Argos Malibu 621/3310 User manual

MADE IN
BRITAIN
Dimensions
Width - 89.5cm
Depth - 89.5cm
Height - 72cm
Malibu - Corner Desk
Assembly Instructions - Please keep for future reference
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Issue 2 - 18/03/13
Important - Please read these instructions fully before starting assembly
617/3223
617/3900
617/3230
ALR2686
621/3310
621/3327
Issue 2 - 18/03/13 - Argos code added for Oak - 617/3900

Safety and Care Advice
Important - Please read these instructions fully before starting assembly
• Warning: This unit weighs
approximately 19kgs.
Please lift with care.
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Parts of the assembly will be
easier with 2 people.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor (use opened
out unit carton).
1
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
Note: If required the next page
can be cut out and used as
reference throughout the
assembly. Keep this page with
these instructions for future
reference.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Safety note: It is
recommended that this unit is
secured to a wall using the
bracket supplied.
• Dispose of all packaging
carefully and responsibly.

Components - Panels
Please check you have all the panels listed below
2
80%
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Top (D0872A)
(895 x 895mm)
1
2 3
Left Side (D0873A)
(706 x 244mm) x 2
Right Side (D0874A)
(706 x 244mm) x 2
Plinth (D0875A)
(445 x 80mm) x 2
4
5Shelf (D0876A)
(445 x 240mm) x 4

Please check you have all the fittings listed below
Tools required
3
Components - Fittings If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Note: The quantities below are the correct amount to complete the assembly. In some cases
more fittings may be supplied than are required.
A
Wooden dowel (F22) x 4
B
Metal dowel (F901) x 8
C
D E
Ruler - Use this ruler to help correctly identify the screws
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
40mm Screw (F910) x 20
Large locking
nut (F900) x 8
Bracket (F327) x 1
F
13mm Screw (F79) x 1
Rule Scissors Hammer
Eye protection
(when using a
hammer or drill)
Cross-head
screwdriver
Electric drill
(only use when
drilling into walls)

D
D
D
D
Assembly Instructions If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Step 1
4
Prepare the 2 left
sides
Insert 2 large locking
nuts into each of the
left sides .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
C
Step 2
x 2
x 2
x 2
C
CC
2
2
C
C
3
Prepare the 2 right
sides
Insert 2 large locking
nuts into each of the
right sides .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
Step 3
Join the left side and
shelves
Position 2 shelves
against each of the left
sides as shown and
secure with 4 screws .
C
3
Finished
front edge
Finished
front edge
Finished
front edge
Finished
front edge
2
5
2
D
plain
chipboard
surface
plain
chipboard
surface
5
5

D
A
Assembly Instructions
5
Step 4
Step 5
A
4
Prepare the plinths
Tap 2 wooden dowels
into each plinth .
Note: Wooden dowels
must not stick out from
the edge by more than
10mm or they may
damage other panels.
A
4x 2
x 2
x 2
Fit the plinths
Push a plinth onto
each left side as
shown and secure with
screw .
Step 6
Fit the right sides
Push a right side
onto each assembly as
shown and secure with 5
screws .
4
2
D
D
D
D
D
D
3
Finished
front edge
3
D
4
2
Plain chipboard
surface
Plain chipboard
surface

Assembly Instructions
6
Step 7
Prepare the top
Screw 8 metal dowels
into the top .
Note: Tighten metal
dowels up fully against
the panels.
B
B
B
B
B
B
B
B
B
1
B
1
2 3
3
Step 8
Fit the top
Push the 2 shelf
assemblies down onto
the top .
Use a screwdriver to
tighten the 8 large
locking nuts fitted to
the inside of the side
panels and .
Note: Turn the large
locking nuts as far as
they will go - more than
1/2 a turn.
Carefully turn the desk
the correct way up
1
1
C
2 3
C
B
C
2
Warning: The
unit is heavy.
Lift with care.

Assembly Instructions
7
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
and quote the reference numbers on the component pages.
Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW
ALR2686
Step 9
Fit the bracket
To prevent possible
overbalancing, we
recommend that this unit
is secured to a suitable
wall by use of the
bracket fitted
underneath the top .
Fixings are not supplied,
as they will need to suit
the wall type and the
length of screw will
depend on the distance
from the back edge of
the unit to the wall.
Place the desk in its final
position.
Fix the bracket
underneath the top
of the unit, flush to the
back edge that is against
the wall, using screw .
Note: Take care when
drilling the wall that you
do not drill into any
pipes, wires etc.
If in doubt, consult an
expert.
Assembly is complete
This shows the bracket being fitted to
the back edge on the left side of the top.
You may fit it in a different position to suit
your requirements.
Warning: The
unit is heavy.
Lift with care.
F
1
F
E
1
1
1
FE
D
Secure unit to a wall
To prevent possible
overbalancing we
recommend that this unit
is secured to a suitable
wall by use of the metal
bracket fitted under
the top of the unit.
Fixings are not supplied
as they will need to suit
the wall type, and the
length of screw will
depend on the distance
of the back of the unit to
the wall.
Warning: Take
care when
drilling the wall that you
do not drill into any
pipes, wires etc. If in
doubt, consult an expert.
1
WALL
WALL
Top of unit
F
