Quick Start
The basic procedures required to power on CEM520:
(1). Make sure the power is OFF before connecting the CEM520.
(2). Check to ensure the onboard switch SW1-1 and SW1-2 are set to
default (OFF position).
(3). Firmly install DDR4 SO-DIMM in DIMM1/DIMM2 until fully seated. For
single memory channel configuration, install memory module in
channel 0 (DIMM1) DDR4 SO-DIMM socket. For dual memory
channel configuration, install memory modules of the same size, chip
width, density and rank in both channel 0 (DIMM1) and channel 1
(DIMM2) DDR4 SO-DIMM sockets.
(4). Attach heatsink to the CEM520, refer to section Installing Thermal
Solution.
(5). Install the CEM520 onto COM Express
TM
baseboard, for example,
CEB94011 baseboard.
(6). Properly install all necessary peripheral devices such as hard disk,
display, keyboard and etc. to the baseboard.
(7). Firmly attach power supply to the baseboard power connector.
(8). Turn on the system power.
(9). Press power button on the baseboard to start CEM520.
CEM520 Quick Installation Guide
© Copyright 2020 Axiomtek Co., Ltd. 1
Version A2 July 2020
Printed in T iw n
Checklist

C
EM
52
0
Board x1

Q
uick Installation Guide
x1
Note: Please contact your local vendors if any damaged or missing items. DO
NOT apply power to the board if there is any damaged component.
For user manual, drivers, certificates and technical
support, please visit our product website or scan
QR code.
Module Layout
Top View
CEM520 COM Express
TM
Type 6 Basic Module
http://www.axiomtek.com.tw/Default.aspx?Men
uId=Products&FunctionId=ProductView&ItemId
=25364&C=CEM520&upcat=332

2 © Copyright 2020 Axiomtek Co., Ltd.
Version A2 July 2020
Printed in T iw n
Bottom View
Switch Settings
Before applying power to the CEM520, please make sure onboard
switches are in factory default positions.
Switch Description Setting
SW1
Auto Power On
Default: Disable
SW1-1 OFF
Restore BIOS Optimal Defaults
Default: Normal Operation
SW1-2 OFF
SW2 PCI-Express Bifurcation Setting
Default: One x16 PCI
-
Express
SW1-1 OFF,
SW1-2 OFF
Connector
Connector Description
CN1
Fan Connector
BAT1
Battery Connector
SS1
COM Expre
ss
TM
Connector
SS2
COM Express
TM
Connector
DIMM1
Channel 0
DDR
4
SO
-
DIMM
Socket
DIMM2
Channel
1
DDR
4
SO
-
DIMM
Socket
© Copyright 2020 Axiomtek Co., Ltd. 3
Version A2 July 2020
Printed in T iw n
Installing Thermal Solution
For thermal dissipation, a thermal solution enables the CEM520’s
components to dissipate heat efficiently. All heat generating components
are thermally conducted to the heatsink in order to avoid hot spots. Figure
below illustrates how to install the thermal solution on CEM520.
1. There is a protective plastic covering on the thermal pads. This must
be removed before the heatsink can be mounted.
2. Each heatsink is designed for a specific CEM module. The thermal
pads on the heatsink are designed to make contact with the necessary
components on the CEM module. When mounting the heatsink you
must make sure that the thermal pads on the heatsink make complete
contact (no space between thermal pad and component) with the
corresponding components on the CEM module. This is especially
critical for CEM modules that have higher CPU speeds (for example
1.0GHz or more) to ensure that the heatsink acts as a proper thermal
interface for cooling solutions.
3. Before installing the heatsink to the CPU module, please apply thermal
grease on the CPU die. This CPU module has assembly holes for
installing heatsink plate. Use the appropriate screws to secure the
heatsink plate to the CEM520. Be careful not to over-tighten the screws.
