Azbil Infilex VC User manual

AB-7177
1
Specifications/Instructions
Infilex™ VC
Variable Air Volume Controller with Actuator
for BACnet® MS/TP Communication
General
Infilex VC Model WY5706C is our new VAV controller with an
actuator that communicates via BACnet MS/TP. Infilex VC
provides high-performance DDC of VAV unit in a building
air-conditioning system. Thus, Infilex VC, networked even
within a complicated HVAC system, controls VAV unit.
Besides, Infilex VC offers building owners and operators the
flexible and enhanced controls of temperature and VAV for
various VAV units.
Infilex VC sends unique energy-saving information to its
networked BACnet zone controller, enhancing overall
controllability of a building management system.
DDC: Direct digital control
HVAC: Heating, ventilation, and air conditioning
VAV: Variable air volume
Features
●BACnet® VAV controller:
Infilex VC Model WY5706C is integrated in the BACnet
MS/TP network.
●Economical efficiency:
- Temperature and air-volume are controlled by a single
controller.
- VAV controller that resides on an actuator offers great
value.
●Wide range of application:
Most of the major VAV types for industry are
preconfigured in the controller.
●Unique energy conservation control:
- VAV damper opens wide to minimize the fan power
consumed by static pressure.
- Network with a zone controller allows supply air
temperature to be modified at an optimum level.
●Advanced building management integrated into BMS:
Our digital user terminal Neopanel enables users and
operators to modify the preset setting of temperature and
operating schedule (to extend) and offers flexibility of
temperature control and schedule control.
●BTL certified product:
Infilex VC Model WY5706C is a BACnet® Application
Specific Controller (B-ASC).
●CE Marking certified product:
Infilex VC Model WY5706C conforms to all the
applicable standards of CE Marking.
BTL: BACnet Testing Laboratory

AB-7177
2
Safety Instructions
Please read instructions carefully and use the product as specified in this manual. Be sure to keep this manual near by for ready
reference.
Restrictions
This product is targeted for general air conditioning. Do not use this product in a situation where human life may be affected. If
this product is used in a clean room or a place where reliability or control accuracy is particularly required, please contact our
sales representative. Azbil Corporation will not bear any responsibility for the results produced by the operators.
Warnings and Cautions
WARNING Alerts users that improper handling may cause death or serious injury.
CAUTION Alerts users that improper handling may cause minor injury or material loss.
Signs
Alerts users possible hazardous conditions caused by erroneous operation or erroneous use. The symbol inside 
indicates the specific type of danger.
(For example, the sign on the left warns of the risk of electric shock.)
Notifies users that specific actions are prohibited to prevent possible danger. The symbol inside graphically
indicates the prohibited action.
(For example, the sign on the left notifies that disassembly is prohibited.)
Instructs users to carry out a specific obligatory action to prevent possible danger. The symbol inside graphically
indicates the actual action to be carried out.
(For example, the sign on the left indicates general instructions.)
WARNING
Before wiring and maintenance, be sure to turn off the power to the product.
Failure to do so might cause electric shock.
To control a VAV unit with electric heater, be sure to provide a circuit to prevent temperature rise.
Failure to do so might cause fire or overheating.
To control a VAV unit with electric heater, configure the system so that air conditioning unit will not stop when the VAV
unit is turned off. This allows the electric heater to cool down after it is turned off.
Failure to do so might cause fire or device damage.
CAUTION (1/2)
Installation and wiring must be performed by qualified personnel in accordance with all applicable safety standards.
Install and use the product in a location that meets the operating conditions (temperature, humidity, power, vibration,
shock, mounting direction, atmospheric condition, etc.) as listed in the specifications.
Failure to do so might cause fire or device failure.
All wiring must comply with applicable codes and ordinances.
Make sure all the wires are tightly connected to the corresponding terminals.
Failure to do so might cause device failure or overheating.

For wiring, strip each wire insulation as specified in this manual. If the strip length is longer than the specified, the
stripped part of the wires will be exposed, causing electric shock or short circuit between adjacent terminals. If it is
shorter, the stripped part will not contact the connector.
If more than the rated power voltage is applied to the product, replace the product with new one for your safety.
Failure to do so might cause device failure or overheating.
Be sure to provide a circuit breaker for the power to the product as the product does not have a power switch.
Do not test the withstand voltage of the product.
Doing so might cause accident or device failure.

AB-7177
3
CAUTION (2/2)
Do not disassemble the product.
Doing so might cause electric shock or device failure.
Do not touch the moving parts of the product.
Doing so might cause injury.
Do not incinerate the product for waste disposal. The cover will generate toxic gas when being incinerated.
Do not reuse all or part of this product after disposal of the product.
Dispose of the product as industrial waste in accordance with your local regulations.
Do not reuse all or part of this product.

AB-7177
4
System Configuration
Infilex VC integrated into our building management system (BMS): savic-net

FX
Notes:
*1 MIS may be used instead of SMS and DSS for your savic-net FX system. Note that MIS cannot coexist with SMS or DSS in the same
system.
*2 Maximum of 75 MS/TP devices including Infilex VC (not including the BACnet router) can be connected to one Infilex BC.
*3 Maximum of 31 Infilex VC are connectable to one MS/TP network segment of the LOYTEC L-IP™ BACnet router Model LIP-ME201. Do not
connect any devices except Infilex VC on this MS/TP network segment (where Infilex VC is connected).
*4 Use LOYTEC L-IP™ BACnet router Model LIP-ME201 for Infilex VC integrated in savic-net FX.
*5 Up to two Neopanel can be connected to one Infilex VC.
For two Neopanel connection, provide Model QY7205C_ _ _1 for the address 1 and Model QY7205C_ _ _2 for the address 2.
*6 Neopanel and a temperature sensor can be connected to the same Infilex VC.
Figure 1. System configuration example: Infilex VC integrated into savic-net FX BMS
BACnet/IP
SMS DSS
MIS*1
Client PC
Infilex

VC
Model WY5706
Temperature
sensor
Neopanel*5
Model QY7205C_ _ _2
Neopanel*5
Model QY7205C_ _ _1
BACnet
router*3*4
Infilex

VC
Model WY5706
Neopanel*6
Model QY7205_ _ _C1
Infilex

VC
Model WY5706
Temperature
sensor
Infilex

VC
Model WY5706
BACnetMS/TP
(Max. 31 devices, Max. 1,200 m long)
Neopanel
Model QY7205C_ _ _1
DSS: Data Storage Server
MIS: Management Integration Server
SMS: System Management Server
Infilex BC
I/O control unit
Expansion bus
I/O modules
Infilex BC*2
Infilex BC
I/O control unit I/O modules
Infilex BC
control unit

AB-7177
5
Model Numbers
Base model
number Power Actuator DO output
Pt input
type Description
WY5706 Infilex VC for BACnet MS/TP communication
C 24 V AC
5 Fixed.
1 5 N

m torque
2 10 N

m torque
1 With internal air flow sensor, DO: 0 pt.
3
With internal air flow sensor,
DO: 3 pts. (2 pts. for reheat control, 1 pt. for fan control)
0 Pt100 input
K Pt1000 input
Part Numbers of Optional Parts and Tools
Item Part number
Universal bracket 12595-00001
Modular branch unit DY7203A0000
Modular relay units (5 pieces/set) DY7202A0000
Adapters for connecting to a Pt100 temperature sensor (10 pieces/set) DY7204A0003
Adapters for connecting to a user terminal (10 pieces/set) DY7204A0008
Modular plugs (100 pieces/set) DY7207A0100
Modular crimper DY7205A0002
Modular cable tester DY7206A0000
Connector cable for two terminals (short cable model) DY7221A
Terminators (10 pieces/set) 83172137-001
Note:
* For details of the optional parts and tools shown above, see the Optional Parts and Optional Tools sections.

AB-7177
6
Specifications
Basic specifications
Item Specification
Power supply 24 V AC

15 % (50 Hz/60 Hz)
Power consumption 5 Nm: 8 VA / 10 Nm: 9.5 VA
Rated torque 5 Nm / 10 Nm
Operating range To 95
Operating time
(for 95operating angle)
Operation mode 5 N

m torque type 10 Nm torque type
Forced open/close 150 seconds 150 seconds
Synchronisation
(An operation mode to synchronise the
actuator position with the damper position.)
75 seconds 86 seconds
Automatic control (with variable speed) 120 to 300 seconds 120 to 300 seconds
Attachable damper shaft 5 Nm torque type 10 Nm torque type
Thickness Φ6 mm toΦ20 mm (circular cross section) Φ8 mm toΦ26.7 mm (circular cross section)
4.5 mm square to 14 mm square
(square cross section)
5.7 mm square to 18.8 mm square
(square cross section)
Length 37 mm or longer 40 mm or longer
Operating environmental
conditions
Temperature 0 C to 50 C
Humidity 10 %RH to 90 %RH (Non-condensing)
Vibration Max. 3.2 m/s² (10 Hz to 150 Hz)
Transport/storage conditions Temperature -20 C to 60 C
Humidity 5 %RH to 95 %RH (Non-condensing)
Vibration Max. 9.8 m/s² (10 Hz to 150 Hz)
Enclosure rating Equivalent to IEC IP30: Dust-proof (in wired, covered, and plugged state)
Sound power level 35 dB or lower
Installation In VAV control box
Address setting Rotary switch 2
Materials Back plate: Zinc plated steel
Clamps and screws : Zinc plated steel
Housing: PC-ABS
Cover of air flow sensor: Thermoplastic elastomer
Cover of nonuse connector (for setting): Thermoplastic elastomer
Universal bracket: Zinc plated steel
Weight 5 Nm torque type: 500 g
10 Nm torque type: 800 g
IEC: International Electrotechnical Commission
PC-ABS: Polycarbonate acrylonitrile butadiene styrene
VAV: Variable air volume

AB-7177
7
Input/output specifications
Unit to be
connected Input/output description Input/output specification Connection type Wire/tube specification
VAV unit
Air flow signal input
Air flow pulse Voltage pulse input Terminal connection:
Push-in terminal block
2.5 mm2or smaller
Max. 5 m
Voltage: 5 V DC

20 % for high level
0 V DC to 0.5 V DC for low level
Current: Max. 10 mA
Pulse width: 450

s or more for high level
450 s or more for low level
Frequency: Max. 1000 Hz + 10 % or less
100 Hz or higher for full span
Current restriction resistance: 470

Direct air flow
sensor
Differential pressure input sensor
Differential pressure sensing range:
P = 0 Pa to 250 Pa
Temperature characteristics:
0.5 % of full span
C (0 C to 50 C, 1013 hPa)
Tube
connection
Length: Max. 1m at each port
Inner diameter (flexible tube):
5.0 mm to 6.0 mm
Inner diameter (inflexible tube):
5.5 mm to 6.5 mm
Outer diameter: Max. 10.0 mm
Material: PVC, silicon rubber
(e.g., TYGONModel R-3603)
Heater and fan Dry contact
30 V AC, 0.8 A or 30 V DC, 0.5 A
Terminal connection:
Push-in terminal block
2.5 mm2or smaller
Max. 5 m
Temperature
sensor
Pt100 input Pt100 temperature sensor
Input temperature range: 0 C to 50 C
Connector
connection*1
LAN cable*2
Max. 50 m
Pt1000 input Pt1000 temperature sensor
Input temperature range: 0 C to 50 C
Connector
connection*3
1.25 to 2.5 mm2+
connector cable (Model
DY7221A)
Max. 50 m
User terminal Temperature setting
Air conditioning
ON/OFF
Serial voltage transmission
Transmission speed: 100 bps
Connector
connection*1
LAN cable*2
Max. 50 m
Communication
line
BACnet MS/TP RS-485, 3-wire
Baud rate (auto-detecting):
9.6 kbps/19.2 kbps/38.4 kbps/76.8 kbps
Terminating resistor: External
Terminal connection:
Screw terminal block
22 AWG or 24 AWG
2 pairs of shielded twist
pair cable /
1 pair of shielded twist
pair and one conductor
cable*4
Max. 1200 m*5
Power supply

Power supply voltage: 24 V AC

15 % Terminal connection:
Push-in terminal block
2.5 mm2or smaller
Notes:
*1 For connector connection, use Bel Stewart Connector’s Plug: Model SS-37000-002.
This plug is also available at Azbil Corporation. (Part No. DY7207A0100, 100 pieces/set)
*2 LAN cable compliant with EIA/TIA-568 Category 3 or over (⌀0.5 mm 4 pairs) is required.
For *1 and *2, the connector cable (regular cable: Part No. DY7210, short cable: Part No. DY7220) are available at Azbil Corporation.
*3 Use the short connector cable for two terminals (Part No. DY7221A). Other cables are not acceptable.
*4 Recommended cable: Belden's Model 3106A/3107A/9842
*5 The maximum wiring length is only for the cable that meets the following specifications:
- Characteristic impedance: 100–130 Ω
- Line capacity: 50 pF/m or less
- Conductor-shield capacity: 100 pF/m or less
CE Marking Conformity
This product complies with the following Electromagnetic Compatibility (EMC).
EMC: EN61000-6-3
EN61000-6-2

AB-7177
8
Dimensions
5 Nm torque type
Figure 2. Dimensions: 5 Nm torque type (mm)
198
22 176
66
67
17
82.5
35
99
29 11.5
⌀6–⌀20
85.25
5.2

AB-7177
9
10 Nm torque type
Figure 3. Dimensions: 10 Nm torque type (mm)
Universal bracket (requiring separate order)
Figure 4. Dimensions: Universal bracket (mm)
7
5
179
18
23
35
47
58.25
71
83
89.5
5
R2.2
R2.2
4 4
R2.2
⌀4.4
12
2
2
10
206
80 66
25 181
⌀8–⌀26.7
38
104
30.5 18.5
11.5
68
83.5
90.5
5.2

AB-7177
10
Parts Identification
Figure 5. Parts identification
Orange LED
A
ddress switch
Gear release button
Connector (modular jack)
Wire connection indication
(printed on the body)
(See Fig. 6.)
Terminal block (11 pin)
Nonuse connector (for setting)
High pressure port
for differential pressure pickup
Mounting slit
Damper shaft
Screw terminal block
Low pressure port
for differential pressure pickup
Rotation angle adjuste
r
Rotation angle adjuste
r

AB-7177
11
Wire Connection Indication
Figure 6. Wire connection indication printed on Model VY5706C5_3_
Wire Connection Examples
Electric heater connection
Notes:
* For wiring to CN1 and CN2 connectors, refer to the following sections.
-Wiring to user terminal / Pt100 temperature sensor
- Wiring to Pt1000 temperature sensor
* For wiring to CN3 and CN4 terminals, refer to the following sections.
- BACnet MS/TP network wiring
* Operate electric heater and fan by a relay with 24 V AC operating voltage.
* When an electric heater is connected, additionally provide a circuit to prevent temperature rise.
Figure 7. Connection example for two-step electric heater + fan output control (Model WY5706C5_3_)
To temperature senso
r
To Neopanel
To another Infilex VC
To the BACnet router o
r
to another Infilex VC
24 V AC

AB-7177
12
To temperature senso
r
To Neopanel
To another Infilex VC
To the BACnet router o
r
to another Infilex VC
24 V AC
Floating control valve connection
Notes:
* For wiring to CN1 and CN2 connectors, refer to the following sections.
-Wiring to user terminal / Pt100 temperature sensor
- Wiring to Pt1000 temperature sensor
* For wiring to CN3 and CN4 terminals, refer to the following sections.
- BACnet MS/TP network wiring
* Operate fan by a relay with 24 V AC operating voltage.
* Rated voltage of reheat output is 30 V AC. If the voltage of reheat output exceeds 30 V AC, operate reheat valve by a relay.
* For accurate control of Infilex VC installed in a 24-hour system, floating valves are automatically closed when they are kept unclosed for 48
hours.
Figure 8. Wiring example for floating control (Model WY5706C5_3_)

AB-7177
13
Two-step control valve connection
Notes:
* For wiring to CN1 and CN2 connectors, refer to the following sections.
-Wiring to user terminal / Pt100 temperature sensor
- Wiring to Pt1000 temperature sensor
* For wiring to CN3 and CN4 terminals, refer to the following sections.
- BACnet MS/TP network wiring
* Operate fan by a relay with 24 V AC operating voltage.
* Rated voltage of reheat output is 30 V AC. If the voltage of reheat output exceeds 30 V AC, operate reheat valve by a relay.
* For ON/OFF valve, use a valve with automatic return or spring return function.
Figure 9. Wiring example for two-step control (Model WY5706C5_3_)
To temperature senso
r
To Neopanel
To another Infilex VC
To the BACnet router o
r
to another Infilex VC
24 V AC

AB-7177
14
Installation
Installation precautions
●Before installation, be sure to turn off the power to the product.
●Leave the maintenance clearance as shown in the figure below.
Note:
* Dimension L must be larger than [size Φof the modular cables to be connected x 4] for the bend radius.
(e.g., Dimension L for ⌀6 mm modular cable is larger than 24 mm for bend radius.)
Figure 10. Maintenance clearance (mm)
Installation procedure
1) Fully close the VAV damper shaft.
Actuator
torque type
L: Minimum length
of the shaft (mm)
Diameter of the shaft (mm)
5 N

m 37 6 to 20 4.5 to 14
10 N

m 40 8 to 26.7 5.7 to 18.8
Rotate to close.
Damper blade
Damper
shaft
L
Figure 11. Damper shaft
70
70 70
70
L*

AB-7177
15
2) Fully close the actuator of this product, and mount it to the damper shaft. Finger-tighten the fastening nuts of the shaft
clamp to temporarily fix the actuator.
Figure 12. Temporal installation of the actuator body
3) While pressing the gear release button, manually rotate the shaft clamp until it is in the upright position. Then, insert the
universal bracket (protruding part) into the slit of this product and fix the bracket with the two M4 tapping screws.
Note:
* The universal bracket, required for the installation of this product, is commercially available. The universal bracket is also available at
Azbil Corporation (Universal bracket: Part No. 12595-00001). Be sure to separately order if necessary.
Figure 13. Attaching the universal bracket
1. Mount.
2. Finger-tighten.
Fastening nuts
Shaft clamp
1. Press and hold.
Gear release button
1. Rotate.
2. Insert.
Universal bracket
Sli
t
M4 tapping screws
Shaft clamp

AB-7177
16
1. Press and hold.
Gear release button
1. Rotate.
1 mm
Shaft clamp
Rotation angle adjuste
r
for fully closed position
2. Tighten with a wrench.
4) Manually rotate the shaft clamp back to the fully closed position while pressing the gear release button. At this time, be sure
to leave a clearance (approx. 1 mm) between the shaft clamp and the rotation angle adjuster (mechanical stopper) for the
fully closed position. This will allow the actuator to shut off the damper. Using a wrench, tighten the fastening nuts of the
shaft clamp to completely fix this product. See the following table for the nut fastening torque.
Actuator torque type Nut fastening torque (N·m)
5 Nm 5 to 6
10 Nm 8 to 9
Figure 14. Complete installation of the actuator body
5) Manually rotate the shaft clamp until the damper fully opens while pressing the gear release button.
Then, set the rotation angle adjuster for the fully open position.
Figure 15. Setting the operating angle for the fully open position
A
djust and set.
Rotation angle adjuste
r
for fully open position

AB-7177
17
Connection of the tubes to the air flow sensor
For differential pressure pickup, connect the total pressure measuring port of the VAV unit to the high pressure port (indicated
with "+") of this product with a tube. Also connect the static pressure measuring port of the VAV unit to the low pressure port
(indicated with "-") of this product with a tube.
Required specification of the air flow sensor tube
Type Length Inner diameter Outer diameter Material
Flexible tube Max. 1 m 5 mm to 6 mm Max. 10 mm PVC, silicon rubber
Inflexible tube 5.5 mm to 6.5 mm
PVC: Polyvinyl chloride
Notes:
* Use the tube as specified in the above table.
* If the tube of the differential pressure pickup (of the VAV unit) does not meet the required specification shown in the above table, use a joint
to meet the specification.
* Total tube length must be 1 m max. even if two tubes with different diameters are connected by the joint.
Figure 16. High and low pressure ports for differential pressure pickup
High pressure port
for differential pressure pickup
Low pressure port
for differential pressure pickup

AB-7177
18
Wiring
Push-in terminal connection
Wires of power supply and DO (digital output) are connected to the push-in terminal block. Follow the procedure below for the
wiring connections.
1) Strip the 5-6 mm insulation of the wire end. (If the insulation stripped part is longer than the specified, it will be exposed
causing electric shock or short-circuit between adjacent terminals. If it is shorter, the wire may not contact the terminal.)
2) Make sure that any wire fiber is unbound from the wire end.
3) Insert a slotted screwdriver into a smaller square hole (for clamp release) on the terminal block located on the front surface.
To insert the screwdriver to the deep end (approx. 10 mm deep), push and tilt it (towards the front surface of Infilex VC main
unit) along the curving surface inside the square hole.
When the screwdriver is inserted to the deep end, the clamp is completely released.
Notes:
* A slotted screwdriver with the blade 3.5 mm wide and 0.5 mm thick (straight type) is acceptable. A screwdriver with the blade tip
narrower than the shaft may not be acceptable.
* Appropriate screwdriver (an example):
Model 9900 (3 mm wide x 100 mm long) or Model 910 (3 mm wide x 75 mm long) manufactured by Vessel Co., Inc.
* Since the terminal block has the inclined surface, required clearance for maintenance varies depending on the length of the screwdriver
to be used.
4) Insert the wire end into a larger square hole. When the wire end is fully inserted, remove the screwdriver.
5) Gently pull out the wire to make sure it is completely held by the clamp.
Wiring of user terminal / Pt100 temperature sensor to Infilex VC
User terminal and Pt100 temperature sensor are wired to Infilex VC with modular connection. For correctly crimping modular
plugs on a LAN cable, refer to the following.
Modular connector connection
Modular connector is composed of a modular plug (male) and a modular jack (female). Modular jacks are provided on Infilex VC,
and modular plugs will be crimped on LAN cables as required. Refer to the following procedure for crimping the modular plugs
on the LAN cables and connecting them to the modular jacks.
Note:
* For modular plugs, refer to Note *1 of the Input/output specifications section.

AB-7177
19
Procedure for modular connector connection
1) Strip the outer sheath of a LAN cable end. Be sure not to scratch or peel off any wire insulation when stripping the sheath.
Figure 17. Stripping the sheath
Make sure there are eight wires inside the sheath.
2) Align the eight wires in the order specified by the LAN cable manufacturer.
An alignment example of the LAN cable wires is shown in the table below.
Figure 18. Alignment of the wires
Note:
* Wire colors shown above may not agree with your LAN cable specification. Ask your LAN cable manufacturer for the latest specification.
3) Insert the aligned wires into a modular plug.
Figure 19. LAN cable insertion into a modular plug
Pin assignment of the modular plug in Fig. 19 is the image when the contacts and the cable stopper of the modular plug are
viewed from above.
Before inserting the wires into the modular plug, even out the length using a nipper. Note that the modular plug may not be
crimped on wires if the wires without the outer sheath are too long.
4) Crimp the modular plug using a crimper. Insert the wires into the modular plug so that the contacts of the modular plug stick
into the wires after crimping. Crimped modular plug is secured on the LAN cable by the cable stopper of the modular plug.
Check the contacts and the cable stopper when crimping the modular plug.
5) Follow 1) to 4) for the other end of the LAN cable.
6) Check continuity of the LAN cable. Modular cable tester (Part No. DY7206A0000) facilitates the continuity check. At the
same time, make sure that the wires are aligned in the specified order, the modular plug contacts stick into the wires, and
that there is no cable damage or disconnection.
7) Connect the modular plugs to the modular jacks.
After successfully finishing the continuity check, insert a modular plug of the LAN cable into the modular jack of Infilex VC
and the other modular plug into the modular jack provided for connecting to the user terminal/Pt100 temperature sensor.
Insert a modular plug until it clicks and gently pull the cable to check complete connection.
LAN cable
Pin numbers 12345678
8 wires
LAN cable
Modular plug
pin number Wire alignment
Wire color code
1 Line 2 of pair 2 White and orange
2 Line 1 of pair 2 Orange
3 Line 2 of pair 3 White and Green
4 Line 1 of pair 1 Blue
5 Line 2 of pair 1 White and blue
6 Line 1 of pair 3 Green
7 Line 2 of pair 4 Brown and white
8 Line 1 of pair 4 Brown
Cable stoppe
r
Contacts
Insert.
10 mm 3 mm
(For the recommended modular plug)
LAN cable
Modular plug
Pin numbers
8
7
4
5
3
1
2
6
Pin assignment of the modular plug

AB-7177
20
Wiring of Pt1000 temperature sensor to Infilex VC
Pt1000 temperature sensor is also wired to Infilex VC with modular connection, and the short connector cable for two terminals
Part No. DY7221A is required for wiring. Refer to the following for details.
1) Connect the modular plug of Part No. DY7221A to the connector CN2 of Infilex VC.
Figure 20. Connection of the connector cable for two terminals to Infilex VC
See the following for the pin assignment of the connector cable for two terminals Part No. DY7221A (between sides A and
B).
Side A Side B
Wire color Pin number
Orange 1
Orange and white 2
Green 3
Blue and white 4
Blue 5
Green and white 6
Brown 7
Brown and white 8
2) Splice the two wires (side B) of Part No. DY7221A and the wires from the Pt1000 temperature sensor with insulation
sleeves.
Note:
* The Pt1000 temperature sensor is a two-wire sensor. Because wire resistance causes measuring error, longer cable, which has larger wire
resistance, will cause greater measuring error. Use Part No. DY7221A (0.1–1.0 m long), and extend the sensor cable (1.25–2.5 mm
2
size)
if needed.
BACnet MS/TP network wiring
Daisy-chain Infilex VC as follows. Be sure to terminate the both ends of the BACnet MS/TP network with 120 Ωterminators.
The maximum wiring length of one network segment is 1200 m. Use the cable explained in the Input/output specifications
section.
Figure 21. Wiring length of BACnet MS/TP network segment
Wiring procedure
1) Strip the cable sheath.
2) Strip 6mm of the wire insulation.
: Terminator
Wiring length of one network segment:
max. 1200 m long
CN2
Infilex VC
Model WY5706C5_ _K
Short connector cable for two terminals
Part No. DY7221A_ _ _ _
* "_ _ _ _" differs depending on the cable length (0.1 m to 1.0 m).
Side A Side B
