Argos Mia 8573429 User manual

Mia 6 Drawer Chest - White
Dimensions
Length - 149.4cm
Depth - 40cm
Height - 73cm
Weight - 43kg
Issue 1 - 22/06/18
Important – Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
0045 7668 8055 or e-mail: order@flexa.dk
Assembly Instructions - Please keep for future reference 8573429

1
Safety and Care Advice
Important – Please read these instructions
fully before starting assembly
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• During assembly children
should be kept away from the
product due to possible risk of
injury.
• Make sure you have enough
space to layout the parts before
starting.
•This product is suitable for
children in the age range 3 to
adult
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close
to its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor.
• Parts of the assembly will be
easier with 2 people.
• Do not use this item if any
components are missing or
damaged
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could
damage the unit. Only use hand
screwdrivers.
• Dispose of all packaging
carefully and responsibly.
• Assembly to be carried out by
a competent adult only.
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• Regularly check all fastenings
to ensure that they properly
tightened.
• This product should not be
discarded with household waste.
Take to your local authority
waste disposal centre.
• This product is suitable for
children in the age 4-12 years.
Maximum load on chest 30 kg.
Maximum load in each drawer
7 kg.
Care and maintenance

Drawer side Right x6
(35x16.7x1.3cm)
8Drawer side Left x6
(35x16.7x1.3cm)
9
Components - Parts
Please check you have all the parts listed below
2
Side panel Right x1
(65.4x36.1x1.2cm)
2Side panel Left x1
(65.4x36.1x1.2cm)
3
No. 4301-1206541-40 No. 4301-1206542-40
Plinth Short x2
(68.3x6.5x1.5cm)
6
Plinth Curved x1
(138.2x6.5x1.5cm)
5
No. 12-01506831No. 12-01513821-40
No. 15-01303503 No. 15-01303504
Top x1
(149.4x40.0x1.6cm)
1
No. 4301-1614941-40
List Long x1
(138.2x2.5x1.5cm)
7
No. 12-01513822-40
Drawer front x6
(68.8x18.9x1.6cm)
10 Drawer back x6
(64.2x16.7x1.3cm)
11 Drawer base x6
(65.4x34.8x0.3cm)
12
No. 4301-1606887-40 No. 15-01306421 No. 4309-0306541
If you have damaged or missing components,
call the Customer Helpline: 0045 7668 8055
Leg x4
(71.4x4.0x2.6cm)
4
No. 12-02607141-20
Partition x1
(71.4x36.1x1.6cm)
13 Back panel x1
(140.6x62.8/31.4x0.3cm)
14
No. 4301-1607142-40 No. 4309-0314061

Please check you have all the fittings listed below
Ø7x34mm Minifix bolt x33
A
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
Ø15x9.5mm Minifix cam x35
B
E
4.0x30mm Chipboard screw x16
C
D
Components - Fittings
F
1.6x16mm Nail square x48Ø18/Ø6,5x9.0mm Spacer x18
No. 4022-004
310x27x10mm Drawer slide x12
G H
Ø8x30mm Dowel x34
No. 3930-08030
J
L
O
3.5x35mm Chipboard screw x30
i
Ø9.5/M4x9mm Machine screw x12
Overbalance protector x2
Ø5/M4x15mm Sleeve connector x1
No. 3901-35035 No. 3912-04009
No. 41-00179
No. 3924-04015
K
M
P
N
Q
3.5x12mm Chipboard screw x2
Ø4.2x9.5mm Euro screw x8
21x21x16mm Angle x1
Ø5.8x19mm Euro screw x30
Ø7x34mm Minifix bolt x2
No. 3901-35012
No. 3907-42010
No. 4008-037
No. 3907-58019
No. 4020-006
Tools required
Phillips
screwdriver
(medium)
Flatblade
screwdriver
(medium)
Small
hammer
Ruler/tape
measure
Eye protection
(when using a
hammer or glue)
44x23x23 Angle x2
No. 3940-00009
No. 4008-112
3
No. 3903-40030
No. 4010-027
No. 3933-15010
No. 4020-007

A
A
A
A
A
A
A
Assembly Instructions
Step 1
Insert the dowels Hinto
the holes in short plinths
6.
It may be necessary
to tap the dowels in
very gently with a small
hammer.
Attach minifix bolts Ato
top panel 1.
Attach the side panels
2and 3to the legs 4
using screws C.
Make sure the top of
the side panel is flush
with the legs and there
are no gaps between
the side panel and the
edge of the groove in
the legs.
Step 2
1
6
6
2
2
3
4
4
4
4
4
H
H
H
H
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
A
UP
UP
42
H
4
C

2
13
3
A A
N
N
N
N
N
N
N
N
NN
N
N
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
H
H
H
H
H H
E
E
EN
NN
NN
D D
D D
D D
D
DD
D
D
D
D
Front edge Front edge
Front edge
Left side Right side
ForwardForward
3rd hole
5th hole
Front edge
Front edge
Assembly Instructions
Step 3
Insert the dowels Hto
the holes in the side
panels 2and 3.
Attach minifix bolts Ato
the side panels 2and
3.
Attach the drawer
runners Dto the side
panels 2and 3with
euro screws N. Start
from the third hole from
the front of the metal
runner Dand align the
rest as instructed on the
pictures.
Note that the runners
need to be attached
with spacers Eplaced
between the side panel
and runner.
Be aware of the front
edge!
Insert the dowels Hinto
the holes in the partition
13 .
Attach drawer runners D
to the partition 13 with
euro screws N. Start
from the fifth hole from
the front of the metal
runner Dand align the
rest as instructed on the
pictures.
Be aware of the front
edge! Note that the
screws must be
inserted from different
holes in the runners!
Step 4
AHE
N
N
5

2
13
13
13
3
N
N
N
N
N
Q
OQ
N
N
N
D
D
D
D
D
Front edge
3rd hole
Front edge
N
Assembly Instructions
Step 5
Attach second set of
drawer runners Dto
the partition 13 with
euro screws N. Start
from the third hole from
the front of the metal
runner Dand align the
rest as instructed on the
pictures.
Be aware of the front
edge! Note that the
drawer screws must be
inserted from different
holes in the runners!
Insert sleeve connector
Ointo the hole inside
partition 13 .
Attach minifix bolts Qto
the sleeve connector O
inside partition 13 .
Attach short plinths 6to
the side panels 2and
3and partition 13 with
minifix cams B.
Step 7
Step 6
B
B
B
B
B
6
6
6
O
Q

B
Assembly Instructions
Step 8
Attach the top 1to the
side panels 2and 3
and partition 13 with the
minifix cams B.
Attach angles Gto the
long plinth 5using
screws M.
Attach plinth 5to side
panels 2and 3using
screws M.
Step 9
B
B
BB
B
B
1
3
3
2
2
7
M
M
M
G
G
G
M
5
5
5
M
13
G

7
i
i
i
K
KP
i
i
i
i
Assembly Instructions
Step 10
Fasten the list 7to the
top panel using screws
i, placing the screws
into the marking holes in
top 1.
Attach long plinth 5
to the partition 13 with
angle Pusing screws
K. Follow the marking
holes.
Don’t overtighten.
Attach the back panel 14
with nails Fto the back
side of the chest.
Nail the back panel 14
to the carcass, ensuring
that there are NO GAPS
between the top 1and
the back panel 16 .
Follow the
measurements.
Step 11
28 mm
28 mm 28 mm
28 mm
1
F
F
14
8
5
5
13
13
KP

Assembly Instructions
Measure out the
positions for the wall
attachment straps.
Drill two holes spaced
as illustrated with the
appropriate size for the
wall attachment fitting
(see next step).
Pull the two straps
through the gaps in
top plate 1.Push the
furniture against the wall
and secure the strap
under the top plate with
washer and screw.
Different types of wall
fittings. Contact your
local DIY or hardware
store for the wall plugs
and screws.
Step 12b
Concrete/Brick wall
Plaster wall
Wooden wall
Step 12a
9
L
L
L
69 cm
60,5 cm
L
1

10
8
9
AA
A
A
H
A
H
Assembly Instructions
Insert the dowels Hinto
the holes in the drawer
sides 8and 9.
Attach the minifix bolts A
to the drawer front 10 .
Repeat for all drawer
sides and drawer
fronts.
Attach the drawer sides
8and 9to the drawer
front 10 with the minifix
cams B.
Repeat for all drawers.
Push the drawer base 12
carefully into the drawer.
Attach the drawer back
11 to the drawer sides
8and 9with the
screws i.
Repeat for all drawers.
Step 13
Step 14a
Step 14b
B
B
B
10
8
9
B
10
i
i
i
i
10
12
11
8
9
i

Assembly Instructions
Place the assembled
drawer between the
drawer runners D.
Attach the drawer sides
8and 9to the runners
using the screws J.
Repeat for all drawers.
Assembly is complete.
Step 15
If you need help or have damaged or missing parts, call the Customer Helpline: 0045 7668 8055
E-mail: order@flexa.dk
Ref.no. 44-01803-20 A Stand: 220618 Page 12 (81-31308-20)
