Axis C3003-E Quick setup guide

1
Please note that AXIS does not take any responsibility for how this configuration
may affect your system. If the modification fails or if you get other unexpected
results, you may have to restore the factory default settings as described in the
User’s manual.
HOW TO
Integration Guide AXIS Camera
Station and AXIS C3003-E
Created: May 12, 2015
Last updated: May 12, 2015

HOW TO –Axis CommunicationsIntegration Guide AXIS Camera Station and AXIS C3003-E
Rev: 1.1, Last updated: 19/05/2015 2
Rev: 1.1
Introduction
The following document highlights how to add a door station to Axis Camera
Station and then complete further configurations that can be made to meet an
operator’s need:
The document explains how to:
Add a horn speaker to Axis Camera Station.
Associate a horn speaker to a camera.
This following configuration has been tested with the following products and
firmware:
AXIS C3003-E, firmware 1.15.0 and Axis Camera Station 4.2.
Step 1 –Adding a horn speaker
To add a horn speaker you must add an auxiliary device:
1) Select the configuration tab (top right corner)
2) Select “Configuration” / “Add/Edit Aux Devices…”
3) Select the horn speaker when it is found by the search to add the device to the system.

HOW TO –Axis CommunicationsIntegration Guide AXIS Camera Station and AXIS C3003-E
Rev: 1.1, Last updated: 19/05/2015 3
Step 2 –Associate a horn speaker with a camera
To associate a horn speaker with a camera:
1) Select the “Video & Audio” configuration setting and Select the camera the horn
speaker is to be associated with.
2) Within the “Edit Video & Audio Settings” tab you can select the horn speaker to be
associated with the camera.
3) Return to the live view window and you will now have a “Speak” button when the
mouse is placed on the video pane.

HOW TO –Axis CommunicationsIntegration Guide AXIS Camera Station and AXIS C3003-E
Rev: 1.1, Last updated: 19/05/2015 4
Notes:
The following describes some of the current limitations:
Audio sent from ACS to a horn speaker cannot be recorded.
C3003-E microphone not available as audio source in ACS.
No speaker support for live view maps.
Only one speaker per camera.
No volume control for computer microphone in ACS client.
