AXIOMTEK DSP501-527 Series User manual

©Copyright 2018 Axiomtek Co., Ltd.
Version A1 October 2018
Printed in aiwan
9412K501000E
4
2 Installation of M.2 Device
Step 1 Turn off the system and unplug the power cord.
Step 2 Turn the system upside down to locate screws at the bottom
and then loosen all screws.
Step 3 Open the TOP cover.
Step 4 Located the M.2 socket on main board.
Step 5 Identify the M.2 slot, insert a M.2 module into the socket and
then fasten a screw.
Step 6 Put the TOP cover and fasten four screws back onto the system.
DSP501-527 Quick Installation Guide
©Copyright 2018 Axiomtek Co., Ltd.
Version A1 October 2018
Printed in aiwan
9412K501000E
1
Packing List
System Unit x 1 60W power adapter x 1
Quick Installation Guide x 1
 Do not try to apply power to the system if any damaged components.
Dimensions
DSP501-527 Series Digital Signage Player

©Copyright 2018 Axiomtek Co., Ltd.
Version A1 October 2018
Printed in aiwan
9412K501000E
2
I/O Outlets
The following figures show I/O outlets on the DSP501-527.
Front View
Rear View
1 12VDC power input 9 Mic in
2 Remote power switch 10 Line out
3 SIM card 11 USB 3.1
4 DP++ 12 GbE LAN port
5 HDMI 13 HDD LED
6 Device management port 14 Reset swtich
7 USB 2.0 15 Power switch
8 RS-232
© Copyright 2017 Axiomtek Co., Ltd.
Version A2 May 2017
Printed in aiwan
9412K501000E
3
1 Installation of Memory DIMM1 / DIMM2 Device
Step 1 Turn off the system and unplug the power cord.
Step 2 Turn the system upside down to locate screws at the bottom
and then loosen all screws.
Step 3 Open the TOP cover.
Step 4 Located the DIMM socket on main board.
Step 5 Locate the memory module, insert a gold colored contact into
the socket and push the module two end latches till locked.
Step 6 Put the TOP cover and fasten four screws back onto the system.
