Aseptico AMC-20CF Manual

OPERATION &
MAINTENANCE MANUAL
AMC-20CF
Mobile Dental System

TABLE OF CONTENTS:
Introduction . . . . . . . . . . . . . . . . . . . . . . . . .1
Package Contents . . . . . . . . . . . . . . . . . . . .1
Safety Precautions . . . . . . . . . . . . . . . . . . .2
Setting Up the Unit . . . . . . . . . . . . . . . . . . .3
Figure 12 - Cart Fro t & Side View . . . . .5
Figure 13 - Cart Back View . . . . . . . . . . .6
Figure 14 - Cart Back View . . . . . . . . . . .7
Operation unctions . . . . . . . . . . . . . . . . . .8
Customizing Electric Motor Settings . . . . .10
Routine Adjustments . . . . . . . . . . . . . . . . .15
Sterilization & Maintenance . . . . . . . . .16-18
Repacking Instructions . . . . . . . . . . . . . . .19
Troubleshooting . . . . . . . . . . . . . . . . . . . . .20
Specifications . . . . . . . . . . . . . . . . . . . . . .21
Symbol Definitions . . . . . . . . . . . . . . . . . . .22
Replacement Parts List . . . . . . . . . . . . . . .23
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . .24
P.O. Box 1548 • Woodinville, WA 98072
8333 216 th Street S.E. • Woodinville, WA 98072
International [phone] • Toll ree [phone]
www.aseptico.com • [email protected]
i.
This device has been tested and found to comply with the
emissions requirements of IEC 60601-1-2:2001-09. These
requirements provide reasonable protection against harmful
electromagnetic interference in a typical medical installation.
However, high levels of radio-frequency (R ) emissions from
electrical devices, such as cellular phones, may disrupt the
performance of this device. To mitigate disruptive
electromagnetic interference, position this device away from
R transmitters and other sources of electromagnetic energy.
Classifications in accordance with
UL-60601-1:
- Class II
- Type B Applied Parts
- Type B Equipment
- Ordinary Protection
- Not suitable for use in the presence of a
flammable anesthetic mixture with air, oxygen,
or nitrous oxide.
Note: or reliable grounding, connect to receptacle
marked “Hospital Grade”.
To prevent injury to people and damage to property,
please heed relevant warnings and remarks. They
are marked as follows:
WARNING: Serious injury or death may result if
ignored.
CAUTION: Damage to property or the
environment may result if ignored.
NOTE: Important additional information
and hints.
INDICATIONS FOR USE:
The AMC-20C is a mobile self-contained dental system that
is used for endodontic and general dentistry applications.
RX: FEDERAL LAW RESTRICTS THIS DEVICE TO
SALE BY OR ON THE ORDER OF A DENTIST
CON ORMS TO UL STD 60601-1;
CERTI IED TO CSA STD C22.2 NO. 601.1

1.
Your new Aseptico AMC-20C Dual Voltage Mobile Dental System is the finest mobile dental
system available. The System provides an array of dental equipment features and functions
designed to serve a wide range of dental applications -- all conveniently and neatly packaged into
a single, self-contained transportable cart:
Congratulations
This System is engineered to provide many years of reliable service. Please read the instructions
provided in this manual to receive the best and longest service from your Aseptico equipment.
Separate manuals may be provided to cover the operation and maintenance of other accessories
for your unit.
PACKAGE CONTENTS:
• Self Contained Mobile Cart
• AEU-5000 Remote Mount Assembly
• HVE and Saliva Ejector Hoses with Valves
• TA-90D 3-Way Air/Water Syringe with Tip
• Two 1-Liter Water Bottles, PN 730631-01
• AA-43W Wet/Dry oot Control
• AA-19LED-20CK5 iber-Optic 5-Hole Handpiece Illumination Kit
• Ultrasonic Scaler with 3 Tips, PN 730500
• Rapid Cure L.E.D. Visible Curing Light, 730624
• Amalgam Separator (PN 730595) and By-Pass ilter (PN 730615)
• Waste Hose Assembly (PN 330673)
• Power Cords – 120V Hospital Grade (PN 840101) and 220V Euro (PN 840102)
• Portable Case for Transporting Mobile Cart, PN 410195
PURCHASED SEPARATELY:
• AHP-72MB O-XL 1:5 Increaser E-Type Handpiece w/ iber Optics
• AHP-77C 1:2 Increaser E-Type Surgical Handpiece
• AHP-63MB O-XL 1:1 E-Type Handpiece w/ iber Optics
• AHP-56MB O-XL 5:1 Reduction E-Type Handpiece w/ iber Optics
• AHP-88MNP 8:1 Reduction E-Type Endodontics Handpiece
NOTE: A List of Replaceme t Parts is Provided o Page 23.
• Automatic handpiece controls for two
pneumatic handpieces w/fiber optic lights.
• Integrated electric motor with control panel.
• Ultrasonic scaler.
• Curing light.
• Each pneumatic and electric handpiece provides
individually controlled water with coolant air.
• 3-way air/water syringe with a self contained
water system.
• High Volume (HVE) and low volume
vacuum lines with adjustable suction valves
and a solids trap.
• Amalgam separator.
• 2 HP compressor with Aseptico pioneered
split head compression and vacuum.
• Aluminum tank for rust-free air supply.
• Rotating arms for positioning of the tubing in
the front of the unit.

2.
SAFETY PRECAUTIONS:
Aseptico accepts no liability for direct or consequential injury or damage resulting from improper
use, arising in particular through the non-observance of the operating instructions, or improper
preparation and maintenance.
WARNING: Clean, disinfect, and sterilize new or repaired handpieces and instruments before
first use and between each patient use. Only use sterilized handpieces and
instruments during treatment. Non-sterilized handpieces and instruments may cause
bacterial or viral infections. Always sterilize handpieces and instruments after
operation.
CAUTION: Always examine unit components for damage before commencing treatment.
Damaged components must not be used and must be replaced.
WARNING: Use for intended purposes only. ailure to observe the operating instructions may
result in the patient or user suffering serious injury or the product being damaged,
possibly beyond repair. Before using this product, make sure that you have studied
and understood the operating instructions.
WARNING: Do not install where there is a risk of an explosion. The Mobile Dental System is not
intended for operation in the presence of flammable anesthetics or gases.
WARNING: CONTRAINDICATIONS
Ultrasonic oscillations emitted by the Ultrasonic Scaler may prevent the proper
function of cardiac pacemakers. Therefore, Aseptico recommends that patients with
a cardiac pacemaker should not be treated with the Ultrasonic Scaler component of
the AMC-20C Cart.
WARNING: The Ultrasonic Scaler instrument tips oscillate at high frequency and can fracture
during operation. To help prevent the tips from fracturing and possibly injuring the
patient, always follow the scaler manufacturer's operating instructions and
recommended ultrasonic power settings.
WARNING: Do not use the Ultrasonic Scaler dry. If used dry, the Instrument Tip will heat
immediately. This may cause thermal injury to the tooth. Ensure that adequate liquid
coolant is always available.
CAUTION: Never use the Ultrasonic Scaler on metal or porcelain restorations. The high
frequency ultrasonic oscillations may loosen the restoration.
WARNING: Always operate a high-speed handpiece with water coolant. Operating a high-speed
handpiece without water coolant can cause thermal injury to the patient.
CAUTION: Observe local regulations concerning disposal of amalgam waste.
WARNING: Avoid looking directly into the Curing Light. Protect patient's eyes with darkened
eyewear when using the Curing Light Probe.
CAUTION: The lens for the electric motor LED is soft and can be damaged. If lens needs to be
cleaned, use a lint-free swab and isopropyl alcohol - do not use other solvents as
they might adversely react with the LED assembly.
WARNING: Never operate unit or work on patients when the top cover is open.
CAUTION: The AEU-5000 Electric Motor is not recommended for use with endodontic files that
have torque limit requirements less than 100 g-cm.
WARNING: Do not use this device for dental implant procedures.
CAUTION: Do not run saline solutions through the water system -- saline will corrode the water
filters.

3.
1. Unpack the AMC-
20C Dental
System from its
shipping case
( ig. 1) per the
instructions
provided in the
Aseptico "Packing
Guide", included
in case.
2. Attach the electric motor/cord to the
receptacle on the front panel. Align the
round dimple on the motor cord connector
with the mark on the receptacle (see ig.
2) and push cord straight into receptacle
until it snaps into position. To remove
motor/cord, pull motor cord connector
straight out of receptacle.
Attach the appropriate E-Type handpiece
(sold separately) to the electric motor.
3. Attach the appropriate ISO Type-C (6-Pin)
fiber optic handpiece(s) to their respective
connectors (see ig. 3).
Place all handpiece and accessories tubes
in their appropriate holders ( igs. 4 & 17).
SETTING UP THE UNIT:
4. Verify that the voltage-selector switch is
set to the proper voltage. To select the
desired voltage, use a long slender tool to
toggle the switch (see ig. 5).
IMPORTANT: When selecting voltage,
align 110V/220V horizontal markers on
switch to the corresponding markers on
faceplate.
5. Open the waste com-
partment door on the
back side of the unit and
place the amalgam
separator into the
FIG. 1
ALIGNMENT
MARKS
FIG. 2
IMPORTANT
WHEN SELECT-
ING VOLTAGES,
ALIGN HORIZON-
TAL MARKERS ON
SWITCH WITH
MARKERS ON
ACEPLATE
FIG. 5
FIG. 6 AMALGAM SEPARATOR
RETAINING SCREW
SEPARATOR
ISO-C 6-PIN
HANDPIECE
HANDPIECE
CONNECTOR
FIG. 3
FIG. 4 INSTRUMENT HOLDERS

4.
amalgam manifold. Tighten the retaining
screw located under the top cover (see
ig. 6, page 3). NOTE: Before installing
the separator into the manifold, remove the
two caps from the inlet and outlet ports of
the separator. Ensure that the two O-rings
that seal the separator against the mani-
fold remain in place on the ends of the port
fittings and are not lodged inside the caps.
6. Attach the 'Waste- ull' sensor to the
connector on the top of the waste
compartment (see ig. 7). Ensure that all
tubes and the bungee tie-down cord are in
place on the waste container.
7ill the water bottles with clean water or
other suitable irrigation fluid and attach to
the water bottle
caps ( ig. 8). The
water bottles
include floating
level indicators,
color coded to
identify different
fluids, e.g., sterile
water vs. distilled
water.
8. Place the foot control on the floor ( ig. 9).
9. Attach
power
cord to
the back
of the unit
( ig. 10)
and plug
into a
grounded
electrical
outlet. Confirm that the power cord is
correct for the voltage source in the
country of use. Turn main power ‘On’ (—).
10. Check system operating pressure on the
pressure gauge located under top cover
( ig. 11). Use the system regulator to set
system operating pressure to optimum 80
PSI (5.51 bar). To adjust pressure, raise
knob on regulator, then turn clockwise to
increase pressure or counterclockwise to
decrease.
SETTING UP THE UNIT - Cont’d
FIG. 7
FIG. 9
WASTE- ULL
SENSOR
OOT
CONTROL
WATER ON/O
TOGGLE
FIG. 11
RAISE KNOB
THEN ROTATE
TO ADJUST PRESSURE
FIG. 8
LEVEL INDICATORS
WATER BOTTLES
FIG. 10
MAIN
POWER
INLET
MAIN
POWER
ON/O
SWITCH
WATER
BOTTLE CAPS

5.
FIG. 12 - AMC-20CF Front View
ACCESSORY TRAY
w/ADJUSTABLE HOLDER
HINGED LID
ALLOWS
ACCESS TO
PLUMBING
SYRINGE,
HIGH & LOW
VACUUM
HOLDERS
REAR CASTER
w/BRAKE
OOT CONTROL
WITH WATER VALVE
BULKHEAD CONNECTORS
COOLANT
AIR
TOGGLE
COOLANT AIR
CONTROL
VALVE
LUSH
TOGGLE
BOTTLE
PRESSURE
RELEASE
TOGGLE
BOTTLE
SELECTOR
TOGGLE
AUXILIARY
WATER
CONNECTION
AUXILIARY
AIR
CONNECTION
SCALER
COOLANT
VALVE
ELECTRIC
MOTOR
CONTROL
PANEL
HANDPIECE,
SCALER, &
CURING
LIGHT
HOLDERS
ELECTRIC
MOTOR
CONNECTOR
HANDPIECE
PRESSURE
GAUGE
SCALER
CONTROL
KNOB
HANDPIECE
COOLANT
VALVES (3)
Water
Bottle
Caps
(2)
Water
Bottles
(2)

6.
FIG. 13 - AMC-20CF Back View
WASTE
HOSE
& HANGER
WASTE
COMPARTMENT
LATCH
WASTE PUMP
ON/O SWITCH
EXHAUST
AN
MAIN POWER
ON/O
SWITCH
110V
OUTLET
AIR TANK
PURGE
TOGGLE
WASTE
COMPARTMENT
ACCESS DOOR
220V
OUTLET
QUICK DIS-
CONNECT
OR WASTE
HOSE
SETTING UP THE UNIT- Cont’d
ACCESSORY TRAY
w/ADJUSTABLE HOLDER
1 AMP
CIRCUIT
BREAKERS (2)
MAIN POWER
INLET
TANK
DRAIN
10 AMP
CIRCUIT
BREAKERS (2)
20 AMP
CIRCUIT
BREAKERS (2)
VOLTAGE
SELECTOR
SWITCH
CORD
RETAINER

7.
FIG. 14 - AMC-20CF - Back View
AMALGAM
SEPARATOR
WASTE CON-
TAINER
WASTE
LOW
VALVE
AMALGAM SEPARATOR
RETAINING SCREW
AMALGAM
BYPASS
ILTER
ILTER REGULATOR
IBER OPTIC/CURING LIGHT
MODULE
SYSTEM
PRESSURE
GAUGE
SCALER
SHIPPING
ASTENERS
PRESSURE
REGULATOR
SYRINGE
SHIPPING
ASTENERS
CENTRAL VACUUM CANNISTER
W/ AMALGAM SOLIDS TRAP INSIDE

8.
1. WET/DRY FOOT CONTROL ( ig. 15) – The
variable-speed foot control activates the
handpieces, scaler, curing light, and water
coolant on/off spray. Position the foot control
on the floor. or handpiece operation, apply
foot pressure to any part of the center disk.
The electric motor or pneumatic turbine
speed is proportional to how far the pedal is
depressed. Depress gradually to increase
speed; release to decrease speed. The
handpiece holder toggle must be 'On' and
the handpiece removed from its holder
before operation can begin. To activate the
water coolant, move the wet/dry toggle
switch on the foot control to the right. Move
switch to the left to disable water.
2. INSTRUMENT CONTROLS ( igs. 16 & 17)
– The Aseptico AMC-20C includes controls
for all handpiece and instrument holders.
Each holder includes an On/Off toggle
switch (see ig. 16)
which when turned 'Off'
(toggle to the left), keeps
the instrument off, even
when removed from its
holder. When the toggle
switch is turned 'On'
(toggle toward the red
dot), the instrument will automatically start
when removed from its holder and the foot
control is pressed. The amount of air
pressure supplied to the pneumatic
handpieces may be adjusted by turning the
flow control screws on the control block
under the upper cover (see ig. 28, page
14). The pressure to the handpiece can be
read on the pressure gauge located on the
front panel of the unit.
OPERATION FUNCTIONS:
APPLY
PRESSURE TO
ACTIVATE
HANDPIECE
ATER
OFF
ATER
ON
FIG. 15
3. AEU-5000 ELECTRIC MOTOR AND
CONTROL PANEL ( ig. 18) - There are
two different control modes that can be
used to operate the Electric Motor: Manual
Mode using the console buttons, or Preset
Mode using the preprogrammed Presets:
A. MANUAL OPERATION - At any time,
the user can adjust the ratio, speed, torque,
motor direction, and electric handpiece LED
settings using the control panel keypad (The
Preset indicator in upper left of LCD will
blink on and off, indicating the change):
1) Depress the Standby
button to turn electric motor
control panel on or off. If the
console was turned off using
the Standby button, the Display will
darken and all the buttons, except the
Standby button, will become inoperative.
Press the Standby button again to turn on
the control panel and return the motor to
its last used settings.
2) Press the RATIO
button repeatedly to
select the ratio that
matches the handpiece being used. Available
ratios are: 1:5, 1:2, 1:1, 5:1, and 8:1.
NOTE: The user can reprogram the unit to
display only a preferred set of ratio(s) from
the five available options. Refer to page 10
for complete instructions on Customizing
Ratios.
FIG. 16
ON
OFF
FIG. 17 PNEUMATIC
HANDPIECE
CONTROLS
(2)
ELECTRIC
HANDPIECE
CONTROL
SCALER CURING
LIGHT

9.
3) Press
the SPEED
Up/Down
buttons to select the desired operating
speed for the handpiece being used. See
igure 19 for handpiece speed ranges.
3) Press the TORQUE Up/Down buttons to
select the
desired op-
erating
torque
percentage.
4) Press MOTOR DIRECTION button
repeatedly to cycle
through and select the
orward ( WD) or
Reverse (REV) settings. An audible tone
indicates reverse direction.
5) To switch the electric
motor to Endodontic
operating mode, first
select the 8:1 handpiece
ratio, then press the MOTOR DIRECTION
button repeatedly until the word "ENDO"
appears in the Motor Direction window.
Next, select the desired Torque level using
the UP/Down Torque buttons. The unit is
then ready to operate in ENDO mode - the
rotation of the handpiece will automatically
alternate between forward and reverse
when the selected torque is reached (in
order to free the instrument).
6) Press and release the ILLUMINATION
button to turn the hand-
piece LED On/Off. To
activate the handpiece
and LED, remove the
handpiece from its holder, turn the
Illumination button 'On', and press the foot
pedal to operate the motor. When the foot
pedal is released and the motor has
stopped, the light will turn off after
approximately 20 seconds.
Press and hold the Illumination button for
three seconds to enter the LED intensity
adjustment mode. When in this mode, press
Fig. 18 - Electric Motor Control Panel
ILLUMINATION
AD USTMENT
w/DISPLAY
SPEED (RPM)
SELECTOR
w/DISPLAY
MOTOR DIRECTION
(FWD/REV) SELECTOR
w/DISPLAY
TORQUE
SELECTOR
w/DISPLAY
PRESET SELECTOR
w/DISPLAY HANDPIECE RATIO
SELECTOR
w/DISPLAY
CONTROL PANEL
STANDBY
BUTTON
Fig. 19 - AMC-20CF Speed Ranges
1:5 10,000 - 200,000 RPM
1:2 4,000 - 80,000 RPM
1:1 2,000 - 40,000 RPM
5:1 400 - 8,000 RPM
8:1* 280 - 5,000 RPM
*280 - 1250 RPM in ENDO Mode
ENDODONTIC MODE
(ENDO) SELECTOR
w/DISPLAY

10.
the Torque Up/Down buttons to select the
desired illumination in 10% increments, from
10% to 100%. The handpiece LED will
automatically turn on and change intensity
as the adjustments are made. The display
icon will also blink as the adjustments are
made. To exit the adjustment mode, press
and release the Illumination button.
B. PRESET OPERATION - The Integrated
Electric Motor module is shipped with five
preprogrammed factory Presets for each
ratio (see ig. 21). This allows the user to
instantly access a wide range of settings.
After the handpiece ratio has been
selected, press the Preset Button
repeatedly to cycle
through five different
Presets (P1 - P5). When
the desired Preset is displayed, its
operating parameters are automatically
activated. Each Preset can store the
following parameters:
- Bur/Drill Speed
- Motor Direction
- Torque Setting
- LED Light 'On' or 'Off'
- Endo Mode Activation (8:1
handpiece ratio only)
NOTE: The Electric Motor is programmed
at the factory to initially start up with Ratio
1:5 and Preset No.1 active. Subsequently,
when the System power is turned on, the
last settings used will be activated.
CUSTOMIZING RATIOS:
The user can enable or disable individual
handpiece ratio options, so that only preferred
or commonly used ratios are displayed during
the ratio selection process. ollow these steps
to reprogram the unit with customized ratio
options:
1. Press and hold the Ratio button to enter the
Ratio Customization Mode.
2. Press the Ratio button repeatedly to switch
between the available ratio options. Each Ratio
displays in the Ratio window as the user cycles
through the five options.
3. When the desired ratio is displayed, press the
Preset button to toggle the ratio to either enabled
or disabled status. The word "On" will appear in
the Preset display window when enabled, and
two dashes "_ _" will appear when disabled (see
igs. 20a & 20b).
4. Repeat Step 3 above for the remaining four ratio
options until the desired ratios are enabled.
5. Press and hold the Ratio button to exit the Ratio
Customization Mode. Only the enabled ratios will
be displayed when selecting Ratio options; any
ratio that has been disabled will not be displayed
(unless you re-enable it).
NOTE: The system must always have at least
one ratio option enabled. If the user attempts to
disable the last operational ratio, the system will
emit a beep sound and ignore the user's
command to disable this remaining option.
NOTE: If the factory defaults are restored, all
customized Ratio option settings will be
overwritten.
CUSTOMIZING PRESETS:
Each Preset can be customized by the user
with its own unique set of operating
parameters:
1) irst select the Ratio, then select the
Preset number of the Preset you wish to
customize.
2) Adjust the Preset's speed, torque,
handpiece illumination, and motor direction
as desired. NOTE: The ENDO Mode feature
can only be enabled when an 8:1 ratio is
selected. The Preset indicator will blink on
and off, indicating a change is in process.
OPERATION FUNCTIONS - Cont'd:
Fig. 20a -Enabled
Fig. 20b -Disabled

11.
Figure 21 - Factory Default Presets
RATIO PRESET
NO.
SPEED
(RPM) DIRECTION TORQUE ENDO MODE
(8:1 Ratio Only)
HANDPC
LED
1:5
1 200,000 WD 100 % —On
2 150,000 WD 100 % —On
3 150,000 WD 50 % Torque Limit —On
4 100,000 WD 100 % —On
5 100,000 WD 50 % Torque Limit —On
1:2
1 80,000 WD 100 % —Off
2 60,000 WD 100 % —Off
3 60,000 WD 50 % Torque Limit —Off
4 40,000 WD 100 % —Off
5 40,000 WD 50 % Torque Limit —Off
5:1
1 2,000 WD 100 % —On
2 1,500 WD 100 % —On
3 1,200 WD 100 % —On
4 800 WD 100 % —On
5 400 WD 100 % —On
8:1
(ENDO
MODE)
1 300 WD 100% YES Off
2 300 WD 70% YES Off
3 300 WD 50% YES Off
4 300 WD 30% YES Off
5 300 WD 10% YES Off
1:1
1 40,000 WD 100 % —On
2 40,000 WD 50 % Torque Limit —On
3 20,000 WD 100 % —On
4 10,000 WD 100 % —On
5 8,000 WD 100 % —On

12.
OPERATION FUNCTIONS - Cont’d:
3) Press and hold the Preset button to
save its new settings (a beep will sound).
4) Press the foot pedal to activate the
motor and begin operation.
FACTORY DEFAULTS: The Electric Motor
Module will retain the factory default
settings ( ig. 21) in memory until changed
by the user. To recall the original factory
defaults, press and hold the PRESET and
RATIO buttons simultaneously for
approximately 3 seconds. IMPORTANT:
When factory defaults are recalled, all user-
customized Ratio and Preset settings will
be overwritten.
SLEEP MODE:
After 20 minutes of motor inactivity, the
Electric Motor Module automatically enables
an energy-saving Sleep Mode which turns
off the Display. When in this mode, three
square symbols will blink consecutively
across the darkened LCD.
To turn the unit on again and light up the
Display, the user can either press the
Standby button on the Control Panel or
remove the handpiece from its holder and
then press on the foot pedal. The last used
settings will be restored.
4. SCALER ( ig. 17) – The AMC-20C
includes a piezoelectric scaler system that
provides adjustable ultrasonic levels and a
water coolant system. The scaler includes
3 instrument tips: The #37 instrument is
specially developed for subgingival
scaling, furcations, supragingival fine
scaling and spot removal. The #38 tip is
used for lingual and buccal subgingival
scaling and furcations. The #39 tip is used
for universal lingual and buccal
supragingival scaling.
The scaler is controlled by the scaler
ultrasonic setting adjustment knob which is
located on the left side of the front panel
(see ig. 22). The ultrasonic intensity can
be adjusted by turning the control knob
clockwise to maximum or counterclockwise
to minimum. When scaling, follow the tip
manufacturer's recommended ultrasonic
settings for each tip.
The coolant level is controlled by the
scaler coolant flow adjustment knob (see
ig. 24, page 13). Turn knob counter-
clockwise to increase coolant flow; turn
clockwise to decrease coolant flow.
5. CURING LIGHT ( ig. 17) - The AMC-
20C provides an LED curing light. When
the light is removed from the holder and
the foot pedal is depressed, the light turns
On. Releasing the foot pedal will turn the
light Off. The light is cooled with drive air
from the AMC-20C manifold at 20 psi. An
audible tone will sound every 10 seconds
while the light is active.
Verify that scaler coolant flow
of no less than 20ml/min is
available at the tip.
SEE ACCOMPANYING SCALER
DOCUMENTS
WARNING:
Avoid looking directly into curing light. Protect
patient with darkened eyewear when using light
probe near patient's eyes.
FIG. 22 SCALER ULTRASONIC CONTROL
SWITCH

13.
6. 3-WAY AIR/WATER SYRINGE ( ig. 23)
• Pressing the left button dispenses water.
• Pressing the right button dispenses air.
• Pressing both buttons simultaneously
dispenses an air/water mist. This mist can be
adjusted with the syringe control block located
under the top cover (see ig. 28, page 15).
7. WATER BOTTLES ( igs. 24 & 25) - The AMC-
20C incorporates a
self-contained
pressurized water
system. The system
consists of two 1-liter
clear water bottles
with a toggle switch to
direct the flow from
either one of the two
bottles, providing the
ability to use different
solutions (NOTE:
lush lines before changing solutions). A
pressure relief valve allows both bottles to be
replaced without draining the air tank. (NOTE:
This valve releases pressure from both bottles;
you cannot remove one bottle while using the
other). To refill the water bottles:
a.) Toggle the bottle pressure relief valve
to 'Off' (see ig. 24) to remove pressure
from both bottles.
b.) Unscrew bottles and remove from their
caps.
c.) ill bottles with water or other solution.
d.) Screw bottles back into their caps.
e.) Toggle the pressure relief valve to 'On' to
pressurize both bottles.
f.) Select bottle to be used via the Bottle
Selector Toggle Switch ( ig. 24).
NOTE: The yellow and blue floating level
indicators can be used to identify bottle
contents when two different types of fluids are
used.
8. COOLANT AIR TOGGLE VALVE ( ig. 24)
When turned on, this valve allows coolant air
to flow to the working handpiece or motor
when the foot pedal is depressed.
9. COOLANT AIR CONTROL VALVE ( ig. 24)
Adjusts the volume of coolant air to the
working handpiece or motor.
10. FLUSH TOGGLE ( ig. 24) – Allows user to
flush the handpiece or motor with water,
washing away contaminants which may have
accumulated in the handpiece and tubing. User
should flush the handpiece for about 5 seconds
after every patient, and about 20 seconds at the
beginning of each day. To flush a handpiece,
remove it from its holder and point the spray
nozzle away from you, i.e., into a basin. lip the
flush toggle and hold the desired number of
seconds. Release the toggle when done.
NOTE: If water bottles drain empty when
flushing, air will be flushed through the lines.
11. BOTTLE PRESSURE RELEASE TOGGLE ( ig.
24, page 13) – Allows pressure to be released
from both bottles while maintaining system
pressure.
12. WATER BOTTLE TOGGLE VALVE ( ig. 24,
page 13) – Allows user to direct the water flow
from either one of the two bottles (toggle points to
the bottle in use).
FIG. 24 COOLANT AIR TOGGLE
COOLANT AIR CONTROL VALVE
LUSH TOGGLE
BOTTLE PRESSURE
RELEASE TOGGLE
BOTTLE SELECTOR TOGGLE
COOLANT
OR SCALER
COOLANT OR
AIR HANDPC #2
COOLANT OR
ELECTRIC HANDPC
COOLANT OR
AIR HANDPC #1
FIG. 23
SYRINGE
SALIVA
EJECTOR
HIGH VACUUM
(HVE)
FIG. 25
LEVEL INDICATORS
WATER BOTTLES
WATER
BOTTLE CAPS

14.
OPERATION FUNCTIONS - Cont’d:
13. HIGH AND LOW VOLUME VACUUMS ( ig. 23,
page 13) – The unit is equipped with a 5-liter
waste tank, a high volume evacuator (HVE) hose,
and a low volume saliva ejector hose. Both high
and low volume systems operate simultaneously
from the same vacuum source. To gain vacuum
on the HVE, fully open the HVE valve and close
the low volume valve. To gain vacuum on the low
volume valve, close the HVE and open the low
volume to full open.
14. CENTRAL VACUUM KIT – Used with the vacuum
system and contains a disposable solids collector.
The system is located under the top cover (see
ig. 14, page 7).
15. AMALGAM SEPARATOR ( ig. 14, page 7) – The
amalgam separator is located in the rear waste
compartment. The separator allows for particulate
from the waste compartment to be trapped prior to
being pumped out of the unit. The separator can be
replaced by unscrewing the knob located under the
top cover, and removing the filter from the waste
compartment. CAUTION: Observe local regulations
concerning disposal of amalgam waste.
16. WASTE FLOW CONTROL ( igs. 14 & 30, pages 7 &
15) The waste flow control is located in the rear waste
compartment. This valve allows for the adjustment of
the waste pump flow rate, to meet a State’s or
Country’s regulatory requirements for wastewater
filtering and collection (refer to para. 5, page 15).
17.
WASTE PUMP SWITCH & WASTE
DISCHARGE QUICK DISCONNECT ( ig. 26)
– A waste pump switch is provided on the back
of the unit to purge the waste system. A quick
disconnect is provided next to the switch, to
attach the drain hose. NOTE: The hose must
be attached before waste will discharge.
18. AIR TANK DRAIN VALVE ( ig. 26) – Allows air
pressure and any condensation to be drained
from air tank. Turn "On" to open drain or "Off" to
close drain.
19. EXTERIOR OUTLETS ( ig. 26) – 110V and
220V (Euro style) outlets are provided on the
back of the unit for powering accessories.
NOTE: The system uses a step down
transformer to apply the proper voltage to the
unit when plugged into 220V. When 110V is
used for the primary voltage entering the unit,
the 220V socket will provide 220V output.
20. ACCESSORY TRAY ( ig. 27) - The height of
the accessory tray can be adjusted: remove the
tray and arm from the pivot block, then use the
3/16" Allen wrench (supplied) to loosen the hex
screw and reposition the block to the desired
height. The tray and arm also pivot horizontally.
FIG. 27 PIVOT
BLOCK
FIG. 26
110V OUTLET
OPTIONAL 220V OUTLET
WASTE DISCHARGE
QUICK-DISCONNECT
WASTE PUMP
ON/O SWITCH
AIR TANK DRAIN
ON/O TOGGLE
EXHAUST AN
AIR TANK DRAIN

15.
ROUTINE ADJUSTMENTS:
4. HANDPIECE PRESSURE AD USTMENT
The amount of air pressure supplied to the
HP1 & HP2 pneumatic handpieces may be
controlled by turning the flow adjustment
screws on the control block and monitoring
the pressure gauge on the front of the
system cabinet. The control block is located
under the top cover, behind the barrier wall
( ig. 29). Turn screws clockwise to decrease
pressure or counterclockwise to increase
pressure. IMPORTANT: Always adjust the
HP1 and HP2 handpieces' pressures to the
manufacturer's recommended settings. The
pressure settings for the scaler, curing light
and electric motor are preset at the factory
and do not require any further adjustments.
5. WASTE FLOW AD USTMENT ( ig. 30)
The waste flow valve
controls the wastewater flow
rate. The valve is located in
the rear waste compartment.
Turn the lever as shown to
adjust the flow rate as
specified by your State or Country laws
regarding disposal of dental wastewater.
The small circle on the flow indicator
represents a 1-liter per minute flow setting
for the specific amalgam separator provided
with this AMC-20C Cart. A bypass filter
has been provided for areas where
amalgam separators are not required.
WASTE LOW
ADJUSTMENT
VALVE
BYPASS
ILTER
FIG. 29
FIG. 30
1. WATER COOLANT FLOW
AD USTMENT ( ig. 24, page 13)
Each handpiece has an individual water
control valve that regulates the water
coolant flow to the handpiece and motor.
Install and run a handpiece at a midrange
speed. Make sure the wet/dry toggle is in
the "ON" position on the foot control. Turn
the appropriate water coolant flow control
(see ig. 24, page 13) clockwise, until it
seats softly. Begin turning counterclock-
wise until a fine mist is visible. This will
provide excellent cooling while the bur is
cutting. (Note that each water coolant
control valve on the control panel controls
its respective handpiece located on the
rotating arm.)
2. COOLANT AIR CONTROL AD USTMENT
( ig. 24, page 13)
A coolant air toggle valve and
control valve are provided to turn
coolant to the handpiece and motor On and
Off, and to control the flow. Turn the coolant
air control valve clockwise until it seats
softly. Begin turning counterclockwise until
the desired amount of air is achieved.
3. SYRINGE AIR/WATER FLOW
AD USTMENT ( ig. 28) – The syringe
flow adjustment block is located under the
top cover, behind the arm barrier wall.
There are two slotted adjustment screws:
the left screw adjusts the air flow and the
right screw adjusts the water flow. Turning
the adjustment screws clockwise will
decrease the pressure, while turning them
counterclockwise will increase the
pressure.
FIG. 28
WATER LOW
ADJUSTMENT
SCREW
AIR LOW
ADJUSTMENT
SCREW
LOW ADJUSTMENT SCREWS (5)

16.
HANDPIECES:
lush the pneumatic handpiece for about 5 seconds
after every patient and about 20 seconds at the
beginning of each day. NOTE: The flush valve is
located on the control panel, on the right side of the
unit (see ig. 24, page 13). When sterilizing E-type
handpieces, follow the
instructions provided by the
handpiece manufacturer.
IMPORTANT! Protect motor from
excess oil draining from E-type
handpiece. After lubricating and
before autoclaving, stand
handpiece by its base on a paper
towel and allow excess oil to
drain (see ig. 31).
ELECTRIC MOTOR & CORD ASSEMBLY:
The entire AEU-5000 Electric Motor and Cord
Assembly is fully autoclavable ( ig. 32). Steam
autoclave motor/cord assembly at 132° C (270°
) for ten minutes. Loosely coil the motor cord
when autoclaving. Avoid sharply bending the
cord when autoclaving. Alternatively, wipe down
the motor cord with disinfecting solution, and/or
sleeve the cord between each patient.
CAUTION FOR ALL STERILIZATION:
• Do not exceed 135° C or 275°
• Do not submerge in any solutions
• Do not use ultrasonic cleaners
The entire motor & cord
assembly is steam
autoclavable.
Fig. 32 - MOTOR & CORD STERILIZATION
CAUTION:
The Electric Motor is sensitive to shock. Do not
drop or impact motor against a hard surface.
STERILIZATION AND MAINTENANCE:
ELECTRIC MOTOR O-RINGS:
Replace electric motor O-rings when worn or
damaged ( ig. 33). Gently peel old O-rings out
of grooves and replace with new rings (PN
520069). Occasionally apply non-toxic
lubricant (preferably containing PT E) to O-
rings to maintain flexibility.
MOTOR LED LENS CLEANING:
The lens of the LED light on the motor (see
ig. 33) is soft and can be damaged. It should
not be exposed to dust and debris. Excessive
dust and debris may cause a drastic decrease
in optical output. In the event that the light
requires cleaning, first try a gentle swabbing,
using a lint-free swab. If needed, use a lint-
free swab and isopropyl alcohol to gently
remove dirt from the lens. Do not use other
solvents as they may adversely react with the
LED assembly.
WATER LINES:
Disinfect the water lines weekly. Prepare a
1:10 bleach solution (1 part household bleach
to 9 parts water). Purge all water lines (see
page 19, Purgi g Water From the System).
ill water bottles with bleach solution. Run
bleach solution through all lines. Allow bleach
solution to stand in lines for 10 minutes but no
longer:
Fig. 33 O-Rings
(3)
LED
• Do not attempt to disassemble the motor or motor
connector.
• Do not oil or lubricate the motor.
• Do not attach a handpiece to the motor while the
motor is running.
• Do not bend motor cord sharply.
WARNING
ailure to comply with any of the above instructions
may void your warranty.
Fig. 31

17.
Immediately remove water bottles and
discard the bleach, then flush water bottles
and all lines thoroughly with clean water.
Purge all water lines with air and leave dry until
next clinical use.
VACUUM SYSTEM:
The HVE and low volume saliva ejector valves
are fully autoclavable. Remove the valves from
their hoses before autoclaving. The vacuum
hoses should not be autoclaved.
Clean hoses
with a disinfectant solution using standard vacuum
hose cleaning procedures. CAUTION: Use only
NON-foaming cleansers in the vaccum lines.
AIR TANK PURGE:
Routinely purge the air tank once a day to
remove condensation from the air storage tank.
3-WAY AIR/WATER SYRINGE:
The syringe features quick-change autoclavable
tips: To remove a tip, press on the locking collar
surrounding the tip socket and pull the used
tip straight out of the socket.
To insert a new tip, press locking collar and
push tip into socket as far as it will go. Release
ring and gently tug on tip before using to
ensure that tip is securely locked into socket.
Syringe Tip Sterilization:
1) Remove contaminated syringe tip.
2) Remove all visible signs of contamination before
autoclaving.
3) Autoclave tip at 132° C (270° ) for ten minutes.
4) Sterilize between each patient use.
NOTE: Since only the tips can be autoclaved, it
is recommended that the air/water syringe be
bagged with a disposable, single-use plastic
sleeve between each patient use.
CAUTION:
Do not run saline solutions through the water
system -- saline will corrode the water filters.
A
A
WASTE REMOVAL:
Routinely empty the waste container once a
day. Since the unit uses a filtered amalgam
separator, no settlement time is required
before draining the waste tank.
To empty the
waste system,
connect the
waste hose
elbow to
the waste dis-
charge on
the back of
the unit by
inserting the
elbow until it
locks into
place. Switch
on the waste
purge pump to empty the waste system. To
disconnect the waste hose, depress the button
on top of the waste discharge. NOTE: The waste
hose must be connected to the waste discharge
to enable pump operation.
AMALGAM SOLIDS TRAP:
Replace the disposable amalgam solids trap
routinely. The performance of the vacuum system
will decrease significantly
as the trap fills up with
solids. The trap sits
inside the central
vacuum canister
located under the top lid.
Keep spare traps in
stock. The AMC-20C
uses standard 1 7/8”
traps (open or closed type):
Check with state laws regardi g the recycli g of
amalgam solids waste.
A
B
C
D
A
PART NO. QUANTITY PART NO. QUANTITY
AA-29 1 AA-290VS 1
AA-29-100 100 AA-290VS-100 100
OPEN TYPE CLOSED TYPE
C
A
B
D
A

18.
ULTRASONIC SCALER:
(Refer to ultraso ic scaler i structio s for use,
supplied separately.)
The scaler handpiece cover and scaler tips are
fully autoclavable. Disinfect and clean the cover
and tips before autoclaving. Autoclave at a
maximum temperature of 135º C (275º ) for
10 minutes or 120º C (248º ) for 20 minutes.
Wipe off the scaler handpiece and its silicone
hose with a soft cloth. Use a 45% isopropyl and
detergent solution. DO NOT IMMERSE the
handpiece in any fluid or spray any fluid directly
on the handpiece.
CURING LIGHT:
(Refer to curi g light i structio s for use, Su lite
Lazer model, supplied separately. Su lite Lazer is
a product of Ki etic I strume ts, I c.)
The curing probe is fully autoclavable. Detach
probe by pressing quick disconnect button on
side of handle. Clean probe with disinfectant
then autoclave at 135°C (275° ) for 20 minutes
minimum. Clean and sterilize probe between
each patient use. NOTE: The lamp module (the
section that seats into the tubing connector) is
NOT autoclavable.
MOTOR/CORD RECEPTACLE O-RINGS
The O-rings for the three water/air ports in the
motor/cord receptacle should be replaced if
damaged or worn. Use the provided O-ring installer
pin and sleeve to replace the O-rings:
1. Remove old O-ring from water or air port
fitting.
2. Slide new O-ring over pointed end of installer
pin, onto the pin’s shank (see igure 35).
WARNING:
Avoid looking directly into curing light. Protect
patient with darkened eyewear when using light
probe near patient's eyes.
O-RING
INSTALLER
PIN
FIG. 35
3. Insert pointed end of installer pin into open end
of installer sleeve until O-ring stops against
end of tool.
4. Position concave end of installer pin against
end of water/air port fitting (see igure 36).
5. Push installer sleeve inward, until new O-ring
seats into groove on fitting (see igure 37).
PURGING WATER FROM THE SYSTEM:
Purge all water from the system if the unit will
be unused for more than a week or exposed to
freezing temperatures. Empty both water
bottles, then reinstall them into their caps.
Rotate open (counter-clockwise) all water
coolant knobs (open knobs fully for fastest
purging). Toggle on all instrument holder
switches. Switch on the main power. Toggle on
the bottle pressure switch. Purge all water
lines simultaneously or one at a time: Hold
handpieces and scaler over a basin while
holding the flush toggle switch in the on
position until all water is purged from the lines
with air. inally, hold the water syringe over the
basin and hold down the water button until all
water is purged from the line with air.
GENERAL CLEANING:
The external surfaces of the chassis should be
cleaned using a soft cloth moistened with a
mild detergent solution. Any external surfaces
of the unit that are contacted during use should
be wiped down with a soft cloth moistened with
a disinfectant at the beginning of each day and
between each patient use.
O-RING
INSTALLER
SLEEVE
FIG. 36
INSTALLER
PIN
O-RING
FIG. 37
WATER/AIR
FITTING
STERILIZATION AND MAINTENANCE - Cont'd:
