ATD Tools ATD-7462 User manual

1
Model: ATD-7462
Capacity: 2 Ton
Model Capacity Min.
Height
Max
Height
Compressed Dimensions Saddle
Diameter
Shipping
Weight
ATD-7462 2 Ton 5” 13” 12.25” x 4.25” x 5.125” 5-1/8” x 2” 7.9 Lbs.
Contents:
SAFETY & WARNING INFORMATION
OWNER’S MANUAL
This is the safety no a on
symbol. This symbol will no fy you
of any poten al injury hazards.
Please follow all instruc ons that
follow this symbol to avoid possible
injuries or death.
Indicates a hazardous
situa on. If proper steps are
not followed, death or
serious injury could result.
Page: 1.
2. Setup, Opera on & Preven ve Maintenance
3. Inspec on, Storage & Troubleshoo ng
4. Exploded View & Warranty Informa on
2-TON SCISSOR JACK
ATD7462_rev_0417
Made in China to ATD Tools, Inc. Specications
Visit us at www.atdtools.com
WARNING: This product may contain chemicals, including lead, known to the State of California
to cause cancer, birth defects or other reproductive harm. Wash hands after handling.

2
Model:ATD-7462
Capacity:2Ton
Before oper ng this device, be sure to read all content within this manual, ensuring that you understand the
oper ng procedures, maintenance requirements and all safety warnings. The owner and/or operator shall have
an understanding of the product, its opera ng characteris cs, and safety opera ng instruc ons before oper ng
this device. Safety informa on shall be emphasized and understood. If the operator is not Ňuent in English, the
product and safety instruc ons shall be read to and discussed with the operator in the operator’s n ve language
by the purchaser/owner or his designee, making sure that theoperator comprehends their contents.
xStudy, understand and follow all instruc ons before opera ng this device.
xDo not exceed the rated capacity stated.
xUse only on hard level surfaces.
xUse only for emergency re changing or for moun ng re chains.
xNever get beneath the vehicle when it is supported by the jack.
xIf the vehicle is pushed oīthe jack, discard jack. Do not reuse.
xLi only on areas of thevehicle as speciĮed by the vehicle manufacturer.
xNo alter ons shall be made to this product.
xThis jack should be used as an emergency device only.
xFailure to heed these markings may result in serious personal injury / property damage.
xPrior to each use, visual inspec on (See Pg. 3) shall be made to the device by checking for abnormal
condi ons, such as cracked welds, leaks, and damaged, loose, or missing parts.
xConsult the vehicle owner’s manual to determine the loca on of li points.
xAc vate hazard warning Ňashers and turn oīthe vehicle.
xBe sure to set the vehicle in park with the emergency brake on and wheels securely chocked in both
direc ons.
xBe sure that the vehicle and the jack are on a hard, level surface.
xFollow the re-changing procedures or re-chain moun ng procedures speciĮed in the vehicle
manufacturer’s owner’s manual.
xAch the handle assembly to the eyehole and use as a handle to raise and lower the jack.
xTurn the handle counter-clockwise to lower the jack to its lowest posi on.
xPosi on the jack under the speciĮed li point.
xBegin li ing by turning the handle assembly clockwise.
xEnsure that the saddle is in the correct posi on and located under a vehicle manufacturer designated
li ing point before vehicle contact has been made.
xLi only to the point that the desired outcome can be reached. Do not over extend this jack.
IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE
ACTIONS TO HELP PREVENT DANGEROUS SITUATIONS
SETUP
ASSEMBLY
LIFTING

3
Model:ATD-7462
Capacity:2Ton
ͻTurn the handle slowly counter-clockwise to lower the jack to its lowest posi on.
ͻDo not get under or let anyone get under the vehicle while lowering.
ͻOnce completely lowered, remove the unit and return it back to its storage loc on.
Lubrica on and Cleaning
xPeriodically clean and lubricate all moving parts and pivot points.
Damaged Equipment
Any jack that appearsto be damaged in anyway, is found to be worn, or operates abnormally SHALL BE REMOVED
FROM SERVICE. It is recommended that in this event, the jack be replaced. No repairs are authorized and no parts
Altera ons
Because of poten al hazards associated with this type ofequipment, no alter ons shall be made to the product.
Aachments and Adapters
xVisual inspec on shall be made before each use of the device by checking for abnormal condi ons, such
as cracked welds, leaks, and damaged, loose, or missing parts.
xOther inspec ons shall be made per product opera ng instruc ons.
xThis device shall be inspected immediately if the device is believed to have been subjected to an abnormal
load or shock. It is recommended that this inspec on be made byĂƋƵĂůŝĮĞĚƐĞƌǀŝĐĞĂŶĚƌĞƉĂŝƌĨĂĐŝůŝƚLJ
xOwners and/or operators should be aware that repair of this equipment may require specialized
knowledge and facili es. It is recommended that an annual inspec on of the product be madeby a
supplier’s speciĮed parts.
This Jack should be stored in a dry locĂƟon.
Symptom Possible Causes Solu on
The jack will not lower
completely.
1. The threadson the adjustment
rod may be bent not allowing the
jack to fully lower.
1. Transfer theweight to another
jack and replace the jack.
Jack will not hold the load. 1. Overall damage to the jack. 1. Replace the jack.
Jack will not rise. 1. Check to see if there is damage to
the adjustment rod.
2. Lubrica on needed on moving
components
1. Replace the jack
2. Lubricate moving partsand test
func on again.
Jack will not li the load. 1. The weight of the unit being li ed
is too high. 1. Decrease the weight of object being li ed or purchase a higher
capacity jack.
Jack arm will not lower. 1. The threads on the adjustment
rod may be bent not allowing the
jack to fully lower.
1. Replace the jack.
LOWERING
MAINTENANCE
INSPECTION
STORAGE
TROUBLESHOOTING
are available for this jack.
dŚĞƌĞĂƌĞŶŽĂƩĂĐŚŵĞŶƚƐŽƌĂĚĂƉƚĞƌƐĂǀĂŝůĂďůĞŽƌĂƵƚŚŽƌŝnjĞĚĨŽƌƵƐĞǁŝƚŚƚŚŝƐũĂĐŬŶLJƵƐĞŽĨĂƩĂĐŚŵĞŶƚƐŽƌ
adapters could result in property damage, injury or death.
ƋƵĂůŝĮĞĚƐĞƌǀŝĐĞĂŶĚƌĞƉĂŝƌĨĂĐŝůŝƚLJĂŶĚƚŚĂƚĂŶLJĚĞĨĞĐƟǀĞĚĞĐĂůƐŽƌƐĂĨĞƚLJůĂďĞůƐďĞƌĞƉůĂĐĞĚǁŝƚŚƚŚĞ

4
Model:ATD-7462
Capacity:2Ton
Part Number Description Qt’y
LB020-1 Handle Assembly 1
* Items not iden Įed by part number are not available for replacement.
WARRANTY INFORMATION
ONE YEAR LIMITED WARRANTY
For a periodof one(1) year from your purchase date, ATD Tools, Inc. willrepair or replace (at itsop on) without
charge, yourATDproduct if it was purchased newand theproduct has failed dueto adefect in material or workmanship
which you experienced duringnormal use of the product. This limited warranty is your exclusive remedy.
To access the beneĮts of this warranty, contact ATD at 1-844-364-9922 for conĮrma on thatthis warranty
applies. Therea er, you may be advised to return the product under warranty, freight prepaid, to the ATD service
department.
If this ATD product is altered, abused, misused, modiĮed, or undergoes service by an unauthorized technician, your
warranty will be void. We are not responsible for damage to ornamental designs you place on this ATD product and such
ornamenta on should not cover any warnings or instruc ons or they may void the warranty. This warranty does not
cover scratches, superĮcial dents, and other abrasions to the paint Įnish that occur under normal use.
Subject to the law in your state:
(1) Your sole and exclusive remedy is repair or replacement of the defec ve product as described above.
(2) ATD is not liable for any incidental damages, including but not limited to, lost proĮts and unforeseeable
consequences.
(3) The repair and replacement of thisproduct under the express limited warranty described aboveis your
exclusive remedy and is provided in lieu of all other warran es, express or implied. All other warran es,
including implied warran es and warran es of merchantability or Įtness for a par cular purpose are
disclaimed and, if disclaimer is prohibited, these warran es are limited to one year from your date of purchase
of this product.
Some states’ laws do not allow limited dura ons on certain implied warran es and some states’ laws do not allow
limita ons on incidental or consequen al damages. You should consult the lawin your state to determine how your
rights may vary. ATD Tools, Inc.
160 Enterprise Drive
Wentzville, MO 63385
Toll Free Service Number 1-844-364-9922
Printed In China
