Axor Showerpipe 27984007 Manual

INSTALLATION
ZH ⁄ 用户手册 ⁄ 组装说明 02
EN ⁄ Instructions for use ⁄ assembly instructions 03
AXOR Showerpipe 800 mm
27984007 ⁄ 27984937

02
安装 (参见第页 05)
问题 原因 补救
⁄龙头出水量小 ⁄ 水压不足 ⁄ 检查总水压
⁄ 调压器过滤网脏污 ⁄ 清洁龙头前面和MTC恒温阀芯的过滤网。
⁄ 花洒滤网有垃圾堵塞 ⁄ 清洗花洒和软管间的过滤网
⁄串水，在龙头关闭的状态下，热水被强迫流入冷水管
路，或者相反。
⁄ 单向阀有垃圾堵塞或漏水 ⁄ 清洗单向阀，如有必要则更换新的
⁄龙头出水温度和温度设定的不符 ⁄ 恒温阀芯未被调节 ⁄ 调节恒温器
⁄ 热水温度过低 ⁄ 将热水温度从42ºC升高到65ºC
⁄水温无法调节 ⁄ 恒温阀芯表面结垢 ⁄ 更换-恒温阀芯
⁄ 热水和冷水连接头已调换 ⁄ 改变接口
⁄使用恒温龙头后，燃气热水器不工作 ⁄ 过滤网有垃圾堵塞 ⁄ 清洁过滤网⁄更换过滤网
⁄ 单向阀装反 ⁄ 正确安装单向阀
⁄ 手持花洒的流量限制器没有去除 ⁄ 去除流量限制器
⁄花洒或龙头出水嘴滴水 ⁄ 在阀体上有灰尘或水垢，阀芯损坏 ⁄ 更换关闭部件
清洗 (参见第页 10)
选装附件 (不在供货范围内)
匹配瓷砖的圆盘 #93155000 (参见第页 12)
备用零件 (参见第页 12)
XX = 颜色代码
00 = 镀铬
93 = Polished Brass
流量示意图 (参见第页 04)
 手持花洒
 顶置花洒
大小 (参见第页 04)
操作 (参见第页 09)
保养
⁄ 为了保证恒温器的稳定运转，请务必定期从最热到最冷转动调温
器。
⁄ 此恒温龙头带有单向阀。 单向阀必须在符合国家或当地的法律的
情况下按照DIN EN 1717定期检查（至少一年一次）。
调节 (参见第页 08)
安装完成后必须检查调温器的出水温度。如在取水处测量所得的温度
与调温器上设定的温度有偏差，那么必须进行调整。
请勿使用含有乙酸的硅！
符号说明
安全技巧
装配时为避免挤压和切割受伤，必须戴上手套。
淋浴系统只允许作为洗浴、卫生和洁身之用。
不得让儿童和肢体、精神和⁄或意识有障碍的成人在不受监管的情况下使用
淋浴系统。受酒精或毒品影响的人员不得使用淋浴系统。
必须避免让身体敏感部位（如眼睛）接触到莲蓬头喷水。必须保持莲蓬头
与人头之间有足够的距离。
该产品不得作扶柄使用。必须安装单独的扶柄。
头顶花洒夹持杆只为夹持头顶花洒而设计，不得让其承载其它物品！
冷热水管间过大的压力差必须予以平衡。
安装提示
⁄ 安装前必须检查产品是否受到运输损害。 安装后将不认可运输损害或表面
损伤。
⁄ 管道和阀门必须根据通用标准进行安装、冲洗和检查。
⁄ 请遵守当地国家现行的安装规定。
⁄ 本安装说明中所规定的安装尺寸理想用于身高 1700 mm 左右的人士。尺寸
可根据需要进行修改。在这种情况下，您必须留意，如果安装高度改变，
则花洒到地板的最小高度也随之改变，且必须考虑到连接尺寸的改变。
⁄ 由有资格的专业人员进行产品安装时请注意：在所有加固区域中，加固表
面是否平整（无突出的接缝或瓷砖），墙体结构是否适合产品安装且未显
露出任何缺点。
⁄ 必须装上花洒所附带的滤柱式过滤网，以过滤管道里的杂质污物。杂质污
物会影响花洒的功能和⁄或损坏花洒的功能部件，由此而产生的产品损坏不
属于汉斯格雅的保修范围。
⁄ 本产品并非设计来与蒸气浴连接使用！
ZH
技术参数
工作压强： 最大 1 MPa
推荐工作压强： 0,1 - 0,5 MPa
测试压强： 1,6 MPa
(1 MPa = 10 bar = 147 PSI)
热水温度： 最大 70°C
推荐热水温度： 65°C
中心距离： 150 mm
连接管线G 1⁄2： 左热右冷
热力消毒: 最大 70°C ⁄ 4 分钟
自动防止回流
该产品专为饮用水设计！

03
ASSEMBLY (see page 05)
FAULT CAUSE REMEDY
⁄ Insufficient water ⁄ Supply pressure inadequate ⁄ Check water pressure (If a pump has been installed check
to see if the pump is working).
⁄ Regulator filter dirty ⁄ Clean filter in front of the mixer and on the MTC-thermo car-
tridge
⁄ Shower filter seal dirty ⁄ Clean filter seal between shower and hose
⁄ Crossflow, hot water being forced into cold water pipe, or
vice versa, when mixer is closed
⁄ Backflow preventers dirty or leaking ⁄ Clean backflow preventers, exchange if necessary
⁄ Spout temperature does not correspond with temperature
set
⁄ Thermostat has not been adjusted ⁄ Adjust thermostat
⁄ Hot water temperature too low ⁄ Increase hot water temperature to 42 ºC to 65 ºC
⁄ Temperature regulation not possible ⁄ thermo cartridge calcified ⁄ Exchange thermo cartridge
⁄ Hot and cold supplies are reversed ⁄ change connections
⁄ Instantaneous heater didn't work with thermostat ⁄ Filters are dirty ⁄ Clean the filter ⁄ exchange filter
⁄ check valve hasn't moved back ⁄ Exchange check valves
⁄ Flow limiter in handshower isn’t removed ⁄ Remove flow limiter
⁄ Shower or spout dripping ⁄ Dirt or sedimentation on valve seat, shut-off unit damaged ⁄ Exchange shut-off unit
CLEANING (see page 10)
SPECIAL ACCESSORIES (order as an extra)
tile-matching-disk #93155000 (see page 12)
SPARE PARTS (see page 12)
XX = Colors
00 = chrome plated
93 = Polished Brass
FLOW DIAGRAM (see page 04)
 Hand shower
 overhead shower
DIMENSIONS (see page 04)
OPERATION (see page 09)
MAINTENANCE
⁄ To guarantee the smooth running of the thermostat, it is necessary from
time to time to turn the thermostat from total hot to total cold.
⁄ The mixer is equipped with check valves. The check valves must be
checked regularly according to DIN EN 1717 in accordance with
national or regional regulations (at least once a year).
ADJUSTMENT (see page 08)
After the installation, the output temperature of the thermostat must be
checked. A correction is necessary if the temperature measured at the output
differs from the temperature set on the thermostat.
Do not use silicone containing acetic acid!
SYMBOL DESCRIPTION
SAFETY NOTES
Gloves should be worn during installation to prevent crushing and cutting injuries.
The shower system may only be used for bathing, hygienic and body cleaning
purposes.
Children as well as adults with physical, mental and ⁄or sensoric impairments must
not use this product without proper supervision. Persons under the influence of
alcohol or drugs are prohibited from using this product.
Do not allow the streams of the shower touch sensitive body parts (such as your
eyes). An adequate distance must be kept between the shower and you.
The product may not be used as a holding handle. A separate handle must be
installed.
The arm of the shower head is intended only to hold the shower head. Do not load
it down with other objects!
The hot and cold supplies must be of equal pressures.
INSTALLATION INSTRUCTIONS
⁄ Prior to installation, inspect the product for transport damages. After it has been
installed, no transport or surface damage will be honoured.
⁄ The pipes and the fixture must be installed, flushed and tested as per the applicable
standards.
⁄ The plumbing codes applicable in the respective countries must be oberserved.
⁄ The installation dimensions stated in these installation instructions are ideal for
people of approximately 1700 mm in body height. The dimensions can be altered
if required. In this case, pay attention to the fact that a change of installation height
will also change the minimum height, and that the altered mounting dimensions must
be taken into consideration.
⁄ During installation of the product by qualified trained personnel, make sure that the
entire fastening surface is even and smooth (no protruding seams or tile offset), that
the finish of the wall is suitable to apply the product and has no weak points.
⁄ The filter insert must be use to protect the shower against incoming dirt by
pipework. Incoming dirt leads to defects or⁄and can damage parts of the shower;
such caused faults voids all liability and guarantee claims.
⁄ The product is not designed to be used with steam baths!
EN
TECHNICAL DATA
Operating pressure: max. 1 MPa
Recommended operating pressure: 0,1 - 0,5 MPa
Test pressure: 1,6 MPa
(1 MPa = 10 bar = 147 PSI)
Hot water temperature: max. 70°C
Recommended hot water temp.: 65°C
Centre distance: 150 mm
Connections G 1⁄2: cold right - hot left
Thermal disinfection: max. 70°C ⁄ 4 min
Safety against backflow
The product is exclusively designed for drinking water!

bar
4,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
4,0
5,0
0,45
0,00
0,05
0,10
0,15
0,20
0,25
0,30
0,35
0,40
0,50
5,50,55
6,00,60
036912151821242730
MPa
00,1 0,2 0,3 0,4 0,5
Q = l/min
Q = l/sec
2
1
1000 1100900
2044 21441944 min. 25
9 2°
39863
639
105
987
1044 54
30
865
G1/2
800
75
16
450
520
25Ø
355Ø
17215028 ±12
70°
70°
70
150±12
478
G1/2
713
9 2°
39863
639
105
987
1044 54
30
865
G1/2
800
75
16
450
520
25Ø
355Ø
17215028 ±12
04
Maße / Durchflussdiagramm Maße ⁄ Durchflussdiagramm

05
SW 2,5 mm
9
12
7
10
1.
1.
2.
2.
3.
8
11
Nr. 10476220
Armaturenfett
Grease
4
1
1.
2.
Silicone
2
1. 2.
X + 34 mm
X
X
1.
2.
3
SW 27 mm
5 6
Nr. 10476220
Armaturenfett
Grease
34±2
MontageMontage

06
60 mm
Ø 6 mm
1513
16
1.
1.
2.
2.
14
17
"
530 mm
SW 3 mm
(5 Nm)
SW 3 mm
(1,5 Nm)
18
SW 5 mm
2119
22
20
23
1.
2.
1.
2.
1.
2.
24
Montage

07
60 mm
Ø 6 mm
SW 8 mm
2725
28
26
29
SW 3 mm
SW 3 mm
SW 3 mm
30
3331
34
32
35
Montage

08
123
Justierung Justierung

更坚固 ⁄ schwerer
更加简单 ⁄ leichter
1.
2.
> 40 °C
09
BedienungBedienung

10
CLEANING RECOMMENDATION FOR HANSGROHE PROD-
UCTS
Today, modern sanitary and kitchen tapware, showers, accessories, washstands, tubs
and radiators consist of very different materials to comply with the needs of the market
with regard to design and functionality.
To avoid damage and reclamations, it is necessary to consider certain criteria when
cleaning.
WITH REGARD TO CARING FOR THE HANSGROHE PROD-
UCTS, THE FOLLOWING MUST IN PRINCIPLE BE HEEDED:
⁄ Only use cleaning material which is explicitly provided for this type of application.
⁄ Never use cleaning materials, which contain hydrochloric acid, formic acid, chlorine
pale lye or acetic acid, as they cause considerable damage.
⁄ Phosphorus acidic cleaners are only conditionally applicable.
⁄ Mixing cleaning agents is not permitted, generally.
⁄ Never use cleaning materials or appliances with an abrasive effect, such as
unsuitable cleaning powders, sponge pads or micro fibre cloths.
⁄ The instructions of the cleaning agent manufacturers have to be followed absolutely.
⁄ Cleaning has to be carried out with a specified cleaner dosage, contact time,
object-related and adapted to the needs.
⁄ The building up of calcifications has to be removed by cleaning regulary.
⁄ When using spray cleaners, spray the cleaning solution onto a soft cloth or sponge,
never directly onto the Hansgrohe products, as the atomised spray could enter
openings and gaps in the Hansgrohe products and cause damage.
⁄ After cleaning rinse thoroughly with clean water to remove any cleaner residue.
⁄ The use of steam cleaners is not permitted. The high temperatures can damage the
products.
IMPORTANT
Residues of toiletries such as liquid soaps, shampoos and shower gels, hair dyes,
perfumes, aftershave and nail varnish can also cause damage.
Here too: Carefully rinse with water after use to remove residues.
Likewise, do not store any cleaning agents or chemicals under the products, for
example in a vanity unit, as the vapours may damage the products.
The damage of already damaged surfaces will deteriorate under the effect of the
cleansers.
COMPONENTS WITH DAMAGED SURFACES MUST BE EXCHANGED,
OTHERWISE THERE COULD BE AN INJURY DANGER.
Damage caused by improper treatment will not be covered by our guarantee.
QUICKCLEAN
The QuickClean cleaning function only needs a small manual rub over to remove the
lime scale from the spray channels.
WARRANTY
Hansgrohe guarantees to the consumer that this product is free of production faults. If
evertheless any defect is detected within 5 years from date of purchase, Hansgrohe
will remedy this defect free of charge. You will find the conditions and details of this
guarantee at www.hansgrohe-int.com⁄guarantee. Please contact your contracting party
to claim your rights under this guarantee. This guarantee does not affect the customer‘s
rights under the respective national legislation.
汉斯格雅产品的清洁建议
现代的卫浴龙头、厨房龙头、花洒、配件、盥洗台、浴盆和加热器采用的制造材料
非常迥异，以适应产品外形设计和使用功能的市场需求。
为了避免产品损坏和由此引发的投诉及争议，必须在使用和清洁产品时遵循有
关规程。
在保养汉斯格雅产品时，原则上必须注意：
⁄只能使用那些有明确注明是适用于本产品的清洁剂。
⁄不允许使用含有盐酸、蚁酸、氯漂或醋酸的清洁剂，因为这些清洁剂会给产
品表面造成严重的损伤。
⁄含磷酸的清洁剂必须在特定条件下使用。
⁄不允许将两种以上清洁剂混合使用。
⁄不允许使用具有研磨作用的清洁工具和设备，如不适合的清洁粉末、海绵垫
或超细麦克布。
⁄必须严格遵守清洁剂生产厂商的使用说明。
⁄严格遵守清洁剂的用量和作用时间，决不允许清洁剂的作用时间长于规定
值。
⁄定期的清洁以预防水垢。
⁄不允许将清洁剂直接喷射到汉斯格雅产品上，因为喷雾会进入汉斯格雅产品
的开口部分和缝隙中而造成损害。首先将清洁剂喷在软布上，再用软布进行
清洁。
⁄清洁之后必须用足够的清水冲洗，以彻底去除残留的吸附物（清洁剂）。
⁄不允许使用蒸汽清洗机，高温会损害产品。
重要说明
肥皂，洗发水、沐浴液、染发剂、香水、刮胡水、指甲油的残留也会对产品造成损
伤。
此 处 ：使 用 后 要 小 心 地 用 清 水 将 剩 余 物 冲 洗 干 净 。
同样在产品下方不得存放洗涤剂和化学药品，例如不可放在用于洗脸盆的梳洗
柜中否则挥发气体将损坏产品。
在已经损伤的表面继续使用清洁剂会给表面造成更大的损伤。
表面损坏的部件必须更换，否则会有受伤的危险。
不按规定进行清洁而造成的任何损坏不在本公司产品保修范围之内。
QUICKCLEAN
有了QuickClean，手工清洁功能，要去掉喷头上的水垢，只需简单地搓除即可。
担保
Hansgrohe 向用户保证，该产品无制造 缺陷。如果自购买之日起
五年内出现缺 陷，Hansgrohe 将免费排除。 保证条件和详 情见
www.hansgrohe-int.com⁄guarantee。 在提 出保修的权利时请联系您的合同方。本
保证 不涉及有关国家法律规定的消费权
QUICK
CLEAN
QUICK
CLEAN
Reinigung

11
1 2 3
4
10 mm
max. 10 min
> 10 min
5 6
20 mm
max. 10 min
A B C
D
> 1 min
E F
ReinigungReinigung

AXOR ⁄ Hansgrohe SE
Auestraße 5–9
77761 Schiltach
Deutschland
[e-mail]
axor-design.com 11 ⁄ 2 0 18 9.06283.52
94246000
95480XX0
93155XX0
94246000
93339000
28532XX7
93291XX0
93360XX0
(1600 mm)
965410 01
92847000
965410 01
98387000
(17x2,5)
98387000
(17x2,5)
98716000
96029000
96029000
98282000
93294000
98058000
98129000
(14x2)
95758000
98368000
93295000
93296000
98433000
(30x1,5)
92936000
(32x1,5)
96179000
96179000
95772000
95773000
98371000
(29x3)
96429000
98199000
(17x2)
98173000
(22x1, 5)
93288XX0
98382000
(12x2,5)
AXOR Showerpipe 800 mm
27984007 ⁄ 27984937 93289XX0
93287XX0
93290000
Serviceteile
