Asus ROG PHONE 07 User manual

E21471
First Edition
Model: ASUS_AI2205_E
ASUS_AI2205_F

First Edition / April 2023
ASUS Phone (Mobile Phone)
Model: ASUS_AI2205_E / ASUS_AI2205_F
Front features
Before you start, ensure that you have read all the safety
information and operating instructions in this User Guide to
prevent injury or damage to your device.
NOTES:
• For the complete E-Manual and more detailed
information, refer to https://www.asus.com/support/.
• Illustrations are for reference only. Actual product
appearance may vary.
Nano-SIM1
Nano-SIM2
Touch screen
display
Receiver & Speaker
Front camera
Proximity sensor
and light sensor
Fingerprint
sensor
LED
indicator
Speaker

Side features
AirTrigger
touch sensor
Power key
Volume key
AirTrigger
touch sensor
Microphone
Nano SIM card slot
Nano SIM card
tray eject hole
USB Type-C port
Pogo Pin
Microphone
USB Type-C port Audio jack
Microphone
Rear features
ASUS_AI2205_E
Rear cameras
Rear cover
NFC
detection
area
Camera ash

NOTES:
• The USB Type-C port supports USB 2.0 transfer rate.
• Go to Settings > Advanced > AirTriggers to set
AirTriggers.
Rear cameras
Rear cover
NFC
detection
area
Camera ash
Second Screen
ASUS_AI2205_F

NOTES:
• For safety purposes, use ONLY the bundled power adapter
and cable to avoid damaging your device and prevent the
risk of injury.
• For safety purposes, use ONLY the bundled power adapter
and cable to charge your ROG Phone.
• The input voltage range between the wall outlet and this
adapter is AC 100V - 240V. The output voltage of the AC
power adapter for this device is +5V-20V 3.25A, 65W. The
charger brand/model is DELTA/ADP-65VW B & AOHAI/A320R-
200325C-US, which supports fast charging mode.
IMPORTANT!
• When using your ROG Phone while it is plugged to a power
outlet, the grounded power outlet must be near to the unit
and easily accessible.
• When charging your ROG Phone through your computer,
ensure that you plug the USB Type-C cable to your
computer’s USB port.
• DO NOT charge your ROG phone underwater or when the
USB connector is wet.
• Avoid charging your ROG Phone in an environment with
ambient temperature of above 35 °C (95 °F).
Charging your ROG Phone
NOTES:
• We recommend that you charge your ROG phone through
one USB Type-C port at a time.
• Only the USB Type-C port on the left side of your ROG
Phone has DisplayPort functionality.
• If you connect USB Type-C OTG or charging devices to
both of the USB Type-C ports on your ROG Phone, the
USB Type-C port on the left side of your ROG Phone will
become the master and the charging current or OTG
device on the bottom port will be limited.

Federal Communications Commission
Statement
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
Changes or modications not expressly approved by the party
responsible for compliance could void the user‘s authority to
operate the equipment.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the user
is encouraged to try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for
help.
The antenna(s) used for this transmitter must not be co-located or
operated in conjunction with any other antenna or transmitter.
The country code selection is for non-US models only and is not
available to all US models. Per FCC regulation, all WiFi products
that are marketed in US must be xed to US-operated channels
only.
The responsible party within the USA per 47 CFR Part 2.1077(a)(3):
ASUS COMPUTER INTERNATIONAL (America)
Address: 48720 Kato Rd., Fremont, CA 94538, USA
Telephone: [phone]

RF Exposure Information (SAR)
This device has been tested and meets applicable limits for Radio
Frequency (RF) exposure.
Specic Absorption Rate (SAR) refers to the rate at which the body
absorbs RF energy. SAR limits are 1.6 Watts per kilogram (over a
volume containing a mass of 1 gram of tissue) in countries that
follow the United States FCC limit and 2.0 W/kg (averaged over
10 grams of tissue) in countries that follow the Council of the
European Union limit. Tests for SAR are conducted using standard
operating positions with the device transmitting at its highest
certied power level in all tested frequency bands.
To reduce exposure to RF energy, use a hands-free accessory or
other similar option to keep this device away from your head
and body. Carry this device at least 15 mm away from your
body to ensure exposure levels remain at or below the as-tested
levels. Choose the belt clips, holsters, or other similar body-worn
accessories which do not contain metallic components to support
operation in this manner. Cases with metal parts may change
the RF performance of the device, including its compliance with
RF exposure guidelines, in a manner that has not been tested or
certied, and use such accessories should be avoided.
The highest FCC SAR values for the device
(ASUS_AI2205_E / ASUS_AI2205_F) are as follows:
• 1.18 W/Kg @1g(Head)
• 1.19 W/Kg @1g(Body)
The FCC has granted an Equipment Authorization for this device
with all reported SAR levels evaluated as in compliance with the
FCC RF exposure guidelines. SAR information on this device is
on le with the FCC and can be found under the Display Grant
section of www.fcc.gov/oet/ea/fccid after searching on FCC ID:
MSQAI2205.
FCC Statement (HAC)
This phone has been tested and rated for use with hearing aids
for some of the wireless technologies that it uses. However, there
may be some newer wireless technologies used in this phone that
have not been tested yet for use with hearing aids. It is important
to try the dierent features of this phone thoroughly and in
dierent locations, using your hearing aid or cochlear implant, to
determine if you hear any interfering noise. Consult your service
provider or the manufacturer of this phone for information on
hearing aid compatibility. If you have questions about return or
exchange policies, consult your service provider or phone retailer.
The Federal Communications Commission has implemented rules
and a rating system designed to enable people who wear hearing
aids to more eectively use these wireless telecommunications
devices. The standard for compatibility of digital wireless phones
with hearing aids is set forth in American National Standard
Institute (ANSI) standard C63.19-2011. There are two sets of ANSI
standards with ratings from one to four (four being the best
rating): an “M” rating for reduced interference making it easier

to hear conversations on the phone when using the hearing aid
microphone, and a“T” rating that enables the phone to be used
with hearing aids operating in the telecoil mode thus reducing
unwanted background noise.
The Hearing Aid Compatibility rating is displayed on the wireless
phone box.
A phone is considered Hearing Aid Compatible for acoustic
coupling (microphone mode) if it has an“M3” or “M4” rating. A
digital wireless phone is considered Hearing Aid Compatible for
inductive coupling (telecoil mode) if it has a“T3” or “T4” rating.
The tested M-Rating and T-Rating for this device (ASUS_AI2205_E
/ ASUS_AI2205_F) are M3 and T3.
You’ll want to try a number of wireless phones so that you can
decide which works the best with your hearing aids. You may also
want to talk with your hearing aid professional about the extent
to which your hearing aids are immune to interference, if they
have wireless phone shielding, and whether your hearing aid has
a HAC rating.
Prevention of Hearing Loss
To prevent possible hearing damage, do not listen at high volume
levels for long periods.
For France, headphones/earphones for this device are compliant
with the sound pressure level requirement laid down in the
applicable EN 50332-1:2013 and/or EN50332-2:2013 standard
required by French Article L.5232-1.
Safety information
CAUTION! Use of controls or adjustments or performance
of procedures other than those specied herein may result in
hazardous radiation exposure.
ROG Phone care
• Use your ROG Phone in an environment with ambient
temperatures between 0 °C (32 °F) and 35 °C (95 °F).

The battery
WARNING: Disassembling the battery by yourself will void its
warranty and may cause serious harm.
Your ROG Phone is equipped with a high performance non-
detachable Li-polymer battery. Observe the maintenance
guidelines for a longer battery life.
• Do not remove the non-detachable Li-polymer battery as
this will void the warranty.
• Avoid charging in extremely high or low temperature. The
battery performs optimally in an ambient temperature of +5
°C to +35 °C.
• Do not remove and replace the battery with a non-approved
battery.
• Use only ASUS battery. Using a dierent battery may cause
physical harm/injury and may damage your device.
• Do not remove and soak the battery in water or any other
liquid.
• Never try to open the battery as it contains substances that
might be harmful if swallowed or allowed to come into
contact with unprotected skin.
• Do not remove and short-circuit the battery, as it may
overheat and cause a re. Keep it away from jewelry or metal
objects.
• Do not remove and dispose of the battery in re. It
could explode and release harmful substances into the
environment.
• Do not remove and dispose of the battery with your regular
household waste. Take it to a hazardous material collection
point.
• Do not touch the battery terminals.
• To avoid re or burns, do not disassemble, bend, crush, or
puncture the battery.
NOTES:
• Risk of explosion if battery is replaced by an incorrect type.
• Dispose of used battery according to the instructions.
The charger
• Use only the charger supplied with your ROG Phone.
• Never pull the charger cord to disconnect it from the power
socket. Pull the charger itself.
Caution
Your ROG Phone is a high quality piece of equipment. Before
operating, read all instructions and cautionary markings on the
AC Adapter.

• Do not use the ROG Phone in an extreme environment where
high temperature or high humidity exists. The ROG Phone
performs optimally in an ambient temperature between 0 °C
(32 °F) and 35 °C (95 °F).
• Do not disassemble the ROG Phone or its accessories. If
service or repair is required, return the unit to an authorized
service center. If the unit is disassembled, a risk of electric
shock or re may result.
• Do not short-circuit the battery terminals with metal items.
• The EUT will automatically stop operating beyond the lesser
temperature range. (When the temperature is lower than
-10 °C (14 °F), the EUT will shut down automatically.)
Operator access with a tool
If a TOOL is necessary to gain access to an OPERATOR ACCESS
AREA, either all other compartments within that area containing
a hazard shall be inaccessible to the OPERATOR by the use of the
same TOOL, or such compartments shall be marked to discourage
OPERATOR access.
ASUS Recycling/Takeback Services
ASUS recycling and takeback programs come from our
commitment to the highest standards for protecting our
environment. We believe in providing solutions for you to be able
to responsibly recycle our products, batteries, other components
as well as the packaging materials. Please go to
http://csr.asus.com/english/Takeback.htm for detailed recycling
information in dierent regions.

Proper disposal
Risk of explosion if battery is replaced by an
incorrect type. Dispose of used batteries according
to the instructions.
DO NOT throw the battery in municipal waste. The
symbol of the crossed out wheeled bin indicates
that the battery should not be placed in municipal
waste.
DO NOT throw this product in municipal waste.
This product has been designed to enable proper
reuse of parts and recycling. The symbol of
the crossed out wheeled bin indicates that the
product (electrical, electronic equipment and
mercury-containing button cell battery) should
not be placed in municipal waste. Check local
regulations for disposal of electronic products.
DO NOT throw this product in re. DO NOT short
circuit the contacts. DO NOT disassemble this
product.
NOTE: For more legal and e-labelling information, check on
your device from Settings > System > Regulatory labels and
Settings > System > About Phone> Legal Information.

Copyright © 2023 ASUSTeK COMPUTER INC.
All Rights Reserved.
You acknowledge that all rights of this Manual remain with ASUS. Any and
all rights, including without limitation, in the Manual or website, and shall
remain the exclusive property of ASUS and/or its licensors. Nothing in this
Manual intends to transfer any such rights, or to vest any such rights to you.
ASUS PROVIDES THIS MANUAL“AS IS”WITHOUT WARRANTY OF ANY KIND.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE
FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE
AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A
COMMITMENT BY ASUS.
ASUS
Address: 1F., No.15, Lide Rd., Beitou Dist., Taipei City 112
Tel: [phone]
Fax: [phone]
Declaration
We declare that the IMEI codes for this product, ROG Phone,
are unique to each unit and only assigned to this model. The
IMEI of each unit is factory set and cannot be altered by the
user and that it complies with the relevant IMEI integrity related
requirements expressed in the GSM standards.
Should you have any questions or comments regarding this
matter, please contact us.
Sincerely yours,
ASUSTeK COMPUTER INC.
Tel: [phone]
Fax: [phone]
Support: https://www.asus.com/support/
ZenTalk Fans Forum
(http://www.asus.com/zentalk/global_forward.php)

FCC COMPLIANCE INFROMATION
Per FCC Part 2 Section 2.1077
Responsible Party:
Asus Computer International
Address: 48720 Kato Rd, Fremont, CA 94538
Phone/Fax No: [phone]/[phone]
hereby declares that the product
Product Name :
ASUS Phone (Mobile Phone)
Model Number :
ASUS_AI2205_E/ ASUS_AI2205_F
compliance statement:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
Ver. 180620

ASUS Warranty Information Form
IMPORTANT! Please store this card in a secured location for future
reference. ASUS reserves the right to request this document
before accepting repair requests. This does not aect or limit your
mandatory statutory rights. Please ll in your product information
in the form and attach the product serial number sticker into the
box below.
Mr/Mrs./Ms/Miss: ____________________________________________
Telephone Number: _________________________________________
Address: ___________________________________________________
___________________________________________________________
E-mail: ____________________________________________________
Purchase Date: ______ /______ / ______ (DD/MM/YYYY)
Dealer's Name: _____________________________________________
Dealer's Telephone Number: __________________________________
Dealer's Address: ___________________________________________
Serial Number:
A. Product Warranty Period and Notice:
1. This warranty ("Commercial Warranty Period") applies for the
same period as the Legal Warranty period regulated by the local
government. This warranty begins at the date of delivery that
is shown on the proof of purchase ("Delivery Date"). If proof of
purchase cannot be provided, the manufacture date as recorded by
ASUS will be deemed to be the start of the Warranty Period.
2. Accessories delivered together with the product are not covered
under the warranty.
3. Please fully back up all the data stored on your product and remove
any personal, condential, or proprietary information before
requesting any warranty service process. ASUS may delete any data,
software, or programs installed on your product without restoring or
transferring them. ASUS shall not be held liable for the permanent
loss, damage, or misuse of your data.
B. Exclusions from the Warranty Service:
(a) Damage caused to this Product(s) by you or any non-authorized
third party;
(b) The serial number of the Product, components or accessories has
been altered, cancelled or removed;
(c) The warranty seals have been broken or altered;
(d) Obsolescence;
(e) Damage (accidental or otherwise) to the product that does not
impact the product’s operation and functions, such as without
limitation to rust, change in color, texture or nish, wear and tear,
and gradual deterioration;
(f) Damage to the Product caused by war, terrorism, re, accident,
natural disaster, intentional or accidental misuse, abuse, neglect or
improper maintenance, and use under abnormal conditions;
(g) Damage to the product caused by an external electrical fault or any
accident;
(h) Damage to the product resulting from use outside of the operation,
storage parameters, or environment detailed in the User’s Manual;

(i) Damage to the product caused by third party software or virus(es);
or there is software loss or data loss that may occur during repair or
replacement;
(j) Unusability of or damage to the product caused by contamination
with hazardous substances, diseases, vermin, or radiation;
(k) Fraud, theft, unexplained disappearance, or damages / detrimental
circumstances caused by a willful act of the customer; and
(l) Unusability or damage to hardware of the product caused by
installing and using any kind of the Unlock Device App, which is a
utility that will unlock your product’s boot loader but will render the
warranty null and void.
C. Out-of-Warranty Cases: If the warranty period has lapsed or if any
of the exclusions above apply, your request will be deemed out of
warranty and a charge will incur on it.
D. Warranty and Support: The warranty service may vary by country.
If you make a purchase in the European Union, European Economic
Area, Switzerland or certain countries in the Western Balkans, ASUS
supports warranty service within warranty period in the countries
above. Some countries may have fees, restrictions or additional
documentation needed on the warranty service.
E. Abandon Property: After your product has been repaired, or if you
reject the repair, ASUS will notify you to pick up your product. If
you fail to do it within a period of 90 days from ASUS’ notice, ASUS
reserves the right to (i) dispose the product in accordance with
the applicable laws and regulations; (ii) claim damages from you,
including costs associated with storage, disposal of the product and
any statutory right of lien for unpaid charges.
F. Privacy: ASUS conduct privacy practices on your personal data in
compliance with ASUS Privacy Policy: Visit http://www.asus.com/
Terms_of_Use_Notice_Privacy_Policy/Privacy_Policy/ for further
information.
ASUS reserves the right to interpret the provisions of ASUS Warranty
Information. The information in this ASUS Warranty Information
Form may change without prior notice. To read the entire warranty
information, please scan the QR code, visit ASUS Support at http://
qr.asus.com/support, or visit the ASUS website for the country of
purchase.
ASUS contact details
This warranty is provided by:
ASUSTeK Computer Inc.
1F., No. 15, Lide Rd., Beitou Dist.,
Taipei City 112
Phone: [phone]

15060-25G50000
