MB-20 MATTEBOX
Compact precision light control
and swing-away lens access.

3
ARRI |PROFESSIONAL CAMERA ACCESSORIES
ARRI QUALITY
For Digital Productions
ARRI’s Professional Camera Accessories bring legendary ARRI quality, reliability
and support to digital cameras. These rugged, location tested Mattebox and
FollowFocus Systems have features demanded by professionals around the
world. Modular construction gives you the capability to work in a wide variety
of production situations, while ergonomic design makes set up and operation
fast and smooth.
Modern digital production requires high quality film style accessories to help
capture the striking images photographed bytoday’screatives. Equally at
home on digital or film cameras, ARRI’snewMattebox and Follow Focus
Systems provide the highest quality and unprecedented flexibility. ARRI’s
worldwide support means that spare parts, service and technical information
are always available.
FF-5HD FOLLOW FOCUS
Modular Follow Focus System for
exacting focus pulls with no backlash.
ULB-3 UNIVERSAL LIGHTWEIGHT BRACKET
ARRI’s on board solution for handheld shooting and
accessory support.
QR-HD1 QUICK RELEASE BASEPLATE
Fast changes between studio and handheld set ups
with rock solid support.

4
Follow Focus FF-5HD Quick Release HD Baseplate QR-HD1

5
ARRI |PROFESSIONAL CAMERA ACCESSORIES
MB-20 Modular Compact Matte Box
The 5.65 x 5.65 Compact Mattebox easily adapts for use
with lightweight support, bridgeplate support rods, or
can be clamped on and supported by the camera lens.
The swing-away Mattebox system works with wide
angle lenses and provides two or three* independently
rotating filter stages for filter sizes up to 5.65 x 5.65.
The MB-20 system includes a unique adjustment
system to ensure precise fit. Optional top, bottom, side
flags and masks are available for optimal light control.
*Note: The addition of a third stage may limit wide-angle use.
Please contact your ARRI representative for more details.
FF-5HD Follow Focus
Essential to professional quality production, ARRI’s
FF-5HD makes pulling focus smooth and accurate.
Featuring a longer swing arm, lower gear ratio and full
selection of focus gears, the FF-5HD is the best choice
for a wide range of video lenses. It can be mounted
in handheld configuration via lightweight support rods or
in studio configuration using 15 mm or 19 mm bridgeplate
support rods.
QR-HD1 Quick Release HD Baseplate
The need to change between studio and handheld
configurations is a common production problem and the
quick release mechanism in ARRI’s QR-HD1 makes
transitions fast and easy. The bridgeplate adapts to either
ARRI Standard 19 mm or 15 mm rods. The Quick Release
Baseplate’sunique attachment mechanism provides rock-
solid camera support with a centering adjustment that
compensates for variations in camera base to optical
axis measurements.

Filter trays for the MB-20 system are
designed to be both practical and flexible.
The Combo 1 filter tray holds either a
4x5.65 filter horizontally or vertically and
also accommodates a 5 x 5 square filter.
The Combo 2 filter tray holds a 5.65 x 5.65
square filter or a 5 x 6 filter. Both filter trays
feature spring-loaded holders to make filter
handling fast and simple.
Production demands flexibility in a
constantly changing shooting environment.
The MB-20 Mattebox System can be used
in a clamp-on mode for handheld or
Steadicam shots, or mounted on a
baseplate rod system for a traditional
studio setup.
COMBO I FILTER TRAY COMBO II FILTER TRAY
CLAMP-ON MATTEBOX STUDIO MATTEBOX
6
MB-20 Modular Compact Matte Box
ARRI’s MB-20 System is the most flexible, compact
mattebox available. The system accepts virtually all
professional lenses including the Canon 4.7 x 11 and Fujinon
4.5 x 13, HD Primes, and film format prime lenses as wide
as 14 mm. The locking swing-away mechanism makes lense
access fast and easy.
The MB-20 System I uses a quick release removable
sunshade for close-up and multiple camera work; while the
MB-20 System II includes a protective cage around the
sunshade for heavy duty use in demanding production
environments. Both are compatible with the same support
brackets, filter rings and filter trays.
MB-20 System Features
Designed for film and digital cameras
Works with wide angle HD zooms
Modular construction allows all mounting options
Offers up to three independently rotating filter stages
Accommodates a wide range of filter sizes
All filterscan be individually rotated and locked off
Can be equipped with top, bottom, side flags and masks
Provides an upgrade path as wider HD lenses come
to market
Locking swing-away lens access

Byadopting a functional, modular
approach, the ARRI MB-20 accommodates
most modern lenses and standard filter
formats. Whether the script calls for a
traditional studio setup, handheld move or
Steadicam shot, the ARRI MB-20 system
adapts to each scenario without a hitch.
MB-20 SYSTEM
7
ARRI |PROFESSIONAL CAMERA ACCESSORIES
MB-20 System II 16x19 Super Wide Module
The MB-20 System II
16 x 9 Super Wide
Module is a sunshade,
carrier and filter stage
primarily intended for
use with 4 x 5.65 filters. When used in HDTV format, it is
compatible with lenses as wide as 3.9 mm. The MB-20
Super Wide Module accepts MB-20 support brackets and
filter rings, improving convenience and utilization for
multiple camera owners.
LMB-15 Lightweight Mattebox LMB-15
The ARRI LMB-15 is
the perfect choice for
those requiring a
lightweight clamp-on
matteboxsolution. The
4x5.65 horizontally
oriented filter trays
slide into heavy duty
machined guides with ease. The LMB-15 can be field
configured for two or three stage capacity. The LMB-15 is
compatible with LMB-5 filter trays, clamp adapter backs
and carbon fiber light shields. For greater flexibility, the
new130 mm back works with clamp-on rings from the
MB-20 system. The LMB-15 accepts ENG lenses as wide as
3.9 mm and has a quick release removable sunshade for
close-up applications.

There is no need to compromise when
focus is critical or complex. The ARRI
FF-5HD follow focus system brings film
style quality and precision to digital
production, giving digital cinematographers
the control necessary to get the shot the
first time, every time.
FOLLOW FOCUS FF-5HD
8
Dual System Lens Support
For long lenses without support posts, the ARRI Dual
System Lens Support attaches to 15 mm, 19 mm
or lightweight support quickly with the same snap-on
adaptersproven on ARRI’s FF-5 Follow Focus.
FF-5HD Follow Focus FF-5HD
The ARRI Follow Focus FF5-HD, a completely modular film-
style follow focus, is now available for digital productions.
Designed specifically for lenses with a smaller diameter
focus barrel, the longer swing arm ensures proper gear
position on the focus ring. A lower gear ratio allows a more
exacting focus pull on smaller diameter lenses or those with
compressed focus scales.
The FF5-HD integral snap-on mechanism locks to 15mm
lightweight support rods and can be adapted to work with
ARRI Standard 15 mm or 19 mm bridgeplate support rods.
ARRI FollowFocus drivegearscan be attached to either
side of the swing arm, allowing greater mounting flexibility.
ARRI gears are made from low friction Delrin for optimal
drive smoothness and use precise self-centering stainless
steel couplings to eliminate runout and wear.
For more options, the FF-5HD is compatible with all ARRI
FF-4 Follow Focus accessories. Right and left focus knobs
and the FF-5’s longer body allow operation from either
camera side with any lens. In addition, an extension is
available to clear the largest matteboxes. Short and long
focus whips allow the assistant to stand farther away from
the camera and a focus crank makes fast snap zooms
smooth and accurate.

DUAL SYSTEM LENS SUPPORT QUICK RELEASE BASEPLATE UNIVERSAL LIGHTWEIGHT BRACKET
9
ARRI |PROFESSIONAL CAMERA ACCESSORIES
QR-HD1 Quick Release Baseplate
The Quick Release Baseplate makes camera mounting and
dismounting immediate and solid. The dedicated baseplate
rod holder has a unique centering system, adjustable both
vertically and horizontally. The rear clamp collar post is
adjustable from 1.5 mm to 2 mm, ensuring a solid
attachment. The QR-HD1 features a mechanically locked
camera base to bridgeplate attachment which can be
adjusted for a perfect fit via a knurled knob on the rear
of the unit. This system provides a more solid attachment
than the common spring-tensioned systems.
ULB-3 Universal Lightweight Bracket
The ULB-3, specifically designed for digital cinematography,
replaces the stock v-shoe attachment common on cameras
such as the Sony F900, Panasonic Varicam and HDX 900.*
Auniversal drill pattern allows direct mounting to the
camera body and newdial support post attachments
provide additional stability and reduce flex. This unit
incorporates a right side rosette for handgrip attachment
with optional left rosette for two handle operation.
As with the QR-HD1, the ULB-3 incorporates a centering
adjustment system to compensate for variations in camera
base to optical axis measurement.
*For compatibility with other cameras please contact your
ARRI representative.

MB-20 SYSTEM I SET
FOR 15 mm LIGHTWEIGHT
SUPPORT K0.60022.0 338100
SET INCLUDES:
K2.65027.0 338200
K2.65032.0 338210
K2.65028.0 338204
K2.65026.0 338202
K2.65025.0 338212
Bellows, Light Protection and
Filter Frames must be ordered
separately
MB-20 SYSTEM II SET FOR
15 mm LIGHTWEIGHT
SUPPORT K0.60040.0 338106
SET INCLUDES:
K2.47738.0 338201
K2.65032.0 338210
K2.65028.0 338204
K2.65026.0 338202
K2.65025.0 338212
Bellows, Light Protection
and Filter Frames must be
ordered separately
TOP FLAG K2.66019.0 338676
BOTTOM FLAG K2.66019.0 338676
SIDE FLAG (PAIR) K2.65056.0 338222
TOP FLAG K2.47740.0 338221
BOTTOM FLAG K2.47740.0 338221
SIDE FLAG (PAIR) K0.60029.0 338223
HARD MATTE SETS
2/3” VIDEO FORMAT 4:3 K2.47689.0 338296
2/3” VIDEO FORMAT 16:9 K2.47690.0 338298
35 mm FILM K2.47691.0 338300
FILTER FRAME COMBO
4x5.65 / 5 x 5 K2.65023.0 338218
5.65 x 5.65 / 5 x 6 K2.65022.0 338220
FILTER FRAME COMBO
4x5.65 / 4 x 4 K2.65095.0 338219
5.65 x 5.65 / 4 x 5.65 VERTICAL K2.65148.0 338217
4x4FILER FRAME
K2.65098.0 333066
4x5.65 FILTER FRAME HORIZONTAL
K2.65048.0 338224
4x5.65 FILTER FRAME VERTICAL
K2.65049.0 338226
Configuration Overview 5.65 x 5.65 MATTEBOX MB-20
LIGHT PROTECTION CARRIERS & FILTER STAGES
MB-20 SYSTEM I BASIC MODULE
WITH SUNSHADE
K2.65027.0 338200
2-FILTER STAGE
K2.65026.0 338202
3-FILTER STAGE
K2.65089.0 338203
MB-20 SYSTEM II BASIC MODULE
WITH SUNSHADE
K2.47738.0 338201
BACK 138 mm BELLOWS
ADAPTER
K2.65028.0 338204
SWING-AWAY MODULE
K2.65032.0 338210
CONSOLE FOR
LIGHTWEIGHT SUPPORT
K2.65025.0 338212
(Requires swing-away module)
STUDIO CONSOLE
FOR 19 mm RODS K2.55031.0 338207
FOR 15 mm RODS K2.55032.0 338208
NOTE: Use Studio Consoles if lens front
diameter exceeds 157 mm. Not compatible
with lightweight support.
CLAMP-ON ADAPTER
K2.65030.0 338216
(Instead of swing-away module)
ADAPTER FOR 19 mm RODS
K2.66039.0 338684
ADAPTER FOR 15 mm RODS
K2.66040.0 338686
K2.47671.0 338260 (ø 80 mm)*
*for Video Lenses
K2.47672.0 338258 (ø 80 mm)-HS*
*for Zeiss Super Speed Lenses
K2.47673.0 338262 (ø 85 mm)
K2.47674.0 338264 (ø 86 mm)
K2.47675.0 338266 (ø 87 mm)*
*for Zeiss Vario Sonnar
K2.47676.0 338268 (ø 90 mm)
K2.47677.0 338270 (ø 92 mm)
K2.47678.0 338272 (ø 95 mm)*
*not for wide angle video zooms
K2.65031.0 338206 (ø 95 mm) WA*
*for 13 x 4.5 mm Fujinon
and 11 x 4.7 mm Canon
K2.47679.0 338276 (ø 96 mm)
K2.47680.0 338278 (ø 98 mm)
K2.47681.0 338280 (ø 100 mm)
K2.47682.0 338282 (ø 104 mm)
K2.65097.0 338248 (ø 105 mm)
K2.47683.0 338284 (ø 110 mm)
K2.47684.0 338286 (ø 114 mm)
K2.47685.0 338288 (ø 117 mm)
K2.47686.0 338290 (ø 120 mm)
K2.47687.0 338292 (ø 128 mm)*
*not for Fujinon HAe 3 x 5
K2.47688.0 338294 (ø 128 mm) WA*
*for Fujinon HAe 3 x 5
RINGS FOR CLAMP-
ON ADAPTER
NOTE ON CATALOG NUMBERS: KX.XXXXX.X FOR CUSTOMERS IN EUROPE AND ASIA 3XXXXX FOR CUSTOMERS IN NORTH AND SOUTH AMERICA
FILTER FRAMES
BASIC MODULES & ACCESSORIES
10
Technical Data subject to change without notice.

11
ARRI |PROFESSIONAL CAMERA ACCESSORIES
41/2" FILTER RINGSCONNECTION RINGS
138 mm FILTER RINGS
CONNECTION RING 100-80
K2.65043.0 338236
(ø 80 mm)-VA80
VIDEO CONNECTION RINGS
CONNECTION RING 100-80
K2.47226.0 333065
(ø 80 mm)-S
CONNECTION RING
K2.52195.0 711306 (ø 104 mm)-V
CONNECTION RING
K2.65045.0 338242 (ø 110 mm)-W
CONNECTION RING 100-85
K2.65038.0 338230
(ø85 mm)-VA85
CONNECTION RING 100-86
K2.65039.0 338232
(ø 86 mm)-VA86
CONNECTION RING 100-90
K2.65040.0 338234
(ø90 mm)-VA90
CONNECTION RING 100-92
K2.65054.0 338238
(ø 92 mm)-VA92
CONNECTION RING 100-95
K2.65029.0 338228 (ø 95 mm)-VA95
NOTE: Only for wide angle lenses with
cutouts (4.9 mm and below). For lenses
larger than 4.9 mm use K2.47224.0-C
CONNECTION RING 114-96
K2.65055.0 338244
(ø 96 mm)-VA96
CONNECTION RING 114-98
K2.65044.0 338240
(ø 98 mm)-VA98
ADAPTER RING 114-100
K2.65046.0 338246 (ø 100 mm)-VA100
with thread to connect following connection
rings: VA80, 85, 86, 90, 92, 95 + 100 mm Film
Connection Rings (B2, C, etc.)
CONNECTION RING 114-105
K2.65096.0 338247
(ø 105 mm)-VA105
CONNECTION RING 114-110
K2.65045.0 338242
(ø 110 mm)-VA110
41/2" (114 mm) FILTER RING
K2.49109.0 333064 (ø 87 mm)-R
FILM CONNECTION RING
K2.47225.0 333063 (ø 87 mm)-B2
FILM CONNECTION RING
K2.47224.0 333062 (ø 95 mm)-C
REDUCTION RING REDUCES TO 4 1/2"
K2.47115.0 338668
138mm FILTER RING
K2.47222.0 333060 (ø 100 mm)-Z
41/2" (114 mm) FILTER RING
K2.52205.0 711312 (ø 114 mm)-U
41/2" (114 mm) FILTER RING
K2.32903.0 339039 (ø 125 mm)-X
ADAPTER RING 114-100
WITH THREAD FIR VA80, 85,
86, 90, 92, 95
K2.65046.0 338246
(ø 100 mm)-VB100
FILM CONNECTION RING
K2.52195.0 711306 (ø 104 mm)-V
FILM CONNECTION RING
K2.65045.0 338242 (ø 110 mm)-W
138mm FILTER RING
K2.47190.0 338568 (ø 114 mm)-H
LARGE DIAMETER WIDE-ANGLE LIGHT TRAP
(not for clamp-on ring) reducing bellows diameter
from 138 mm to listed below
K2.65069.0 338250 (ø 117 mm)
K2.65070.0 338252 (ø 120 mm)
K2.65123.0 338251 (ø 121 mm)
K2.65071.0 338253 (ø 128 mm)
*not for Fujinon 3 x 5 HAe Super Zoom
K2.65090.0 338254 (ø 128 mm)
*for Fujinon 3 x 5 HAe Super Zoom
K2.65072.0 338984 (ø 130 mm)
K2.65073.0 338256 (ø 132 mm)
REFLEX PREVENTION RING
K2.32911.0 339038 (ø 125 mm)-Y
ø=diameter of connection ring to lens
NOTE ON CATALOG NUMBERS: KX.XXXXX.X FOR CUSTOMERS IN EUROPE AND ASIA 3XXXXX FOR CUSTOMERS IN NORTH AND SOUTH AMERICA
Technical Data subject to change without notice.

12
Configuration Overview LIGHTWEIGHT MATTEBOX LMB-15
LMB-15 FOR 4 x 5.65 AND 4 x 4 FILTERS
LMB-5 FOR 4 x 5.65 AND 4 x 4 FILTERS
CLAMP ADAPTER
K2.65103.0 333985
(ø 130 mm)
CLAMP ADAPTER
K2.47243.0 333932
(ø 80 mm)-A
CLAMP ADAPTER
K2.47241.0 333936
(ø 95 mm)-C
CLAMP ADAPTER
K2.47253.0 711302
(ø 104 mm)-I
CLAMP ADAPTER
K2.47240.0 333938
(ø 114 mm)-D
RINGS FOR
CLAMP-ON
ADAPTER
LIGHT SHIELD FOR LMB-5/LMB-15
K2.47244.0 333940
4x5.65 FILER FRAME SPARE
K2.47669.0 338688
4x4FILER FRAME
K2.47104.0 338680
SET OF MASKS FOR LMB-15
K2.66021.0 333987 HD 16 x 9 / SUPER 16
K2.66022.0 333989 35 mm
CLAMP ADAPTER
K2.47242.0 333934
(ø 87 mm)-B
CLAMP ADAPTER
K2.52097.0 711303
(ø 110 mm)
SET-LMB-15 K0.60047.0 333970
INCLUDING
-1x BASIC MODULE, K2.66012.0 333980
-1x 3-FILTER STAGE, K2.66013.0 333981
-1x 2-FILTER STAGE, K2.66014.0 333982
-3x FILTER FRAME 4 x 5.65, K2.47669.0 338688
-1x LIGHTSHIELD, K2.47244.0 333940
SET-LMB-15 TWO STAGE K0.60048.0 333972
INCLUDING
-1x BASIC MODULE, K2.66012.0 333980
-1x 2-FILTER STAGE, K2.66014.0 333982
-2x FILTER FRAME 4 x 5.65, K2.47669.0 338688
-1x LIGHTSHIELD, K2.47244.0 333940
SET-LMB-15 THREE STAGE K0.60049.0 333974
INCLUDING
-1x BASIC MODULE, K2.66012.0 333980
-1x 3-FILTER STAGE, K2.66013.0 333981
-3x FILTER FRAME 4 x 5.65, K2.47669.0 338688
-1x LIGHTSHIELD, K2.47244.0 333940
LMB-5 LIGHTWEIGHT MATTEBOX
SET 1 K0.60032.0 333930
INCLUDING
-1x K2.47670.0 333929 (MATTEBOX)
-2x K2.47669.0 338688
(4 x 5.65 FILTER FRAME)
LMB-5 LIGHTWEIGHT MATTEBOX
SET 2 K0.60032.A 333931
INCLUDING
-1x K2.47670.0 333929 (MATTEBOX)
-2x K2.47104.0 338680
(4 x 4 FILTER FRAME)
Clamp adapters and rings must be
ordered separately.
LMB-15 TECHNICAL DATA
MIN FOCAL LENGTH ENG LENSES: 3.9 mm
MIN FOCAL LENGTH 16 mm LENSES: 6 mm
MIN FOCAL LENGTH 35 mm LENSES: 14 mm (TO 180 mm)
MAX NUMBER OF 4 x 5.65 FILTERS: 3 FILTERS
LMB-15 ADVANCED FEATURES (COMPARED TO LMB-5)
+WORKS WITH WIDE ANGLE ENG LENSES DOWN TO 3.9 mm
+QUICK RELEASE SUNSHADE FOR CLOSE UPS
+OPTIONAL 2 OR 3 FILTER CAPACITY
+OPTIONAL BOTTOM FLAG
LMB-5 TECHNICAL DATA
MIN FOCAL LENGTH ENG LENSES: 6mm
MIN FOCAL LENGTH 16 mm LENSES: 6 mm
MIN FOCAL LENGTH 35 mm LENSES: 14 mm (TO 180 mm)
MAX NUMBER OF 4 x 5.65 FILTERS: 2 FILTERS
ø=diameter of connection ring to lens
K2.47671.0 338260 (ø 80 mm)*
*for Video Lenses
K2.47672.0 338258 (ø 80 mm)-HS*
*for Zeiss Super Speed Lenses
K2.47673.0 338262 (ø 85 mm)
K2.47674.0 338264 (ø 86 mm)
K2.47675.0 338266 (ø 87 mm)*
*for Zeiss Vario Sonnar
K2.47676.0 338268 (ø 90 mm)
K2.47677.0 338270 (ø 92 mm)
K2.47678.0 338272 (ø 95 mm)*
*not for wide angle video zooms
K2.65031.0 338206 (ø 95 mm) WA*
*for 13 x 4.5 mm Fujinon
and 11 x 4.7 mm Canon
K2.47679.0 338276 (ø 96 mm)
K2.47680.0 338278 (ø 98 mm)
K2.47681.0 338280 (ø100 mm)
K2.47682.0 338282 (ø 104 mm)
K2.65097.0 338248 (ø 105 mm)
K2.47683.0 338284 (ø 110 mm)
K2.47684.0 338286 (ø 114 mm)
K2.47685.0 338288 (ø 117 mm)
K2.47686.0 338290 (ø 120 mm)
K2.47687.0 338292 (ø 128 mm)*
*not for Fujinon HAe 3 x 5
K2.47688.0 338294 (ø 128 mm) WA*
*for Fujinon HAe 3 x 5
NOTE ON CATALOG NUMBERS: KX.XXXXX.X FOR CUSTOMERS IN EUROPE AND ASIA 3XXXXX FOR CUSTOMERS IN NORTH AND SOUTH AMERICA
Technical Data subject to change without notice.

FOLLOW FOCUS FF-4 FF-5HD
TRANSMISSION RATIO I=
1,84 1,00
GEAR MODULE TEETH DRIVEN TEETH PER HANDWHEEL REVOLUTION
K2.47252.0 Cine 0,8 35 64,47 35,00
K2.47002.0 Cine 0,8 43 79,21 43,00
K2.65102.0 Cine 0,8 64 117,89 64,00
K2.47631.0 Video 0,5 75 138,16 75,00
K2.47632.0 Video 0,6 64 117,89 64,00
FF-5 WITH LARGE GEAR K2.65102.0 APPROXIMATES FF-4 WITH STANDARD GEAR K2.47252.0
13
ARRI |PROFESSIONAL CAMERA ACCESSORIES
FOLLOW FOCUS DEVICE FF-4
(INCLUDES LEFT FOCUS KNOB + MARKING DISK)
K2.47121.0 381440
Configuration Overview FOLLOW FOCUS FF-4 AND FF-5HD
FOLLOW FOCUS FF-5 HD FOLLOW FOCUS FF-4
FOLLOW FOCUS DEVICE FF-5
(INCLUDES LEFT FOCUS KNOB + MARKING DISK)
K2.47637.0 381550
ADAPTER FOR BRIDGEPLATE 15 mm RODS
K2.47630.0 381562
RIGHT FOCUS KNOB
K2.47215.0 381442
LEFT FOCUS KNOB
K4.47589.0 381443
MARKING DISK FLAT
K4.32713.0 381150
ACCESSORIES FOR FOLLOW FOCUS DEVICES
FOCUS LEVER K2.32730.0 380140
EXTENSION FOR FOCUS KNOB K2.32985.0 381120
FLEXIBLE SHAFT, SHORT 11.8" (300 mm) K2.34100.0 381130
COUPLING FOR FLEXIBLE SHAFT K2.47235.0 381444
FLEXIBLE SHAFT, LONG 35.4" (900 mm) K2.32731.0 380130
GEARSFOR ALL LISTED FOLLOW FOCUS DEVICES
ACCESSORIES FOR FF-4/5 HD
GEARS SEE BELOW
MARKING DISK,
FLAT
K4.32713.0 381150
(FOR FF-3, FF-4,
FF5-HD)
MARKING DISK,
BEVELLED
K2.47248.0 381450
(FOR FF-3, FF-4,
FF5-HD)
0.8 MODULE
TEETH: 35
MODULE GEAR FOR
SMALLER PRIME
LENSES AND
16 mm ZOOMS
K2.47252.0 381468
0.8 MODULE
TEETH: 43
MODULE GEAR FOR
LARGER PRIME
LENSES AND
35 mm ZOOMS
K2.47002.0 381574
0.8 MODULE
TEETH: 35
GEAR FOR LENSES
WITH AXIAL
MOVEMENT OF
FOCUS RING
K2.47557.0 381180
0.8 MODULE TEETH: 64
MODULE GEAR FOR LARGER
PRIME LENSES OR FOR
HIGHER TRANSMISSION
RATIO ON FF-5 WITH
LARGER LENSES
K2.65102.0 381576
0.6 MODULE
TEETH: 64
FOCUS GEAR
0.6 MODULE FOR
FUJINON ENG/EFP
LENSES
K2.47632.0 381572
0.5 MODULE
TEETH: 75
FOCUS GEAR
0.5 MODULE FOR CANON
ENG/EFP LENSES
K2.47631.0 381570
ADAPTER FOR BRIDGEPLATE 19 mm RODS
K2.47629.0 381560
ADAPTER BA-2 FOR 19 mm RODS
K2.43268.0 381411
ADAPTER BA-3 FOR 15 mm RODS
K4.47598.0 381412
NOTE ON CATALOG NUMBERS: KX.XXXXX.X FOR CUSTOMERS IN EUROPE AND ASIA 3XXXXX FOR CUSTOMERS IN NORTH AND SOUTH AMERICA
Technical Data subject to change without notice.

14
Configuration Overview SUPPORT ACCESSORIES
QUICK RELEASE BASEPLATE DUAL SYSTEM LENS SUPPORT
19 mm SUPPORT RODS
QUICK RELEASE BASEPLATE
•Quick switch from tripod to handheld for digital cameras
•Compatible with ARRI Studio System
•Unique centering adjustment allows perfect fit with many
digital cameras
DUAL SYSTEM LENS SUPPORT
•Bridge for lightweight rods and clamping ring to support heavy lenses
•Snap-on mechanism allows quick change
•Compatible with FF-5HD adapter bridge for mounting to 15 mm and 19 mm studio rods
•Clamp rings available for video and film lenses
UNIVERSAL LIGHTWEIGHT BRACKET ULB-3
UNIVERSAL LIGHTWEIGHT BRACKET ULB-3 SET
K2.47650.0 338995
LEFT HANDGRIP ROSETTE
K2.47639.0 338999
CLAMP RING FOR FUJINON STYLE LENSES K2.47801.0 338371
CLAMP RING FOR CANON CINE STYLE LENSES K2.47803.0 338373
LWS SUPPORT BRIGDE K2.478000.0 338370
BRIDGEPLATE SLED K2.47797.0 338356
SUPPORT ROD HOLDER 19 mm K2.47798.0 338357
SUPPORT ROD HOLDER 15 mm K2.47799.0 338358
12" BASEPLATE K4.54362.0 18" BASEPLATE 339866
QUICK RELEASE BASEPLATE K2.47796.0 338355
SET QUICK RELEASE BASEPLATE 19 mm RODS K0.60058.0 338351 *
SET QUICK RELEASE BASEPLATE 15 mm RODS K0.60059.0 338353 *
*Includes pair 440 mm rods
17.3" (440 mm) K5.42904.0 339083
13.4" (340 mm) K4.47347.0 339082
9.4" (240 mm) K2.43046.0 339801
LIGHTWEIGHT ROD SET 7.3" K2.55024.0 200734
LIGHTWEIGHT ROD SET 6.5" K2.55023.0 200733
13.4" (340 mm) K4.47348.0 339081
9.4" (240 mm) K2.21958.0 339087
15 mm SUPPORT RODS WITH THREADS FOR
LWS-3/4 (PAIR)
0.2" K2.47111.0 339011, 1" K2.47112.0 339012
0.5" K2.47114.0 339014, 5" K2.47113.0 339013
LENS SUPPORTS
LENS SUPPORT LS-9
FOR 19 mm RODS
K2.47227.0 339870
LENS SUPPORT LS-10
FOR 15 mm RODS
K2.47228.0 339872
15 mm SUPPORT RODS
17.3" (440 mm) K5.21957.0 339089
NOTE ON CATALOG NUMBERS: KX.XXXXX.X FOR CUSTOMERS IN EUROPE AND ASIA 3XXXXX FOR CUSTOMERS IN NORTH AND SOUTH AMERICA
Technical Data subject to change without notice.

15
ARRI |PROFESSIONAL CAMERA ACCESSORIES
LENS DIAMETER TABLE
CINE LENSES
*Shift and Tilt range limited by Matte Box.
FOCAL LENGTH LENS FRONT
DIAMETER
ARRI MACROS
All Lenses ø80
ANGENIEUX
HR7-81 mm ø100
11.5-138 mm ø114
17-102 mm ø144
HP 25-250 mm ø110
HR25-250 mm ø136
CANON
7-56 mm ø95
8-64 mm ø95
11-165 mm ø95
11.5-138 mm ø95
17-35 mm ø95
COOKE S4i
12 mm ø156
14 mm ø110
Primes 16-135 mm ø110
150 mm ø125
COOKE ZOOM
10-30 mm ø121
10.4-52 mm ø125
18-100 mm ø150
20-100 mm ø144
20-250 mm ø124
MK2 25-250 mm ø121
T3.7 25-250 mm ø150
VANTAGE/HAWK
10-24 mm ø156
150-450 mm ø156
17-35 mm ø110
Primes 15-180 mm ø110
FOCAL LENGTH LENS FRONT
DIAMETER
ARRI/ZEISS MASTER PRIME
All Master Primes ø114
ARRI/ZEISS LDS ULTRA PRIME
12mm ø156
14mm ø114
Primes 16-180 mm ø104
ARRI/ZEISS ULTRA PRIME
8mm ø134
10mm ø156
12mm ø156
14 mm ø114
Primes 16-135 mm ø95
180 mm ø114
ARRI/ZEISS STANDARD SPEED (T2.1)
10 mm ø156
12 mm ø135
14 mm ø114
Primes 16-180 mm ø80
300 mm ø125
ARRI/ZEISS ZOOM
10-100 mm ø87
11-110 mm ø87
VP 1, 2, 3mm ø150
ARRI SHIFT & TILT*
18 mm ø95
Primes 20-150 mm ø87
ARRI/ZEISS SUPER SPEED
All Lenses ø80
ARRI/ZEISS ULTRA 16
All Lenses ø95
Technical Data subject to change without notice.

www.arri.com
Specifications are subject to change without notice. © 2008 ARRI Inc. RP-3/2008/5000 aMintDesign
ARRI Inc.
617 Route 303 Blauvelt NY, 10913-1109
Tel.[phone] Fax[phone]
www.arri.com
ARRI Inc.
600 N. Victory Blvd. Burbank CA, 91502-1639
Tel.[phone] Fax[phone]
www.arri.com
ARRI Inc.
2385 Stirling Road Ft. Lauderdale FL, 33312-6608
Tel.[phone] Fax[phone]
www.arri.com
ARRI Canada LTD.
415 Horner Avenue, Unit 11 Etobicoke, Ontario M8W 4W3,
Canada
Tel.[phone] Fax[phone]
www.arrican.com
