AXOR Citterio Showerpipe
39620007
ZH ⁄ 用户手册 ⁄ 组装说明 02
EN ⁄ Instructions for use ⁄ assembly instructions 03
INSTALLATION

安装 (参见第页 04)
选装附件 (不在供货范围内)
匹配瓷砖的圆盘 镀铬 #95239000 (参见第页 10)
备用零件 (参见第页 10)
清洗 (参见第页 08)
操作 (参见第页 11)
请在使用喷头后略微倾斜，排空其中水分。
流量示意图 (参见第页 07)
 顶置花洒
 手持花洒
大小 (参见第页 07)
保养 (参见第页 09)
单向阀必须在符合国家或当地的法律的情况下按照DIN EN 1717定期
检查（至少一年一次）。
调节 (参见第页 06)
热水温度调节。如果使用即热式喷头，则不建议安装热水阀门。
请勿使用含有乙酸的硅胶！
符号说明
安全技巧
装配时为避免挤压和切割受伤，必须戴上手套。
本产品只允许作为洗浴、卫生和洁身之用。
头顶花洒夹持杆只为夹持头顶花洒而设计，不得让其承载其它物品！
不得让儿童和肢体、精神和⁄或意识有障碍的成人在不受监管的情况下使用
淋浴系统。受酒精或毒品影响的人员不得使用淋浴系统。
必须避免让身体敏感部位（如眼睛）接触到莲蓬头喷水。必须保持莲蓬头
与人头之间有足够的距离。
该产品不得作扶柄使用。必须安装单独的扶柄。
冷热水管间过大的压力差必须予以平衡。
安装提示
⁄ 安装前必须检查产品是否受到运输损害。 安装后将不认可运输损害或表面
损伤。
⁄ 管道和阀门必须根据通用标准进行安装、冲洗和检查。
⁄ 请遵守当地国家现行的安装规定。
⁄ 本安装说明中所规定的安装尺寸理想用于身高 1700 mm 左右的人士。尺寸
可根据需要进行修改。在这种情况下，您必须留意，如果安装高度改变，
则花洒到地板的最小高度也随之改变，且必须考虑到连接尺寸的改变。
⁄ 在安装产品的位置，安装人员必须确保安装面的墙面是平的（没有突出物
或瓷砖没有突起），墙体结构适合产品的安装并没有弱点。包装内的膨胀
螺丝只适用于混凝土墙体。对于其他墙体结构必须咨询膨胀螺丝生产商的
建议。
⁄ 必须使用预装配好的过滤器芯，以保障手持花洒达到标准水流量并避免从
管网中冲出污物。污物可损害功能和⁄或导致损坏手持花洒的功能件，对由
此所产生的损害汉斯格雅公司将不承担责任。
⁄ 紧急情况下,可使用细的锯子将下方区域中阀门与头顶莲蓬头之间的管子锯
短。
技术参数
工作压强： 最大 1 MPa
推荐工作压强： 0,16 - 0,5 MPa
测试压强： 1,6 MPa
(1 MPa = 10 bar = 147 PSI)
热水温度： 最大 70°C
推荐热水温度： 65°C
中心距离： 150±12mm
连接管线R 1/2： 左热右冷
热力消毒: 最大 70°C ⁄ 4 分钟
⁄ 自动防止回流
⁄ 该产品专为饮用水设计！
ZH
STÖRUNG URSACHE ABHILFE
⁄ Wenig Wasser ⁄ Rückflussverhinderer sitzt fest ⁄ Rückflussverhinderer austauschen
⁄ Filtereinsatz der Brause verschmutzt ⁄ Filtereinsatz zwischen Brause und Schlauch reinigen
⁄ Armatur schwergängig ⁄ Kartusche defekt, verkalkt ⁄ Kartusche austauschen
⁄ Armatur tropft ⁄ Kartusche defekt ⁄ Kartusche austauschen
⁄ Zu niedrige Warmwassertemperatur ⁄ Warmwasserbegrenzung falsch eingestellt ⁄ Warmwasserbegrenzung einstellen
⁄ Durchlauferhitzer schaltet nicht ein ⁄ Drossel in der Handbrause nicht ausgebaut ⁄ Drossel aus der Handbrause entfernen
⁄ Filtereinsatz der Brause verschmutzt ⁄ Filtereinsatz zwischen Brause und Schlauch reinigen
⁄ Rückflussverhinderer sitzt fest ⁄ Rückflussverhinderer austauschen
02

ASSEMBLY (see page 04)
SPECIAL ACCESSORIES (order as an extra)
tile-matching-disk chrome plated #95239000 (see page 10)
SPARE PARTS (see page 10)
CLEANING (see page 08)
OPERATION (see page 11)
To empty the overhead shower after use, hold it in a slightly inclined position.
FLOW DIAGRAM (see page 07)
 overhead shower
 Hand shower
DIMENSIONS (see page 07)
MAINTENANCE (see page 09)
The check valves must be checked regularly according to DIN EN 1717 in
accordance with national or regional regulations (at least once a year).
ADJUSTMENT (see page 06)
To adjust the hot water limiter. Using a hot water limiter in combination with a
continuous flow water heater is not recommended.
Do not use silicone containing acetic acid!
SYMBOL DESCRIPTION
SAFETY NOTES
Gloves should be worn during installation to prevent crushing and cutting injuries.
The product may only be used for bathing, hygienic and body cleaning purposes.
The arm of the shower head is intended only to hold the shower head. Do not load
it down with other objects!
Children as well as adults with physical, mental and⁄or sensoric impairments must
not use this product without proper supervision. Persons under the influence of
alcohol or drugs are prohibited from using this product.
Do not allow the streams of the shower touch sensitive body parts (such as your
eyes). An adequate distance must be kept between the shower and you.
The product may not be used as a holding handle. A separate handle must be
installed.
The hot and cold supplies must be of equal pressures.
INSTALLATION INSTRUCTIONS
⁄ Prior to installation, inspect the product for transport damages. After it has been
installed, no transport or surface damage will be honoured.
⁄ The pipes and the fixture must be installed, flushed and tested as per the applicable
standards.
⁄ The plumbing codes applicable in the respective countries must be observed.
⁄ The installation dimensions stated in these installation instructions are ideal for
people of approximately 1700 mm in body height. The dimensions can be altered
if required. In this case, pay attention to the fact that a change of installation height
will also change the minimum height, and that the altered mounting dimensions must
be taken into consideration.
⁄ Where the contractor mounts the product, he should ensure that the entire area of
the wall to which the mounting plate is to be fitted, is flat (no projecting joints or tiles
sticking out), that the structure of the wall is suitable for the installation of the prod-
uct and has no weak points. The enclosed screws and dowels are only suitable for
concrete. For another wall constructions the manufacturer's indications of the dowel
manufacturer have to be taken into account.
⁄ The premounted filter insert must be used to ensure a normal flow of the shower and
to prevent dirt from entering through the pipes. Dirt entering can affect the function
and⁄or lead to damages to the shower. Hansgrohe will not be held liable for this
type of damage.
⁄ If required, the bottom part of the pipe between the fixture and the shower head
can be shortened with a fine-toothed saw.
TECHNICAL DATA
Operating pressure: max. 1 MPa
Recommended operating pressure: 0,16 - 0,5 MPa
Test pressure: 1,6 MPa
(1 MPa = 10 bar = 147 PSI)
Hot water temperature: max. 70°C
Recommended hot water temp.: 65°C
Centre distance: 150±12mm
Connections R 1/2: cold right - hot left
Thermal disinfection: max. 70°C ⁄ 4 min
⁄ Safety against backflow
⁄ The product is exclusively designed for drinking water!
EN
STÖRUNG URSACHE ABHILFE
⁄ Wenig Wasser ⁄ Rückflussverhinderer sitzt fest ⁄ Rückflussverhinderer austauschen
⁄ Filtereinsatz der Brause verschmutzt ⁄ Filtereinsatz zwischen Brause und Schlauch reinigen
⁄ Armatur schwergängig ⁄ Kartusche defekt, verkalkt ⁄ Kartusche austauschen
⁄ Armatur tropft ⁄ Kartusche defekt ⁄ Kartusche austauschen
⁄ Zu niedrige Warmwassertemperatur ⁄ Warmwasserbegrenzung falsch eingestellt ⁄ Warmwasserbegrenzung einstellen
⁄ Durchlauferhitzer schaltet nicht ein ⁄ Drossel in der Handbrause nicht ausgebaut ⁄ Drossel aus der Handbrause entfernen
⁄ Filtereinsatz der Brause verschmutzt ⁄ Filtereinsatz zwischen Brause und Schlauch reinigen
⁄ Rückflussverhinderer sitzt fest ⁄ Rückflussverhinderer austauschen
03

04
Montage
1.
2.
Silicone
1 2 3
4 5 6
1.
2.
SW 5 mm
(6 Nm)
1.
2.
7
10
8 9
150
SW 27 mm
1.
2.
0 - 5 mm

05
Montage
13
16
15
17 18
14
11 12
Silicone
Silicone
SW 3 mm
(4 Nm)
1.
1.
2.
2.
SW 2 mm
(1 Nm)
19 20 21
SW 5 mm
23,5 mm
200 mm
23,5 mm
60 mm
Ø 6 mm
Ø 6 mm
SW 17 mm
(10 Nm)
60 mm
Ø 6 mm
Ø 6 mm
2.
10
1.

60 °C 10 °C 0,3 MPa
+
21 3 4
56 7
4.
3.
1.
2.
3.
1.
2.
6 x
36°C
38°C
43°C
50°C
55°C
60°C
17 x
SW 4 mm
SW 4 mm
(5 Nm)
SW 4 mm
SW 4 mm
06
Justierung

07
AXOR Citterio Showerpipe
39620007
150±16
220220
Ø180
70
22Ø
70
2157 2257
2057
40
442
2 6°
2 6°
29
132
44
1000
1100
900 845262
Ø60
R 1/2
1865
1965
1765
G 1/2
Ø 128
> 50
AXOR Citterio Showerpipe
39620007
1
2
bar
4,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
4,0
5,0
0,45
0,00
0,05
0,10
0,15
0,20
0,25
0,30
0,35
0,40
0,50
5,50,55
6,00,60
036912151821242730
MPa
00,1 0,2 0,3 0,4 0,5
Q = l/min
Q = l/sec
Maße ⁄ Durchflussdiagramm

08
QUICK
CLEAN
CLEANING RECOMMENDATION FOR HANSGROHE PROD-
UCTS
Today, modern sanitary and kitchen tapware, showers, accessories, washstands, tubs
and radiators consist of very different materials to comply with the needs of the market
with regard to design and functionality.
To avoid damage and reclamations, it is necessary to consider certain criteria when
cleaning.
WITH REGARD TO CARING FOR THE HANSGROHE PROD-
UCTS, THE FOLLOWING MUST IN PRINCIPLE BE HEEDED:
⁄ Only use cleaning material which is explicitly provided for this type of application.
⁄ Never use cleaning materials, which contain hydrochloric acid, formic acid, chlorine
pale lye or acetic acid, as they cause considerable damage.
⁄ Phosphorus acidic cleaners are only conditionally applicable.
⁄ Mixing cleaning agents is not permitted, generally.
⁄ Never use cleaning materials or appliances with an abrasive effect, such as
unsuitable cleaning powders, sponge pads or micro fibre cloths.
⁄ The instructions of the cleaning agent manufacturers have to be followed absolutely.
⁄ Cleaning has to be carried out with a specified cleaner dosage, contact time,
object-related and adapted to the needs.
⁄ The building up of calcifications has to be removed by cleaning regulary.
⁄ When using spray cleaners, spray the cleaning solution onto a soft cloth or sponge,
never directly onto the Hansgrohe products, as the atomised spray could enter
openings and gaps in the Hansgrohe products and cause damage.
⁄ After cleaning rinse thoroughly with clean water to remove any cleaner residue.
⁄ The use of steam cleaners is not permitted. The high temperatures can damage the
products.
IMPORTANT
Residues of toiletries such as liquid soaps, shampoos and shower gels, hair dyes,
perfumes, aftershave and nail varnish can also cause damage.
Here too: Carefully rinse with water after use to remove residues.
Likewise, do not store any cleaning agents or chemicals under the products, for
example in a vanity unit, as the vapours may damage the products.
The damage of already damaged surfaces will deteriorate under the effect of the
cleansers.
COMPONENTS WITH DAMAGED SURFACES MUST BE EXCHANGED,
OTHERWISE THERE COULD BE AN INJURY DANGER.
Damage caused by improper treatment will not be covered by our guarantee.
QUICKCLEAN
The QuickClean cleaning function only needs a small manual rub over to remove the
lime scale from the spray channels.
WARRANTY
Hansgrohe guarantees to the consumer that this product is free of production faults. If
evertheless any defect is detected within 5 years from date of purchase, Hansgrohe
will remedy this defect free of charge. You will find the conditions and details of this
guarantee at www.hansgrohe-int.com⁄guarantee. Please contact your contracting party
to claim your rights under this guarantee. This guarantee does not affect the customer‘s
rights under the respective national legislation.
汉斯格雅产品的清洁建议
现代的卫浴龙头、厨房龙头、花洒、配件、盥洗台、浴盆和加热器采用的制造材料
非常迥异，以适应产品外形设计和使用功能的市场需求。
为了避免产品损坏和由此引发的投诉及争议，必须在使用和清洁产品时遵循有
关规程。
在保养汉斯格雅产品时，原则上必须注意：
⁄只能使用那些有明确注明是适用于本产品的清洁剂。
⁄不允许使用含有盐酸、蚁酸、氯漂或醋酸的清洁剂，因为这些清洁剂会给产
品表面造成严重的损伤。
⁄含磷酸的清洁剂必须在特定条件下使用。
⁄不允许将两种以上清洁剂混合使用。
⁄不允许使用具有研磨作用的清洁工具和设备，如不适合的清洁粉末、海绵垫
或超细麦克布。
⁄必须严格遵守清洁剂生产厂商的使用说明。
⁄严格遵守清洁剂的用量和作用时间，决不允许清洁剂的作用时间长于规定
值。
⁄定期的清洁以预防水垢。
⁄不允许将清洁剂直接喷射到汉斯格雅产品上，因为喷雾会进入汉斯格雅产品
的开口部分和缝隙中而造成损害。首先将清洁剂喷在软布上，再用软布进行
清洁。
⁄清洁之后必须用足够的清水冲洗，以彻底去除残留的吸附物（清洁剂）。
⁄不允许使用蒸汽清洗机，高温会损害产品。
重要说明
肥皂，洗发水、沐浴液、染发剂、香水、刮胡水、指甲油的残留也会对产品造成损
伤。
此 处 ：使 用 后 要 小 心 地 用 清 水 将 剩 余 物 冲 洗 干 净 。
同样在产品下方不得存放洗涤剂和化学药品，例如不可放在用于洗脸盆的梳洗
柜中否则挥发气体将损坏产品。
在已经损伤的表面继续使用清洁剂会给表面造成更大的损伤。
表面损坏的部件必须更换，否则会有受伤的危险。
不按规定进行清洁而造成的任何损坏不在本公司产品保修范围之内。
QUICKCLEAN
有了QuickClean，手工清洁功能，要去掉喷头上的水垢，只需简单地搓除即可。
担保
Hansgrohe 向用户保证，该产品无制造 缺陷。如果自购买之日起五年内出
现缺 陷，Hansgrohe 将免费排除。 保证条件和详 情见 www.hansgrohe-int.
com⁄guarantee。 在提 出保修的权利时请联系您的合同方。本保证 不涉及有关
国家法律规定的消费权
Reinigung

SW 17 mm
SW 17 mm
(10 Nm)
SW 2 mm
123
456
7 8
SW 2 mm
(1 Nm)
> 1 min
1.
2.
2.
1.
1 32
09
Reinigung
Wartung

98131000
(15 x 2,5)
98137000
(17x1,5)
98184000
(13x3)
981810 00
(18x2)
28276000
98058000
96395000
96338000
39491000
96059000
97236000
94074000
95367000
96770000
95688000
96179000
98131000
(15x2,5)
92730000
96461000
96466000
97738000
98398000
(23x2)
94077000
94073000
98230000
(12x2,5)
97589000
94136000
94246000
95659000
98187000
(50x2)
98165000
(20x2)
26051007
93339000
94246000
92137000
95692000 96769000
39525000
97705000
40916000
97716000
97530000
95008000
95239000
10
Serviceteile Serviceteile

热 ⁄ hot 冷 ⁄ cold
关 ⁄ close开 ⁄ open
Bedienung
1.
2.
11
Bedienung

AXOR ⁄ Hansgrohe SE
Auestraße 5–9
77761 Schiltach
Deutschland
[e-mail]
axor-design.com
08 ⁄2018 9.09796.51
