Argos Atlas Internal Cube 339/5176 User manual

MADE IN
BRITAIN
Low Unit
Dimensions
Width - 97cm
Depth - 59cm
Height - 47cm
Tall Unit
Dimensions
Width - 47cm
Depth - 59cm
Height - 97cm
Atlas - Internal Cube
Assembly Instructions - Please keep for future reference
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Issue 1 - 03/12/14
Important - Please read these instructions fully before starting assembly
ALR3125
339/5176

Safety and Care Advice
Important - Please read these instructions fully before starting assembly
• Warning: This unit weighs
approximately 30kgs.
Please lift with care.
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Parts of the assembly will be
easier with 2 people.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor (use opened
out unit carton).
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Safety note: If there is any
chance of this unit being pulled
over by children etc. it is
recommended that the unit is
secured to a wall using suitable
fixings (not supplied).
• Dispose of all packaging
carefully and responsibly.
1
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
Note: If required the next page
can be cut out and used as
reference throughout the
assembly. Keep this page with
these instructions for future
reference.

Components - Panels
Please check you have all the panels listed below
2
80%
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
3Top/Base (DF1808)
(968 x 590mm) x 2
Shelf (DF1811)
(222 x 584mm) x 4
Side (DF1809)
(438 x 586mm)
Divider (DF1810)
(438 x 586mm) x 4
4
1 2
Part-drilled
holes
Through
holes

Please check you have all the fittings listed below
Tools required
3
Components - Fittings If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Note: The quantities below are the correct amount to complete the assembly. In some cases
more fittings may be supplied than are required.
Rule Scissors Hammer
Eye protection
(when using a
hammer or drill)
Cross-head
screwdriver
Ruler - Use this ruler to help correctly identify the screws
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
A B
D
C
Large locking
nut (F900) x 30
Metal dowel (F901) x 30 Wooden dowel (F22) x 20
Shelf stud (F372) x 16

C
C
Assembly Instructions
4
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Step 1
x 4
B
B
B
B
B
B
B
C
C
10mm
C
C
C
B
B
B
B
B
B
C
C
Prepare the side and
the 4 dividers
Insert 6 large locking
nuts into the side
and each of the 4
dividers .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
Tap 4 wooden dowels
into the side and
each of the 4 dividers .
Note: Wooden dowels
must not stick out from
the edge by more than
10mm or they may
damage other panels.
B1
2
C
1
2
1
2
Finished
front edge
Finished
front edge

Finished
front edge
Assembly Instructions
5
Step 2
Prepare the top and
base
Screw 15 metal dowels
into the top and base .
Note: Tighten the metal
dowels up fully against
the panels.
Step 3
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
3
3
Finished
front edge
3
Finished
front edge
Part-drilled
holes
Finished
front edge
B
A
Fit the side to the
base
Push the side onto
the base .
Use a screwdriver to
tighten the 3 large
locking nuts fitted to
the side .
Note: Turn the large
locking nuts as far as
they will go - more than
1/2 a turn.
B
B
1
1
3
1
Note: Make sure that you are not using one of the dividers.
The holes shown arrowed, should only be part-drilled.
x 2

Assembly Instructions
6
Step 4
3
Fit the 4 dividers to
the base
Push the 4 dividers
onto the base .
Use a screwdriver
to tighten the 3
large locking nuts
fitted to each of
the 4 dividers .
B
2
2
3
1
2
2
2
2
Finished
front edge
Finished
front edge
Fit the top
Push the top down
onto the assembly.
Use a screwdriver
to tighten the 3
large locking nuts
fitted to the side
and each of the 4
dividers .
B
1
2
3
1
2
2
2
2
2
Finished
front edge
Finished
front edge
Step 5
2
2
1
3

Assembly Instructions
7
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
and quote the reference numbers on the component pages.
Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW
ALR3125
Step 6
Step 7
Fit the 4 shelves
Lower the shelves
down onto the shelf
studs and tighten
their screws.
Assembly is complete
The unit can now be
placed inside your
wardrobe.
If you are standing the
unit up, the side panel
must be at the top so
there are no holes
showing.
1
2
Dx 4
Dx 4
2
2
2
2
2
1
Fit the shelf studs
Push 4 shelf studs for
each shelf into the
side and dividers ,
as shown.
Note: The screws in the
shelf studs must be
pointing upwards.
Dx 4
Dx 4
2
D
4
1 2
D
4
4
4
4
4
DFinished
front edge
Finished
front edge
