Audiovox MVP200 Quick start guide

-1-
VES WIRING DIAGRAM
RELAY
BOX
YELLOW/BLACK
RED
BLACK
LAMP ON-BLACK/WHITE
LAMP AUTO-RED/WHITE
LAMP COMMON-RED/BLACK
ACC
BATT
VEHICLE
ANTENNA
VEHICLE RADIO
CONNECTOR
NOT USED
EXTENSION IF
NEEDED
SEE PAGE
TWO
P/N112D2989 P/N112D2813
P/N112D2816
GND
128-6241
MVP200

-2-
Positive Switched Dome Lighting
CONNECTING THE DOME LIGHTS
The dome lights in the video monitor require three connections to the vehicle's wiring. There are
two common types of dome light circuits used, positive or negative switched. Positive systems supply
voltage to the interior lights to turn them on, negative switched systems apply ground to illuminate the
bulbs. To determine which system you have you must locate the wires at the dome light. On a positive
switched system, with all the doors closed and the lights out, both wires at the dome light will rest at
ground. When the light is activated, one of these wires will switch to +12 vdc. This is the vehicle's
switching wire. On a negative switched system, with all the doors closed and the lights out, both wires at
the dome light will rest at + 12vdc. When the light is activated, one of these wires will switch to ground.
This is the switching wire.
For positive systems, connect the red/white (Lamp auto) wire to the vehicle's switched wire. Then
connect the black/white (lamp on) wire to a fused constant 12 volt source and the red/black (lamp com-
mon) wire to a good ground. Positive systems are commonly found on Ford vehicles.
For negative systems, connect the red/white (Lamp auto) wire to the vehicle's switched wire.
Then connect the black/white (lamp on) wire to a good ground and the red/black (lamp common) wire to
fused constant 12 volt source. Negative systems are commonly found on General Motors and import
vehicles.
Note: Some vehicles which incorporate transistorized control of the dome light circuit, such as the 1999
Dodge Caravan, may require that the red/white (Lamp auto) wire be connected to the door pin switch
wire, as the additional current draw of the Monitor's lights may not be supported by the output of the
vehicles body control computer.
Negative Switched Dome Lighting
To 12 pin
connector
To
constant
To
constant
Factory Door
ajar switch or
Body
Factory Dome light
To 12 pin
connector
To
constant
Factory Door
ajar switch or
Factory Dome light
Red/Black-Lamp Common
Black/White-Lamp On
Red/White-Lamp Auto
Red/Black-Lamp Common
Black/White-Lamp On
Red/White-Lamp Auto
To
constant
