Avaya 4600 Series User manual

IP Office - Job Aid
Infrared Dialing on 4600 Series Phones
Summary
This document looks at how the infrared (IR) port on 4606, 4612, 4624 and 4620
phones can be used. It covers the 'beaming' of numbers to dial and at transferring
files between IR devices at either end of the call.
The methods in this document are available to a wide range of PDA's and other
devices that have infrared ports conforming to the IrDA standard.

Infrared Dialing on 4600 Series Phones Overview
Infrared Dialing on 4600 Series Phones Page 2
IP Office - Job Aid 010 Issue 1a (15th November 2002)
Infrared Dialing on 4600 Series Phones
Overview
Several phones in the 4600 Series include an infrared (IR) port at the front of
the phone. This includes the 4606, 4612, 4624 and 4620.
•The port appears as a dark plastic window just in front of the phones
dialing keys.
•Support for IR port operation is part of 4600 Series 1.6 phone
software and higher. This software is supported as part of IP Office
Level 1.3.
You can use the IR port in the following ways:
•Dial a Number to Start a Call:
This can be done by beaming the contact information held in a PDA's
address book.
•Swap Text Files During a Call:
If calling another 4600 Series telephone extension that has an IR port,
text files can be beamed between extensions.
When using infrared beaming the following must be remembered:
•The device beaming or receiving must be IrDA compatible. This is the
case for most computer and PDA IR ports.
•The range of transmission is typical a maximum of 5 feet (1.5 meters)
and with a 5° degree spread. (This is unlike IR devices used for
remote controls which typically beam over a long range and much
wide angle spread).
•For details of enabling and using IR beaming from your PDA or PC
refer to the manufacturer's information. Note that some PDA's can be
set to beam to modems and mobile phones which use different
transmission formats. The PDA may need to be set to beaming to
another PC/PDA for dialing to work.
•Important Note: Though we have tested these features with several
devices as indicated, this is not a commitment to continually test or support
those devices against future levels of software.
Enabling the IR Port
By default, where fitted the IR port on 4600 Series phones is enabled. If
necessary it can be disabled.
1. With the phone on-hook and idle, press Hold 4 6 8 # (Hold I N T #).
2. The phone displays PHY2= and the current status. This is the setting for
the phone's pass-through Ethernet port.
3. Press #to continue.
4. The phone displays IR= and the current status.
5. Change the status if required by following the displayed prompts. Then
press #.
6. The phone will restart.

Infrared Dialing on 4600 Series Phones Dialing Phone Numbers
Infrared Dialing on 4600 Series Phones Page 3
IP Office - Job Aid 010 Issue 1a (15th November 2002)
Dialing Phone Numbers
You can use the IR port to receive telephone numbers beamed from an IR
enabled PC or pocket organizer device. Any device that can beam contacts in
the VCard format (.vcf) can be used.
If you are unsure of the file format used by your IR device, you can try beaming
a contact anyway. The display on the 4600 Series phone will display the name
of the file it received. If that ends in .vcf then the phone should dial the number
in the VCard file.
You will need to remember the following:
•The phone will only dial the first phone number in the VCard file.
•If your IP Office system has been setup to need a prefix for external
dialing, that prefix must be in the VCard phone number.
The following are example of beaming contacts dialing from different devices.
Palm Organizer
The following was tested using a Palm Vx and M505. The connection setting
(found through Prefs | Connection) must be Ir to PC/Handheld.
1. Click on phone button or icon to enter the address book.
2. Locate person or organization that you want to dial.
3. Click on the entry to go to Address View.
4. On the letters area of the graffiti pad, make a sweep from the bottom-left to
the top-right. A set of icons should appear. Click on the beam icon.
•Alternatively click on the menu icon and select Beam Address.
Psion Revio
The following was tested using a Psion Revio.
1. In Contacts, select the entry you want to dial.
2. Click on the beam icon at the left-hand edge of the display.
Note: The above also works for Contacts accessed via the Phone application
but does not work for Phone application entries.
Windows Pocket PC
The following was tested using a Compaq iPAQ Pocket PC.
1. In Contacts select the entry you want to dial.
2. Click on Tools and select Beam Contact.
3. The Pocket PC will search for and then display the IR enabled devices it
could find. The 4600 Series phone should appear on the list.
4. Select the 4600 Series phone and the contact information will be beamed
to it.

Infrared Dialing on 4600 Series Phones Beaming Files During a Call
Infrared Dialing on 4600 Series Phones Page 4
IP Office - Job Aid 010 Issue 1a (15th November 2002)
Beaming Files During a Call
During a call between one 4600 IR enabled extension and another on the
same system, you can also beam files between the IR devices at each end.
The types of file sendable and receivable will depend on those supported by
the devices sending and receiving, ie. as if they were face to face.
VCard files can be exchanged without being interpreted as a number to dial.
Palm Organizer
The following was tested using a Palm Vx and M505.
1. Inform the caller that you want to beam them a file and to have their Palm
positioned in front of their extensions IR port ready to receive.
2. Locate the file that you want to send.
3. On the letters area of the graffiti pad, make a sweep from the bottom-left to
the top-right. A set of icons should appear. Click on the beam icon.
•Alternatively click on the Menu icon and select the displayed Beam
option.
4. The phones should display the first eight characters and the file extension
of the file being transferred.
