A. Cable Type
□B Hytrel 0.31” Ø - Black (with vent tube)
□ C▲PVC - Black (with vent tube
□E Polyurethane - Black (with vent tube)
B. Pressure Range - PSI
□5
□10
□15
□20
C. Output
□L01▲ 4-20 mA, 2-wire (+ ground)
D. Cable Length
□XXX (specify length of cable needed in feet)
040▲40 foot length standard for 5 & 10 PSI
060▲60 foot length standard for 15 & 20 PSI
Note: ▲Indicates this option is standard.

5
Tel: [phone] • Fax: [phone] • www.apgsensors.com • [email protected]
Chapter 2: Installation and Removal Procedures and Notes
• Mounting Instructions
• Connect the wires of your PT-510 to your control system according to the pinout table above.
• Electrical Installation
• Electrical Pinout Table and Supply Power Table
Your PT-510/PT-510W series submersible pressure transducer is designed to be free-hanging.
• Tools necessary to make electrical connection.
• Tools Needed
PT-510/PT-510W Series Pin Out Table
Pigtail
4-20 mA
Red + Power/Signal
White - Power/Signal
Green Case Gnd
PT-510/PT-510W Series Supply Power Table
4-20 mA
Power Supply 11-30 VDC
NOTE: If your PT-510 has a vent tube, do not seal, cover, or close the vent tube with
anything other than an APG-provided venting cap or desiccant drying cartridge (See Fig-
ure 3.1 and 3.2). Unapproved seals or covers will prevent proper sensor operation.

6Tel: [phone] • Fax: [phone] • www.apgsensors.com • [email protected]
Removing your PT-510/PT-510W from service must be done with care. It’s easy to damage your sensor if you
are not careful to follow these guidelines:
• Retrieve the sensor from the vessel. Follow any and all procedures for safely isolating any media con-
tained inside the line or vessel.
• Carefully clean the sensor’s tting and diaphragm of any debris (see General Care) and inspect for
damage.
• Store your sensor in a dry place, at a temperature between -40° F and 180° F.
• Removal Instructions
Your PT-510/PT-510W series pressure transmitter is very low maintenance and will need little care as long as
it is installed correctly. However, in general, you should:
• Avoid applications for which the transmitter was not designed, such as extreme temperatures, contact
with incompatible corrosive chemicals, or other damaging environments.
• Avoid touching the diaphragm. Contact with the diaphragm, especially with a tool, could permanently
shift the output and ruin accuracy.
• Clean the diaphragm or the diaphragm bore only with extreme care. If using a tool is required, make
sure it does not touch the diaphragm.
Chapter 3: Maintenance
• General Care
IMPORTANT: Any contact with the diaphragm can permanently damage the sensor.
Use extreme caution.
