Aseptico ADU-17X Express II Manual

ADU-17X Express II Portable Dental System
OPERATION and MAINTENANCE
INSTRUCTION MANUAL

TABLE OF CONTENTS:
Introduction . . . . . . . . . . . . . . . . . . . . . . . . .1
Package Contents . . . . . . . . . . . . . . . . . . . .1
Safety Precautions . . . . . . . . . . . . . . . . . . .2
Setting Up the Unit . . . . . . . . . . . . . . . . . . .3
Figure 1 - ADU-17X System . . . . . . . . . .3
Figures 2a thru 2e - Changing Voltage . .4
Figure 3 - Installing Instrument Holder . . .5
Figure 4 - Waste Tank Conne tions . . . .5
Figure 5 - Saliva Eje tor Conne tion . . . .5
Operation Functions . . . . . . . . . . . . . . . . . .6
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Figure 6 - Run Mode Swit h . . . . . . . . . .7
Figure 7 - Handpie e Controls . . . . . . . . .7
Sterilization & Maintenance . . . . . . . . . . . . .8
Figure 8 - TA-90D Syringe . . . . . . . . . . . .8
Troubleshooting . . . . . . . . . . . . . . . . . . . . . .9
Repacking Instructions . . . . . . . . . . . . . . .10
Symbol Definitions . . . . . . . . . . . . . . . . . . .11
Specifications . . . . . . . . . . . . . . . . . . . . . .12
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . .13
To prevent injury to people and damage to property,
please heed relevant warnings and remarks. They
are marked as follows:
WARNING: Serious injury or death may result if
ignored.
CAUTI N: Damage to property or the
environment may result if ignored.
N TE: Important additional information
and hints.
i.
P.O. Box 1548 • Woodinville, WA 98072
8333 216 th Street S.E. • Woodinville, WA 98072
International [phone] • Toll Free(800) 426-5913
www.aseptico.com • [email protected]
INDICATI NS F R USE:
The ADU-17X is a mobile self-contained dental system that is
used for endodontic and general dentistry applications.
RX: FEDERAL LAW RESTRICTS THIS DEVICE T
SALE BY R N THE RDER F A DENTIST
Conforms To:
AAMI STD ES60601-1
AAMI IEC STD 62366
IEC STD 80601-2-60
IEC STD 60601-1-6
Certified To:
CSA STD C22.2 # 60601-1

1.
Your new Aseptico Express II Portable Dental System is the finest portable electric dental system
available. The ADU-17X features a handpiece control, 3-way air/water syringe, VE and saliva
ejector vacuum systems, a self contained water system, oilless air compressor, and vacuum
pump. The dual voltage system comes in a case with wheels and a handle for maximum
portability.
Congratulations!
This system is engineered to provide many years of reliable service. Please read the instructions
provided in this manual to receive the best and longest service from your Aseptico equipment.
Separate manuals may be provided to cover the operation and maintenance of other accessories
for your unit.
PACKAGE CONTENTS:
• Portable Case with Compressor and Vacuum Pump
• TA-90D 3-Way Air/Water Syringe
• VE and Saliva Ejector Vacuum oses with Valves
• Water Supply Bottle
• AE-7P Foot Switch
• Power Cord
• Operation & Maintenance Manual
• ighspeed or Lowspeed Pneumatic andpiece (Purchased separately)
• AWS-1C Cavitron Connector
• Two Spare 6.3A Fuses for 120V Operation

2.
SAFETY PRECAUTIONS:
Aseptico accepts no liability for direct or consequential injury or damage resulting from improper use,
arising in particular through the non-observance of the operating instructions, or improper preparation
and maintenance.
WARNING: Sterilize before first and all uses. Clean, disinfect, and sterilize new or repaired instru-
ments before first use. Only use sterilized handpieces and instruments during treatment.
Non-sterile handpieces and instruments may cause bacterial or viral infections. Always
sterilize instruments after operation.
CAUTI N: Always examine unit components for damage before commencing treatment. Damaged
components must not be used and must be replaced.
CAUTI N: For device transport, always keeps the pull handle in hand during transport and ensure
stable platform before releasing.
WARNING: Use for intended purposes only. Failure to observe the operating instructions may result
in the patient or user suffering serious injury or the the product being damaged, possibly
beyond repair. Before using this product, make sure that you have studied and under-
stood the operating instructions.
WARNING: For use by qualified and trained personnel only.
WARNING: Do not install where there is a risk of an explosion. The Express Air is not intended for
operation in the presence of flammable anesthetics or gases.
WARNING: Always operate a high-speed handpiece with water coolant. Operating a high-speed
handpiece without water coolant can cause thermal injury to the patient and damage the
handpiece.
WARNING: Only connect device to AC outlet with Protective Earth (Safety Ground) connection.
WARNING: The power supply cord is the mains appliance disconnect means. Before use, position
the equipment so it is readily accessible.
Expected Serv ce L fe
The expected service life is seven years from the date of first use.

3.
SETTING UP THE UNIT:
FIG. 1 - ADU-17X Express II
CLIP-ON
INSTRUMENT
OLDER
3-WAY
AIR/WATER
SYRINGE
IG
VOLUME
VACUUM
( VE)
VOLTAGE
SELECTOR
MODULE
WASTE
TANK
WASTE
TANK
TIE-DOWN
WATER
SUPPLY
BOTTLE
LOW
VOLUME
VACUUM
(SALIVA
EJECTOR)
FOOT
SWITC
RUN MODE
SWITC
CASE
ANDLE
RESERVOIR
CONNECTOR
COMPRESSOR
AND FAN
OUSING
ANDPIECE
ON/OFF
SWITC
COOLANT
ON/OFF
SWITC
AIR
CONTROL
VALVE
CAVITRON
CONNECTOR
ANDPIECE
COOLANT
CONTROL
VALVE

4.
120V
Indicator
Fig. 2a
240V
Indicator
Voltage Selector Module
Fig. 2d
Fig. 2b
Fig. 2c
Fig. 2e
1. Unpack the ADU-17X Case.
2. Verify that the Voltage Selector Insert is
configured properly by checking the voltage
indicator on the Voltage Selector Module (Figure
2a). The Voltage Module is located on the lower
left of the Motor Cover. The Voltage Selector
Insert must be installed in the “120” position for
120V 60 z operation or in the “240” position for
230V 50 z operation.
To switch the voltage configuration, disconnect
power cord and insert a small flat screwdriver
under the locking tab in the front of Selector
Module. Gently depress tab until the fuse
housing releases (Figure 2b). Carefully remove
fuse housing to reveal Voltage Selector Insert
(Figure 2 ). Pull insert out of housing, turn it
around and reinsert into housing with proper
voltage indicator facing out (Figure 2d).
IMP RTANT: For 120V use, check that the
Fuse in use is a 6.3A medium time delay; for
230V use, check that the Fuse is a 4A Slo-Blo
type. User may have to change fuses before
use.
For 230V use, confirm that the power cord is
correct for the country of usage and carries the
proper certifications.
Carefully reinstall fuses into Fuse older and
slide older back into Selector Module (Figure
1e). Apply pressure until locking tab snaps back
into position, producing a distinct clicking sound.
FU E LOCATED
IN VOLTAGE
ELECTOR
MODULE
WARNING:
ALWAYS DISCONNECT POWER TO
T E SYSTEM BEFORE OPENING
VOLTAGE SELECTOR MODULE
SETTING UP THE UNIT Cont’d :

5.
3. Mount the clip-on older to the extended handle of
the Case, as shown in Figure 3.
4. Attach a sterile handpiece to the ISO Type B
(4-Line) handpiece connector and place the
handpiece in older (Fig. 3).
5. Remove the 3-way air/water Syringe from its travel
clip inside the Case and place it in the older.
6. Position the Waste Tank in the Case with the large
white connection to the rear left of the instrument
as shown in Figure 4. Attach the hose connector
coming from the Vacuum Motor to this large white
connection. Connect the igh Volume Vacuum
( VE) hose to the large gray connector located on
the front of the Waste Tank. Connect the Low
Volume Vacuum (Saliva Ejector) hose to the black
connector located on the front of the Tank.
Note: When attaching the Saliva Ejector hose to
the top of the Waste Tank, push in and rotate 1/4
turn (see Figure 5).
7. Secure Waste Tank by running Bungee Cord from
hooks on bottom panel overtop Tank lid. Verify that
the Waste Tank and vacuum lines are properly
installed. ang the igh Vacuum and Saliva
Ejector instruments on the Clip-On older.
8. Fill the Water Supply Bottle with clean water and
connect to the Water Reservoir Connector.
9. Place Foot Switch on the floor.
Fig. 5
TO IN TALL ALIVA EJECTOR HO E,
TURN CONNECTOR 1/4 TURN CLOCKWI E
VACUUM LINE
WITH QUICK
DI CONNECT
Fig. 4
Waste Tank
Water
upply
Bottle
High
Volume
Connector
Vacuum
Motor
Connector
Bungee
Cord
Low
Volume
Connector
Water
Reservoir
Connector
Clip-On
Holder
Handle
Fig. 3
3-Way
yringe
HVE
aliva
Ejector
Handpiece

6.
b.) Release pressure from Bottle by slightly
loosening bottle from reservoir connector
approximately 1/8-turn, or by depressing the
air button on the 3-Way Syringe.
c.) Unscrew and remove Bottle from cap.
d.) Fill Bottle with clean water.
e.) Screw Bottle into the Water Reservoir
Connector.
f.) Plug in the power cord.
6. HVE and SALIVA EJECT R VACUUMS:
The Express II is equipped with a 5-liter Waste
Tank, a igh Volume ( VE) hose, and a Low
Volume (Saliva Ejector) hose. Both igh and
Low Volume systems operate simultaneously
from the same vacuum source. To gain vacuum
on the VE, open the VE valve to full open and
close the Saliva Ejector Valve. To gain vacuum
on the Saliva Ejector, close the VE and open
the Saliva Ejector to full open.
The vacuum Waste Tank contains a ball float
shutoff to prevent accidental overflow. The Tank
should be emptied when it is ¾ full.
The igh Volume ( VE) vacuum system
contains a screen inside the Waste Tank
container. The screen is used for collecting large
debris upon vacuum intake. Clean screen when
necessary.
To empty the Waste Container:
a.) Unplug the power cord.
b.) Disconnect the hoses.
c.) Empty container.
d.) Reconnect hoses.
e.) Plug in power cord.
7. CAVITR N WATER UTLET:
Provides water via standard 1/4” quick
disconnect to independent Cavitron or scaler
units requiring a water supply.
The waste container has a ball float shutoff to
prevent accidental overflow. If the waste container
becomes full and the ball float activates, the
vacuum motor may not restart, and could
potentially blow the fuse. Immediately empty
waste container to continue operation.
N TE:
OPERATION FUNCTIONS:
1. F T SWITCH RUN M DE:
All Express II System components are activated
by the on/off Foot Switch. The Foot Switch
enables the operation of the handpiece, high
vacuum, Saliva Ejector, and the 3-Way
Air/Water Syringe.
2. C NTINU US RUN M DE:
Enables all the Express II System components
to operate in continuous mode without
activating the foot switch.
3. HANDPIECE C NTR LS:
a.) andpiece Off/On Toggle Switch - Turns
andpiece pneumatic drive pressure Off/On.
b.) Off/On Coolant Toggle Switch - Turns
andpiece water coolant On/Off.
c.) Air Control Switch - Allows adjustment of air
pressure to the andpiece.
d.) Coolant Control Switch - Allows adjustment
of water coolant to the andpiece.
4. THREE-WAY AIR/WATER SYRINGE:
- Pressing the left button dispenses water.
- Pressing the right button dispenses air.
- Pressing both buttons simultaneously
dispenses an air/water mist.
5. WATER SUPPLY B TTLE:
The Express II incorporates a self contained
pressurized water system. This system consists
of a 1-liter white bottle, which dispenses water
through the handpiece and 3-Way Air/Water
Syringe. The Water Supply Bottle threads into
the Reservoir Connector, located in the upper
right corner of the case.
To refill the Water upply Bottle:
a.) Before removing the Bottle for refilling,
unplug the power cord from the Express II
unit.
T E WATER SUPPLY BOTTLE IS
PRESSURIZED DURING OPERATION.
DEPRESSURIZE BOTTLE BEFORE
REMOVAL BY SLIG TLY LOOSENING
BOTTLE FROM RESERVOIR
CONNECTOR.
WARNING:

7.
OPERATION:
1. Connect the power cord to the unit and
plug into appropriate power source.
IMP RTANT: Ensure that the Voltage
Selector Insert is properly configured for
the power source - Refer to Page 4.
2. F T SWITCH RUN M DE:
a. Turn the Run Mode Switch on the front
of the Fan ousing to the “FOOT
SWITC ” position (See Fig. 6).
b. Depress the Foot
Switch: The unit will
pressurize and all
four system
components
( andpiece, 3-Way
Syringe, VE, and
Saliva Ejector) will
activate.
3. C NTINU US RUN M DE:
a. Turn the Run Mode Switch on the front
of the Fan ousing to the
“CONTINUOUS” position.
b. The unit will pressurize and all four
system components ( andpiece, 3-Way
Syringe, VE, and Saliva Ejector) will
activate. The Foot Switch is not
functional.
4. Turn andpiece Switch On and adjust air
pressure and water coolant flow to the
desired settings (See Fig. 7). (Turn the
water coolant control knob clockwise to
decrease flow, or counterclockwise to
increase flow.)
5. Use the 3-Way Air/Water Syringe as
necessary for irrigation or drying.
6. Adjust the vacuum pressure by moving
the valves on both the VE and saliva
ejector vacuum heads.
7. Empty the Vacuum Waste Tank when it is
3/4 full.
After you have set up the Express II unit and
have become familiar with its functions,
enable one of the following two Run Modes:
• Foot Switch Run Mode - Depressing
Foot Switch activates all components.
• Continuous Run Mode - Switch ‘ON’
activates all components.
FIG. 7 - ANDPIECE CONTROLS
ANDPIECE
ON/OFF
SWITC
COOLANT
ON/OFF
SWITC
AIR
CONTROL
VALVE
COOLANT
CONTROL
VALVE
CAUTI N:
Some new ADU-17X compressor motors
might require a 2-week “break-in” when first
used. As a precaution against stalling the
compressor or possibly blowing the fuses
during this break-in period, it is
recommended that either the handpiece or
the water bottle be removed from the
System for approximately 5 minutes before
each initial daily startup, during the first 2
weeks of use.
CAVITRON
CONNECTOR
WARNING:
Always operate a high-speed handpiece with water
coolant. Operating a high-speed handpiece without
water coolant can cause thermal injury to the patient
and damage the handpiece. Consult the handpiece
manufacturer’s instructions for additional information.
RUN
MODE
WITCH
FIG. 6

8.
STERILIZATION AND MAINTENANCE:
Because of its simple design, the Aseptico ADU-17X Express II requires very little maintenance. Any maintenance that
is needed can be performed in minutes.
BLEEDING THE SYSTEM
If the unit will not be used for an extended period of time, or the unit might be subjected to freezing conditions, you
should bleed the system. Simply empty the contents of the water supply tank and install the tank back into the cap.
Operate the air/water syringe and handpiece with water coolant ‘ON’ until just air comes through the water line. Pack
unit and store as normal.
HANDPIECE FLUSH
Flush the handpiece for about 5 seconds after every patient, and about 20 seconds at the beginning of each day.
GENERAL CLEANING
The external surfaces of the case should be cleaned using a soft cloth moistened with a mild detergent solution. Any
external surfaces of the unit that are contacted during use should be wiped down with a soft cloth moistened with a
disinfectant at the beginning of each day and between each patient use.
WATER LINES
Disinfect the water lines weekly. Prepare a 1:10 bleach solution (1 part household bleach to 9 parts water). Remove
water reservoir and discard residual water. Replace empty water supply tank and air purge all waterlines. Fill water
supply tank with bleach solution. Run bleach solution through all lines. Allow bleach solution to stand in lines for 10
minutes. Remove water supply tank and discard bleach. Flush water supply tank and all lines thoroughly
with clean water. Air purge and leave lines dry until next clinical use.
VACUUM SYSTEM
The VE and Saliva Ejector Valves are fully autoclavable. Remove the valves from the hoses before autoclaving. The
vacuum hoses should not be autoclaved. Clean hoses with a disinfectant solution. CAUTI N: Use only NON-foaming
cleansers in the vaccum lines.
SYRINGE TIPS
The ADU-17X unit features a three-way air/water syringe with quick-
change autoclavable tips. To remove a tip, press on the locking
collar surrounding the tip socket and pull the used tip straight out of
the socket (see Fig. 8). To insert a new tip, press locking collar and
push tip into socket as far as it will go. Release collar and gently
tug on tip before using to ensure that tip is securely locked into
socket.
Syringe Tip Sterilization:
1) Remove contaminated syringe tip.
2) Remove all visible signs of contamination before autoclaving.
3) Autoclave tip at 132° C (270° F) for ten minutes.
4) Sterilize between each patient use.
N TE: Since only the tips can be autoclaved, it is recommended that the Air/Water Syringe be bagged with a
disposable, single-use plastic sleeve between each patient use.
This device requires periodic maintenance to remove dust in and around the compressor every 12 months or if
accumulations are seen. The fan on the unit vents air from inside the device to the outside. With the unit operating,
use compressed air to spray into the intake vents and blow dust out of the unit.
FIG. 8 DEPRE
LOCKING COLLAR

9.
Problem:
Unit will not start
Unit starts but blows fuse
No water coming out
Insufficient vacuum
Insufficient handpiece operation
Compressor makes a chugging
sound and does not start up
properly
Correction:
Check system’s power connection.
Turn Run Mode Switch to “Continuous” or “Foot Switch” Mode and begin operation.
Check that voltage selector module is set for source voltage.
Check fuse. If blown, replace with 6.3A/125V medium time delay fuse for 120V
operation, or a 4A/250V slo-blo fuse for 230V operation.
Check that voltage selector module is set for source voltage.
Check vacuum waste container. If full, immediately empty to continue operation.
Check vacuum hose assembly for blockage.
Check that fuse is correct for source voltage.
Check water supply tank for water level and verify that cap is tight.
Depress foot switch for 5+ sec. to pressurize supply tank.
Ensure the handpiece air control valve is not opened all the way.
Check vacuum waste container. If full, immediately empty to continue operation.
Check vacuum hose assembly for blockage.
Check that waste container lid is properly seated and tightly secured.
Check that handpiece ON/OFF toggle is “ON”.
Check that handpiece coolant ON/OFF toggle is “ON”.
Check that air control valve is turned up adequately
Check that handpiece tubing is untangled and not crimped.
Check handpiece connection for missing gasket.
Check for sufficient power source and avoid long light-grade extension cords
(Refer to Figure 8 Extension Cord Recommendations - below)
TROUBLESHOOTING:
EXTENSION CORD RECOMMENDATIONS:
Use only a 3-wire extension cord that has
a 3-blade grounding plug. Connect
extension cord plug to a matching 3-slot
receptacle. Ensure that the extension
cord is in good condition and that its gage
wire is the correct size wire to carry the
current this product will draw. An
undersized cord is a potential fire hazard
and will cause a drop in line voltage,
resulting in loss of power and causing the
product to overheat. Figure 9 indicates
the correct size cord for the length
required and the ampere rating listed on
the product nameplate. If in doubt, use
the next heavier gage cord. The
smaller the gage number, the heavier
the wire gage.
FIG. 9

10.
REPACKING INSTRUCTIONS:
1. Remove all accessories from the unit.
2. Remove water bottle and place in travel
pouch provided.
3. Position syringe in its holder on left side of
case (Fig. 10). Lay tube behind syringe,
next to waste tank.
4. Leave waste tank in place, with tie-downs
connected. Remove suction hoses from
waste tank, coil hoses, and place in
bottom of case to the right of tank.
5. Place travel pouch with water bottle on top
of coiled hoses.
6. Coil foot switch cable and place in pouch
with foot switch. Coil motor drive air line
and place in pouch. Place power cord and
fuses in pouch. Close pouch flap.
7. Position the blue water bottle tube on top
of the pouch and tuck between the pouch
and waste tank.
8. Remove instrument clip-on holder from
extended handle and place in space
located above waste tank. Retract handle.
9. Carefully close case lid, taking care not to
pinch any internal components.
W EN TRANSPORTING UNIT, DO NOT
PLACE OBJECTS ON TOP OF CASE.
CAUTI N:
FIG. 10

Foot Switch Run Mode
Continuous Run Mode
11.
Alternating current
Protective earth (ground)
Dangerous Voltage
Warning—Potential danger to
patient or user (consult accom-
panying documents)
SYMBOL DEFINITIONS:
Type B Equipment
Protect Against Dripping Water
Serial Number
IPX1
SN
Foot Switch
andpiece - Air
On/Off Switch
Coolant
Adjustment Switches
This symbol indicates that the
waste of electrical and electronic
equipment must not be disposed
as unsorted municipal waste and
must be collected separately.
Disposing of your old product
Each Member State in the European Union (EU) requires that the waste from electrical and
electronic products be disposed of separately from normal household waste. This includes
electronics, metals and electrical accessories, such as signal cables or power cords.
Products in this category carry the symbol below.
Contact your local disposal authority and comply with the correct disposal method and fol-
low national guidelines for unit disposal.
Follow instructions for use.
Cavitron Connector
Fuses

12.
SPECIFICATIONS:
Size: 10.5” x 14.5” x 24”
(27 cm x 36 cm x 61 cm)
Volume: 1.81 cu. ft. (0.05 m3)
Weight: 43.5 lbs (19.7 kg)
Power Source: AC Dual Voltage Manual-Switching
120V / 230V at 50 z / 60 z
Current Rating: 6.3A at 120 VAC, or
4A at 230 VAC
Power Rating: 800 W
Operating Pressure: 45 - 50 PSI (344 kPa)
Average Air Flow Pressure: 35 PSI
igh Volume Vacuum: 3.0 SCFM @ -4” g (84.9 liters/min)
Low Volume Vacuum: 1.4 SCFM @ -1.5” g (39.6 liters/min)
Water Reservoir Capacity: 33.9 fl. oz. (1.0 liter)
Water Flow: 5.07 fl. oz./min (0.15 liter/min)
Waste Tank Capacity: 1.08 gal. (4.08 liters)
Noise Level: 72 dBA @ 3’4” (1 meter)
Environmental Conditions: Operating Temperature: 10° to 40° C (50° to 104° F)
Transport/Storage Temperature: -20° to 60° C (-4° to 140° F)
Relative umidity: 10 to 90% non-condensing
Altitude: 0 to 3048 meters (0 to 10,000 feet)
Unit Duty Cycle: Continuous
This device has been tested and found to comply with the
emissions requirements of IEC 60601-1-2:2001-09. These
requirements provide reasonable protection against harmful
electromagnetic interference in a typical medical installation.
owever, high levels of radio-frequency (RF) emissions from
electrical devices, such as cellular phones, may disrupt the
performance of this device. To mitigate disruptive
electromagnetic interference, position this device away from RF
transmitters and other sources of electromagnetic energy.
Note: For reliable grounding, connect to receptacle
marked “ ospital Grade”. IMP RTANT N TE:
When running the ADU-17X unit at 230VAC
50 z, expect approximately 17% less vacuum
and pressure volume due to the slower turning
of the compressor.

13.
Aseptico warrants its products against defects in material or workmanship for a period of two
(2) years, from date of original invoice. Some handpieces are warranted for one year under
the same conditions. Other handpieces and expendable components, such as air turbines
and light bulbs, are covered by shorter warranty periods, or have no warranty. Aseptico's
sole obligation under product warranty is (at its sole option and discretion) to repair or
replace any defective component or product in part or whole. Aseptico shall be the sole
arbiter of such action.
In the event of alleged defect under warranty, the purchaser is to notify Aseptico's Customer
Service Department promptly. Customer Service will provide instructions, usually directing
that the product be returned for service. Shipment to Aseptico and the cost thereof is always
the responsibility of the purchaser.
Accidental misuse, inappropriate installation, or failure to perform directed maintenance
voids the warranty. Deliberatley defacing, modifying, or removing the serial number voids the
warranty.
Aseptico does not assume, under this warranty, any risks or liabilities arising from the clinical
use of its products, whether or not such use involves coincidental utilization of products
manufactured by others.
WARRANTY

P/N: 420627
Rev. L
ECO 14117
03/2017
PRINTED IN
T E U.S.A.
P.O. Box 1548 • Woodinville, WA 98072
8333 216th Street SE • Woodinville, WA 98072
[phone] • [phone]
www.aseptico.com • [email protected]
