Autel MaxiCharger User manual

MaxiCharger AC Wallbox
Quick Reference Guide
Version 2.0
Kurzanleitung

Scan the QR code below to access the manuals and CE certificate.
Thank you for purchasing this Autel MaxiCharger AC Wallbox. Our euipment is manufactured to a high
standard and - when used according to these instructions and properly maintained - will provide years
of trouble-free performance.
This equipment should only be installed by a licensed electrician in accordance with all local codes
and ordinances.
1

Technical Specifications
Item Description
Charging mode Mode 3
Input/Output power rating and current Up to 22 kW/32 A
Input/Output voltage 400 V ± 15%, three-phase, 50 Hz
Network type TT, TN
Protection
Overcurrent, overvoltage, undervoltage, integrated surge
protection
Card reader ISO 15693, ISO 14443, NFC 18092
Communications protocol OCPP 1.6J
User authentication APP, RFID card, Auto-Start
Software update OTA updates via web portal
Safety and compliance IEC 61851-1, IEC 62955, EN 62311, EN 50665
Certifications CE (TUV)
Warranty 36 months
Bluetooth, Wi-Fi, Ethernet, 4G, CAN, RS485,
Modbus TCP/IP
IEC 62196 type 2 plug, 5 m
IEC 62196 type 2 socket or socket with shutter
Residual current detection AC 30 mA + DC 6 mA
± 1.0%
Build-in MID certified meter (only applicable to the
products with LCD screen)
Operating altitude Max. 2000 m above sea level
Operating temperature range -40 to +55 ° C
Storage temperature range -40 to +85 ° C
Mounting Wall or floor using a pedestal
Dimensions (H × W × D) 336 × 187 × 85 mm
Status indication LED, app, touchscreen (5-inch LCD, 800 x 480 mm)
User interface Autel Charge app, Autel Charge Cloud
IP65 (IP54 for socket version), IK10 (screen: IK08)
Power measurement accuracy
Connectivity
Connector type
IP and IK rating

3

4

5

Yellow
6

850 and 1150
7

8

9

10

3. Switch on the electrical power to the MaxiCharger.
