Avantco S30 User manual

Mechanical side arm S30
2019 1
Operator's Manual for Attachment
Mechanical side arm S30
Product number:
A431070
English
A436866 2019 1 EN 2018-
www.avanttecno.com

Mechanical side arm S30 2019 1

Mechanical side arm S30 2019 1
CONTENTS
1. FOREWORD ............................................................................................................................................4
Warning symbols used in this manual ............................................................................................................................... 5
2. DESIGNED PURPOSE OF USE.............................................................................................................6
3. SAFETY INSTRUCTIONS FOR USING THE ATTACHMENT........................................................7
4. TECHNICAL SPECIFICATIONS ..........................................................................................................11
4.1 Outreach ................................................................................................................................................................. 12
4.2 Safety labels and main components of the attachment.................................................................................. 13
5. ASSEMBLING THE ATTACHMENT....................................................................................................15
5.1 Coupling the side arm to the loader ................................................................................................................. 15
5.2 Connecting and disconnecting hydraulic hoses............................................................................................... 17
5.3 Coupling an attachment to the side arm .......................................................................................................... 19
5.4 Electric connection................................................................................................................................................ 20
5.4.1 To connect the electric harness of the attachment to the loader ..................................................... 20
6. INSTRUCTIONS FOR USE....................................................................................................................21
6.1 Checks before use................................................................................................................................................. 22
6.2 Operating position ................................................................................................................................................ 23
6.3 Using the mechanical side arm ........................................................................................................................... 24
6.3.1 Tilting the attachment coupling bracket when an attachment is not fitted ...................................... 24
6.3.2 To start and tilt an attachment that is coupled to the side arm ......................................................... 25
6.4 Vertical adjustment ............................................................................................................................................... 26
6.5 Working on uneven ground................................................................................................................................ 27
6.6 Transport position ................................................................................................................................................ 27
6.7 Uncoupling and storage........................................................................................................................................ 28
6.7.1 Storage............................................................................................................................................................. 28
6.7.2 Storage with attachment.............................................................................................................................. 29
7. MAINTENANCE AND SERVICE ..........................................................................................................30
7.1 Inspection of hydraulic components.................................................................................................................. 30
7.2 Cleaning the attachment ...................................................................................................................................... 31
7.3 Lubrication .............................................................................................................................................................. 31
7.4 Inspection of metal structures............................................................................................................................ 31
8. WARRANTY TERMS..............................................................................................................................32

4 (34)
1. Foreword
Avant Tecno Oy would like to thank you for your purchase of this attachment for your Avant loader. It has
been designed and manufactured based on years of experience on product development and manufacturing.
By familiarising yourself with this manual and following the instructions, you ascertain your safety and ensure
the reliable operation and long service life of the equipment. Read the instructions carefully before starting to
use the equipment or performing maintenance.
The purpose of this manual is to help you to:
operate the equipment in a safe and efficient manner
observe and prevent any hazardous situations
keep the equipment intact and ensure a long service life
With these instructions, even an inexperienced user can use the attachment and loader safely. The manual
includes important instructions for experienced AVANT operators as well. Ensure that all persons using the
loader have received proper guidance and familiarised themselves with the manual of the loader, each
attachment that are used, and all safety instructions before using the equipment. Using the equipment for
other purposes or use in any other way than described in this manual is prohibited. Keep this manual at hand
throughout the service life of the equipment. If you sell or transfer the equipment, be sure to hand over this
manual to the new owner. If the manual is lost or damaged, you can request a new one from your Avant
dealer or from the manufacturer.
In addition to the safety instructions included in this manual, you must observe all occupational safety
regulations, local laws, and other regulations concerning the use of the equipment. Particularly the regulations
concerning the use of the equipment on public road areas must be observed. Contact your Avant dealer for
more information about local requirements before you operate the loader on road areas.
Contact your local AVANT dealer for any questions, service, spare parts or about any problems that may
occur with the operation of your machine.
This manual contains the original instructions in English. Due to continuous product development some of the
details shown in this manual may differ from your equipment. Pictures may also depict optional equipment or
features that are not currently available. We reserve the right to change the contents of the manual without
notification. Copyright © 2019 Avant Tecno Oy. All rights reserved.

5 (34)
.
Warning symbols used in this manual
The following warning symbols are used throughout this manual. They indicate factors that must be taken into
account to reduce the risk of personal injury or damage to property:
WARNING SAFETY ALERT SYMBOL
This symbol means: “Warning, be alert! Your safety is involved!”
Carefully read the message that follows, it warns of an immediate hazard
that could cause serious personal injury.
The safety alert symbol by itself and with related safety statement
indicates important safety messages throughout this Manual. It is used to
draw attention to instructions involving your personal safety or the safety
of others. When you see this symbol, be alert, your safety is involved,
carefully read the message that follows, and inform other operators.
DANGER
This signal word indicates a hazardous situation which, if not avoided, will cause
death or serious injury.
WARNING
This signal word indicates a potentially hazardous situation which, if not avoided,
could cause serious injury or death.
CAUTION
This signal word is used when minor injury could result if the instructions are not
followed properly.
This signal word indicates information about the correct operation and maintenance
of the equipment.
Failure to observe the instructions accompanying the symbol can lead to equipment
breakdown or other property damage.

6 (34)
2. Designed purpose of use
The AVANT Mechanical side arm with S30 quick coupling system is an attachment that is intended for use
with AVANT multi purpose loaders that are shown in Table 1. The side arm has a S30 type quick coupling for
coupling attachments to the arm. The side arm is intended to be used with attachments that are specifically
designed for use with a side arm, such as, for example, the S30 cutting bar A430938, and the S30 Multi-
function drive unit A429926. The maximum weight of an attachment that can be coupled to the side arm is 200
kg.
The Side arm is equipped with a mechanical, manually extendable straight telescopic arm, and a hydraulic jib
arm which tilts the attachment up and down. Telescoping to the side is max. 1000 mm and jib arm movement
is max. 45° down and 90° up from the horizontal position. The side arm is pivoted in the middle and locked
with a pin. This makes it possible to turn the entire arm manually up and down with 45° steps. It also possible
to rotate the arm full 180° to the other side, which makes it possible to work either on the right or on the left
side of the loader.
When a loader is equipped with a side arm the loader can tip over sideways more easily. Heavy attachment
and a fully extended side arm can cause the loader to tip over on uneven surface. Additional counterweights
are recommended for all loader models. The loader should be fitted with tyres that are as wide as standard
tyres of each loader model, or even wider. The arm is rigid to all directions, there is no release mechanism in
case it hits an obstacle.
The loader must be equipped with the Attachment control switch pack in order to use the Side arm and any
attachment connected to it. Tilting the S30 coupling of the Side arm, or any attachment connected to it, is
possible only with the switches of the Attachment control switch pack. It is also is possible to tilt the
attachment during the use of the attachment.
The Mechanical side arm S30 is not designed for any other use than what is specified in this manual and must
not be used for any other purposes than intended. The side arm or any attachment or tool connected to it
must not be used for lifting purposes.
The attachment has been designed to require as little maintenance as possible. The operator can perform
regular maintenance tasks. All repair work can’t be performed by the operator, and demanding repair and
maintenance operations are to be left for professional maintenance. All maintenance work must be done using
proper safety equipment. Spare parts must be identical with original specifications, which can be ensured by
using only original spare parts. A separate spare parts catalogue may be available, consult your Avant dealer.
Familiarise yourself with the manual's instructions regarding service and maintenance. Please contact your
AVANT retailer if you have additional questions about the operation or maintenance of the equipment, or if
you require spare parts or maintenance services.
Table 1 - Mechanical side arm S30 - Compatibility with Avant loaders
Model
220
225
225LPG
313S
320S
420
423
520
523
R20
525LPG
R28
528
530
630
R35
635
640
745
750
755i
760i
e5
e6
A431070 −−••••(•)
It is recommended to use the attachment only with loaders marked with •in Table 1. When using with models
marked with (•), full performance may not be achieved. Additional counterweights may also be required. For
compatibility with a model not shown in table, contact your Avant dealer.
The table above applies for side arm only. The attachments that are compatible with the
side arm are not necessary compatible with all loaders.

7 (34)
3. Safety instructions for using the attachment
Please bear in mind that safety is the result of several factors. The loader-attachment combination is highly
powerful and improper or careless use or maintenance may cause serious personal injury or property
damage. Due to this, all operators must carefully familiarise themselves about correct use and the operator's
manuals of both the loader and the attachment before starting operation. Do not use the attachment if you
have not completely familiarised yourself with its operation and the related hazards.
DANGER
Misuse, careless use, or using an attachment that is in poor condition, may
cause risk of serious injuries.
Familiarise yourself with the controls of the loader,
correct coupling procedure, and the correct way to operate the attachment at a safe
area. Stu
dy especially how to stop the equipment in a safe manner. Read all safety
precautions carefully.
Read all safety instructions carefully before handling the attachment
WARNING
When attaching an attachment to the loader, ensure that the locking pins of the
loader's quick attach plate are in the lower position and that they have locked
the attachment to the loader. Never lift or move an unlocked attachment.

The Mechanical side arm S30 is designed to be used by one operator at a time. Do
not let others near the danger area of the equipment when it is in use.

Always transport the attachment as low as possible to keep the centre of gravity low,
and keep the telescopic boom retracted during driving.
Risk of entanglement, severing, and impact - Never leave the driver’s seat when
the attachment is running or if the auxiliary hydraulics control lever is locked
on.
Depending on the attachment that is connected to the side arm there may be
serious risks of personal injury if anyone gets close to the attachment
while it is in
use. Always shut down the attachment and place it to a safe position before leaving
the driver's seat or if anyone gets close to the work area. If there are rotating parts on
the attachment that keep rotating for a short period after the hyd
raulic supply has
been shut off, wait until all parts have stopped completely before leaving the driver's
seat.
Sudden movements can cause the loader to tip over - Operate the controls of
the loader in a slow and calm manner. Be careful when lifting loa
d to high level or
lifting load from high. Avoid sudden changes in speed or direction to maintain
balance of the loader especially when handling heavy loads. Drive slowly and
carefully especially on inclined terrain or slippery surfaces.
Risk of tipping over - Side arm reduces the lateral stability of the loader. Do not
drive on inclined surfaces when the side arm is equipped with an attachment and the
arm is extended. Use of additional counterweights is recommended. Make sure that
the tyres of the loader are filled to their recommended pressure to reduce tilting of the
loader. Drive carefully on uneven surfaces where movements caused by holes or
bumps on the surface can cause the loader to tip over when driving at high speed.
Risk of tipping over - Keep the loader articulation in straight position when
handling heavy loads. When turning the articulation, the loader may tilt forward
Do not leave the driver’s seat when the loader boom is lifted. Going under a raised
attachment or loader boom is dange
rous. Always remember that the boom may lower
due to loss of stability, mechanical fault, or if another person operates the controls of
the loader.

8 (34)
Hazard of entanglement - Never wear or allow any assisting persons to wear
loose clothes, such as loose
shoelaces, or long scarves when working with or
near the attachment.
Always stop the attachment before anyone gets near it. Keep
hands and feet away from moving components. To eliminate the risk of entanglement
at the work site pay attention to proper clothing.
Risks of collision, electric shock, and tipping over - Make sure that overhead
clearance is sufficient.
Hitting an overhead obstacle may cause the loader to tip
over. Keep a safe distance from electric cables, lamps, or other electric systems;
hitting live parts may cause electric shock.
Use the attachment only for its intended use and only with original tools and spare
parts.
When unlocking and dismounting the attachment off from the loader, ensure that it is
secured against accidental move
ment. To secure the attachment from tipping over
lower it firmly on the ground and disconnect only on level surface. Ensure the
attachment is properly supported during storage. Never climb on the attachment.
Make sure that the attachment is properly supported before performing any
inspections, maintenance, or adjustments. If necessary, secure the attachment with
suitable lifting equipment, or lower it on firm blocks of wood, for example.
Shut down the loader and place the attachment to a safe position as shown in Safe
stopping procedure before any cleaning, maintenance, or adjustments.
Pay attention to the surroundings and any other persons and machines moving in the
vicinity. Pay attention to the contours of the terrain and other hazards, such as
b
ranches and trees that can reach to the driver's area, loose rocks, and slippery
surfaces.
Make sure to use only an attachment that is in good condition. Do not modify the
attachment in any way that could affect its safety.
Use the attachment only for its intended purpose. Other use may create unnecessary
safety risks, and the equipment may get damaged.
Make sure that the loader is equipped with necessary safety components, and that
they are in working condition. Seat belt must be used. If there ar
e specific hazards
related to the operating area, use appropriate safety equipment.
Also read the safety instructions and correct use of the loader from the operator's
manual of the loader.
WARNING

9 (34)
DANGER
Wrong, improper, or careless use of the attachment
causes serious risk of severe
injuries or death.
Familiarise yourself with the controls of the loader in a safe area. Pay
particular attention to the safe stopping of the attachment and the loader; follow the safe
stopping procedure shown in this manual before leaving the driver's seat.
WARNING
Risk of crushing -
Never allow anyone to get under a
lifted attachment or loader boom.
Keep in mind that the
loader boom can be lowered or tilted even if the engine has
been shut down (crushing hazard). The l
oader is not intended
to be left to keep a load elevated for longer periods. Always
lower the attachment to a safe position before leaving the
driver's seat.
WARNING
Risk of tipping over -
Side arm reduces the lateral
stability of the loader. Alwa
ys keep load close to the
ground, and always wear seat belt.
Pay special attention to
stability of the loader when an extended side arm is equipped
with an attachment. The loader may tip over on inclined or
uneven surfaces causing serious injuries from imp
act and
crushing. Always wear seat belt. Use the side arm only with
loaders that are equipped with ROPS and FOPS. Avoid
abrupt movements and always drive slowly and carefully on
inclined terrains, and on uneven or slippery surfaces. Use of
additional counterweights is recommended.

10 (34)
Remember to wear proper personal protective equipment:

The noise level at the driver's seat may exceed 85 dB(A) depending on loader
model and operating cycle. Extended exposure to loud noise can cause
hearing impairment. Wear hearing protection while working with the loader.
Wear protective gloves.
Wear safety boots whenever working with the loader.
Wear safety glasses e.g. when handling hydraulic components.
Handling some materials can cause spreading of dust
. Wear respirator mask
when handling loose materials.
. ..
Safe stopping of the attachment, before going near the attachment:
WARNING
Always stop the attachment following safe stopping procedure before leaving
the driver's seat. Safe stopping proc
edure prevents all unintentional movements of
the attachment. Note that the loader boom can move down even if the engine of the
loader is turned off. Safe stopping procedure:
Lower the boom and the attachment on the ground.
Shut down the loader engine and lock the parking brake.

Release residual pressure from the hydraulic system; move all hydraulic control
levers to their extreme positions a couple of times.
Prevent starting of the machine, remove ignition key.

11 (34)
4. Technical specifications
Table 2 - Mechanical side arm S30 - Specifications
Product number A431070
Width (boom retracted): 1 645 mm
Max. telescoping: 1000 mm
Jib arm movement: 135° (- 45°/+ 90°)
Weight: 130 kg
Max attachment weight: 200 kg
Recommended hydraulic flow: 20 - 50 l/min
Maximum input of hydraulic energy: 22,5 MPa (225 bar), 50 l/min
Compatible Avant loaders: See Table 1

12 (34)
.
4.1 Outreach
The outreach diagram below is illustrated without an attachment. The actual outreach depends on the
attachment in use, therefore the diagram should be used as an estimation. See additional instructions from
the corresponding attachment manuals.

13 (34)
4.2 Safety labels and main components of the attachment
Listed below are the labels and markings on the attachment. They must be visible and readable on the
equipment. Replace any unclear or missing label. New labels are available via your retailer or contact
information provided on the cover.
WARNING
Make sure all warning decals are readable.
The warning labels contain important
safety information and t
hey help to identify and remember the hazards related to the
equipment. Replace damaged or missing warning labels with new ones.
Attachment identification plate
A433442
A46771
A46772
A46803
To apply a new label: Clean the surface thoroughly to remove all grease. Allow it to dry completely. Peel off
the protective film of the label and press firmly to apply. Take care not to touch the glue of the label.

14 (34)
.
Table 3 - Decal locations and warning messages
Decal Warning message
1 A36771 Misuse hazard - Read instructions before
use.
2 A36772
Crushing hazard - Do not go under a
raised attachment; stay away from raised
equipment.
3 A36803
Pinching and cutting hazard, keep clear
of moving parts, do not leave the
equipment running. Operate the
attachment only from the driver’s seat.
4 A433442 Attachment identification plate
. ..
. ..
Table 4 - Mechanical side arm S30 - Main components
1 Avant quick coupling
2 S30 quick coupling
3 Hydraulic quick couplers for attachment
4 Multiconnector
5 Locking pin for telescopic arm
6 Locking screw of S30 quick coupling
7 Locking pin for telescopic arm rotation
8 Adjusting tool for S30 quick coupling
9 Tilting cylinder
10 Telescopic arm
11 Multiconnector holder

15 (34)
5. Assembling the attachment
Attaching the attachment to the loader is quick and easy, but it must be done carefully. The attachment is
mounted to the loader boom by using the quick attach plate on the loader boom and the counterpart on the
attachment.
If the attachment is not locked to the loader, it may detach from the loader and cause a hazardous situation.
The loader must not be driven and the boom must never be lifted when the attachment has not been locked.
To prevent hazardous situations, always follow the coupling procedure shown below. Also remember the
safety instructions shown in this manual. The attachment is mounted to the loader as follows:
WARNING
Crushing risk - Make sure that an unlocked attachment will not move or fall over.
Do not stay i
n the area between the attachment and the loader. Mount the attachment
only on level surface.
Never move or lift an attachment that has not been locked.
5.1 Coupling the side arm to the loader
Avant quick coupling system:
Step 1:
Lift the quick attach p
late locking pins up and turn them backwards into the slot
so that they are locked in the upper position.

If your loader is equipped with a hydraulic attachment locking system, see
additional instructions about the use of the locking system from the relevant
manuals.

Ensure that the hydraulic hoses and the electric harness are not in the way
during installation.
Step 2:
Turn the quick attach plate hydraulically to an obliquely forward position.
Drive the loader onto the attachment. If your loader is e
quipped with a
telescopic boom, you can utilise this.

Align the upper pins of the loader’s quick coupling plate so that they are under
the corresponding brackets of the attachment.
Step 3:
Lift the boom slightly – pull the boom control lever backward
to raise the
attachment off the ground.

Turn the boom control lever left to turn the bottom section of the quick attach
plate onto the attachment.
Lock the locking pins manually or lock the hydraulic locking.
Always check the locking of both locking pins.

16 (34)
WARNING
Risk of crushing - Avoid tipping over the attachment.
Excessive tilting or lifting of an
unlocked attachment increases the risk of tipping the attachment over. Do not use the
automatic locking of the locking pins when the attachment is lift
ed more than one meter
from the ground. If the locking pins do not return to the normal position when tilting, do
not tilt or raise the attachment any more. Lower the attachment on the ground and
secure the locking manually.
WARNING
Risk of falling objects -
Prevent dropping of
attachment.
An attachment that has not been completely locked to the
loader may fall on the boom or towards the operator, or
fall under the loader during driving, causing loss of
control of the loader. Never move or lift an at
tachment
that has not been locked. Before moving or lifting the
attachment, make sure that the locking pins are in the
lower position and come through the fasteners on the
attachment on both sides.
WARNING
Make sure the loader is compatible with the attachment.
Stability of the loader,
possible overload of the attachment, and compatibility of loader control systems must be
ensured in addition to mechanical compatibility of the attachment. If you use the
attachment with a loader that is not f
it to be used with the attachment model you have,
risks include tipping over, damage to attachment due to overload, and risks related to
uncontrolled motion of attachment and its parts. If your loader is not listed in Table 1 on
page 6, ask your Avant dealer before using this attachment.

17 (34)
.
5.2 Connecting and disconnecting hydraulic hoses
On Avant loaders the hydraulic hoses are connected using the multi connector system. If you have an Avant
300-700 series loader with the conventional quick couplers and wish to change to the multi connector system,
contact your Avant dealer or service point for instructions or installation services.
WARNING
Risk of movement of the attachment and ejection of hydraulic oil -
Never connect
or disco
nnect quick couplings or other hydraulic components while the control
lever of the auxiliary hydraulics control lever is locked on or if the system is
pressurized.
Connecting or disconnecting the hydraulic couplings while the system is
pressurized may lead to unintended movements of the attachment, or ejection of high-
pressure fluid, which can cause serious injuries or burns. Follow safe stopping procedure
before disconnecting hydraulics.
Keep all fittings as clean as possible; use the protective caps on both the attachment and
the loader. Dirt, ice, etc. may make using the fittings significantly more difficult. Never
leave the hoses hanging on the ground; place the couplings onto the holder on the
attachment.
Connecting the multiconnector system:
1.
Align the pins of the attachment connector with corresponding
holes of the loader connector. The multiconnector will not connect
if the attachment connector is upside down.
2.
Connect and lock the multiconnector by turning the lever towards
the loader.
The lever should move easily all the way to its locking position. If the lever does not slide smoothly, check the
alignment and position of the connector and clean the connectors. Also shut down the loader and release the
residual hydraulic pressure.
To disconnect the multiconnector system:
Before disconnecting put the attachment down on a solid and even
surface.
1. Switch off the auxiliary hydraulics of the loader.
2.
While pushing unlock button, turn the lever to disconnect the
connector.
3. After ending oper
ation put the multiconnector on its holder on the
attachment.

18 (34)
Disconnecting hydraulic hoses:
Before disconnecting the fittings, lower the attachment to safe position on solid and level surface. Turn the
control lever of the auxiliary hydraulics to its neutral position.
When uncoupling the attachment, always disconnect the hydraulic couplings before
unlocking the quick attach plate, to prevent hose damage and any oil spills. Reinstall the
protective caps on the fittings to prevent impurities from entering the hydraulic system.
Releasing residual hydraulic pressure:
In case residual pressure is left in the hydraulic system of the attachment, it is often possible to disconnect the
hydraulic couplings, but it may be difficult to connect them the next time. If the fittings will not connect, the
residual pressure must be released by turning the auxiliary hydraulics control lever of the loader, when the
engine is turned off. To make sure that there will not be residual pressure in the hydraulic system of the
attachment, shut down the loader engine and move the auxiliary hydraulics control lever of the loader back
and forth before disconnecting the couplings.

19 (34)
5.3 Coupling an attachment to the side arm
Connect an attachment to the mechanical (A431070) or hydraulic side arm (A424552) after the side arm is
fully connected and locked to the loader. Also the hydraulic hoses and the electric harness of the side arm
must be connected to the loader before it is possible to couple an attachment to the side arm. See instructions
in this manual.
A tool for tightening and opening of the S30 coupling is stored at the Avant quick coupling plate of the side
arm.
S30 Quick coupling:
1. Make sure the side arm or the hydraulic boom is connected and locked to the loader. The hydraulic and
electric connectors must also be coupled.
2. Open the S30 coupling of the side arm with the Allen key that is stored at the Avant quick coupling plate
of the side arm.
3. Drive the loader close to the attachment. Turn and tilt the side arm with the controls of the loader to set
the S30 coupling of the side arm to its counterpart on the attachment.
4. Lock the attachment by tightening the screw on the S30 coupling of the side arm.
Do not lift or move the side arm until the attachment is fully connected to it.
1.
Align the quick coupling with the counterpart and
lower the boom on its place.
2.
When the quick coupling of the boom is aligned
with the attachment, lock the attachment with the
locking element of S30 (1) by tightening the
locking screw (2).
WARNING
Risk of falling objects -
Prevent dropping of
attachment.
An attachment that has not been completely locked to the
loader may fall on the boom or towards the operator, or
fall under the loader during driving, causing loss of
control of the loader. Never
move or lift an attachment
that has not been locked.

20 (34)
5.4 Electric connection
Electric functions of the attachment:
The loader must be equipped with the optional Attachment control switch pack. If it is not installed on the
loader, it is not possible to fully operate the side arm and its attachments. Contact you Avant dealer or service
point for more information about installation of the Attachment control switch pack, if necessary.
5.4.1 To connect the electric harness of the attachment to the loader
Starting from year 2016, there is an integrated electric plug in the multiconnector of all attachments that have
electric functions.
1. If your loader is

equipped with the attachment control switch
pack and
the loader is manufactured in 2016 or later:
The
electric socket is integrated in the
multiconnector. The electric harness of the
attachment is connected when the multiconnector
is coupled.
Clean both multiconnectors before connecting the
multiconnector.
Attachment control switch pack, loader
manufactured in 2016 or later
2. If your loader is

equipped with the attachment control switch
pack, and
the loader is manufactured in 2015 or before:
There is an electric socket near the multiconnector
of the loader. Connect the electric plug of the
attachment to the socket of the loader.
Attachment control switch pack, loader
manufactured in 2015 or before
If your loader is not equipped with the attachment control switch pack:
All functions of the side arm and an attachment that is connected to it can't be used without the Attachment
control switch pack of the loader.
Make sure that electric cables will not get stuck, squeezed, or stretched when the
equipment moves.
With the help of the attachment control switch pack available for the loader, t
he
attachment control switches are easily accessible at the end of the boom control lever.
More information about the power outlet of the loader can be found in the operator’s
manual of the loader.
