2 Specications
PUSH-N-GO
USER’S GUIDE
MANUAL PUSH DOOR LEAF REACTIVATION MODULE
1 Description
DESCRIPTION SPECIFICATION
Supply Voltage 12 VDC (± 10%) supplied by CU2
Current Consumption 2 to 16mA
Temperature Range -4F to 131F
Relay 1 Contact Ratings 0.5A @ 125 VAC
1A @ 24 VDC
Dimensions 2 3/4” x 2 1/8” x 1” (70mm x 55mm x 25mm)
75.5653.01 20100330 Page 1 of 2
The Push-N-Go module is designed for use with the Besam CU2 door control and can be used with or without the CU-Hub module. The unit
provides a dry activation output whenever a door leaf is manually pushed while closed or during any point of the closing cycle. One module can
be used to monitor up to two door leafs simultaneously for either direction. The push force required to trigger activation is slightly adjustable to t
application needs. The Push-N-Go module can be used for a single or pair of doors.
3 Precautions
Shut off all power going to header before attempting any wiring procedures.
Maintain a clean and safe environment when working in public areas.
Constantly be aware of pedestrian trafc around the door area.
Always stop pedestrian trafc through the doorway when performing tests that may result in unexpected reactions by the
door.
ESD electrostatic discharge: Circuit boards are vulnerable to damage by electrostatic discharge. Before handling any board
ensure you dissipate your body’s charge.
Always check placement of all wiring before powering up to insure that moving door parts will not catch any wires and cause
damage to equipment.
Ensure compliance with all applicable safety standards (i.e. ANSI A156.10) upon completion of installation.
DO NOT attempt any internal repair of the sensor. All repairs and/or component replacements must be performed by BEA,
Inc. Unauthorized disassembly or repair:
1. May jeopardize personal safety and may expose one to the risk of electrical shock.
2. May adversely affect the safe and reliable performance of the product will result in a voided product warranty.
4 Pre Installation Check
1. When preparing to wire multiple devices together for a ‘system’ conguration, it is best to ensure the correct operation of each device
independently before starting to help reduce troubleshooting time later in the event of a discrepancy.
2. Prior to installing any equipment, ensure the correct line voltage and stability. When applying equipment on a new installation utilizing new
electrical supply circuits, always ensure that correct line voltage exists and is stable. Remember to shut the power back off after this is
checked and before performing any wiring to the system.
5 Connections and Settings
CONNECTOR NAME DESCRIPTION
JP1 Power and Relay connector Red: 12V
[connect to ‘IHB’ on the CU2 (TB1, Pin 10)]
Black: GND
[connect to ‘0VDC’ on the CU2 (TB1, Pin 3)]
Green: NO
White: COM
[If used with a CU-Hub connect to the Auxiliary input]
[If used without a CU-Hub connect to the CU2 control ‘IMP’ & ‘0VDC’
(TB1, Pin 1 & Pin 3)]
Page 2 of 2 75.5653.01 20100330
7 Company Contact
5 Connections and Settings (Continued)
CONNECTOR NAME DESCRIPTION
JP2 Motor voltage Input Motor voltage input from CU2 control. Connect to the unused motor
voltage connector on the CU2 control for the door leaf to be opened.
J1 & J2 Door leaf selector for JP2 Set to determine the motor voltage polarity connected to JP2. Both
jumpers have to be moved for proper operation. Set jumpers to reect
the connection made on the CU2 control.
Figure 1: In this conguration JP2 is connected to the RH motor
connector of the CU2 control for the LH door leaf.
Figure 2: In this conguration JP2 is connected to the LH motor
connector of the CU2 control for the RH door leaf.
JP3 Motor voltage input Motor voltage input from CU2 control. Connect to the unused motor
voltage connector on the CU2 control for the door leaf to be opened.
J3 & J4 Door leaf selector for JP3 Set to determine the motor voltage polarity connected to JP3. Both
jumpers have to be moved for proper operation. Set jumpers to reect
the connection made on the CU2 control.
Figure 3: In this conguration JP3 is connected to the RH motor
connector of the CU2 control for the LH door leaf.
Figure 4: In this conguration JP3 is connected to the LH motor
connector of the CU2 control controller for the RH door leaf.
R2 Activation force adjustment Used to adjust the push sensitivity of the module.
6 Troubleshooting
PROBLEM PROBABLE CAUSE CORRECTIVE ACTION
Module will NOT react to any input. 1. Incorrect wiring
2. Incorrect jumper settings
3. Faulty module
1. Verify wire connections according the “Connections & Settings”
chart. Ensure that power is not reversed.
2. Ensure jumpers are set correctly for the motor terminal it is
connected to.
3. Replace module.
Do not leave problems unresolved. If a satisfactory solution cannot be achieved after troubleshooting a
problem, please call Besam technical services. If you must wait for the following workday to call Besam
technical services, leave the door inoperable until satisfactory repairs can be made. Never sacrice the
safe operation of the automatic door or gate for an incomplete solution.
For more information, visit www.besam.com.
1-800-97BESAM (1-800-972-3726)
UST[email protected]
Figure 1 Figure 2
Figure 3 Figure 4
J1
J2
RH RH
LH LH
J1
J2
RH RH
LH LH
J3
J4
RH RH
LH LH
J3
J4
RH RH
LH LH
DUO HSO BCK HLD
HSC2RMP TD HSC1
HOLDBKO IMP OPD
ORANGE YELLOW GREEN RED
1 2 3 4 5 6 7 8 9 10
11 12 13 14 15 16 17 18 19 20
IMP
0VDC
OPD
BC1
BC2
LOT
HLD
HNO
HNC
IHB
TB1
18VDC+
-0VDC
KILL
DONT USE
18VAC
TB2
-0VDC
-0VDC
18VAC
18VAC
BESAM
SWINGMASTER
CU2
J2 J3
SYNCH CUHUB INTERFACE
.... ............
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
..
..
RH
CAM
LH
CAM
RH
MTR
LH
MTR
2A
FUSE
18VAC
DUO HSO BCK HLD
HSC2RMP TD HSC1
HOLDBKO IMP OPD
ORANGE YELLOW GREEN RED
1 2 3 4 5 6 7 8 9 10
11 12 13 14 15 16 17 18 19 20
IMP
0VDC
OPD
BC1
BC2
LOT
HLD
HNO
HNC
IHB
TB1
18VDC+
-0VDC
KILL
DONT USE
18VAC
TB2
-0VDC
-0VDC
18VAC
18VAC
BESAM
SWINGMASTER
CU2
J2 J3
SYNCH CUHUB INTERFACE
.... ............
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
..
..
RH
CAM
LH
CAM
RH
MTR
LH
MTR
2A
FUSE
18VAC
POWER
COM.
N.O.
0VDC
IHB
MOTOR INPUTS ADJ
RH RH RH RH
LH LH LH LH
JP1 JP2 JP3 R1
besam
ASSA ABLOY
LEFT HAND OUT SWING RIGHT HAND OUT SWING
DC
MOTOR
DC
MOTOR
