Aseptico ADC-01 AseptiChair User manual

OPERATION MANUAL &
PARTS LIST
ADC-01
Portable Dental Chair
AseptiChair

2
ADC-01
!
SAFETY PRECAUTIONS
Aseptico accepts no liability for direct or consequential injury or dam-
age resulting from improper use, arising in particular through the
non-observance of the operating instructions, or improper preparation
and maintenance of this product.
To prevent injury to people and damage to property, please
heed relevant warnings and remarks. They are marked as follows:
• WARNING: Serious injury or death may result if ignored.
• CAUTION: Damage to property or the environment may re-
sult if ignored.
• NOTE: Important additional information and hints.
s WARNING: Use for intended purposes only. Failure to observe
the operating instructions may result in the patient or user suf-
fering serious injury or the product being damaged, possibly
beyond repair. Before using this product, make sure that you
have studied and understood the operating instructions.
s WARNING: To avoid tipping hazard, never sit on the edge of the
seat — always sit in the center of the seat.
s WARNING: Always use the chair on a hard at surface.
s WARNING: The chair must be unoccupied when making height
adjustments to the chair.
s CAUTION: Before using the Chair, ensure that the leg adjust-
ment pins have been fully inserted through the adjustment
holes in the legs.
s CAUTION: Do not alter the chair assembly.
s CAUTION: All repairs are to be performed by authorized service
personnel only.
Congratulations!
Your new Aseptico ADC-01 portable chair is the nest manually
adjustable chair available to the dentistry and medical professions.
Features include:
• Quick setup and disassembly
• Chair seat height adjustable from 11” to 22” (28 to 56 cm)
• Backrest and footrest each adjustable from vertical to horizontal
• High-strength steel frame
• Replaceable rugged vinyl covering
• Color option: Gray, Blue, or Red
• Chair is designed for a 300 lb (136 kg) maximum load
• Chair weighs 30 lb (13.6 kg)
• Padded carrying case with handles
• Made in the USA
CHAIR SETUP
1. ADJUSTMENT PINS – Remove the leg adjustment pins from
their storage pouches Aunderneath the chair seat, then place
the chair feet down on the oor.
A
2. CHAIR HEIGHT – Put your toes on the tips of the chair legs to
hold them down, then lift up on the chair to extend the legs to
the desired height. Insert the leg adjustment pins Athrough
chair leg tubes and into one of the 5 holes on the adjustment
links Bon both sides of the chair.
A
B

3
ADC-01
3. LEG PANELS (HORIZONTAL POSITION) – Unfold the leg and
foot panels Aof the chair and they will automatically stop in
the horizontal position.
A
4. LEG PANELS (VERTICAL POSITION) – Start with the foot panel
Afolded closed on top of the leg panel. Pull out on the black
knobs Bon the sides of the chair to swing the panels down,
then attach the strap Cfrom the foot panel to the chair leg to
keep the panels in place. Swing the panels up to lock back in
the horizontal position.
A
B
C
5. Insert right and left arm sling pins Ainto holes on the sides of
the seat frame.
A
6. BACKREST – To lower the backrest, lift up on the release
lever Aand push down on the backrest. To raise the backrest,
simply lift up on the backrest.
CAUTION: Completely support the patient’s weight
before lowering the backrest.
A
7. HEADREST – Adjust the headrest Aby pulling on the straps
from the rear.
A

4
ADC-01
COLLAPSING THE CHAIR
WARNING: Never force the chair into the collapsed
position. Forcing the chair down without releasing the
backrest adjustment lever may bend the adjustment
assembly and will void the warranty.
1. Fold toe and then leg panels onto seat as it was originally
stored.
2. Pull arm slings out of the holes in the chair frame.
3. Put your toe onto one of the front chair legs and lift up slightly
on the seat, then remove height adjustment pins. While
supporting chair weight, let the chair fold down toward the
oor.
4. As the chair folds down, release the backrest adjustment lever
until the chair collapses completely. Rotate the chair up onto
one side and insert the leg adjustment pins into their storage
pouch underneath the chair seat.
5. Fold the arm slings and headrest onto the chair and place
folded chair into carrying case.
CLEANING
Although bleach, when diluted to <10% and wiped o immediately
could be used, it is not recommended. The use of barrier covers
and mild cleaning solutions is recommended as the primary asep-
sis approach on chair and stool upholstery instead of relying on
chemicals. The use of barriers greatly extends the life of chair and
stool upholstery and can be replaced between patients.
WARRANTY
Aseptico Inc. warrants this product against defects in material or
workmanship for a period of two (2) years, from date of original
invoice. Some handpieces are warranted for one year under the
same conditions. Other handpieces and expendable components,
such as air turbines and light bulbs, are covered by shorter warran-
ty periods, or have no warranty. Aseptico’s sole obligation under
product warranty is (at its sole option and discretion) to repair or
replace any defective component or product in part or whole.
Aseptico Inc. shall be the sole arbiter of such action.
In the event of alleged defect under warranty, the purchaser is
to notify Aseptico’s Customer Service Department promptly.
Customer Service will provide instructions, usually directing that
the product be returned for service. Shipment to Aseptico and the
cost thereof is always the responsibility of the purchaser.
Accidental misuse, inappropriate installation, or failure to perform
directed maintenance voids the warranty. Deliberately defacing,
modifying, or removing the serial number voids the warranty.
Aseptico Inc. does not assume, under this warranty, any risks or
liabilities arising from the clinical use of its products, whether or
not such use involves coincidental utilization of products manufac-
tured by others.

5
ADC-01
SYMBOL DEFINITIONS
Consult Instructions For Use
Caution – Consult Accompanying Documents
Manufacturer
Authorized European Representative
Serial Number
Part Number
SPECIFICATIONS
Dimensions:
Chair (Folded): 37’’ W x 23’’ L x 9.5’’ H (94 cm W x 58.2 cm L x 24.1 cm H)
Chair (Extented): 72’’ W x 28’’ L x 46’’ H (182.9 cm W x 71.2 cm L x 116.8 cm H)
Soft carrying case: 38’’ W x 24’’ L x 11’’ H (96.5 cm W x 61 cm L x 27.9 cm H)
Capacity:
300 lb (136 kg)
Range of Seat Positions:
Minimum Seat Height: 11’’ (27.9 cm)
Maximum Seat Height: 22’’ (55.9 cm)
Weight:
Chair only: 30 lb (13.6 kg)
Chair in soft carrying case: 34.5 lb (15.6 kg)
Color Option:
Gray, Blue, or Red
INFORMATION CONCERNING THE ACCURACY AND PRECISION OF
THIS PRODUCT MAY BE OBTAINED UPON REQUEST BY CONTACTING
ASEPTICO AT THE ADDRESS SHOWN ON THIS PAGE.

6
PART PART NUMBER QTY
1Seat Cover Assembly 460451 (Gray)
462551 (Blue)
460451-01 (Red)
1
2
3
Armrest Right/Left 460447 (Gray)
462550 (Blue)
460447-01 (Red)
2
4Cover, backrest 460462 (Gray)
462537 (Blue)
462588 (Red)
1
5Strap, headrest 460449 (Gray)
462538 (Blue)
461847 (Red)
1
6Screw, #8x5/8" Chrome SEMS 510239 8
7Headrest, pillow assembly 460450 (Gray)
462549 (Blue)
462589 (Red)
1
8Armrest support rod assembly 460444-08 2
9Tie Wrap, 30" 510135 6
10 Tie Wrap, 13" 510134 3
11 Strap, leg 460448 1
12 C/S, 1/4-20x1" BtnSoc S/S 510294 1
13 Hinge, back support 460382-08 1
14 Nut, 1/4-20 Nyloc S/S 510296 8
15 Back Support Assembly 330088 1
16 Leg adjustment link 460097-08 2
17 Hole plug, 1/4" black 510201 2
18 Endcap, 1" domed 850026 4
19 Leg Assembly, inside 330099 1
20 Leg Assembly, outside 330101 1
21 Bolt, 5/16-18 Grade 5 carriage 510242 2
22 Washer, 5/16 Flat S/S 510266 4
23 Nut, 5/16-18 Nyloc S/S 510126 2
24 Endcap, 1" insert 510204 2
25 C/S, 1/4-20x1-1/4" BtnSoc S/S 510295 3
26 Toe Frame Assembly 330091 1
27 Nut, 5/16-18 hex S/S 510103 2
28 Foam, seat pad 460576 1
29 Spring Pin, 1/4x3/4" S/S 510251 2
30 Leg Frame Assembly, cmpl 330093 1
31 Knob, 5/16-18 insert cornet 850025 2
32 Spring, .420Dx.038Wx.875L comp. 510233 2
33 C/S, 5/16-18x1-1/4" S/S 510050 2
34 C/S, 5/16-18x1" S/S 510048 4
35 SMS, PanPhl #6 x 5/8“ Tapping 510362 2
36 Washer, 5/16 SAE S/S 510107 8
37 Seat Frame Assembly, cmpl 330097 1
38 Pin, leg adjustment assembly 460445-08 2
39 C/S, 1/4-20x1-3/4" BtnSoc S/S 510027 4
40 Hole plug, 3/4" black 510263 2
41 Backrest Frame Assembly 330089 1
42 Spacer, 1/4ID x 3/4OD Coved 510261 2
43 Spacer, 1/4ID x 3/4OD x .250 thick 510379 2
Not Shown Case, carrying w/handles 410193 1
Not Shown Backrest Assembly, cmpl 330090 1
ADC-01

7
ADC-01
