Installation Instructions
PED4000/PED5000 Series Exit Devices
Copyright © 2023, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
Electrical Wiring and Wire Routing for:
• M91 Prefix (Latch Monitor Switch)
• M93 Prefix (Exit Trim Lever Monitor Switch)
• M92 Prefix (Push Bar Signal Switch)
• M97 Prefix (Electric Dogging)
• 910/A, 930/A, 903/A, 905/A (Electromechanical Wide Exit Trim)

PED4000/PED5000 Series Exit Devices
Installation Manual
with optional connections
2FM575 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
Note: The M92, M91, M97, 910/A, 930/A, 903/A, 905/A, and M93 options are combined into this one
instruction.
TOC Table of Contents
1 Function .........................................................................3
2 General Description................................................................. 3
3 Specifications ....................................................................3
4 ElectroLynx Connector System Notes ..............................................4
5 Wire Routing.....................................................................5
6 PED4000/PED5000 Series Device Installation and Wiring Overview................ 16
7 M91 Prefix (Latch Monitor Switch) - Exit Device to Frame Connection ............. 17
8 M93 Prefix (Trim Monitor Switch) - Exit Device to Frame Connection .............. 18
9 M92 Prefix Push Bar (Signal Switch) - Exit Device to Frame Connection............. 19
10 M97 Prefix (Electric Dogging) - Exit Device to Frame Connection................... 20
11 910/A, 930/A, 903/A, 905/A (Electromechanical Exit Trim) -
Exit Device to Frame Connection ...................................................21
12 Appendix A: Harness Wiring Reconfiguration.......................................23

3
Installation Manual
with optional connections
PED4000/PED5000 Series Exit Devices
FM575 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
1Function
• The M92 prefix signal switch monitors the touch bar. When the rail is depressed or dogged, the switch is
de-activated.
• The M91 prefix latchbolt monitor switch provides positive indication of latchbolt extension or retraction
when the push rail is depressed, dogged or if the latch bolt itself is depressed.
• When the M97 PE series exit device is energized and the rail is depressed, it will continuously hold the push
rail down and latch in an unlocked (dogged) position. When the device is de-energized (or power is inter-
rupted), the latch will extend.
• 910/A, 930/A, 903/A, 905/A Electromechanical Trims
• M93 prefix signal switch monitors the outside lever. When the lever is rotated, the switch is deactivated.
2General Description
This instruction manual includes wiring instructions for all Premium Exit (PE) Series Electrified Exits Options to
ElectroLynx connector system. The correct wiring configuration must be selected depending on type and function
of the product being installed. Refer to table of contents to select appropriate wiring instruction for product op-
tions being installed. Options/prefixes can be combined and wired together, as ordered.
Caution: The DC voltage applied to the electromechanical exit trim must not exceed 30VDC. If the voltage
exceeds 30VDC the motor may be damaged.
3Specifications
Motor
Type: 12 or 24VDC, Intermittent or Continuous Duty
Current draw is 400mA inrush / 15mA continuous @12VDC / 24VDC
Caution: Disconnect all input power before beginning installation to prevent electrical shock and
equipment damage. All wiring must comply with applicable local electrical codes, ordinances and
regulations. Installer must be a trained, experienced service person.
Fail Safe Models: Fail Secure Models:
910/A without cylinder 930/A without cylinder
903/A with cylinder 905/A with cylinder
Electromechanical Exit Trim
M91 prefix (latch monitor switch)
M93 prefix (exit trim lever monitor switch)
M92 prefix (push bar signal monitor switch)
M97 prefix (electric dogging) Electromagnet current: 200mA @ 24VDC
M91, M93, and M92 switch contact rating: 1A max @ 30VDC

PED4000/PED5000 Series Exit Devices
Installation Manual
with optional connections
4FM575 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
4ElectroLynx Connector System Notes
The system is designed to be installation friendly with quick connectors from the electric hinge
through the door to the rail. The only wiring required is to the loose wires on the pigtail harness
assembly on the frame side of the electric hinge.
Important: The plug and receptacle connectors are designed to mate and lock together as shown in
the figure. Plug the connectors into each other with the locking mechanism aligned as indicated.
Do not force connectors on any other way.
Plug
Locking mechanism
Receptacle
1. With new applications, a raceway harness with 8 and 4 pin connectors will be pre-installed inside door by ASSA
ABLOY door manufacturer when specified during the ordering process. Raceway harness kits are also available
for retrofit applications.
2. If door does not have a raceway harness with connectors, cut connectors off product, or consult factory for
raceway retrofit kit.
3. Wiring to pigtail harness is per facility wiring requirement. The rail, raceway, electric hinge and pigtail connec-
tor terminations and wire colors all match.
These notes apply to all of the following devices concerning the installation and wiring to the
ElectroLynx Connector System

5
Installation Manual
with optional connections
PED4000/PED5000 Series Exit Devices
FM575 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
5Wire Routing
PED4600
OVERVIEW
M91 Connection
Step 1. Install mortise lock. Route wire
as shown.
M93 Lever Monitoring
(if applicable)
M91 Connection
Electric Trim
(If applicable)
Step 2. Route trim wires as shown.
M93 Lever Monitoring
(if applicable)
Electric Trim
(If applicable)
Electric Trim
(If applicable)
M91 Connection
M93 Lever Monitoring
(if applicable)
Step 3. Install chassis and rail.
Make wire connections.
Step 4. Pull back excess wire
through rail. Route wires as
shown. Install wire clip.
Wire Clip

PED4000/PED5000 Series Exit Devices
Installation Manual
with optional connections
6FM575 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
PED4800
OVERVIEW
5Wire Routing - continued
Electric Trim
(If applicable)
M93 Lever Monitoring
(if applicable)
M91 Connection

7
Installation Manual
with optional connections
PED4000/PED5000 Series Exit Devices
FM575 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
Step 2. Route wires through chassis
as shown and secure chassis to door.
Step 3. Install rail. Step 4. Make wire connections.
5Wire Routing - continued
Electric Trim
(If applicable)
M93 Lever Monitoring
(if applicable)
Step 1. Route wires as shown and secure trim to door.
Step 5. Pull back excess wire
through rail. Route wires as
shown. Install wire clips.
PED4800
M91 Connection

PED4000/PED5000 Series Exit Devices
Installation Manual
with optional connections
8FM575 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
PED4200
OVERVIEW
5Wire Routing - continued
Step 3. Pull additional wire slack through rail
from insert end and tuck latch bolt monitor (M91)
connection into chassis.
Step 2. Secure trim. Make M91 connection.
Step 1. Install chassis to rail.
Route wires through door as shown.
Electric Trim
(If applicable)
M93 Lever Monitoring
(if applicable)
M91 Connection

9
Installation Manual
with optional connections
PED4000/PED5000 Series Exit Devices
FM575 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
PED5800
OVERVIEW
5Wire Routing - continued
Electric Trim
(If applicable)
M93 Lever Monitoring
(if applicable)
Electric Trim
(If applicable)
M91 Connection

PED4000/PED5000 Series Exit Devices
Installation Manual
with optional connections
10 FM575 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
5Wire Routing - continued
M91 Connection
Electric Trim
(If applicable)
M93 Lever Monitoring
(if applicable)
Step 1. Route wires as shown and
secure trim to door.
Step 2. Install chassis (Section 4) and route wires
through chassis as shown.
Main Slide & Roller
Step 3. Install rail. Step 4. Make wire connections. Step 5. Snap trim jumper to clip
and route excess wire as shown.
Step 6. Tuck wire connections along side of
main slide. Pull back excess wire through rail.
PED5800

11
Installation Manual
with optional connections
PED4000/PED5000 Series Exit Devices
FM575 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
5Wire Routing - continued
PED5400
OVERVIEW
Electric Trim
(If applicable)
M93 Lever Monitoring
(if applicable)
M91 Connection

PED4000/PED5000 Series Exit Devices
Installation Manual
with optional connections
12 FM575 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
5Wire Routing - continued
Step 1. Install chassis and rail. Route trim wires from rail
under brass lift lever as shown.
Step 2. Make M91 connection.
M93 Lever Monitoring
(if applicable)
Electric Trim
(If applicable)
M91 Connections
Step 3. Route trim wires through chassis and door as shown. Step 4. Make trim wire connections and secure trim to door.
Pull back excess wire through rail.
M93 Lever Monitoring
(if applicable)
Electric Trim
(If applicable)
Brass lift lever
PED5400

13
Installation Manual
with optional connections
PED4000/PED5000 Series Exit Devices
FM575 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
5Wire Routing - continued
M93 Lever Monitoring
(If applicable)
Step 3. Connect wires and secure trim to door.
PED5200
OVERVIEW
M91 Connection
Electric Trim
(If applicable)
Optional Trim
Wire Route
M93 Lever Monitoring
(if applicable)
Electric Trim
(If applicable)
Step 1. Install chassis and rail. Step 2. Route trim wires through chassis and
door as shown above.
Step 2A. Additional view
Electric Trim
(If applicable)

PED4000/PED5000 Series Exit Devices
Installation Manual
with optional connections
14 FM575 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
5Wire Routing - continued
PED5600
OVERVIEW
M93 Lever Monitoring
(if applicable)
Electric Trim
(If applicable)
M91 Connection
Step 2. Install chassis and connect M91
jumper at chassis.
Step 3. Install rail to chassis.
Step 1. Install mortise lock. Route
wire as shown.

15
Installation Manual
with optional connections
PED4000/PED5000 Series Exit Devices
FM575 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
5Wire Routing - continued
Step 4. Make wire connections.
Electric Trim
(If applicable)
M93 Lever Monitoring
(if applicable)
M91 Jumper
Step 5. Secure trim to door.
Step 6. Pull back excess wire through rail.
PED5600

PED4000/PED5000 Series Exit Devices
Installation Manual
with optional connections
16 FM575 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
6PE Series Installation and Wiring Overview
ElectroLynx System Wiring Options
QC12 Hinge (12 wires)
Pluggable 8-pin & 4-pin connectors
Close up of end bracket
(with metal tab for P5 Installation)
P5 connector (EGND) -Plug this into
the end bracket’s metal tab.
42
3 1
1
75
64
3
2
8
8, Yellow (55- NC)
4-pin
8-pin
Rail to Hinge Harness
(with 8-pin, 4-pin, & 22-pin connectors )
ElectroLynx Field
Wiring Termination
Options
(12 wires max)
8, Yellow (55- NC)
4, Tan (54- NO)QC12 HingePremium Electrified
Exit Rail Assembly
Door Harness
3" Typical
QC12 Hinge Pigtail
or
15' Frame Harness
22-pin
Premium Electrified
Exit Rail Assembly
Door Harness
3" Typical
QC12 Hinge
QC12 Hinge Pigtail
or
15' Frame Harness
Lorem ipsum
42
3 1
1
75
64
3
2
8
4-pin
8-pin
(with 8-pin, 4-pin, & 22-pin connectors )
22-pin
1, Black (M97 PWR-)
2, Red (M97 PWR+ 24VDC)
3, White (M91 COM)
4, Green (M91 NO)
5, Orange (M91 NC)
6, Blue (M92 COM)
7, Brown (M92 NO)
8, Yellow (M92 NC)
1, Violet (ET-)
2, Gray (ET+)
3, Pink (M93 COM)
4, Tan (M93 NO)
1, Black (M97 PWR-)
2, Red (M97 PWR+ 24VDC)
3, White (M91 COM)
4, Green (M91 NO)
5, Orange (M91 NC)
6, Blue (M92 COM)
7, Brown (M92 NO)
8, Yellow (M92 NC)
1, Violet (ET-)
2, Gray (ET+)
3, Pink (M93 COM)
4, Tan (M93 NO)

17
Installation Manual
with optional connections
PED4000/PED5000 Series Exit Devices
FM575 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
ElectroLynx System Wiring Options
QC12 Hinge (12 wires)
Pluggable 8-pin & 4-pin connectors
7M91Prefix (Latch Monitor Switch) - Exit Device to Frame Connection
NOTES:
• Switch contact rating: 1A @ 30VDC.
• Wires must be protected from abrasion.
• For use with class II circuits only.
• Wiring diagram indicates push bar
extended.
• The rail, raceway, electric hinge and pigtail
connector terminations and wire colors all
match.
Installation Instructions:
To insure trouble free operation, check that the push rail can be fully depressed. On vertical rod exit devices,
check that the latch bolts do not go into hold back position until the push rail is fully depressed.
1Mount exit device per instruction sheet provided.
Plug rail connector into raceway connector. Then feed through 1” hole in door. Install rail mounting bracket
with two screws supplied. Install rail insert and end cap.
Plug raceway connector into electric hinge connector, then feed through door prep. Mount electric hinge to
door.
Go to (A) if wiring now. Go to (B) if wiring is to be done later.
(A) Wire frame side wires to wires on pigtail harness as required using connectors allowed by local code.
Plug pigtail harness connector into electric hinge connector. Feed harnesses through frame prep and
mount electric hinge.
(B) Plug pigtail harness connector into electric hinge connector. Feed harnesses through frame prep and
mount electric hinge.
QC8
Raceway harness with 8
& 4 pin connectors. The
4-pin connectors are
not used or shown.
1” Ø wire hole
M91
2
M91 PED4000/PED5000 Series
Rail with 8-pin connector
2
3
4
2
1
3
4

PED4000/PED5000 Series Exit Devices
Installation Manual
with optional connections
18 FM575 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
8M93 Prefix (Trim Monitor Switch) - Exit Device to Frame Connection
7. Test lock – M93 trim lever monitor switch monitors lever movement. Switch changes state when lever
is rotated.
1” Ø wire hole
M93 PED Series Rail with
8-pin connector
1
5
6
4
NOTES:
• Switch contact rating: 1A @ 30VDC.
• Wires must be protected from abrasion.
• For use with class II circuits only.
• Wiring diagram indicates push bar extended.
• Rail, raceway, electric hinge and pigtail connector
terminations and wire colors all match.
Mount exit device per instruction sheet provided.
2. From outside of door, route Electromechanical ET wire harness through chassis and door, then plug
3-pin connector into mating rail harness 3-pin connector.
3. Ensure wires are tucked in to avoid pinching wires by push bar or chassis mechanism.
Plug rail connector into raceway connector. Then feed through 1” hole in door. Install rail mounting
bracket with two screws supplied. Install rail insert and end cap.
Plug raceway connector into electric hinge connector, then feed through door prep. Mount electric
hinge to door.
Go to (A) if wiring now. Go to (B) if wiring is to be done later:
Installation Instructions:
1
5
4
6
(A) Wire frame side wires to wires on pigtail harness as required using connectors allowed by local code.
Plug pigtail harness connector into electric hinge connector. Feed harnesses through frame prep and
mount electric hinge.
(B) Plug pigtail harness connector into electric hinge connector. Feed harnesses through frame prep and
mount electric hinge.
Connect
4-pin connector
to QC12
Hinge 4-pin
connector
1, Violet (ET-)
2, Gray (ET+)
3, Pink (M93 COM)
4, Tan (M93 NO)
QC12 Hinge Pigtail or
15' Frame Harness
Note: The Electromechanical ET
mounts on other side of door
behind the chassis (ET not shown)
5, Green (M93 NC)
4, Yellow (M93 NO)
3, Orange (M93 COM)
Rail
M93 PED4000/PED5000 Series
Rail with 8-pin connector
Wire M93 switch (COM & NO) contacts to monitor
device as required. Note: If M93 NC contact is
required, refer to Appendix A instruction.

19
Installation Manual
with optional connections
PED4000/PED5000 Series Exit Devices
FM575 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
9M92 Prefix Push Bar (Signal Switch) - Exit Device to Frame Connection
M92 PE Series (Signal Switch) Installation and Wiring
NOTES:
• Switch contact rating: 1A @ 30VDC.
• Wires must be protected from abrasion.
• For use with class II circuits only.
• Wiring diagram indicates push bar
extended.
• The rail, raceway, electric hinge and pigtail
connector terminations and wire colors all
match.
Installation Instructions:
To insure trouble free operation, check that the push rail can be fully depressed. On vertical rod exit devices,
check that the latch bolts do not go into hold back position until the push rail is fully depressed.
1Mount exit device per instruction sheet provided.
Plug rail connector into raceway connector. Then feed through 1” hole in door. Install rail mounting bracket
with two screws supplied. Install rail insert and end cap.
Plug raceway connector into electric hinge connector, then feed through door prep. Mount electric hinge to
door.
Go to (A) if wiring now. Go to (B) if wiring is to be done later.
(A) Wire frame side wires to wires on pigtail harness as required using connectors allowed by local code.
Plug pigtail harness connector into electric hinge connector. Feed harnesses through frame prep and
mount electric hinge.
(B) Plug pigtail harness connector into electric hinge connector. Feed harnesses through frame prep and
mount electric hinge.
QC8
Raceway harness with 8
& 4 pin connectors. The
4-pin connectors are
not used or shown.
Mounting Bracket
1” diameter
wire hole
M92
M92 PED4000/PED5000 Series
Rail with 8-pin connector
2
2
3
4

PED4000/PED5000 Series Exit Devices
Installation Manual
with optional connections
20 FM575 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
10 M97Prefix Electric Dogging - Exit Device to Frame Connection
1” diameter
wire hole
Maintained
Dry Contact
Switch or Relay
For Fire Door
Applications, use
normally closed
(NC) Fire Alarm
Contacts
To 24VDC
Regulated
Power Supply
-24VDC Pigtail harness
with 8-pin connector
Red (+), 2
Black (-), 1
Installation Instructions:
To insure trouble free operation, check that the push rail can be fully depressed. On vertical rod exit devices,
check that the latch bolts do not go into hold back position until the push rail is fully depressed.
1Mount exit device per instruction sheet provided.
Plug rail connector into raceway connector. Then feed through 1” hole in door. Install rail mounting bracket
with two screws supplied. Install rail insert and end cap.
Plug raceway connector into electric hinge connector, then feed through door prep. Mount electric hinge to
door.
Go to (A) if wiring now. Go to (B) if wiring is to be done later.
(A) Wire frame side wires to wires on pigtail harness as required using connectors allowed by local code.
Plug pigtail harness connector into electric hinge connector. Feed harnesses through frame prep and
mount electric hinge.
(B) Plug pigtail harness connector into electric hinge connector. Feed harnesses through frame prep and
mount electric hinge.
2
3
4
• Electromagnet current: 200mA @24VDC
• Wires must be protected from abrasion
• For use with Class II circuits only
• Wiring diagram indicates push bar extended
• Rail, raceway, electric hinge and pigtail connector
terminations and wire colors all match
Raceway harness with
8- & 4-pin connectors.
The 4-pin connectors
are not used or shown.
QC8
Electric Hinge with
8-pin connectors
M97 PED4000/PED5000
Series Rail with 8-pin
connector
8642
7531
Note: Typical raceway location is shown.
Other locations may exist depending on
door type.
NOTES:
1
4
3
2
