Azbil ACTIVAL VY5460F Series User manual

AB-6675
1
Specifications/Instructions
Intelligent Component Series
ACTIVAL™
Motorized Three-Way Valve
with Flanged-End Connection (JIS 10K / FC200)
General
ACTIVAL™Model VY5460F is a series of motorized three-
way valves with flanged-end connection. Rotary valve and
actuator are integrated in a single unit.
Valve size ranges from DN50 (2”) to DN80 (3”), and valve
body rating corresponds to JIS 10K.
Actuator has a reversible synchronous motor, which
operates at a low voltage of 24 V AC.
Model VY5460F communicates with a controller via SAnet
(Azbil Corporation’s communication protocol).
∗Note
JIS: Japanese Industrial Standards
Features
•Compact and lightweight:
Rotary valve actualizes small body and light weight.
•Valve and actuator integrated in a single unit:
•SAnet communication:
Intelligent Component Series ACTIVAL communicates
with a controller via SAnet, and thus position control
signal/ position feedback signal is input/output from/to
the controller.
•Durable actuator with low power consumption.
•Linear flow characteristic.
•Sub-DI and sub-DO for wire saving:
Sub-DIO (digital input and output) provided takes signals,
including humidifying output and differential pressure
switch of neighboring devices, leading to wire saving.
•CE Marking certified product:
Model VY5460F conforms to all the applicable standards
of CE Marking.

AB-6675
2
Safety Instructions
Please read instructions carefully and use the product as specified in this manual. Be sure to keep this manual near by for ready
reference.
Usage Restrictions
This product is targeted for general air conditioning. Do not use this product in a situation where human life may be affected. If
this product is used in a clean room or a place where reliability or control accuracy is particularly required, please contact Azbil
Corporation’s sales representative. Azbil Corporation will not bear any responsibility for the results produced by the operators.
WARNING
•DANGER: To prevent the risk of severe or fatal electrical shock, always disconnect power source and product
power supply before performing any wiring.
•Be sure to reattach the terminal cover after wiring and engineering work. Without the terminal cover, electrical
shock may occur.
•This product weighs 18 kg or over (depending on the models). To prevent hazardous accident and severe injury,
move or carry the product with enough manpower or using a vehicle.
•Do not disassemble the product. Disassembly may result in electrical shock or equipment damage.
CAUTION
•This product must be operated under the operating conditions (power, temperature, humidity, vibration, shock,
installation position, atmospheric condition, etc) specified in this manual to prevent fire or equipment damage.
•This product must be operated within its rated operating ranges specified in this manual. Failure to comply will
cause equipment damage.
•Installation and wiring must be performed by qualified personnel in accordance with all applicable safety standards.
•Avoid application that keeps the operating cycle of product excessively frequent. Excessively frequent operation
may cause fire or equipment failure.
•All wiring must comply with local codes of indoor wiring and electric installation rules.
•Install externally the protective device such as fuse or circuit breaker for your safety.
•Install the product in the position as specified in this manual. Excessively tight connection of the valve to a pipe and
improper installation position may damage the valve.
•User full gaskets for the flat-face flange type valve.
•After installation, make sure no fluid leaks from the connecting parts of valve and pipes. Incorrect piping may cause
fluid leakage.
•Do not allow any foreign substance inside the piping. Flush the piping so that no foreign substance remains.
Attach a strainer in a pipe on the inflow side of the product to prevent equipment damage.
•Avoid using the product in an atmosphere containing oxidizing gas, explosive gas, etc. since it may damage the
actuator, valve, or their components.
•Do not leave the controlled fluid frozen to prevent equipment damage or fluid leakage.
•Do not put heavy load on the actuator.
•Do not install the product nearby a steam coil or a hot-water (in high temperature) coil. High heat radiation may
result in an actuator malfunction.
•Avoid touching the installed product. When being used to control hot water, it may reach high temperature and may
cause burn injury.
•Use crimp terminal lugs with insulation for electric wires to be connected to the screw terminals.
•Make sure all the wires are tightly connected to the screw terminals. Loose connection may cause fire or heat
generation.
•Do not touch the moving parts of the product to prevent personal injury.
•Do not stack unpacked products. Piled products without package will be polluted or damaged.
•Dispose of this product as an industrial waste in accordance with your local regulations. Do not reuse all or part of
this product.

AB-6675
3
System Configurations
Notes:
∗MIS may be used instead of SMS and DSS for your system. Note that MIS cannot be mixed with SMS or DSS in the same system.
∗Up to two SAnet I/F (interface) module can be connected to one Infilex GC/Infilex GD.
∗For detailed specifications of SAnet, refer to Installation Manual of Intelligent Component Series for SAnet Communication (AB-6713).
∗1 ACTIVAL or 1 damper actuator requires 1 SAnet address. 1 ACTIVAL PLUS requires 2 SAnet addresses.
Figure 1. System configuration example: SAnet connection in savic-net™FX system
Client PC
SCS
SMS
Infilex™AC
Model WY5117C
Infilex™GC
Model WY5111
Infilex™GD
Model WY5110
PMX-III
Model WY2001
Infilex
™
FC
Model WY5205
Infilex
™
VC
Model WY5206
Neopanel
Model QY7205
(Digital user terminal)
Neoplate Model QY7290
(Analog user terminal)
NC-bus (Max. 25 units and 500 m, but extendable up to 1000 m with the repeater module.)
SC-bus (Max. 50 units and 1000 m)
BACnet®/IP
DSS
MIS
SAnet
I/F
Intelligent Component
Series
ACTIVAL™
Infilex™ZM
Model WY5122
SAnet (Max. 15 addresses)
Intelligent Component
Series
Damper actuator
Display Panel
Intelligent Component
Series
ACTIVAL™PLUS
Temperature sensor
for pipe surface
DSS: Data Storage Server
MIS: Management Integration Server
PMX-III: PARAMATRIX™-III
SCS: System Core Server
SMS: System Management Server

AB-6675
4
Model Numbers
Model VY5460F00XX is the model for the valve and actuator integrated into a single unit.
The model number label is attached to the yoke.
Actuator/valve Actuator Valve
Base
model
number
Control
signal
Rating/
material Type ⎯Nominal size/Cv
⎯Description
VY54 Motorized three-way valve with flanged-end connection
6 SAnet
0 JIS 10K / JIS FC200
F
IEC IP54 protected and standard torque type actuator
with terminal block
(Mountable valve sizes: DN50 to DN80)
00 Fixed
51 DN50 (2”) / 45 in Cv value
61 DN65 (21/2”) / 70 in Cv value
81 DN80 (3”) / 100 in Cv value
-BFixed
Specifications
For weight, refer to the table shown in the section Dimensions.
Valve specifications
Item Specification
Model Three-way valve with flanged-end connection, proportional control
Body pressure rating JIS 10K (Max. working pressure: 1.0 MPa)
Model number Nominal size Cv Close-off ratings
VY5460F0051 DN50 (2”) 45 0.3 MPa
VY5460F0061 DN65 (21/2”) 70 0.2 MPa
Size, Cv, Close-off rating.
VY5460F0081 DN80 (3”) 100 0.15 MPa for mixing use
0.1 MPa for diverting use
Body Gray cast iron (equivalent to JIS FC200)
Retainer Stainless steel
Ball, stem Stainless steel
Seat ring PTFE with filler
Gland packing Inorganic fiber
Materials
Gasket Non-asbestos joint sheet
End connection JIS 10K flanged-end, flat face flange (FF)
Applicable fluid Chilled/hot water, brine (ethylene glycol solutions, 50 % max.)
Allowable fluid temperature 0 °C to 100 °C (Non-freezing)
Flow characteristic Linear (Refer to Fig. 2 for the linear flow characteristic diagram.)
Rangeability 30 : 1
Seat leakage 0.1 % of rated Cv value
Paint Gray (equivalent to Munsell 5B 4/1)
Actuator to be combined Integrated with the valve
Linear flow characteristic diagram Flow direction
Figure 2. Linear flow characteristic Figure 3. Flow direction
Cv value / Rated Cv value (%)
A
ctuator input signal (%)
Port B Port A
Composite flow characteristic Mixing:
Port A/Port B
to Port AB
Diverting:
Port AB
to Port A/Port B

AB-6675
5
Actuator specifications
Item Specification
Power supply 24 V AC ±15 %, 50 Hz/60 Hz
Power consumption 10 VA
Timing 63 ±5 sec (50 Hz) / 53 ±5 sec (60 Hz)
Control signal SAnet
Input type Potential free (dry) contact inputSub-DI
(contact input) Voltage, current 20 V DC, 5 mA (∗Unlike Models VY516XK, VY516XH, this product does not have forced
fully-close input.)
Output type Potential free (dry) contact output
Contact rating 200 V AC/24 V DC, Max. 0.5 A (2 A at startup)
Sub-DO
(contact output)
Min. applicable load 24 V DC, 5 mA
LED indication Description
Initializing Continuous ON →LED indication corresponding to the operating status (after initializing is
complete.)
Normal Repetition of
1-second ON →1-second OFF.
Major alarm Continuous ON.
Minor alarm Repetition of
1-second ON →0.25-second OFF →
0.25-second ON →0.25-second OFF.
Communication error
(and minor alarm)
Repetition of
0.25-second ON →0.25-second OFF
Manual operation Repetition of
0.25-second ON →0.25-second OFF →
0.25-second ON →1.25-second OFF.
Error during
manual operation
Repetition of
0.25-second ON →0.25-second OFF →
0.25-second ON →0.25-second OFF →
0.25-second ON →0.75-second OFF.
Communication Transmission system Voltage transmission (SAnet)
(via SAnet) Transmission speed 1200 bps
Transmission distance Transmission distance varies depending on the number of devices and the type of devices to be
connected to. For details on the transmission distance, refer to Installation Manual of Intelligent
Component Series for SAnet Communication (AB-6713).
Case Die cast aluminum
Top cover, terminal cover Polycarbonate resin (Color: gray)
Materials
Yoke Steel plate
Case NoneSurface finishing
Yoke Electro-galvanized (Bright chromate finish)
Valve position indication Pointer located at the bottom of the actuator shows the position by pointing at the value of the
scale (0 to 100) on front, rear, and bottom sides.
(0: B-AB (Port B fully open) to 100: A-AB (Port A fully open))
Manual operation Available. Refer to the section Manually opening/closing the ACTIVAL.
Wires connection M3.5 screw terminal connection
Enclosure rating IEC IP54 (dust-proof and splash-proof)
Insulation resistance Between terminal and case: 5 MΩor higher at 500 V DC
Dielectric strength Between terminal and case: 500 V AC/min with 5 mA or less leakage current
0.25s
0.25s
0.25s
0.25s0.25s
0.75s
ON
OFF
0.25s
0.25s
0.25s
1.25s
ON
OFF
0.25s
0.25s
0.25s
0.25s 0.25s
0.25s
ON
OFF
0.25s
1s
0.25s
0.25s
0.25s
ON
OFF
1s
1s
ON
OFF

AB-6675
6
Valve and actuator (as a single unit) specifications
Item Specification
Environmental conditions Rated operating condition Limit operating condition Transport/storage conditions
(packaged*2)
Ambient temperature*1-20 °C to 50 °C -20 °C to 60 °C -20 °C to 70 °C
Ambient humidity 5 %RH to 95 %RH
Vibration 4.9 m/s2(10 Hz to 150 Hz) 4.9 m/s2to 9.8 m/s2
(10 Hz to 150 Hz)
19.6 m/s2(10 Hz to 150 Hz)
Notes: ∗1 Do not allow the fluid to freeze.
∗2 Actuator shall be packed during transport.
Installation locations Indoor / outdoor (Keep away from direct sunlight.)
Installation orientation Installable in any position ranging from upright to sideways (90°tilted.)
Position for shipment Port A 100 % (fully open) preset at factory.
Function
Function Specification
Data monitoring Following items can be monitored/operated from the host system (savic-net FX) and Infilex GC/ Infilex GD.
Valve position setting, valve position measuring, sub-DO output, sub-DI monitoring
∗Note:
Above function is available in combination with Infilex GC/Infilex GD and savic-net FX.
Wire specifications
For details regarding specifications of SAnet communication line (24 V (∼), GND (⊥), SAnet), refer to the Installation Manual of
SAnet for Intelligent Component Series (AB-6713).
Item Specification Length
Contact input (sub-DI) JIS CVV, JIS VCT, JIS IV, KPEV for low power
0.75 mm2, 0.9 mm2, 1.25 mm2, 2.0 mm2
30 m
Contact output (sub-DO) JIS CVV, JIS VCT, JIS IV, KPEV for low power
0.75 mm2, 0.9 mm2, 1.25 mm2, 2.0 mm2
30 m
Note
∗KPEV: Wire standard provided by Furukawa Electric Co., Ltd.
Options
For options, separate order is required.
Item Specification Note
Part No. 83104346-003 Applicable wire size: φ7 mm to φ9 mm
Part No. 83104346-004 Applicable wire size: φ9 mm to φ11 mm
Seal connector
Part No. 83104346-005 Applicable wire size: φ11 mm to φ13 mm
Seal connector is necessary for IEC IP54
protection.
Part No. 83104346-012 Applicable wire size: φ6 mm to φ8 mm
Part No. 83104346-013 Applicable wire size: φ7 mm to φ9 mm
Seal connector
for SAnet cable
gland Part No. 83104346-014 Applicable wire size: φ9 mm to φ11 mm
Seal connector for SAnet cable gland with three
ports is necessary for IEC IP54 protection.
SAnet cable gland with three ports
Part No. DY7000A1000
For the specifications of SAnet cable gland with three ports, refer to the Specifications (AS-923E).
For the installation of SAnet cable gland with three ports, refer to the Installation Manual of
Intelligent Component Series for SAnet Communication (AB-6713).
Outdoor cover Part No. DY3001A1017 Required when the product is installed outdoors.
Service parts
Item Part number Description
Seat ring and O-ring set 83164610-001
83164610-002
83164610-003
for DN50 (2”) model
for DN65 (21/2”) model
for DN80 (3”) model
Retainer adaptor set 83164612 for DN50, DN65, DN80 models
A tool to remove the seat ring retainer
Spacer 82550709-001 for DN50, DN65, DN80 models
O-ring (large) 83104662-117 for DN50, DN65, DN80 models
O-ring (small) 83104662-113 for DN50, DN65, DN80 models
Packing 82550159-002 for DN50, DN65, DN80 models
Gasket 82550154-001 for DN50, DN65, DN80 models

AB-6675
7
CE Marking Conformity
This product complies with the following Electromagnetic Compatibility (EMC).
EMC : EN61000-6-2, EN55011 Class A
Dimensions
Model number Valve size
(DN) H (mm) H1(mm) H2(mm) L (mm) L1(mm) t (mm) φC (mm) φD (mm) φh (mm) N Weight
(kg)
VY5460F0051 50 269.5 131 125 204 102 20 120 155 19 4 14
VY5460F0061 65 274 135.5 130 230 115 22 140 175 19 4 18.5
VY5460F0081 80 278.5 140 150 240 120 22 150 185 19 8 20
Figure 4. Dimensions and maintenance clearance (mm): Models VY5460F
Parts Identification
Figure 5. Parts identification
Top cover
Terminal cover
Top cover
Knockout hole
Yoke
A
ctuato
r
Valve bod
y
Pointer
Stem
Seat ring
Retainer
: Heat insulation
Joint
Gland packing
Gasket
Ball
O-ring
Note:
Leave enough clearance for maintenance and wire connection afte
r
installation. 600 mm or more clearance is recommended.
Install the product in a location where address setting inside the cover can
visually be checked.
Min. 300 70 70 Min. 300
H
H2H1
L1
L
t
φD
Flow direction
Min. 600 82 85 Min. 300
Min. 300
N ×φh
t
φ
C

AB-6675
8
Installation
Precautions for installation
CAUTION
•Installation and wiring must be performed by qualified personnel in accordance with all applicable safety
standards.
•Install the product in the position as specified in this manual. Excessively tight connection of piping and improper
installation position may damage the valve.
•After piping installation, make sure no fluid leaks from the connecting parts. Incorrect piping may cause fluid
leakage.
•Do not allow any foreign substance inside the piping. Flush the piping so that no foreign substance remains.
Attach a strainer in a pipe on the inflow side of the product to prevent equipment damage.
•ACTIVAL Model VY5460F is the valve and actuator integrated into a single unit. Do not combine the valve with any other
actuator, or do not combine the actuator with any other valve.
•To remove foreign substances inside the pipes, install a strainer with 40 or more meshes on the inflow side of each valve. In
case that the strainers cannot be installed on the inflow side of each valve, install it on the pipe diverting sections (sections
diverting from main piping system to sub piping system).
•To use the product as mixing valve, install the product so that the flow direction of process fluid agrees with the arrow
indicated on the valve body. As diverting valve, install the product so that the flow direction of process fluid disagrees with
the arrow.
Installation location
CAUTION
•Avoid using the product in an atmosphere containing oxidizing gas, explosive gas, etc. since it may damage the
actuator, valve, or their components.
•Do not install the product nearby a steam coil or a hot-water (in high temperature) coil. High heat radiation may
result in an actuator malfunction.
IMPORTANT:
•The top and the terminal covers might be corroded by chemicals and organic solvent or their vapor. Do not
expose the ACTIVAL to such substances/vapor.
•
A
lthough the ACTIVAL can be used in high humidity environments (max. 95 %RH), do not immerse the
actuator in water.
•Although the ACTIVAL can be used outdoors, be sure not to expose the ACTIVAL to direct sunlight.
•Install the ACTIVAL in a position allowing easy access for maintenance and inspection. Fig. 4 shows the minimum
clearance for maintenance and inspection. When installing the ACTIVAL in a ceiling space, provide an access hole within
the 50 cm radius of the ACTIVAL. And, place a drain pan under the valve.
•Do not mount the ACTIVAL on a pipe where water hammer occurs, or where solid objects including slug may accumulate.
Identification between Ports A and B
Valve body without heat insulation wrapped:
Identify ports A and B with the letters ‘A’ and ‘B’ marked on the valve body.
Valve body with heat insulation wrapped:
Identify ports A and B with the raised bar shape on the valve bonnet.
Figure 6. Identification between Ports A and B
Bar shape
Facing the bar shape,
Left: Port A
Right: Port B

AB-6675
9
Mounting position
The ACTIVAL can be mounted in any position ranging from upright to sideways (90°tilted). The ACTIVAL should be installed
with its actuator vertically positioned above the valve body. (See Fig. 7.) However, the ACTIVAL must be installed always in
upright position outdoors.
Figure 7. Mounting position
Piping
•Check that the model number of the product is what you ordered. The model number is shown on the label attached to the
yoke.
•Install a bypass pipe and gate valves on the inflow, outflow, and bypass sides. If difference between the coil side pipe
resistance (which contains coil resistance) and the bypass side pipe resistance are extremely large, use the gate valves to
adjust the pressure. Also, install a strainer with 40 or more meshes on the inflow side.
•When installing the ACTIVAL to the pipes, do not allow any object, such as chips, to get inside a pipe or valve. Valve cannot
fully close, or the valve seat may get damaged causing fluid leakage, due to an object jammed inside the valve.
•When piping, do not apply too much sealing material, such as solidifying liquid and tape, to the pipe connection sections so
that these materials flow into the valve. Valve cannot fully closes, or the valve seat may get damaged causing fluid leakage,
due to the sealing material jammed inside the valve.
•Before activating the ACTIVAL, flush the pipes (with the ACTIVAL installed) at the maximum flow rate to remove all the
foreign substances. Fully open (100 % position) the ACTIVAL to flush. (Factory preset position: Port A 100 %)
Heat insulation
Do not apply heat insulation to the actuator or to the yoke, as shows in Fig. 5. If the yoke and the actuator are covered
with insulation material, the pointer cannot be checked and may be distorted.
Factory preset position
The actuator shaft is positioned at 100 % (in fully open position) of the port A for shipment. The shaft is thus completely turned
clockwise, and the pointer points at ‘100’. (See Fig. 8.)
Figure 8. Pointer position for shipment
Correct mounting Incorrect mounting
Pointer

AB-6675
10
Application examples
For diverting valve application For mixing valve application
Figure 9. Example of diverting valve application Figure 10. Example of mixing valve application
Installation examples
For diverting valve installation For mixing valve installation
Figure 11. Example of diverting valve installation Figure 12. Example of mixing valve application
Manually opening/closing the ACTIVAL
IMPORTANT:
•Manually opening/closing the ACTIVAL with the power (24 V AC) applied may damage the actuator.
•To manually open/close the ACTIVAL, do not turn the joint beyond the fully open (100)/closed (0) mark.
•To manually open/close the ACTIVAL, slowly turn the joint. If shock is sent to the actuator, the actuator may
get damaged.
Disconnect the power from the ACTIVAL before manually operating the ACTIVAL. As shown in Fig. 13, from the front of the
ACTIVAL, hold the joint using a tool such as a wrench, and turn the joint slowly toward the set position.
Figure 13. Manual operation
Joint
Hold the joint using a wrench
and turn slowly.
B A
B A
AB AB
B A
B A
AB AB
A
B
AB
AB
A
B
Upright
90°tilted
A
B
AB
B
AB
A
Upright
90°tilted

AB-6675
11
Procedure to change the actuator mounting position
IMPORTANT:
•Do not change the combination of the valve, yoke, and actuator.
•Set the ACTIVAL (actuator and valve) in 100 % position when changing the mounting position. If the valve in
0 % position is assembled with the actuator in 100 % position, the actuator puts torque on the closed valve, and
the gear of the actuator gets damaged.
1) Remove the screws connecting the actuator and the yoke. Lift the actuator and detach it from the yoke. Make sure that the
mark on the valve stem faces the same direction as the bar shape on the valve bonnet faces. <Step 1 in Fig. 14>
2) Remove the screws connecting the yoke and the valve. <Step 2 in Fig. 14>
3) Change the facing direction of the yoke. The yoke and actuator can be horizontally rotated every 90°(0°/90°/180°/270°
from the factory preset position) to mount onto the valve.
4) A thermal insulation sheet is inserted between the yoke and the valve. When changing the mounting positions, reinsert the
sheet and then fit the yoke into the new mounting position.
5) Before fixing the yoke to the valve with the screws, check that the actuator engages correctly with the valve stem (at the new
mounting position). Check that the pointer of the actuator indicates 100 % position as well. Then, fix the yoke to the valve.
<Step 3 in Fig. 14>
6) Mount the actuator. Place the actuator, with its facing direction changed, on the yoke, and fix them with the screws.
<Step 4 in Fig. 14>
7) Check that the ACTIVAL with the mounting position changed operates smoothly (from 0 % to 100 %).
Figure 14. Changing the actuator mounting position
Step 1 Step 4
Lift off the actuator.
Change the actuator mounting
position, and remount the
actuator on the yoke.
Step 2 Step 3
Detach the yoke from the
valve.
Change the yoke mounting
position, and remount the yoke
on the valve.
Thermal insulation sheet
Mark
Valve stem
Bar shape

AB-6675
12
Wiring
WARNING
•DANGER: To prevent the risk of severe or fatal electrical shock, always disconnect power source and product
power supply before performing any wiring.
CAUTION
•Installation and wiring must be performed by qualified personnel in accordance with all applicable safety
standards.
IMPORTANT:
•The ACTIVAL is designed for 24 V AC power supply voltage.
Do not apply any other power voltage (e.g., 100 V AC, 200 V AC) to the ACTIVAL.
•To prevent damage, cover the terminals except when connecting/disconnecting wires.
•Do not leave any refuse including metal chips after cutting a knockout hole and after connecting the wires
inside the actuator.
Wiring precautions
1) To lead the wires into the terminals, cut out a knockout hole for a wiring port. Two knockout holes are provided on the
bilateral sides of the actuator terminals. Select a knockout hole according to the conduit mounting direction, and cut it out by
lightly knocking the hole using a screwdriver.
Figure 15. Knockout hole for wiring port
2) Unscrew the 3 setscrews (M4 ×10) of the terminal cover and remove the terminal cover, as shown in Fig. 16.
Figure 16. Terminal cover removal
Knockout hole
for wiring port
1. Unscrew the setscrews.
2. Remove terminal cover.
Terminal cover
Setscrews
Terminal block
Ground terminal

AB-6675
13
3) Correctly connect the wires to the terminals with M3.5 screw terminal lugs, referring to Fig. 17.
To connect a device with over 100 V AC to the sub-DO, be sure to ground the actuator with 100 Ωor lower ground
resistance. Refer to Fig. 16 for the location of each terminal.
Figure 17. Basic connection example
4) Separate sub-DO line from SAnet and sub-DI lines. Do not lead the sub-DO line through the wiring port (knockout hole) for
SAnet and sub-DI lines to protect sub-DO line from noise.
Figure 18. Separation of sub-DO line from other lines
If sub-I/O is used, SAnet line cannot be daisy-chained since the number of the wiring ports is limited. In such a case, use
SAnet cable gland with three ports to daisy-chain the SAnet line, or branch the SAnet line ahead of connecting to the
terminals.
Note:
For wiring of SAnet line, refer to the Installation Manual of Intelligent Component Series for SAnet Communication (AB-6713).
To keep IP54 protection (dust-proof and splash-proof),
Use a water-proof connector for the ACTIVAL in a high-humidity environment or outdoor location. Through wiring port with the
seal connector (Part No. 83104346-00X) attached to, 1 cable can be lead in. Through wiring port with the SAnet cable gland
(with three ports) and the seal connectors attached to, 3 cables can be lead in.
•Be sure to completely close the terminal cover and the top cover.
•Waterproof the wiring port.
- For cable connection, use a water-proof connector. Following is the recommended parts Azbil Corporation supplies.
Seal connector: Part Nos. 83104346-003, 83104346-004, 83104346-005
- To daisy-chain the SAnet line, use the SAnet cable gland with three ports and the seal connector Azbil Corporation
supplies.
SAnet cable gland with three ports: Part No. DY7000A1000
Seal connector: Part Nos. 83104346-012, 83104346-013, 83104346-014
- For conduit connection, use a water-proof plica tube or the like.
1234567
∼⊥SAnet
24 V AC
DI
SAnet
Humidifier
∼
DO
Cable
Thermostat, differential
p
ressure swtich
,
etc.
Actuator of Model VY5460F
3-core
2-core Actuator of
Model VY5460F
SAnet
Filter alarm
,
etc.
5-core
∼
⊥
SAnet
DI
DO
Joint box

AB-6675
14
Address Setting (Addressing)
To SAnet interface module, ACTIVAL Model VY5460F and other Intelligent Component Series devices including ACTIVAL
PLUS and damper actuators are connected via SAnet. Set address for the terminal devices (Intelligent Component Series
devices) so that the SAnet interface module can recognize all the terminal devices connected. Follow the procedure below to
set the address. For details regarding address setting (addressing), ask our sales/service personnel.
1) Unscrew the setscrews and remove the terminal cover. See Fig. 16 for removing the terminal cover.
2) Set address. (See Table 1.) Address can be set with rotary switch, with service pin switch, or based on SAnet ID. Rotary
switch and service pin switch are provided on this product. To set the address with rotary switch or based on SAnet ID, Data
Setter or PC-MMI is required. Set the address in either way according to your availability.
Setting with rotary switch:
Turn the rotary switch using a precision Phillips screwdriver and set.
Setting with service pin switch:
1. Set the rotary switch to ‘0’.
2. Start addressing operation* of Data Setter or PC-MMI.
Then, press the service pin switch. Do not keep the
switch pressed for longer than 5 seconds.
3. Address is set within 5 seconds after pressing the
service pin switch.
∗For the addressing operation of Data Setter or PC-MMI, ask
our sales/service personnel.
Setting based on SAnet ID:
1. Set the rotary switch to ‘0’.
2. With Data Setter or PC-MMI, enter the SAnet ID (on the
product code label) and address number to set. The
product code label is attached on the side surface of the
actuator, as shown in Fig. 20.
∗For the addressing operation of Data Setter or PC-MMI, ask
our sales/service personnel.
3) Attach the terminal cover after setting the address.
IMPORTANT:
•While the terminal cover is removed, do not touch the terminal block or allow anything to touch the terminal
block.
•If the service pin switch is kept pressed for longer than 5 seconds, the mode will be switched and operation
error (data point trouble) will be occurred. In such a case, press the service pin switch again and keep it
pressed for longer than 10 seconds to go back to the normal mode.
Table 1. Basic address setting of this product and other Intelligent Component Series devices
Add. Device Sub-DO Sub-DI
1 Outdoor air damper
2 Exhaust air damper
3 Return air damper
4 Switch damper of total heat exchanger for outdoor air
5 Switch damper of total heat exchanger for exhaust air
6 Chilled/hot water valve / Chilled water valve Filter alarm
7 Hot water valve (Chilled water valve*) Humidifying ON/OFF
8 Humidifying valve
D (13) Reserved
E (14) Reserved
F (15) Reserved
Notes:
∗1. For ‘chilled/hot water valve + chilled water valve’ application, set address 6 for chilled/hot water valve and 7 for chilled water valve.
∗2 Items in bold characters are the basic address to set for this product.
∗3 The above table is a basic setting example. Set address and use sub-I/O in response to system configuration, installation location, and
wiring best suitable for your application.
LED
Service pin switch
(for Data Setter/PC-MMI)
Rotary switch
Terminal block
Figure 19. Terminal block, LED, setting switches
(without terminal cover)
Figure 20. SAnet ID on the product code label
SAnet ID

AB-6675
15
System Indication Label
A part of the product code label can be a system indication label. Clip the part, and write down the name of the system, host
controller number of the system, SAnet line number, and address. Then attach the part, as the system indication label, to a
location where you can easily check.
Figure 21. System indication label
IMPORTANT:
•Attach the system indication label to a clean location with no dust, oil, or moisture.
•Attach the system indication label by pressing the whole surface of the label to stick on the product surface.
Manual Operation Mode
In the manual operation mode, even when this product has not been connected via SAnet yet, the operations shown in Table 2
can be performed. Follow the procedure below for the operation check. For the locations of the service pin switch and the rotary
switch, see Fig. 19.
1) Keep the service pin switch pressed for 10 seconds to enter the manual operation mode.
2) Turn the rotary switch to the desired position (See Table 2.), using a precision slotted screwdriver.
Operation will start in 3 seconds after setting the rotary switch.
Table 2. Operations in the manual operation mode
Rotary switch scale Operation
0 Restart (to go back to the normal operation mode)
2 Fully close (in 0 % position)
4 Open in 50 % position
6 Fully open (in 100 % position)
E Automatic adjustment of the potentiometer.
Notes:
∗Rotary switch scales 1, 3, 5, 7, 8, 9, A to D and F are
not available in the maual operation mode.
∗Generally, potentiometer is not replaced by itself.
Operation of auxiliary switch ‘E’, therefore, is not
necessary.
3) After the operation, press and hold the service pin switch for 10 seconds to go back to the normal operation mode.
4) If the address is set with the rotary switch, be sure to reset the rotary switch at the address after entering the normal
operation mode.
Clip and write down the following.
•SYSTEM NAME:
System name or device number
•CON No.:
Host controller number
(Infilex GC/Infilex GD number)
•SAnet No.:
SAnet line number
•ADDRESS:
SAnet address
System indication label

AB-6675
Specifications are subject to change without notice.
Building Systems Company
1-12-2 Kawana, Fujisawa, Kanagawa
251-8522 JAPAN
http://www.azbil.com
Rev. 3.0 Dec. 2015 AB-6675
(J: AI-6675 Rev. 2.0)
16
Inspection and Troubleshooting
CAUTION
•Avoid touching the installed product (valve body, yoke, joint). When being used to control hot water, it reaches high
temperature and may cause burn injury.
•Inspect the ACTIVAL according to Table 3.
•Manually open/close the ACTIVAL at least once a month if it is left in inactive state for a long period.
•Visually inspect the fluid leakage of the valve and the actuator operations every six months. If any of the problems
described in Table 4 are found, take corresponding actions shown in the table.
If your problem is not solved by the corresponding action, please contact Azbil Corporation near you.
Table 3. Inspection items and details
Inspection item Inspection interval Inspection detail
Visual inspection Semiannual •Fluid leakage from the gland and the flange face
•Loosened bolts
•Valve and actuator damages
Operating status Semiannual •Unstable open/close operation
•Abnormal noise and vibration
Routine inspection Any time •Fluid leakage to the outside
•Abnormal noise and vibration
•Unstable open/close operation
•Valve hunting
Table 4. Troubleshooting
Problem Part to check Action
Fluid leaks from the flange face. Loosened flange bolts
Gasket on the flange face
Misaligned piping
Tighten the flange bolts.
Replace the gasket.
Redo piping.
Fluid leaks from the gland part. ⎯Consult with our sales personnel.
Fluid leaks from the bonnet. Loosened bolts Tighten the bolts.
Valve does not operate smoothly /
valve stops halfway /
valve does not operate at all.
Conditions of the power applied and of the input
signal applied
Loosened terminals
Wiring condition / disconnected wires
Check the power supply and the controller
connected to.
Tighten the terminals.
Check the wiring.
Fluid leaks to the outside of the valve
when the ACTIVAL is in fully closed
position.
Actuator pointer not pointing to fully closed
position
Fully close the ACTIVAL.
The valve vibrates or produces an
abnormal noise.
Primary pressure condition
Differential pressure condition
Adjust the mounting position and change the
installation location.
Valve hunting occurs. Secondary pressure condition
Differential pressure condition
Control stability
Adjust the mounting position and change the
installation location.
Correct the control parameter setting of
controller.
SAnet communication error occurs. ⎯Consult with our sales/service personnel.
ACTIVAL and savic-net are trademarks of Azbil Corporation in Japan or in other countries.
BACnet is a registered trademark of American Society of Heating, Refrigerating and Air-Conditioning Engineers (ASHRAE).
KPEV is a registered trademark of Furukawa Electric Co., Ltd.
