Argos Double Tidy Rail 8751698 User manual

Width - 89.5cm
Depth - 38.5cm
Height - 101/167.5cm
Assembly Instructions-Please keep for future reference
Double TidyRail
Dimensions
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
8751698

Safety and care advice
Important - Please read these instructions fully before starting assembly
Care and maintenance
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them into
their groups.
• Keep children and animals away
from the work area, small parts
could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• Assemble the unit as close to its
final position (in the same
room) as possible.
• Assemble on a soft level surface
to avoid damaging the unit or your
floor.
• Parts of the assembly will be
easier with 2 people.
• If using power tools, please
follow the safety instructions
supplied with the tools.
• We do not
recommend the use
of power drill/ drivers
for inserting screws,
as this could damage
the unit. Only use hand
screwdrivers.
• Dispose of all packaging carefully
and responsibly.
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on this
unit.
• This product should not be
discarded with household waste.
Take to your local authority waste
disposal centre.
Note: if required the next page
can be cut out and used as a
reference throughout the
assembly. Keep this page with
these instructions for future
reference.
1

Rail x 2 (89cm)
1
Bottom Support x 2
(83cm)
2
Bottom Tube x 4
(87cm)
3
Upper Tube x 4
(78cm)
4
Foot x 2
(39cm)
5
Castor x 4
6
(Inserted inside component 3)
Lock x 2(33cm)
7
Components - Parts
Please check you have all the panels listed below
2

Connector x 4
Small
hammer
A
Components - Fittings
Please check you have all the fittings listed below
Tools required
Ruler - Use this ruler to help correctly identify the screws
If you have damaged or missing components,
call the Customer Helpline: 08456 400800
3
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
05 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 115 120 125 130 135 140 145 150 155 160 165 170

22
5
5
3
5
5
3
NOTE: It would be useful to ask
someone to help you at this stage.
a: Insert Bottom Supports 2
into Feet 5 .
b: Insert Bottom Tubes 3 into
Feet
5 .
Assembly Instructions
Step 1
Fitting the Feet
4
a:
b:
2
5
3
5

1
44
6
6
5
5
NOTE: It would be useful to ask
someone to help you at this stage.
a: Insert Rail into Connectors
A.
AA
A A
b: Insert Upper Tubes 4 into
Connectors
A.
c: Insert Castors into Feet
5 .
Assembly Instructions
Step 2
Fitting the Rails
Repeat steps
a and bto
assemble the other Rail .
5
a:
b:
c:
1
4
6
5
1
A
A

If you need help or have damaged or missing parts, call the
Customer Helpline: 08456 400800
3
3
Finishing the Unit
7
7
b: Insert Upper Tubes 4 into
the Locks
7 .
Set the height of the unit using
the Upper Tubes
4 . Ensuring
the Locks
7 are loosened,
slide the tubes to the desired
height and tighten the Locks to
fix in position.
Adjustment Range: 101-167.5cm.
a: Insert Locks 7 onto the Top
of Bottom Tubes
3 . Align the
Screw on Lock
7 into the hole
on Bottom Tube
3 .
Assembly Instructions
Step 3
c: With help, place the unit in
the intended position.
The assembly is now complete.
NOTE: It would be useful to ask
someone to help you at this stage.
6
a:
b:
c:
4
3
4
7
7
7
3
7
