ATD Tools ATD-7500 Instructions for use

Capacity: 3 Ton
1
Model: ATD-7500
ATD 3-Ton Jack Pack
Service Jack Model Number: ATD-7504
Capacity Min. Height Max Height
Jack Size
(L x W x H) Saddle Diameter Net Weight
3 Ton 5 3/8” 19 1/2” 26 3/4” x 13 3/8” x 7 1/4” 4 5/16” 78 LB
Jack Stands Model Number: ATD-7443
Capacity Min. Height Max Height Saddle Size Base (L x W) Net Weight
3 Ton 11-13/16” ”61/5-71 ”1x”2/1-3 BL157-11/16” x 6-15/16”
Contents:
Page: 1. Speci ca ons
2. Safety & Warning Informa on
3. 4. & 5. Setup, Opera on & Preven ve Maintenance
6. Inspec on, Storage & Troubleshoo ng
7. Exploded View & Replaceable Part Numbers
8. Warranty Informa on
O
p
era n
g
Instru ons & Parts Manual
- - - - --
ATD7500_rev_0417
Made in China to ATD Tools, Inc. Specications
Visit us at www.atdtools.com
WARNING: This product may contain chemicals, including lead, known to the State of California
to cause cancer, birth defects or other reproductive harm. Wash hands after handling.

Capacity:3Ton
2
Model: ATD-7500
SAFETY & WARNING INFORMATION
Before opera ng this device, be sure to read all content within this manual, ensuring that you
understand the opera ng procedures, maintenance requirementsand all safety warnings.
The owner and/or operator shall have an understanding of the product, its opera ng
characteris cs, and safety opera ng instruc ons before opera ng this device. Safety
informa on shall be emphasized and understood. If the operator is not uent in English, the
product and safety instruc ons shall be read to and discussed with the operator in the
operator’s na ve language by the purchaser/owner or his designee, making sure that the
operator comprehendstheir contents.
Study, understand, and follow all instruc ons before opera ng this device.
Do not exceedthe ratedcapacity stated.
Use only on hard level surfaces.
This jack is to be used as a li ing device only. Immediately a er li ing, support the
vehicle with appropriate means.
Do not move or dolly the vehicle while it is on the jack.
Li only on areas o he vehicle as speci ed by the vehicle manufacturer.
No altera ons shall be made to this product.
Jack Stands are designed to support stated capacity. Stands should only be usedto
support par al loads that consist of one end of avehicle. Always use as a matched pair
to support one end of avehicle only.
Never use jack stands tosupport both ends or one side of a vehicle.
Use only one (1) pair of stands per vehicle.
Rated capacity is per pair only.
Rated capacity of this pair is 6000 lbs.
Failure to heed these markings may result in serious personal injury and/orproperty
damage.
This is the safety n con
symbol. This symbol will n fy you
of any poten al injury hazards.
Please follow all instruc ons that
follow this symbol to avoid possible
injuries or death.
Indicates a hazardous
situa on. If proper steps are
not followed, death or
serious injury could result.
IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE
ACTIONS TO HELP PREVENT DANGEROUS SITUATIONS
WARNING
WARNING

Capacity:3Ton
3
Model: ATD-7500
SETUP, OPERATION & PREVENTIVE MAINTENANCE
Prior to each use, visual inspec on (See Pg. 6) shall be made to the device by checking
for abnormal condi ons, such ascracked welds, leaks, and damaged, loose, or missing
parts.
Consult the vehicle owner’s manual to determinethe loca on of li points.
Be sure to set the vehicle in park with the emergency brake on and wheels securely
chocked.
Be sure thatthe vehicle and the jack areon a hard, levelsurface.
Service Jack
Assemble the upper sec on of the twopiece handle intothe lower sec on, line up the
holes, insert and ghten the screw.
Insert the bo om end of handle into handle fork and securely ghten the bolt and
washer. Ensure the handle canturn freely.
Jack Stands
Tools Required: Hammer & Punch (not included with set)
Insert the ratchet bar into the base frame withthe ratchet por on of the bar aligned
with the locking pawl.
Move the ratchet bar to its lowest posi on byraising the locking handle, disengaging
the stopper and slowing lowering the ratchet bar downward into the base.
Collar lock is achieved by simply pressing the press tab (See Pg. 5) inward using the
hammer and punch.This will prevent accidental loss of the ratchetbar.
Turn the handle/releasevalve clockwise to the closed posi on. Do not over ghten.
Posi on the jack under the speci ed li point.
Begin li ing by pumping the handle up and down.
Immediately a er li ing, insert safety pins into the appropriately rated jack stands and
Turn the handle/release valve slowly counterclockwise to lower the vehicle ontojack
stands.
SETUP
ASSEMBLY
LIFTING
support the vehicle. NEVER support the vehicle with only the jack.

Capacity:3Ton
4
Model: ATD-7500
SETUP, OPERATION & PREVENTIVE MAINTENANCE (Cont.)
Turn the handle/release valve clockwise to the closed posi on. Do not over ghten.
Pump the handle up and down to li vehicle o jack stands.
Remove the jack stands and safety pins. DO NOT get under or let anyone get under
the vehicle while lowering.
Turn the handle/releasevalve slowly counterclockwise to lower the vehicle ontothe
ground.
NOTICE: Use high grade hydraulic oil only. Never use brake uid, motor oil, transmission uid,
turbine oil or any other uids. ISO-VG22 or equivalent hydraulic oil is recommended.
CheckandReĮllOil
With the jack in thefully lowered, level posi on, if unit cover is provided, remove unit
cover, then remove oil ller plug.
Proper oil level should be just covering inner cylinder as seen fromthe oil ller plug hole.
Do not over ll. Always ll with new, clean hydraulic jack oil as recommended above.
Reinstall oil ller plug, then reinstall unit cover.
Lubr nandCleaning
Periodically clean and lubricate all moving partsand pivot points.
AirVentingProcedures
With the jack in thefully lowered posi on, release valve open, remove oil ller plug.
Pump the handle rapidly several mes. Reinstall oil ller plug.
Turn the handle/release valve clockwise to the closed posi on.
Pump the handle un l the li arm reaches maximum height and con nue to pump
several mes to remove trapped air in the system.
Turn the handle/release valve counterclockwise in onefull turn and lower li arm to the
lowest posi on. Use force on saddle if necessary.
Carefully and slowly loosen oil ller plug to release pressurized air.
Repeat above steps un l trapped air is completely vented.
LOWERING
SERVICE JACK MAINTENANCE

Capacity:3Ton
5
Model: ATD-7500
SETUP, OPERATION & PREVENTIVE MAINTENANCE (Cont.)
Inspect each standbefore use. Ensure all parts move freely. Only apply grease to the locking
handle pivot point of thisproduct and ensure allexcess grease is wiped away before stand is
used. If rust appears, sand away the rust areaand cover with appropriate u lity paint. Please
Any service jack that appears to be damaged in any way, is found to be worn, or operates
abnormally SHALL BE REMOVED FROM SERVICE UNTIL REPAIRED. It is recommended that
necessary repairs be made by a manufacturer’s or supplier’s authorized repair facility if repairs
are permi ed by the manufacturer or supplier.
Any jack stand that appears to be damaged, is found to be worn, or
operates abnormally in any way will be removed from service and destroyed
immediately.
Altera ons
Because of poten al hazards associated with this type of equipment, no altera ons shall be
made to the product.
Aachments and Adapters
Only a achments and/or adapters supplied by the manufacturer shall be used.
Oil Filler Plug
( Located on Reservoir)
Handle
Handle Fork
Caster
Front Wheel
Saddle
JACK STANDS
DAMAGED EQUIPMENT
Ratchet Bar
Tab
Collar
Locking Handle
Base
Safety Pin
note that there are no replacement parts available for this product.

Capacity:3Ton
6
Model: ATD-7500
INSPECTION, STORAGE & TROUBLESHOOTING
Visual inspec on shall be made before each use of the device by checking for abnormal
condi ons, such as cracked welds, leaks, anddamaged, loose, or missing parts.
Other inspec ons shallbe made per product opera ng instruc ons.
These devices shall be inspected immediately if the device is believed to have been
subjected to an abnormal load or shock. It is recommended that this inspec on be made
by a manufacturer’s or supplier’s authorized repair facility.
Owners and/or operators should be aware that repair of this service jack may require
specialized knowledge and facili es. It is recommended that an annual inspec on of the
product be made by amanufacturer’s or supplier’s authorized repair facility and that
any defec ve parts, decals, or safety labelsor signs be replaced with manufacturer’s or
supplier’s speci ed parts.
The service jack and jack stands should be stored in a dry loca on on a level surface.
Symptom Possible Causes Solu on
Jack will not li the load. 1. Release valve not ghtly
closed.
2. Low oil level.
3. Defec ve or worn internal
parts.
4. Load exceeds maximum
allowance.
1. Tighten release valve.
2. Check and add oil. Follow “Check
and Re ll Oil” instruc ons on Pg.4.
3. Discon nue use and contact a
local repair center.
4. Use a higher capacity jack.
Jack will not hold the load. 1. Release valve not ghtly
closed.
2. Power unit malfunc on.
1. Tighten release valve.
2. Discon nue use and contact a
local repair center.
Jack will not descend to
minimumheight, or will not
remain in lowered posi on.
1. Air trapped in system.
2. Reservoir oil over led. 1. Vent air out of system. Follow
“Air Ven ng Procedures” above.
2. Check and ensure proper oil level.
Follow “Check and Re ll Oil”
instruc on on Pg.4.
Jack will not li to max
height. 1. Low oil level. 1. Check and ensure proper oil level.
Follow “Check and Re ll Oil”
instruc ons above.
Jack will not func on
properly a er tried solu on. 1. Internal malfunc on or
structural damage. 1. Stop usage and contact an authorized repair center.
INSPECTION
STORAGE
TROUBLESHOOTING

Capacity: 3 Ton
7
Model: ATD-7500
EXPLODED VIEW & REPLACEABLE PART NUMBERS
2
4
7
1
3
6
5
8
9
Item Part Number* Descrip on Qty
1LYD3D-100 Front wheel assembly 2
21elddaSB5.D3DYL
3LYD3D-101 Two Piece Handle 1
41tinUrewoP6.C3DYL
5LYD3D-102 Handle Fork Assembly 1
6LYD3D-103 Rear Caster Assembly 2
71gnirpSnruteR9-2DYL
8ATD-7443 3 Ton Jack Stands W/ Safety Pin 2
N/A 1lebaLtcudorPL-0057DTA
* Items not iden ed by part number are not available for replacement.
9Safety Pin With Chain 2 ZJ3H-PJ-5
N/A Oil Filler Plug (rubber) 1 LYD3F-100

Capacity:3Ton
8
Model: ATD-7500
WARRANTY INFORMATION
ONE YEAR LIMITED WARRANTY
For a period of one (1) year from your purchase date, ATD Tools Inc. will repair or
replace (at its option) without charge, your ATD product if it was purchased new and the product
has failed due to a defect in material or workmanship which you experienced during normal use
of the product. This limited warranty is your exclusive remedy.
To access the benefits of this warranty, contact ATD at 1-844-364-9922 for confirmation
that this warranty applies. Thereafter, you may be advised to return the product under warranty,
freight prepaid, to the ATD service department.
If this ATD product is altered, abused, misused, modified, or undergoes service by an
unauthorized technician, your warranty will be void. We are not responsible for damage to
ornamental designs you place on this ATD product and such ornamentation should not cover
any warnings or instructions or they may void the warranty. This warranty does not cover
scratches, superficial dents, and other abrasions to the paint finish that occur under normal use.
Subject to the law in your state:
(1) Your sole and exclusive remedy is repair or replacement of the defective product as
described above.
(2) ATD is not liable for any incidental damages, including but not limited to, lost profits and
unforeseeable consequences.
(3) The repair and replacement of this product under the express limited warranty described
above is your exclusive remedy and is provided in lieu of all other warranties, express or
implied. All other warranties, including implied warranties and warranties of
merchantability or fitness for a particular purpose are disclaimed and, if disclaimer is
prohibited, these warranties are limited to one year from your date of purchase of this
product.
Some states’ laws do not allow limited durations on certain implied warranties and some states’
laws do not allow limitations on incidental or consequential damages. You should consult the
law in your state to determine how your rights may vary.
ATD Tools, Inc.
160 Enterprise Drive
Wentzville, MO 63385
Toll Free Service Number 1-844-364-9922
Visit us at www.atdtools.com
