AXIOMTEK GOT-3100T User manual

i
GOT-3100T/3100TL/3108T
All-in-One
10.4” TFT SVGA Fanless Touch Panel
Computer
User’s Manual

ii
Disclaimers
The information in this manual has been carefully checked and is believed to
be accurate. AXIOMTEK Co., Ltd. assumes no responsibility for any
infringements of patents or other rights of third parties, which may result from
its use.
AXIOMTEK assumes no responsibility for any inaccuracies that may be
contained in this document. AXIOMTEK makes no commitment to update or
to keep current the information contained in this manual.
AXIOMTEK reserves the right to make improvements to this document and/or
product at any time and without notice.
No part of this document may be reproduced, stored in a retrieval system, or
transmitted, in any form or by any means, electronic, mechanical,
photocopying, recording, or otherwise, without the prior written permission of
AXIOMTEK Co., Ltd.
©Copyright 2006 by AXIOMTEK Co., Ltd.
All rights reserved.
February 2006, Version A1
Printed in Taiwan

iii
Safety Approvals
CE Marking
FCC Class A
FCC Compliance
This equipment has been tested and complies with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. If not installed and used in
accordance with proper instructions, this equipment might generate or
radiate radio frequency energy and cause harmful interference to
radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measurers:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for
help.
Shielded interface cables must be used in order to comply with
emission limits.ou

iv
Safety Precautions
Before getting started, read the following important cautions.
1. The GOT-3100T/3100TL/3108T does not come equipped with
an operating system. An operating system must be loaded first
before installing any software into the computer.
2. Be sure to ground yourself to prevent static charge when
installing the internal components. Use a grounding wrist strap
and place all electronic components in any static-shielded
devices. Most electronic components are sensitive to static
electrical charge.
3. Disconnect the power cord from the
GOT-3100T/3100TL/3108T before making any installation. Be
sure both the system and the external devices are turned OFF.
Sudden surge of power could ruin sensitive components.
Make sure the GOT-3100T/3100TL/3108T is properly
grounded.
4. The brightness of the flat panel display decreases with usage.
However, hours of use vary depending on the application
environment.
5. Turn OFF the system power before cleaning. Clean the
system using a cloth only. Do not spray any liquid cleaner
directly onto the screen. The GOT-3100T/3100TL/3108T may
come with or w/o a touchscreen. Although the touchscreen is
chemical resistant, it is recommended that you spray the liquid
cleaner on a cloth first before wiping the screen. In case your
system comes without the touchscreen, you must follow the
same procedure and not spray any cleaner on the flat panel
directly.
6. Avoid using sharp objects to operate the touchscreen.
Scratches on the touchscreen may cause malfunction or
internal failure to the touchscreen.
7. The flat panel display is not susceptible to shock or vibration.
When assembling the GOT-3100T/3100TL/3108T, make sure
it is securely installed.

v
8. Do not open the system’s back cover. If opening the cover for
maintenance is a must, only a trained technician is allowed to
do so. Integrated circuits on computer boards are sensitive to
static electricity. To avoid damaging chips from electrostatic
discharge, observe the following precautions:
9Before handling a board or integrated circuit, touch an
unpainted portion of the system unit chassis for a few seconds.
This will help to discharge any static electricity on your body.
9When handling boards and components, wear a
wrist-grounding strap, available from most electronic
component stores.
Trademarks Acknowledgments
AXIOMTEK is a trademark of AXIOMTEK Co., Ltd.
IBM, PC/AT, PS/2, VGA are trademarks of International
Business Machines Corporation.
Intel and Pentium are trademarks of Intel Corporation.
MS-DOS, Microsoft C and QuickBASIC are trademarks of
Microsoft Corporation.
VIA is a trademark of VIA Technologies, Inc.
SST is a trademark of Silicon Storage Technology, Inc.
UMC is a trademark of United Microelectronics Corporation.
Other brand names and trademarks are the properties of their
respective owners.

vi
This page does not contain any information.

Table of Contents vii
Table of Contents
Disclaimers........................................................................... ii
Safety Approvals................................................................iii
Safety Precautions ............................................................. iv
C h a p t e r 1.....................................................................1
Introduction ..........................................................................1
1.1 General Description................................................1
1.2 Specifications..........................................................2
1.2.1 Main CPU Board...................................................... 2
1.2.2 I/O System............................................................... 2
1.2.3 System Specification.............................................. 3
1.3 Dimensions..............................................................4
1.4 I/O Outlets................................................................4
1.4 I/O Outlets................................................................5
1.5 Package List ............................................................6
C h a p t e r 2.....................................................................7
Hardware Installation.........................................................7
2.1 HDD Installation ......................................................7
2.2 CF card Installation.................................................9
2.3 Wireless Card Installation....................................10
2.4 3 x Serial Ports......................................................12
2.5 VGA ........................................................................14
2.6 Ethernet..................................................................14
2.7 Mountings: Panel / Wall / Desktop / VESA..........15
2.7.1 VESA-ARM/Wall-Mount........................................... 15
2.7.2 Desktop Kit Assembly ............................................. 16
2.7.3 Panel-mount Kit Assembly ..................................... 17
C h a p t e r 3......................................................................18
Driver Installation .............................................................18
3.1 Touch Screen ........................................................18

Table of Contents
viii
3.1.1 Driver Installation- Windows 2000/XP.................... 19
3.2 Embedded O.S.........................................................22
3.2.1 Windows XP Embedded.......................................... 22
3.2.2 Windows CE.NET 5.0 ................................................ 22

GOT-3100T/3100TL/3108TT User’s Manual
Introduction 1
C h a p t e r 1
Introduction
This chapter contains the general information and the detail
specifications of the GOT-3100T/3100TL/3108T. Chapter 1 includes
the following sections:
General Description
System Specification
Dimensions
I/O Outlets
Utilities Supported
Package List
1.1 General Description
The GOT-3100T/3100TL/3108T is a fan-less and compact-size touch
panel computer, and is equipped with a 10.4" TFT LCD display and
low power consumption CPU, Celeron M 1GHz/0K. The
GOT-3100T/3100TL/3108T supports Windows® 2000/XP, Windows®
CE.NET, Windows® XP embedded, and Linux. The panel is able to
install in a CompactFlash™ card and provides a MiniPCI slot for
wireless module.
GOT-3100T: 10.4” TFT SVGA Fanless Touch Panel Computer
w/ High brightness
GOT-3100TL: 10.4” TFT SVGA Fanless Touch Panel
Computer(Light version)
GOT-3108T: 10.4” TFT SVGA Fanless Touch Panel Computer
w/ NEMA4X Stainless Front Bezel
Reliable and Stable Design
The GOT-3100T/3100TL/3108T adopts a fan-less cooling system and
a CompactFlash™ card, which makes it especially suitable for
vibration-heavy environments, best for the transportation, ship, and
industrial machinery markets.
Embedded O.S. Supported
The GOT-3100T/3100TL/3108T not only supports Windows®2000/XP,
but also supports embedded OS, such as Windows®CE.NET, and

GOT-3100T/3100TL/3108T User’s Manual
Introduction
2
Windows®XP embedded. For storage device, the
GOT-3100T/3100TL/3108T supports 2.5" HDD or CompactFlash™
card.
Industrial-grade Product Design
The GOT-3100T/3100TL/3108T has an incredible design that can be
used in different industrial harsh environments.
A fuse helps prevent over-voltage for power input.
Stainless steel back chassis and Aluminum front bezel meets
the IP65/NEMA4 standard.
For connecting other devices, the GOT-3100T/3100TL/3108T
also features several interfaces: USB, Ethernet, and
RS-232/422/485.
1.2 Specifications
1.2.1 Main CPU Board
CPU: Intel® Celeron® M ULV 1GHz/0K onboard.
System Chipset: Intel® 852GM+ICH4
BIOS: Award 4Mbit with RPL/PEX LAN boot ROM,
SmartView and customer CMOS backup.
System Memory: One 200-pin DDR DIMM socket.
Maximum up to 1GB
1.2.2 I/O System
Standard I/O:
−3 x serial ports
−2xRS-232,
1 x RS-232/422/485
−2 x USB 2.0

GOT-3100T/3100TL/3108TT User’s Manual
3
Ethernet:
- RJ45 x1
Expansion Slot:
- MiniPCI for wireless module
Audio
1.2.3 System Specification
10.4” TFT LCD
Heat dispensing design
Net weight:
−4.1 Kg
Dimension (main body size):
−290x71.9x248mm
Operating temperature: O° to 45°C ; Relative
umidity:40%
Relative humidity: 10% to 90% @ 40° C, on-condensing
Vibration (operating):
5 to 500 Hz, 1.3 G random ( install HDD )
5 to 500 Hz, 2.0 G random ( install CompactFlash card )

GOT-3100T/3100TL/3108T User’s Manual
1.3 Dimensions
The following diagrams show the dimensions and outlines of
GOT-3100T/3100TL/3108T
4

GOT-3100T/3100TL/3108TT User’s Manual
1.4 I/O Outlets
The following figure shows the I/O locations of the
GOT-3100T/3100TL/3108T. Most of the I/O connectors are located on
the back panel of the GOT-3100T/3100TL/3108T
1 2 3456 7 8 91 2 3456 7 8 9
1: Power connector 6: USB v2.0 * 2
2: Audio 7: PS2 keyboard/mouse
3: COM4 8: Ethernet (RJ45)
4: COM2 9: VGA
5: COM1
5

GOT-3100T/3100TL/3108T User’s Manual
6
1.5 Package List
When you receive the GOT-3100T/3100TL/3108T there are following
items in the package. If you can not find it, please contact AXIOMTEK
distributors.
1. GOT-3100T/3100TL/3108T x 1
2. Panel mount kit x 6
3. CD driver x1
4. Desktop kit x 2 (optional)
5. VESA ARM/Wall-mount kit(optional)

GOT-3100T/3100TL/3108TT User’s Manual
C h a p t e r 2
Hardware Installation
The GOT-3100T/3100TL/3108T provides lots of flexible ways for you
to select different configuration such as HDD,(recommend wide
temperature HDD) CF card and more. The chapter will show you how
to install the hardware. It includes:
2.1 HDD Installation
The GOT-3100T/3100TL/3108T offers a convenient drive bay module
for users to install HDD. The GOT-3100T/3100TL/3108T offers one
2.5” HDD drive for users to install. Please follow the steps:
1. Take out the, HDD bracket kit, 4 anti-vibration screws, 4
anti-vibration rubbers and 4 bracket screws from the accessory
package.
2. Screw 4 anti-vibration screws and fix HDD on the bracket kit.
7

GOT-3100T/3100TL/3108T User’s Manual
3. Fix the HDD kit to system by 4 screws.
8

GOT-3100T/3100TL/3108TT User’s Manual
2.2 CF card Installation
The GOT-3100T/3100TL/3108T offers a slot for users to install CF
card. When installing the CF card, refer to the following instructions
and illustration:
1. Open the back cover. Find SBC84810 and turn to back side.
2. Install user’s CF card.
9

GOT-3100T/3100TL/3108T User’s Manual
2.3 Wireless Card Installation
The GOT-3100T/3100TL/3108T provides one miniPCI slot for user to
install one wireless card. When installing the wireless card, refer to the
following instructions and illustration:
1. Open the back cover and find SBC84810 andAX93200
2. Install MiniPCI wireless card.
10

GOT-3100T/3100TL/3108TT User’s Manual
3. Connect cable from antenna to wireless card..
11

GOT-3100T/3100TL/3108T User’s Manual
2.4 3 x Serial Ports
The connector, COM 1, is a DB-9 connector, and the following table
shows the pin assignments of this connector.
COM1 Port Connectors
Pin Signal Name
1 DCD, Data carrier detect
2 RXD, Receive data
3 TXD, Transmit data
4 DTR, Data terminal ready
5 GND, ground
6 DSR, Data set ready
7 RTS, Request to send
8 CTS, Clear to send
9 RI, Ring indicator
COM1
COM2 Port Connectors: CN9
The RS-232 pin assignments are listed on the following table.
Pin Description Pin Description
1 Data Carrier Detect
(DCD) 2
Data Set Ready (DSR)
3 Receive Data (RXD) 4
Request to Send (RTS)
5 Transmit Data (TXD) 6
Clear to Send (CTS)
7 Data Terminal Ready
(DTR) 8
Ring Indicator (RI)
9 Ground (GND) 10
NC
CN9
2
4
6
1
3
5
78
910
12
