ARDES AR4P14W User manual
AR4P14W
keRámiAbetétes
A készüléket 8 év feletti gyermekek, valamint testi, mentális,
-
-
-
-
leges veszélyeket megértették.
-
-
-
-
-
ISTRUZIONI PER L’USO
INSTRUCTIONS FOR USE
VENTILATORE BOX
BOX FAN
AR5B23
Il presente apparecchio può essere
utilizzato dai bambini a partire da 8 anni
in su e da persone dalle ridotte capacità
siche, sensoriali o mentali, oppure con
mancanza di esperienza e di conoscenza
se a loro è stata assicurata un’adeguata
sorveglianza, oppure se hanno ricevuto
istruzioni circa l’uso in sicurezza
dell’apparecchio e hanno compreso i
pericoli correlati.
I bambini non devono giocare con
l’apparecchio. Le operazioni di pulizia
e di manutenzione non devono essere
effettuate dai bambini senza sorveglianza.
Se il cavo di alimentazione dovesse essere
danneggiato, deve essere sostituito
solamente presso i centri di assistenza
autorizzati dal costruttore.
2
-
10
less than 8 years shall not plug in, regulate
and clean the appliance or perform user
maintenance.
CAUTION — Some parts of this product
can become very hot and cause burns.
Particular attention has to be given
where children and vulnerable people
are present.
If the power cable gets damaged, it has
to be replaced only at a service centre
approved by the manufacturer.
WARNING: In order to avoid overheating,
do not cover the heater.
Do not place the appliance immediately
below a socket outlet.
Do not use this heater in the immediate
surroundings of a bath, a shower or a
swimming pool.
DO NOT COVER
-
alá.
-
-
-
-
-
3
-
-
-
- Ne érintsük a készüléket nedves, vizes kézzel.
-
-
-
-
-
-
-
4
2
5
4
2
A B C DEF
G
1
3
H I M N
6
7
A
EF
DC
B
L
kerültek feltüntetésre.
5
-
-
-
-
-
-
-
-
-
-
5
6
Szim-
Érték Egység Egység
nom 2,2
N.A.
min 1,1
N.A.
Maximális
folyamatos
max,2,2
-
N.A.
fogyasztás N.A.
kimenet elmax N.A.
kimenet elmin N.A.
Készenléti
elSB
vezérlés
Van
Helyiség
Helyiség
Van
7
-
-
lékelve van.
-
-
-
-
-
-
10
Condizioni
La garanzia ha validità 24 mesi dalla data d’acquisto.
La presente garanzia è valida solo se viene correttamente compilata ed accompagnata
dallo scontrino scale che ne prova la data di acquisto.
L’apparecchio deve essere consegnato esclusivamente presso un nostro Centro
Assistenza autorizzato.
Per garanzia si intende la sostituzione o la riparazione dei componenti dell’apparecchio
che risultano difettosi all’origine per vizi di fabbricazione.
Viene comunque garantita l’assistenza (a pagamento) anche a prodotti fuori garanzia.
Il consumatore è titolare dei diritti applicabili dalla legislazione nazionale disciplinante la
vendita dei beni di consumo; questa garanzia lascia inpregiudicati tali diritti.
La Casa costruttrice declina ogni responsabilità per eventuali danni a persone, animali
o cose, conseguenti ad uso improprio dell’apparecchio e alla mancata osservanza delle
prescrizioni indicate nell’apposito libretto istruzioni.
Limitazioni
Ogni diritto di garanzia e ogni nostra responsabilità decadono se l’apparecchio è stato:
- Manomesso da parte di personale non autorizzato.
-Impiegato, conservato o trasportato in modo improprio.
Sono comunque escluse dalla garanzia le perdite di prestazioni estetiche o tali da non
compromettere la sostanza delle funzioni.
Se nonostante la cura nella selezione dei materiali e l’impegno nella realizzazione del
prodotto che Lei ha appena acquistato si dovessero riscontrare dei difetti, o qualora
avesse bisogno di informazioni, Vi consigliamo di telefonare al rivenditore di zona.
GARANZIA
INFORMAZIONE AGLI UTENTI
ai sensi dell’art. 26 del Decreto Legislativo 2 Aprile 2014, n. 49 “Attuazione
della Direttiva RAEE 2012/19/EU , relativa alla riduzione dell’uso di sostanze
pericolose nelle apparecchiature elettriche ed elettroniche, nonché allo
smaltimento dei riuti”.
Il simbolo del cassonetto barrato riportato sull’apparecchiatura o sulla sua
confezione indica che il prodotto alla ne della propria vita utile deve essere
raccolto separatamente dagli altri riuti.
L’utente dovrà, pertanto, conferire l’apparecchiatura giunta a ne vita agli idonei
centri di raccolta differenziata dei riuti elettronici ed elettrotecnici, oppure
riconsegnarla al rivenditore al momento dell’acquisto di una nuova apparecchiatura
di tipo equivalente, in ragione di uno a uno.
L’adeguata raccolta differenziata per l’avvio successivo dell’apparecchiatura
dismessa al riciclaggio, al trattamento e allo smaltimento ambientalmente
compatibile contribuisce ad evitare possibili effetti negativi sull’ambiente e
sulla salute e favorisce il reimpiego e/o riciclo dei materiali di cui è composta
l’apparecchiatura.
Lo smaltimento abusivo del prodotto da parte dell’utente comporta l’applicazione
delle sanzioni amministrative previste dalla normativa vigente.
-
-
-
-
-
-
-
-
AR4P14W
ISTRUZIONI PER L’USO
INSTRUCTIONS FOR USE
TERMOVENTILATORE CERAMICO
CERAMIC HEATER
IT Il presente prodotto è adatto solo a ambienti correttamente
isolati o ad un uso occasionale.
GB This product is only suitable for well insulated spaces or
occasional use.
2
5
4
2
A B C DEF
G
1
3
H I M N
6
7
A
EF
DC
B
L
10
This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning use of
the appliance in a safe way and understand
the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not
be made by children without supervision.
Children of less than 3 years should be
kept away unless continuously supervised.
Children aged from 3 years and less than 8
years shall only switch on/off the appliance
provided that it has been placed or installed
in its intended normal operating position
and they have been given supervision or
instruction concerning use of the appliance
in a safe way and understand the hazards
involved. Children aged from 3 years and
GB
11
less than 8 years shall not plug in, regulate
and clean the appliance or perform user
maintenance.
CAUTION — Some parts of this product
can become very hot and cause burns.
Particular attention has to be given
where children and vulnerable people
are present.
If the power cable gets damaged, it has
to be replaced only at a service centre
approved by the manufacturer.
WARNING: In order to avoid overheating,
do not cover the heater.
Do not place the appliance immediately
below a socket outlet.
Do not use this heater in the immediate
surroundings of a bath, a shower or a
swimming pool.
DO NOT COVER
12
Warnings GB
ATTENTION : read this booklet carefully it contains important
instructions for a safe installation, use and maintenance.
Important instructions to be kept for future reference.
Keep handy the guarantee, receipt of payment and these instructions for
future use and reference.
After removing the packaging, check the appliance for any signs of
damage.
In case of visible damage, do not use it and contact a qualied technician.
Do not leave parts of the packaging with in the reach of children.This
appliance is not a children’s toy: it is an electrical device and must be
treated with the necessary caution.
Before connecting the appliance, make sure that the power supply
voltage matches the indication on the data plate.
If the plug and socket are not compatible, the socket has to be replaced
with a suitable type by skilled persons.
Do not use adapters or extension cables which do not meet current
safety standards or that exceed the current carrying capacity limits.
When you don’t use the appliance disconnect it from the power supply
and assure that the interruptor is off.
Do not tug on the power cable or on the appliance itself to remove the
plug from the socket.
The use of any electrical appliance requires that a number of basic
rulesare observed, namely:
- Never touch the appliance with wet or humid hands.
- Do not leave the appliance exposed to weathering (rain, sunlight).
- Do not subject it to rough handling.
In case of a breakdown or malfunctioning of the appliance, disconnect
it at once.
Do not attempt to repair it, but take it to a service centre approved by the
manufacturer.
If you decide you do not want to use this appliance any longer, disable
it by cutting the power cable - of course, after disconnecting it from the
socket.
The power cable should be extended to its full lenght to avoid over
heating.
For safety reasons, the appliance should never be opened.
The appliance has been designed and manufactured to operate in the
home.
Any other use is considered inappropriate and dangerous.
Do not insert objects through the safety grill or the air inlets.
13
During use, rest the appliance on a at surface.
Do not use this heating appliance with programmers, timers, separate
remote control systems (different to the ones provided with the appliance)
or any other device that automatically turns on the appliance, as there is a
risk of re in the event the appliance is covered or positioned incorrectly.
Do not use the heater in presence of ammable substances (petrol,paints,
etc.).
Do not place the cord near sources of heat.
WARNING: DO NOT COVER THIS PRODUCT NEAR CURTAINS OR
OTHER COMBUSTIBLE MATERIAL.
WARNING: DO NOT COVER THE APPLIANCE OR OBSTRUCT THE
AIR INLETS TO AVOID OVERHEATING.
14
GBTechnical informations
1 - Display and control panel:
A: On/stand-by pushbutton
B: Power level pushbutton
C: Oscillation pushbutton
D: Timer pushbutton
E: + pushbutton (increase)
F: - pushbutton (decrese)
G: fan light icon
H: minimum power light icon
I: maximum power light icon
L: digits (set temperature / timer)
M: timer light icon
N: oscillation light icon
2 - Air outlet
3 - Pilot lamp
4 - Handle
5 - Air inlet
6 - Main switch On/Off
7 - Remote control
Instructions for use GB
1. Plug the appliance into the mains socket.
2. Turn on the main switch (6) located in the back of the product (“I”
position). The appliance emits a “beep” and the digits (L) will show
25°C.
3. Push On/stand-by (A) to turn the appliance on; the indicator light (3)
will be on.
4. When the unit is operating, push the power level (B) to select the
desired power level: fan function only (G light icon), minimum power
level (H light icon) and maximum power level (I light icon).
5. When the unit is operating, push the oscillation (C) to activate the
automatic oscillation of the product. N light icon will be on. To deactivate
the oscillation push again oscillation (C) pushbutton.
6. When the unit is operating, push the timer (D) to set the switch
the appliance off automatically after the set time. Press this button
repeatedly to select the desired time period in 1 hour increment, from
Technical data indicated on the appliance.
15
1 hour to 8 hours. The digits (L) will show the set time before the
automatic shutdown. If the timer is set the light icon (M) will turn on
in the display.
7. To activate the automatic operation press E and F button to set the
desired ambient temperature (from 10°C to 49°C). When the ambient
temperature is close to the set ambient temperature (+/- 3°C) the
appliance disable / enable the heating.
Functions can be activated by pressing the pushbutton on the control
panel or by using remote control. The remote control is provided with
battery: before use it remove the plastic tag from the battery tray. When
the battery is exhausted it must be replaced with another of the same
type (CR2025).
GB
Maintenance
This appliance does not require any special maintenance.
Disconnect the plug from the socket and let the appliance cool down well
before cleaning it.
In order to clean the appliance, use a soft or slight damp cloth.
Never use abrasives or chemical solvents.
Do not use very wet substances, liquids or cloths to prevent water from
entering into the apparatus and irreparably damaging it.
NEVER IMMERSE THE APPLIANCE INTO THE WATER.
16
Information requirements for electric local space heaters
Model identier(s): AR4P14W
Item Symbol Value Unit Item Unit
Heat output Type of heat input, for electric storage local
space heaters only (select one)
Nominal heat
output Pnom 2,2 kW Manual heat charge control, with
integrated thermostat
N.A.
Minimum heat
output (indicative) Pmin 1,1 kW Manual heat charge control with room
and/or outdoor temperature feedback
N.A.
Maximum
continuous heat
output
Pmax,c 2,2 kW Electronic heat charge control with
room and/or outdoor temperature
feedback
N.A.
Auxiliary electricity consuption Fan assisted heat output N.A.
At nominal heat
output elmax N.A. kW Type of heat output/room temperature
control (select one)
At minimum heat
output elmin N.A. kW Single stage heat output and no room
temperature control
No
In standby mode elSB 0,002 kW Two or more manual stages, no room
temperature control
No
With mechanic thermostat room
temperature control
No
With electronic room temperature
control
Yes
Electronic room temperature control
plus day timer
No
Electronic room temperature control
plus week timer
No
Other control options (multiple selections
possible)
Room temperature control, with
presence detection
No
Room temperature control, with open
window detection
No
With distance control option No
With adaptive start control No
With working time limitation Yes
With black bulb sensor No
Contact details POLY POOL S.p.A. - via Sottocorna 21/B, 24020 Parre (BG) - Italy
19
GB
GUARANTEE
Terms and Conditions
The guarantee is valid for 24 months.
This guarantee applies only if it has been duly lled in and is submitted with the
receipt showing the date of purchase.
The guarantee covers the replacement or repair of parts making up the appliance
which were faulty at source due to manufacturing faults.
After the guarantee has expired, the appliance will be repaired against payment.
The manufacturer declines any responsibility for damage to persons, animals
or property due to misuse of the appliance and failure to observe the directions
contained in the instructions.
Limits
All rights under this guarantee and any responsibility on our part will be voided if
the appliance has been:
- mishandled by unauthorized persons
- improperly used, stored or transported.
The guarantee does not cover damage to the outward appearance or any other that
does not prevent regular operation.
If any faults should be found despite the care taken in selecting the materials and
in creating the product, or if any information or advice are required, please contact
your local dealer.
USER INFORMATION
“Implementation of Directive 2012/19/EU on Waste Electrical and Electronic
Equipment (WEEE)”, pertaining to reduced use of hazardous substances in
electrical and electronic equipment, as well as to waste disposal”.
The symbol of the crossed-out wheelie bin on the equipment or on its packaging
indicates that the product must be disposed of separately from other waste at the
end of its service life.
The user must therefore take the dismissed equipment to suitable separate
collection centres for electrical and electronic waste, or return it to the dealer in
case they purchase a new device of equivalent type, at a one-to-one-ratio.
Suitable segregated collection of the equipment for subsequent recycling, treatment
or environmentally-friendly disposal helps prevent damage to the environment and
to human health, and encourages the re-use and/or recycling of the materials that
make up the equipment.
Abusive disposal of the product by the user shall result in the application of
administrative nes in accordance with the laws in force.
AR4P14W.040618
POLY POOL S.p.A. Via Sottocorna, 21/B
24020 Parre (Bergamo) - Italy
Tel. 035703244 r.a. - Fax 035702716
MADE IN CHINA
Importőr:
MULTIKOMPLEX BUDAPEST KFT.
a páraelszívók szakértője... 1995 óta
H - 1211 Budapest, Mansfeld Péter u. 27
(volt Bajáki Ferenc utca)
tel.: +(36-1) 427 0325, +(36-1) 427-0326;
fax: +(36-1)427 0327
www.multikomplex.hu
Table of contents
Languages:
Other ARDES Heater manuals
