The RW1900-901APO is a wireless analogue addressable
manual call point. The unit has a resettable plastic element,
which displays a drop-down warning indicator when
operated. A key is supplied with the MCP for reset and case
opening. A transparent cover protects against accidental
operation is available as an accessory (not included).
REACH Wireless®
Manual Call Point
Product information
• Resettable Element
• Bi-directional wireless communication
• Dual channel redundancy
• Ten year battery life
• Five year product warranty
Product overview
Product REACH Wireless Manual Call
Point
Part No. RW1900-901APO
Digital Communication Apollo protocol compatibility is
handled via the Loop-Interface device,
RW1700-030APO.
See product for more detail.
Communication Range
between Loop-Interface and
Devices
100 m (in open space)
Field Device Radio Frequency
Channel Pairs
22 pairs
Radiated Power 14 dBm (25 mW)
Battery Type 2x VARTA CR123A Lithium 3 V,
1250mAh typical
Battery Lifespan 10 years in normal operation with
good signal strength (no dropped
messages)
Operating Temperature -10°C to +55°C
Maximum Relative Humidity
(non-condensing)
95%
IP Rating IP 30
Standards and approvals EN54-11, EN54-25
Dimensions 88 mm diameter x 87 mm height x
61 mm depth
Weight (including batteries) 160 g
Technical data
All data is supplied subject to change without notice. Specifications
are typical at 24 V, 25°C and 50% RH unless otherwise stated.
67
25
61
66
Approvals

PP5115/2022/Issue 1
Page 2 of 2
Operating Principles
The RW1900-901APO REACH Wireless Manual Call Point is a
wall-mounted device that, when activated, initiates an alarm
on the fire security system. After its use the call point unit can
be simply reset with its proper key, making it immediately
ready for reactivation.
Status LED
When one or more faults are present in the system they are
shown on the LCD and the fault LED is switched on yellow.
LCD is ON only when the tamper switch is not activated
(cover open) regardless of the configuration of the translator
tamper fault. See table 1 for LED status meanings.
Table 1: REACH Wireless Device Status & LED
Indication
Device Status LED Indication
Power Up Blinks green four times
Power Up (dip-switch ON) Blinks red four times
Entering Wake-Up Blinks alternatively green/red four
times
Link Success Blinks green four times, then
repeats
Link Failure
Enters wake-up mode and signals
‘Entering wake-up mode’ following
this failure
Normal Condition LED o
Activation Red on 1s, period 2s
Battery Faults LED o
Tamper Fault LED o
Replaced Blinks amber two times
Device Addressing
Device addressing is handled by the REACH Wireless Loop-
Interface device (RW1700-030APO.
Devices are soft-addressed automatically when pairing with
the Loop Interface and can be changed manually. Hard-
addressing using Apollo XPERT cards are not supported.
Communication
REACH Wireless Devices use ‘radio-frequency’ wireless
communication to connect to the Loop-Interface.
The Loop-Interface (RW1700-030APO) translates the wireless
communication into wired Apollo protocol communication,
with each device addressable individually by the fire panel.
See datasheets for the Loop-Interface for more information.
Tamper detection
REACH Wireless devices contain an anti-tamper mechanism.
In the event of removal from its base, it sends a tamper
detection message to the Loop-Interface.
Tampering detection is not signalled visually by the device
LED.
EMC Directive 2014/30/EU
REACH Wireless Manual Call Point complies with the
essential requirements of the EMC Directive 2014/30/EU,
provided that it is used as described in this datasheet.
A copy of the Declaration of Conformity is available from
Apollo on request.
Construction Products Regulation (EU) 305/2011
The REACH Wireless Manual Call Point complies with
the essential requirements of the Construction Products
Regulation (EU) 305/2011
A copy of the Declaration of Performance is available from
Apollo on request.
