ATD Tools ATD-7447 Instructions for use

Model ATD-7447 Model ATD-7449
Capacity per pair
10 Ton
22 Ton
Model Number
ATD-7447
ATD-7449
Pin Style
Jack Stands
Operating Instructions & Parts Manual
Printed in China
ATD7447_ATD7449_rev_0417
WARNING: This product may contain chemicals, including lead, known to the State of California to cause cancer,
birth defects or other reproductive harm. Wash hands after handling.
Made in China to ATD Tools, Inc. Specications
Visit us at www.atdtools.com

2
SPECIFICATIONS
For your safety, read, understand, and follow the information provided with and on these jack stands. The owner
and operator shall have an understanding of these jack stands and safe operating procedures before attempting
to use. The owner and operator shall be aware that use of this product may require special skills and knowledge.
Instructions and safety information shall be conveyed in the operator’s native language before use of these stands
is authorized. Make certain that the operator thoroughly understands the inherent dangers associated with the use
and misuse of the product. If any doubt exists as to the safe and proper use of the jack stands, remove from service
immediately. Inspect before each use. Do not use if there are broken, bent, cracked or damaged parts (including
labels). Any jack stand that appears damaged in any way, or operates abnormally shall be removed from service
immediately. If the jack stand has been or is suspected to have been subjected to a shock load (a load dropped
suddenly, unexpectedly upon it), immediately discontinue use until jack stand has been inspected by a factory
authorized service center. It is recommended that an annual inspection be done by quali¿ed personnel. Labels and
Operator’s Manuals are available from manufacturer.
PRODUCT DESCRIPTION
ATD Tools Heavy-Duty Pin Style Jack Stands are designed to safely support one end of level, rated capacity loads,
typically vehicles, for extended periods. Heavy gauge steel base section and welded construction helps prevent
distortion and twisting. Compliance with the latest ASME / ANSI - PALD standards ensure safety, strength and
stability.
RATED CAPACITY IS PER PAIR ONLY! USE ONLY ONE PAIR PER VEHICLE.
DO NOT USE FOR ANY PURPOSE OTHER THAN THOSE USES OUTLINED ABOVE !
Figure 2 - Model ATD-7449 componentsFigure 1 - Model ATD-7447 components
Height
Adjustment
Holes
Saddle
Extension Tube
Collar
Base Section
Roll Pin
Extension Tube
Support Bar
Lanyard
Support Bar Holder
Saddle
Extension Tube
Handle
Base
Extension Tube
Support Bar
Lanyard
Support Bar Holder
Collar
Height
Adjustment
Holes
Corresponding Radii
Model Capacity
(per pair) Base Size Min. Height Max. Height Saddle Size
3-3/8” x 5”
3-1/8” x 2-3/4”
Net Weight
ATD-7447 10 Ton 16" x 16" 28" 47" 120 lbs.
ATD-7449 22 Ton 9-7/8" x 9-7/8" 12-1/4" 19-7/8" 65 lbs.

3
!WARNING
Study, understand and follow all instructions
provided with and on this device before use.
Rated capacity is per pair! Do not exceed rated
capacity.
Use only on hard, level surface.
Center load on saddle.
Use as a matched pair to support one end of a
vehicle only. One pair per vehicle only.
Jack stands are not to be used to simultaneously
support both ends or one side of a vehicle.
No alterations shall be made to this device.
Failure to heed these markings may result in
personal injury and/or property damage.
BEFORE USE
1. Inspect stands before each use. Do not use if bent,
broken or cracked components are noted. Ensure
that all parts move freely.
2. Verify that the product and the application are
compatible, if in doubt call for Technical Service
[phone].
3.Beforeusingthis product,read theoperator’smanual
completely and familiarize yourself thoroughly with
the product and the hazards associated with its
improper use.
4. Insert roll pin into the bottom hole of the extension
tubetopreventinadvertentloss oftheextension tube.
Model ATD-7449 is pre-installed.
5. Always check the vehicle owners or service manual
for location of proper lift and support points.
OPERATION
IMPORTANT! Rated capacity is per pair. Use ONLY
one pair per vehicle. No alterations shall be made to
this device. Do not use adapters or accessories on the
saddle or base frame.
1.Adjust saddleheight bypulling upthe extension tube,
then insert the tube support bar through the hole on
extension tube.
2. For model ATD-7447:Ensure that support bar is
secure before loading. Insert support bar into the
extension tube far enough to create equal distance
of bar extending from the extension tube on both
sides.
For model ATD-7449:Check to ensure support bar
is secure and nested across 2 corresponding radii
before loading. Ensure that support bar is inserted
completely so that bar stop engages the collar.
3. Carefully position stands so that load is centered on
stand’s saddle.
4. Slowly lower the vehicle onto the stands.
5. Check to ensure that vehicle is secure before
working on, around or under. When used to support
vehicle, use wheel chocks to prevent inadvertent
movement.
To lower load
1. With suitable jack, raise vehicle clear of stands.
2. Carefully release support bar and allow extension
tube to glide down to lowest position.
3.Carefully remove stands,then carefullylower vehicle
with jack.
MAINTENANCE
To help prevent rust, wipe clean and/or blow dry after
each use. Do not apply oil or lubricant to ANY portion
of this product. Keep support bar in bar holder on base
section.
Note:Noreplacement partsareavailable forthisdevice.
Replace as matched pair only. To replace missing or
damaged labels and operator’s manuals, contact
Customer Service [phone].
!WARNING
Be sure all tools and personnel are clear before
lowering load.

4
ATD Tools, Inc.
160 Enterprise Drive
Wentzville, MO 63385
www.atdtools.com
ONE YEAR LIMITED WARRANTY
For a period of one (1) year from date of purchase, ATD Tools,Inc. will repair or replace, at its option, without charge,
any of its products which fails due to a defect in material or workmanship, or which fails to conform to any implied
warranty not excluded hereby.
Performance of any obligation under this warranty may be obtained by contacting your distributor or point of sale
for further instructions. Please retain your proof of purchase, as it will be needed for any claim.
Except where such limitations and exclusions are VSHFL¿FDOO\ prohibited by applicable law, (1) the CONSUMER'S
SOLEAND EXCLUSIVE REMEDYSHALLBE THE REPAIR OR REPLACEMENT OF DEFECTIVE PRODUCTSAS
DESCRIBEDABOVE, and (2)ATD Tools,Inc. SHALL NOTBE LIABLE FORANY CONSEQUENTIALOR INCIDEN-
TALDAMAGE OR LOSS WHATSOEVER, and (3) THE DURATION OFANYANDALLEXPRESSEDAND IMPLIED
WARRANTIES, INCLUDING WITHOUT LIMITATION,ANYWARRANTIES OF MERCHANTABILITYAND FITNESS
FOR A PARTICULAR PURPOSE, IS LIMITED TOA PERIOD OF ONE (1) YEAR FROM DATE OF PURCHASE.
Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply
to you. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you. This warranty gives you VSHFL¿F legal rights, and you may also have
other rights which vary from state to state.
