ARRI cforce mini RF User manual

cforce mini RF
Software Update Package 1.2
USER MANUAL
14th December 2018
cforce mini RF
Software Update Package 1.2
USER MANUAL
14th December 2018

2 Imprint
Imprint
Copyright
Copyright © 2018 ARRI Cine + Video Geräte Gesellschaft m.b.H. (ARRI).
All rights reserved. No portions of this document may be reproduced without
prior written consent of ARRI Cine + Video Geräte Gesellschaft m.b.H.
Specifications are subject to change without notice. Errors, ommissions, and
modifications excepted.
ARRI, ALEXA, LDS and LENS DATA SYSTEM are trademarks or registered
trademarks of Arnold & Richter Cine Technik GmbH & Co. Betriebs KG. All
other brands or products are trademarks or registered trademarks of their
respective holders and should be treated as such.
Original version.
This product was manufactured by ARRI Cine + Video Geräte Ges.m.b.H for
Arnold & Richter Cine Technik GmbH & Co. Betriebs KG.
For further assistance
ARRI Cine + Video Geräte Gesellschaft m.b.H.
Pottendorferstraße 23-25/3/2/1
1120 Vienna, Austria
E-mail: [email protected]
www.arri.com
Scope
This USER MANUAL applies to the following product:
K2.0016802 cforce mini RF with Software Update Package 1.2

Imprint 3
Document revision history
Version ID Order # Release Date
1.0 10002881 K5.0016851 F06617 03.05.2018
1.1 10002881 K5.0016851 W01412 25.09.2018
2.0 10002881 K5.0016851 W01453 14.12.2018

4
Disclaimer
Before using the products described in this manual, be sure to read and
understand all the respective instructions.
The ARRI Software Update Package 1.2 cforce mini RF is/are only available
to commercial customers. By utilization, the customer agrees that the cforce
mini RF or other components of the system are deployed for commercial use
only. Otherwise the customer must contact ARRI before utilization.
While ARRI endeavors to enhance the quality, reliability and safety of their
products, customers agree and acknowledge that the possibility of defects
thereof cannot be eliminated entirely. To minimize the risk of damage to
property or injury (including death) to persons arising from defects in the
products, customers must incorporate sufficient safety measures in their work
with the system and heed the stated canonic use.
ARRI or its subsidiaries do not assume any responsibility for losses incurred
due to improper handling or configuration of the cforce mini RF or other
system components.
ARRI assumes no responsibility for any errors that may appear in this
document. The information is subject to change without notice.
For product specification changes after this manual was published, refer to
the latest published ARRI data sheets or release notes, etc., for the most up-
to-date specifications. Not all products and/or types are available in every
country. Please check with an ARRI sales representative for availability and
additional information.
Neither ARRI nor its subsidiaries assume any liability for infringement of
patents, copyrights or other intellectual property rights of third parties by or
arising from the use of ARRI products or any other liability arising from the
use of such products. No license, express, implied or otherwise, is granted
under any patents, copyrights or other intellectual property right of ARRI or
others.
ARRI or its subsidiaries expressly exclude any liability, warranty, demand or
other obligation for any claim, representation, cause, action, or whatsoever,
express or implied, whether in contract or not, including negligence, or
incorporated in terms and conditions, whether by statue, law or otherwise.
In no event shall ARRI or its subsidiaries be liable for or have a remedy
for recovery of any special, direct, indirect, incidental, or consequential
damages, including, but not limited to lost profits, lost savings, lost revenues

5
or economic loss of any kind or for any claim by a third party, downtime,
good-will, damage to or replacement of equipment or property, any cost or
recovery of any material or goods associated with the assembly or use of our
products, or any other damages or injury of the persons and so on or under
any other legal theory.
In the event that one or all of the foregoing clauses are not allowed by
applicable law, the fullest extent permissible clauses by applicable law are
validated.

6 Contents
Contents
1 For your safety...................................................................7
2 Audience and intended use.............................................. 9
3 Scope of delivery and warranty..................................... 10
4 Introduction...................................................................... 11
4.1 LBUS..................................................................... 12
5 Motor layout..................................................................... 13
5.1 Control panel......................................................... 13
5.2 Setup..................................................................... 14
5.3 Status LEDs.......................................................... 18
6 Motor preparation............................................................ 19
7 Compatibility.....................................................................22
7.1 Sample configurations...........................................22
8 Software update............................................................... 25
9 Power disconnection....................................................... 26
10 Appendix........................................................................... 27
10.1 Antenna connector................................................ 27
10.2 Specifications........................................................ 27
10.3 Dimensions and weight......................................... 30
10.4 Pinouts...................................................................31
10.5 Part numbers.........................................................32
10.6 Service contacts.................................................... 36
10.7 International declarations...................................... 37
10.7.1 Certifications.......................................... 39

For your safety 7
1 For your safety
Before use, please ensure that all users comprehensively read, understand,
and follow the instructions in this document.
Risk levels and alert symbols
Safety warnings, safety alert symbols, and signal words in these instructions
indicate different risk levels:
DANGER!
DANGER indicates an imminent hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING!
WARNING indicates a potentially hazardous situation which, if not
avoided, may result in death or serious injury.
CAUTION!
CAUTION indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
NOTICE
NOTICE explains practices not related to physical injury. No safety alert
symbol appears with this signal word.
Note: Provides additional information to clarify or simplify a procedure.

8 For your safety
Vital precautions
DANGER!
Risk of electric shock and fire!
Short-circuits may entail lethal damage!
Before use, read and follow all valid instructions.
Use solely and exclusively as described in the instructions.
Never open. Never insert objects.
For operation, always use a power source as indicated in the instructions.
Always unplug the cable by gripping the plug, not the cable.
Never try to repair. All repair work should be done by a qualified ARRI
Service Center.
Never remove or deactivate any safety equipment (incl. warning stickers
or paintmarked screws).
Always protect from moisture, cold, heat, dirt, vibration, shock, or
aggressive substances.
DANGER!
Risk of fire!
Short-circuits and back currents to power supplies/batteries may entail
lethal damage!
Always use original ARRI/cmotion LBUS cables to external power
sources (D-Tap, XLR)! ARRI/cmotion LBUS cables to external power
sources provide a protection circuit to prevent back currents to power
supplies/batteries.

Audience and intended use 9
2 Audience and intended use
NOTICE
The product is solely and exclusively available for commercial costumers
and shall be used by skilled personnel only. Every user should be trained
according to ARRI guidelines. Use the product only for the purpose
described in this document. Always follow the valid instructions and
system requirements for all equipment involved.
The cforce mini RF is solely and exclusively for use on professional camera
setups.

10 Scope of delivery and warranty
3 Scope of delivery and warranty
NOTICE
Product and packaging contain recyclable materials. Always store, ship,
and dispose of according to local regulations. ARRI is not liable for
consequences from inadequate storage, shipment or disposal.
Delivery
On delivery, please check that the package and content are intact. Never
accept a damaged or incomplete delivery. A complete delivery includes:
cforce mini RF motor unit with antenna
cforce mini clamp console 19/15mm
cforce mini gear 0.8/40t
User manual
Original packaging
Warranty
For scope of warranty, please ask your local ARRI Service Partner. ARRI is
not liable for consequences from inadequate shipment, improper use, or third-
party products.

Introduction 11
4 Introduction
ARRI and cmotion have partnered up to develop the new intelligent cforce
mini RF motor.
The ARRI cforce mini RF is an intelligent lens motor with integrated white-
coded ARRI radio module, eliminating the need for an additional receiver unit
mounted on the camera.
The cforce mini RF can pair with up to three hand units for split focus, iris and
zoom operation and provides full lens data when used with the WCU-4 hand
unit.
The simple user interface includes two soft buttons and a display for setting
the motor axis, triggering motor calibration and selecting one of the 14 radio
channels.
Using the LBUS interface, the system can be expanded with up to two
additional cforce motors while the new CAM connector provides a versatile
interface for power supply and run/stop control for cameras including ARRI,
Red, Sony, Canon and Blackmagic.

12 Introduction
Main features
Integrated white radio module
Supports lens data with WCU-4 hand unit
Daisy-chainable via LBUS
Small and lightweight (~186g/6.56oz incl. gear and antenna)
Compatible with all hand units containing ARRI’s white-coded radio
module
4.1 LBUS
LBUS is a bus standard designed to allow multiple lens motors and control
devices to communicate with each other. Up to three cforce-type motors can
be chain-linked in a row. Each cforce motor has two identical, bi-directional
LBUS interfaces providing power and control signals to the motor.

Motor layout 13
5 Motor layout
1 Antenna
2 Gear
3 Display
4 Upper soft button
5 Lower soft button
6 CAM connector
7 LBUS connector
5.1 Control panel
The cforce mini RF features a user interface to configure the system. The
display shows menu and status information.

14 Motor layout
Soft buttons
Two soft buttons are located below the display. They change their behavior
depending on the screen content.
Menu navigation
Use the soft buttons to enter the setup menus as follows:
Menu Buttons Press button...
Motor axis (FIZ) Upper button short
Motor calibration Upper button long (3 sec)
Flip screen Upper button short (in menu "System info")
Region settings Lower button 6 sec
RF channel Lower button short
System info Lower button long (3 sec)
Note: Main screen turns off after 3 seconds.
5.2 Setup
Motor assignment
Push the upper button short to assign motor to focus, iris or zoom control.
Make sure that the assignment matches the lens axis the motor is attached
to.
Motor calibration
Hold the upper button for three seconds to start the automatic calibration of
the motor.
Press the upper button momentarily to interrupt the calibration process.

Motor layout 15
System info
Hold the lower button for three seconds to view the system info. The System
info shows the current firmware version.
Region settings
RF offers radio settings for different areas (with white-radio module
EMIP400). Make sure that you select the proper area you are operating the
device in. All available region settings comply with Part 15 of the FCC rules.
Push the lower button for 6 seconds to enter the region settings menu. Push
momentarily to toggle through the regions. Select World your specific region
is not listed.
NOTICE
If the master device (camera) is also equipped with a radio module which
is able to set regions, turn off the radio module from the cforce mini RF
motor.

16 Motor layout
Region Setting Country code
Australia AU
Canada CA
China CN
Egypt EG
Europe EU
Hong Kong HK
India IN
Japan JP
New Zealand NZ
Philippines PH
Singapore SG
South Africa ZA
South Korea KR
Taiwan TW
Thailand TH
UAE (United Arab Emirates) AE
USA US
World WORLD
Radio channel
The RF menu lets you switch the radio on and off and select the radio
channel.
Press the lower button momentarily to enter the Radio menu.
Toggle through the channels until you reach the desired Radio channel.
The channel will be automatically set after three seconds.

Motor layout 17
RF (Radio) Note
OFF Radio=OFF / Mo-
tor controller = ON
0
1
2
3
4
5
6
7
8
9
10
11
12
13
Client Radio = OFF / Mo-
tor Controller = OFF
Motor behaves like a
normal cforce motor
without a radio module.

18 Motor layout
5.3 Status LEDs
The status LED of the upper button indicates the current motor status:
LED (Upper button) Status
Solid green Motor is ready and calibrated, no
warnings
Green flashing Motor is in passive mode
Green/red flashing No motor master available (idle)
Yellow flashing Motor is currently calibrating
Green/yellow flashing Motor needs to be calibrated (calibra-
tion request)
Solid yellow Motor is in calibration timeout state
Solid red Motor power supply is below 10V
The status LED of the lower button indicates the current radio status:
LED (Lower button) Status
Solid green Radio ready, client logged on
Yellow/red flashing Selected channel used by another
master device
Solid red Motor initializing / hardware fault
Red flashing Update

Motor preparation 19
6 Motor preparation
Mounting to 19 mm rods
1. Open the clamp console by turning the thumbscrew counterclockwise.
2. Remove the 19/15mm clamp insert.
3. Attach the clamp console on the rod, with the motor gear engaged to
the lens barrel.
4. Close the clamp console by turning the thumbscrew clockwise.
Mounting to 15 mm rods
1. Open the clamp console by turning the thumbscrew counterclockwise.
2. Attach the 19/15mm clamp insert (K2.0006175) on the 15 mm rod.
3. Attach the clamp console around the clamp insert on the rod, with the
motor gear at the respective lens barrel.
4. Close the clamp console by turning the thumbscrew clockwise.
Note: For high torque applications use CLM-4 Clamp insert
(K2.0002080, not included)
Mounting to Panavision rods
1. Open the clamp console by turning the thumbscrew counterclockwise.
2. Remove the 19/15mm clamp insert.

20 Motor preparation
3. Attach the CLM-4 Clamp Insert 5/8" (K2.72115.0, not included) to the
5/8" rod.
4. Attach the clamp console around the clamp insert on the rod, with the
motor gear at the respective lens barrel.
5. Close the clamp console by turning the thumbscrew clockwise.
Setting up motor
1. Press the lower button for six seconds to select the region you are in.
Repeat this step each time you change a region.
2. Use the upper button to assign the cforce motor to the focus, iris or
zoom control of the control device. Make sure that the assignment
matches the lens axis the motor is attached to.
3. Press the lower button short to select the radio channel.
4. Press the upper button for three seconds to start the automatic
calibration of the respective motor. Alternatively, activate the calibration
process through the control device.
Connecting to hand unit
1. Set the hand unit to the same radio channel as the cforce mini RF (refer
to user manual of the hand unit).
2. Set the motor side, torque and direction (refer to user manual of the
hand unit).
You are now ready to shoot.
