Quick Reference Guide for Model C15
This guide offers a summary of key operations, parameter flowcharts, and settings, for convenient reference at
the operation site. This guide is made for repeated use. Dirt wipes off easily and even notes written with an oil-
based felt-tip pen can be removed with an eraser. If more detailed information on model C15 is needed, refer
to the user's manuals: CP-SP-1147E for basic operation and CP-SP-1148E for installation and configuration.
The most convenient way to configure the C15 is with the Smart Loader Package (model No. SLP-C35J50).
Please contact the azbil Group or a distributor for more information.
Upper display
Indicators during AT
[para] key
Mode indicators
Lower display
Various indicators
Loader connector (bottom panel)
[mode] key
[ ], [ ], and [ ] keys
Upper display This display shows either the PV value or the display value and set value for each displayed item. If an alarm is triggered, the
normal display and alarm code are displayed alternately. During auto tuning (AT), the rightmost decimal point flashes twice
repeatedly.
Lower display This display shows either the SP/MV/CT or the display value and set value for each displayed item. The rightmost decimal
point lights up or flashes to show RUN/READY mode or communications status, depending on the setting.
Mode indicators rdy: Lights when READY (RUN mode if not lit)
man: Lights when MANUAL (AUTO mode if not lit)
ev1, ev2, ev3: Lights when event relays are ON
ot1, ot2: Lights when the control output is ON (always lit when the current output is used)
[mode] key • When this key is pressed and held for more than 1 second in the operation display mode, any of the following operations
from 0 to 7 which have been set previously can be executed:
0 : Mode key does not operate (Initial value)
1 : AUTO/MANUAL mode selection
2 : RUN/READY mode selection
3 : AT (Auto Tuning) start/stop selection
4 : LSP (Local SP) group selection
5 : Release all DO (Digital Output) latches
6 : Mode key does not operate
7 : ON/OFF selection of communication DI1
• When pressing the [mode] key in the setup display mode, the display is changed to the operation display
[para] key • This key is used to change the display item.
• When this key is kept pressed for 2 s. or longer in the operation display mode, the display is then changed to the setup
display
[<], [ ] , [ ] keys Theses keys are used to increase or decrease the numeric value, or to shift the digit.
Loader connector The Smart Loader connector is on the bottom of the C15. Use the dedicated cable that is included with the Smart Loader
Package to connect the controller to a PC.
: Initial value
(Not for use in Japan)

2
(AUTO)
For change from
MANUAL to AUTO
to (2)
(MANUAL)
For change from
AUTO to MANUAL
to (1)
[para] key *3
[mode]
2-second press + hold of [para] key
[SP] [Event] [PID] [Parameter] [Extended tuning]
(2) (1)
Upper and lower displays
remain off for 6s after power
ON. Each mode indicator
lights sequentially, and
then the operation display
appears.
When the power
is turned ON LSP group
number
SP value
Manipulated
variable
MV value
Heat manipulated
variable
MV value
Cool manipulated
variable
MV value
PV value
SP value
Timer remaining
time 3
Internal event 3
delay time
*1
[para] key
2-second
press + hold
of [para] key
[para] key *3
Flowchart of key operations and displays
(A)
to (A)

3
Analog inputControl actions
SPContinuous outputsCommunications
Key operations and displays
Setting displays
Operation displays
Some items are not displayed depending on the availability of optional functions, model number, display setup (C73 to
C78) and display level (C79).
Pressing [para] key while changing settings has the effect of canceling and moving to the next item.
*1 The parameters and numerical values registered as user functions UF are displayed.
*2 If no key is pressed for 3 minutes, the display automatically returns to (2) , PV display.
*3 If the [<] key is pressed while holding down the [para] key, various displys/settings can be
navigated in reverse order.
*4 Cannot be selected if ROM version 1 (id02) of the instrument information bank is 2.26 or
earlier.
Explanation of arrows
[para] key :
2-second press + :
hold of [para] key
Movement through each setup menu
• [para] key Forward movement
• [para] key + [<] key Backward movement
Internal event 3
sub setting
Setting value
Internal event 3
main setting
Setting value
Timer remaining
time 2
Internal event 2
delay time
Internal event 2
sub setting
Setting value
Internal event 2
main setting
Setting value
[Setup] [ Event configuration ] [ DI assignment ] [ DO assignment ] [ User function ] [ Instrument information ][Lock]
[para] key
PV value
AT progress
value
Internal event 1
main setting
Setting value
CT1
Current
value
CT2
Current
value
Internal event 1
sub setting
Setting value
Timer remaining
time 1
Internal event 1
delay time
2-second press + hold of [para] key
*2
*4
to (2)
(B)
to (B)
*4

4
Setup of PV input range type
1Start from the opera-
tion display (if neces-
sary press [mode]
once to get the op-
eration display).
If the sensor has not
been wired or is discon-
nected, an alarm for
abnormal PV input (any
one from AL0 1to AL11)
may appear on the
upper display.
2Press and hold [para]
for more than 2s to
get the parameter
setup display. a--M
is shown on the
upper display.
In case of ON/OFF con-
trol, r--r appears on
the upper display.
3Press and hold [para]
for more than 2s
again to get the
setup setting display.
The current set
value for C0 1(PV
input range type) is
displayed.
4When the [<], [ ] or
[ ] key is pressed,
the rightmost digit
on the lower display
flashes. If no key is
pressed for more
than 2s after chang-
ing to the desired
value in the PV input
range list, the display
changes from flash-
ing to continuously
lit, and the displayed
value is now set.
Setup of event operation type
In this example, the event 1 operation type is set to deviation high
limit.
1Start from the opera-
tion display (if neces-
sary press [mode]
once to get the op-
eration display).
2Press and hold [para]
for more than 2s to
get the parameter
setup display. a--M
is shown on the
upper display.
3Press and hold [para]
for more than 2s
again to get the
setup setting display.
The current set
value for C0 1(PV
input range type) is
displayed.
4Press [para] repeat-
edly to get e1.c 1on
the upper display. 0
is displayed on the
lower display.
0on the lower display
indicates that the event
operation type is set to
"none."
5When the [ ] or [ ] key is pressed, the rightmost digit on
the lower display flashes. Change the flashing digit to 4by
pressing [ ] or [ ].
If no key is pressed for more than 2s, the displayed value is
set and the display changes from flashing to continuously
lit.
4on the lower display indicates that the event operation type is set for
deviation high limit.
Similarly, use e2.C 1to set the event 2 operation type, and use
e3.C1for event 3.
Red letters : Items before operation
Blue letters : Items during operation
Execution of auto tuning (AT )
AT forces ON/OFF of the MV a number of times (a limit cycle) to cal-
culate PID values.
Check that this operation does not create any problems for the as-
sociated equipment before executing AT.
1Start from the opera-
tion display (if neces-
sary press [mode]
once to get the op-
eration display).
2Press and hold [para]
for more than 2s to
get the parameter
setup display. a--M
is shown on the
upper display.
3Press [para] twice.
The upper display
says at and the lower
display says at.Of.
If the control method
is ON/OFF control and
if Bit 3 (AT stop/start
display) of the mode
display setup (C73) is set
to "disabled: 0," nothing
is displayed.
4When [ ] or [ ] is
pressed, at.Of
flashes.
Flashing occurs only in
RUN and AUTO modes,
if there is no PV input
abnormality.
Also, if "AT stop/start" is
selected for DI assign-
ment, the display does
not blink and no change
can be made.
5[Press [ ] once.
The lower display
starts to flash at.On.
6If no key is pressed
for more than 2s,
at.ON remains
steadily lit and AT
begins.
During AT, the
rightmost decimal
point flashes twice
repeatedly. (When
AT is done, the light
goes off and the new
PID values go into
effect.)
During the AT process, if the mode is changed to READY or
MANUAL, if PV input is faulty, or if a power failure occurs, AT stops
automatically without changing the PID values.
AT can also be stopped by changing the setting from At.ON to
At.OF (return to step 3 above).
Setup of SP value
1Start from the opera-
tion display (if neces-
sary press [mode]
once to get the op-
eration display).
2Check that the op-
eration display is
displaying the SP.
(If not, press [para]
repeatedly until the
SP is displayed.)
3When the [<], [ ] or
[] key is pressed,
the rightmost digit
on the lower display
flashes and the SP
can be changed to
the desired value.
In this case, the flash-
ing of the numerical
value implies that it
is not yet set. A nu-
merical setting that
is being changed
flashes the same way.
If an SP limit is in effect,
the numerical value
cannot be changed to
a value above the limit.
The SP limit must be
changed first.
4If no key is pressed
for more than 2s, the
displayed value is
set and the display
changes from flash-
ing to continuously
lit.
If the [mode] key is
pressed when the
display is flashing, the
status returns to that of
step 1.
Operation examples

5
For step numbers indicated in red like 4, the following precaution applies:
• If the key lock is set, the numerical value does not flash, and the value cannot be changed.
To change a numerical value, cancel the key lock first.
RUN/READY mode selection
1Start from the opera-
tion display (if neces-
sary press [mode]
once to get the op-
eration display).
2Press and hold [para]
for more than 2s to
get the parameter
setup display. a--M
is shown on the
upper display.
In case of ON/OFF con-
trol, r--r appears on
the upper display.
3Press the [para] key
once. The upper dis-
play says r--r and
the lower display
says rdy (or run).
The current mode is in-
dicated by run for RUN
mode or rdy for READY
mode.
4When [ ] or [ ] is
pressed, the lower
display flashes.
If the DI assignment is
set to "RUN/READY se-
lection," the display does
not flash and no change
can be made.
5When [ ] or [ ] is
pressed, run (or
rdy) on the lower
display flashes.
6If no key is pressed
for more than 2s, the
displayed value is
set and the display
changes from flash-
ing to continuously
lit.
Setup of PID value
1Start from the opera-
tion display (if neces-
sary press [mode]
once to get the op-
eration display).
2Press and hold [para]
for more than 2s to
get the parameter
setup display. a--M
is shown on the
upper display.
3Press [para] repeat-
edly to get p-1 (for
proportional band)
on the upper display.
The value set for p-1
is displayed on the
lower display.
If the control method is
"ON/OFF control," noth-
ing is displayed.
4When [<], [ ] or [ ]
is pressed, the right-
most digit on the
lower display flashes,
and can be changed
to the desired value
for the proportional
band.
In this case, the flash-
ing of the numerical
value implies that it
is not yet set. A nu-
merical setting that
is being changed
flashes the same
way.
The proportional band
can be set in a range
from 0.1 to 999.9%.
5If no key is pressed for more than 2s, the displayed value is
set and the display changes from flashing to continuously
lit.
If the [mode] key is pressed when the display is flashing, the status re-
turns to that of step 1.
Similarly, use i-1 to set the integral time (0 to 9999s), and d-1 to set
the derivative time (0 to 9999s).
Setup of event value
1Start from the opera-
tion display (if neces-
sary press [mode]
once to get the op-
eration display).
2Press and hold [para]
for more than 2s to
get the parameter
setup display. a--M
is shown on the
upper display.
3Press [para] repeat-
edly to get e1on the
upper display. The
lower display says 0.
0on the lower display
indicates that the event
main set value is "zero."
4When [<], [ ] or [ ]
is pressed, the right-
most digit on the
lower display flashes,
and can be changed
to the desired value
for the event.
In this case, the flash-
ing of the numerical
value implies that it
is not yet set.
A numerical set-
ting that is being
changed flashes the
same way.
5If no key is pressed for more than 2s, the displayed value is
set and the display changes from flashing to continuously
lit.
If the [mode] key is pressed when the display is flashing, the status returns
to that of step 1.
Similarly, use e2 to set a value for event 2, and e3 to set a value
for event 3.
6To set hysteresis as
well, press [para]
once (or twice,
depending on the
settings) to display
e1.hy on the upper
display.
The lower display
says 5.
5on the lower display
indicates that the cur-
rent set value for event
hysteresis is 5.
7When [<], [ ] or [ ]
is pressed, the right-
most digit on the
lower display flashes,
and can be changed
to the desired value
for hysteresis.
If no key is pressed
for more than 2s, the
displayed value is
set and the display
changes from flash-
ing to continuously
lit.
Similarly, use e2.hy to set a hysteresis value for event 2, and e3.hy
to set a hysteresis value for event 3.
Memo

6
List of operation displays
Display
Upper display: PV
Lower display: SP
Item Contents Initial
value
Setting
value
PV
SP
SP (Target value) SP low limit to SP high limit 0
LSP 1(
Display example )
LSP
LSP No.
(
1st digit: Value at the right end digit )
1 to LSP system group (Max. 4) 1
Out
MV
MV (Manipulated Variable) -10.0 to +110.0%
Setting is enabled in MANUAL mode
(Numeric value flashed)

HEAt
Numeric value
Heat MV (Manipulated Variable) Setting is disabled.
-10.0 to +110.0%

COOL
Numeric value
Cool MV (Manipulated Variable) 
PV
At 1(
Display example )
AT progress display
( 1st digit=Numeric value at right end digit )
Setting is disabled. 
Ct 1
Numeric value
CT current value 1 Setting is disabled. 
Ct2
Numeric value
CT current value 2 Setting is disabled. 
E1
Numeric value
Internal Event 1 main setting -1999 to +9999U or 0 to 9999U 0
E1.Sb
Numeric value
Internal Event 1 sub setting 0
t1.--(
Display example )
Numeric value
Timer remaining time 1 Setting is disabled.
Upper display: The distinction by ON delay or
OFF delay is displayed at the side location of“t1.”.

E2
Numeric value
Internal Event 2 main setting Same as Internal Event 1 main setting 0
E2.Sb
Numeric value
Internal Event 2 sub setting Same as Internal Event 1 sub setting 0
t2.--(
Display example )
Numeric value
Timer remaining time 2 Same as Timer remaining time 1 
E3
Numeric value
Internal Event 3 main setting Same as Internal Event 1 main setting 0
E3.Sb
Numeric value
Internal Event 3 sub setting Same as Internal Event 1 sub setting 0
t3.--(
Display example )
Numeric value
Timer remaining time 3 Same as Timer remaining time 1 
List of parameter setting displays
MOdE [Mode bank]
Display Item Contents Initial value Setting value
A--M AUTO/MANUAL AUTO: AUTO mode MAN: MANUAL mode AUTO
r--r RUN/READY RUN: RUN mode RDY: READY mode RUN
At AT stop/start At.OF: AT stop At.ON: AT start AT stop
dO.Lt Release all DO latches Lt.ON: Latch continue Lt.OF: Latch release
Latch continue
C.dI 1Communication DI1 dI .OF: OFF dI .On: ON OFF
SP [SP bank]
Display Item Contents Initial value Setting value
SP- 1to SP-4 SP (for LSP1 to 4) SP low limit to SP high limit 0
Ev [Event bank]
Display Item Contents Initial value Setting value
E1to E5
Internal Event 1 to 5 main setting -1999 to +9999 or 0 to 9999 * 0
E1.Sb to E5.Sb
Internal Event 1 to 5 sub setting 0
E1.Hy to E5.Hy
Internal Event 1 to 5 hysteresis 0 to 9999 * 5
E1.On to E5.On 
Internal Event 1 to 5 ON delay time 0.0 to 999.9 or 0 to 9999 0
E1.OF to E5.OF 
Internal Event 1 to 5 OFF delay time 0
* The decimal point position varies by meeting the internal event operation type.
PI D[PID bank]
Display Item Contents Initial value Setting value
P- 1Proportional band (PID1) 0.1 to 999.9% 5.0
I-1Integration time (PID1) 0 to 9999s (
No integration control action when set at "0" ) 120
d- 1Derivative time (PID1) 0 to 9999s (
No derivative control action when set at "0" ) 30
rE- 1Manual reset (PID1) -10.0 to +110.0% 50.0
OL- 1MV low limit (PID1) -10.0 to +110.0% 0.0
OH- 1MV high limit (PID1) -10.0 to +110.0% 100.0
P- 1C
Cool-side proportional band (PID1) 0.1 to 999.9% 5.0
I-1C
Cool-side integration time (PID1) 0 to 9999s ( No integration control action when set at "0" ) 120
d- 1C
Cool-side derivative time (PID1) 0 to 9999s ( No derivative control action when set at "0" ) 30
OL. 1C Cool-side MV low limit (PID1) -10.0 to +110.0% 0.0
OH. 1C Cool-side MV high limit (PID1) -10.0 to +110.0% 100.0
PARA [Parameter bank]
Display Item Contents Initial value Setting value
Control
CtrL Control method 0: ON/OFF control 1: Fixed PID 2: ST(Self-tuning) 0 or 1
At. OL MV low limit at AT -10.0 to +110.0% 0.0
At. OH MV high limit at AT -10.0 to +110.0% 100.0
dI FF ON/OFF control differential 0 to 9999U 5
OFFS 
ON/OFF control operating point offset -1999 to +9999U 0
PV
FL PV filter 0.0 to 120.0s 0.0
rA PV ratio 0.001 to 9.999 1.000
bI PV bias -1999 to +9999U 0
Time proportional output
CyU Time proportional cycle unit 1 0 to 3 *10
Cy Time proportional cycle 1 5 to 120s or 1 to 120s *210 or 2
CyU2 Time proportional cycle unit 2 0 to 3 *10
Cy2 Time proportional cycle 2 5 to 120s or 1 to 120s *210 or 2
tP. ty 
Time proportional cycle mode 0: Controllability aiming type
1: Operation end service life aiming type (Only ON/
OFF operation within Time proportional cycle)
0 or 1
SP
SPU SP up ramp (U/min) 0.0 to 999.9U(No ramp when set at "0.0U") 0.0
SPd SP down ramp (U/min) 0.0
*1 0: Unit of "1s" 1: Fixed at 0.5s 2: Fixed at 0.2s 3: Fixed at 0.1s
*2 5 to 120s when output includes the relay output
U: Unit Maximum unit of Industrial volume in
PV range (°C, Pa,L/min, etc.)
: Essential parameters for PV measurement and control
: Basic parameters
: Required parameters when using optional functions
Et [Extended tuning bank]
Display Item Contents Initial value Setting value
At.ty AT type 0: Normal 1: Immediate response 2: Stable *11
JF.bd Just-FiTTER setting band 0.00 to 10.00 0.30
SP.LG SP lag constant 0.0 to 999.9 0.0
At-P AT Proportional Band adjust 0.00 to 99.99 1.00
At-I AT Integral time adjust 0.00 to 99.99 1.00
At-d AT Derivative time adjust 0.00 to 99.99 1.00
Ctr.A Control algorithm 0: PID(Conventional PID)
1: Ra-PID(High-performance PID)
0
JF.Ov 
Just-FiTTER assistance coefficient 0 to 100 0
St.SA 
ST step execution resolution band 0.0 to 99.99 10.0
St.Sb ST step setting band 0.0 to 10.00 0.50
St.Hb ST hunting setting band 0.0 to 10.00 1.00
St.ud ST step ramp change 0: ST is executed when the PV moves up or down.
1: ST is executed only when the PV moves up.
0
*1 Normal = Standard control characteristics, Immediate response = Control characteristics that respond immediately to
external disturbance, Stable = Control characteristics having less up/down fluctuation of PV
List of setup setting displays
StUP [Setup bank]
Display Item Contents Initial value Setting value
Analog input
C0 1PV input range type For details, refer to the PV Input Range Table
Depending on Model No.
C02 Temperature unit 0: Celsius (°C) 1: Fahrenheit (°F) 0
C03 Cold junction compensation
0: Performed (internal) 1: Not performed (external) 0
C04 Decimal point position 0: No decimal point
1 to 3: 1 to 3 digits below decimal point *1
0
C05 PV range low limit
When the PV input type is DC voltage/DC current,
-1999 to +9999U
0
C06 PV range high limit 1000
C07 SP low limit PV input range low limit to PV input range high
limit

C08 SP high limit 
C09 
PV square root extraction dropout 0.0 to 100.0% (PV square root extraction is not
performed when set at "0.0".)
0.0
Control action
C13 
PID calculation adjustment function *2 0: Enabled 1: Disabled 0
C14
Control action (Direct/Reverse) 0: Heat control (Reverse action)
1: Cool control (Direct action)
0
C15 Output operation at PV alarm 0: Control calculation is continued.
1: Output at PV alarm is output.
0
C16 Output at PV alarm -10.0 to +110.0% 0.0
C17 Output at READY (Heat) -10.0 to +110.0% 0.0
C18 Output at READY (Cool) -10.0 to +110.0% 0.0
C19 
Output operation at changing AUTO/MANUAL 0: Bumpless transfer 1: Preset 0
C20 Preset MANUAL value -10.0 to +110.0%
0.0 or 50.0
C2 1
Initial output type (mode) of PID control 0: Auto 1: Not initialized 2: Initialized 0
C22 Initial output of PID control -10.0 to +110.0%
0.0 or 50.0
C26 Heat/Cool control 0: Not used 1: Used 0
C27 Heat/Cool 0: Normal 1: Energy saving 0
C28 Heat/Cool control dead zone -100.0 to +100.0% 0.0
C29 Heat/Cool change point -10.0 to +110.0% 50.0
SP
C30 LSP system group 1 to 4 1
C32 SP ramp unit 0: 0.1U/s 1: 0.1U/min 2: 0.1U/h 1
C36 CT1 operation type
0: Heater burnout detection 1: Current value measurement 0
C37 CT1 output
0 to 1: Control output 1 to 2, 2 to 4: Event output 1 to 3 0
C38 CT1 measurement wait time 30 to 300ms 30
C39 CT2 operation type Same as CT1 0
C40 CT2 output Same as CT1 0
C4 1CT2 measurement wait time Same as CT1 30
Continuous output
C42 Control output 1 range 1: 4 to 20mA 2: 0 to 20mA 1
C43 Control output 1 type 0: MV 1: Heat MV 2: Cool MV 3: PV
4: PV before ratio, bias, and filter 5: SP
6: Deviation 7: CT1 current value
8: CT2 current value 10: SP+MV 11: PV+MV
0
C44
Control output 1 scaling low limit -1999 to +9999U 0.0
C45
Control output 1 scaling high limit 100.0
C46
Control output 1 MV scaling bandwidth 0 to 9999 (Valid when control output 1 type is 10 or 11) 200
C47 Control output 2 range Same as control output 1 1
C48 Control output 2 type Same as control output 1 3
C49
Control output 2 scaling low limit Same as control output 1 0
C50
Control output 2 scaling high limit Same as control output 1 1000
C5 1
Control output 2 MV scaling bandwidth Same as control output 1 200
Communication
C64 Communication type 0: CPL 1: Modbus (ASCII format)
2: Modbus (RTU format)
0
C65 Station address
0 to 127 (Communication is disabled when set at "0".) 0
C66 Transmission speed (bps) 0: 4800 1: 9600 2: 19200 3: 38400 2
C67 Data format (Data length) 0: 7 bits 1: 8 bits 1
C68 Data format (Parity) 0: Even parity 1: Odd parity 2: No parity 0
C69 Data format (Stop bit) 0: 1 bit 1: 2 bits 0
C70 
Communication minimum response time 1 to 250ms 3
Key operation • display
C7 1Key operation type 0: Standard type 1: Special type 0
C72 [mode] key function 0: Invalid 1: AUTO/MANUAL selection
2: RUN/READY selection 3: AT Stop/Start
4: LSP group selection 5: Release all DO latches
6: Invalid 7: Communication DI1 selection 8: Invalid
0
C73 MODE display setup
(Sum of the weighting)
Bit 0: AUTO/MANUAL display (Enabled: +1)
Bit 1: RUN/READY display (Enabled: +2)
Bit 3: AT Stop/Start display (Enabled: +8)
Bit 4: Release all DO latches display (Enabled: +16)
Bit 5: Communication DI1 ON/OFF display (Enabled: +32)
Other invalid setting, 0, +4, +64, +128
255
C74 PV/SP display setup
(Sum of the weighting)
Bit 0: PV display (Enabled: +1)
Bit 1: SP display (Enabled: +2)
Bit 2: LSP group number display (Enabled: +4)
Other invalid setting, 0, +8
15
C75 MV display setup
(Sum of the weighting)
Bit 0: MV display (Enabled: +1)
Bit 1: Heat MV/cool MV display (Enabled: +2)
Bit 3: AT progress display (Enabled: +8)
Other invalid setting: 0, +4
15
C76 EV display setup
(Operation display)
0: Not displayed
1: Set value of Internal event 1 is displayed
2: Set values of Internal event 1 to 2 are displayed
3: Set values of Internal event 1 to 3 are displayed
0
C77 
Event remaining time display setup
(Operation display)
0: Not displayed
1: Internal event 1 is displayed
2: Internal event 1 to 2 is displayed
3: Internal event 1 to 3 is displayed
0
C78 
CT input current value display setup
(Operation display)
0: Not displayed 1: CT1 current value is displayed
2: CT1 to 2 current values are displayed
0
List of parameters

7
Display Item Contents Initial value Setting value
Key operation • display
C79 User level 0: Simple configuration 1: Standard configuration
2: High function configuration
0
C80 LED monitor 0: Not used
1:
Flashing while data is sending through RS-485 communication.
2: Flashing while data is receiving through RS-485 communication
3: Logical OR of all DI statuses
4: Flashing in READY mode
0
C90 Number of CT1 turns 0: 800 turns 1 to 40: CT turns divided by 100 8
C9 1
Number of CT1 power wire loops 0: 1 time 1 to 6: Number of times 1
C92 Number of CT2 turns 0: 800 turns 1 to 40: CT turns divided by 100 8
C93 
Number of CT2 power wire loops 0: 1 time 1 to 6: Number of times 1
C97 PV input failure (under range)
type *2
0: 10 %FS
1: 5 mV (This setting is applicable if C01 (PV input
range type) is set for sensor type B (No.17) or
PR40-20 (No. 23))
0
*1 Cannot be set for a thermocouple if ROM version 1 (
id02) of the instrument information bank is 2.26 or earlier.
*2 Cannot be selected if ROM version 1 (
id02) of the instrument information bank is 2.26 or earlier.
EvCF [Event configuration bank]
Display Item Contents Initial value Setting value
E1.C 1to E5.C 1
Internal event 1 to 5 Configuration 1 Refer to event type (see page 8) 0
E1.C2 to E5.C2
Internal event 1 to 5 Configuration 2 The digits are determined to 1st, 2nd, 3rd, and
4th digit from the right end.
1st digit: Direct/Reverse 0: Direct 1: Reverse 0
2nd digit: Standby 0: None 1: Standby 2:
Standby + Standby at SP change 0
3rd digit:
EVENT state at READY 0: Continue 1: Forced OFF 0
4th digit: Undefined 0 0
E1.C3 to E5.C3 
Internal event 1 to 5 Configuration 3 The digits are determined to 1st, 2nd, 3rd, and
4th digit from the right end.
1st digit: Alarm OR 0: None 1: Alarm direct + OR operation
2: Alarm direct + AND operation
3: Alarm reverse + OR operation
4: Alarm reverse + AND operation
0
2nd digit: Special OFF 0: As usual
1: When the event set value (main setting) is 0,
the event is "OFF".
0
3rd digit: Delay time unit 0: 0.1s 1: 1s 2: 1min 0
4th digit: Undefined 0 0
di [DI assignment bank]
Display Item Contents Initial value Setting value
dI 1. 1to dI 3. 1Internal contact 1 to 3
Operation type
0: No function 1: LSP group selection (0/+1)
2: LSP group selection (0/+2)
3: LSP group selection (0/+4) 4: Invalid
5: Invalid 6: Invalid 7: RUN/READY selection
8: AUTO/MANUAL selection
9: LSP/RSP selection 10: AT Stop/Start
11: ST disabled/enabled
12: Control action direct/reverse
13: SP Ramp enabled/disabled
14: PV Hold 15: PV Maximum value hold
16: PV Minimum value hold 17: Timer Stop/Start
18: Release all DO latches (Continue/Release)
19: Invalid 20: Invalid
0
dI 1.2 to dI 3.2 Internal contact 1 to 3
Input bit operation
0: Not used (Default input)
1: Function 1 ((A and B) or (C and D))
2: Function 2 ((A or B) and (C or D))
3: Function 3 (A or B or C or D)
4: Function 4 (A and B and C and D)
0
dI 1.3 to dI 3.3 Internal contact 1 to 3
Input assignment A
0: Normally opened 1: Normally closed
2: DI1 3: DI2 4 to 9: Undefined
10 to 14: Internal Event 1to 5
15 to 17: Undefined
18 to 21: Communication DI1 to 4
22: MANUAL 23: READY 24: Undefined
25: AT running 26: During SP ramp 27: Undefined
28: Alarm occurs 29: PV alarm occurs
30: Undefined 31: mode key pressing status
32: Event output 1 status 33: Control output 1 status
2: Contact 1
3: Contact 2
4: Contact 3
dI 1.4 to dI 3.4 Internal contact 1 to 3
Input assignment B
0
dI 1.5 to dI 3.5 Internal contact 1 to 3
Input assignment C
0
dI 1.6 to dI 3.6 Internal contact 1 to 3
Input assignment D
0
dI 1.7 to dI 3.7 Internal contact 1 to 3
Polarity A to D
The digits are determined to 1st, 2nd, 3rd and
4th digit from the right end.
1st digit: Polarity A 0: Direct 1: Reverse 0
2nd digit: Polarity B 0
3rd digit: Polarity C 0
4th digit: Polarity D 0
dI 1.8 to dI 3.8 Internal contact 1 to 3 Polarity 0: Direct 1: Reverse 0
dI 1.9 to dI 3.9 Internal contact 1 to 3
Internal event No. assignment
0: Every Internal Event
1 to 5: Internal Event No.
0
dO [DO assignment bank]
Display Item Contents Initial value Setting value
Ot 1. 1to Ot2. 1�
Ev 1. 1to Ev3. 1
Control output 1 to 2, event
output 1 to 3 Operation type
0: Default output 1 to 2: MV1 to 2
3 to 6: Function 1 to 4
0
Ot 1.2 to Ot2.2�
Ev 1.2 to Ev3.2
Control output 1 to 2, event
output 1 to 3 Output assign-
ment A
0: Normally opened 1: Normally closed
2 to 6: Internal Event 1 to 5
7 to 13: Undefined 14 to 15: MV1 to 2
16 to 17: Undefined 18 to 19: DI1 to 2
20 to 25: Undefined
26 to 28: Internal Contact 1 to 3
29 to 33: Undefined 34 to 37: DI1 to 4
38: MANUAL 39: READY 40: Undefined
41: AT running 42: During SP ramp
43: Undefined 44: Alarm occurs
45: PV alarm occurs 46: Undefined
47: Mode key pressing status
48: Event output 1 status
49: Control output 1 status
14: Output 1
15: Output 2
2: Event 1
3: Event 2
4: Event 3
Ot 1.3 to Ot2.3�
Ev 1.3 to Ev3.3
Control output 1 to 2, event
output 1 to 3 Output assign-
ment B
0
Ot 1.4 to Ot2.4�
Ev 1.4 to Ev3.4
Control output 1 to 2, event
output 1 to 3 Output assign-
ment C
0
Ot 1.5 to Ot2.5�
Ev 1.5 to Ev3.5
Control output 1 to 2, event
output 1 to 3 Output assign-
ment D
0
Ot 1.6 to Ot2.6�
Ev 1.6 to Ev3.6
Control output 1 to 2, event
output 1 to 3 Polarity A to D
The digits are determined to 1st, 2nd, 3rd, and
4 th digit from the right end.
1st digit: Polarity A 0: Direct
1: Reverse
0
2nd digit: Polarity B 0
3rd digit: Polarity C 0
4the digit: Polarity D 0
Ot 1.7 to Ot2.7�
Ev 1.7 to Ev3.7
Control output 1 to 2, event
output 1 to 3 Polarity
0: Direct
1: Reverse
0
Ot 1.8 to Ot2.8�
Ev 1.8 to Ev3.8
Control output 1 to 2, event
output 1 to 3 Latch
0: None 1: Latch (Latch at ON)
2: Latch (Latch at OFF except for initialization
at power ON)
0
UF [User function bank]
Display Item Contents Initial value Setting value
UF- 1to UF-8 User function 1 to 8  
LOC [Lock bank]
Display Item Contents Initial value Setting value
LOC Key lock 0: All settings are possible
1: Mode, event, operation display, SP, UF, lock,
manual MV, [mode] key can be set
2: Operation display, SP, UF, lock, manual MV,
[mode] key can be set
3: UF, lock, manual MV, [mode] key can be set
0
C.LOC Communication lock 0: read/write enabled 1: read/write disabled 0
L.LOC Loader lock 0: read/write enabled 1: read/write disabled 0
PASS Password display 0 to 15 (5: Password 1A to 2B display) 0
PS 1A Password 1A 0000 to FFFF (Hexadecimal value) 0000
PS2A Password 2A 0000 to FFFF (Hexadecimal value) 0000
PS 1b Password 1B 0000 to FFFF (Hexadecimal value) 0000
PS2b Password 2B 0000 to FFFF (Hexadecimal value) 0000
Id[Instrument information bank]
Display Item Contents Initial value Setting value
Id0 1ROM ID 0: Fixed 0
Id02 ROM Version 1 XX. XX (2 digits after decimal point) 
Id03 ROM Version 2 XX. XX (2 digits after decimal point) 
Id04 Loader information 
Id05 EST information 
Id06 Manufacturing date code
(year)
Subtract 2000 from the year.
Example: "3" means the year 2003.

Id07 Manufacturing date code
(month, day)
Month + day divided by 100.
Example: "12.01" means the 1st day of December.

Id08 Serial No. 
Precaution for setup
• The type of auto tuning can be changed by changing the value of
At.ty (AT type) in the extended tuning bank. Set it to match the
control characteristics.
Memo
Changing the user level
This controller's user level can be set to 1 of 3 types in setup C79.
The number of possible displays and settings decreases according
to the user level: high function > standard > simple. All items are
displayed when high function is selected.
1If necessary press
[mode] once to
change to the op-
eration display.
Next, press and hold
[para] for more than
2s to get the param-
eter setup display.
a--M or r--r ap-
pears on the upper
display.
2Press and hold
[para] for more than
2s again to display
c0 1on the upper
display.
3Press [para] repeat-
edly to change the
upper display to c79
(user level).
4When [<], [ ] or [ ]
is pressed, the lower
display flashes and
can be changed to
the desired numerical
value. Then, if no key
is pressed for more
than 2s, the displayed
value is set and the
display changes from
flashing to continu-
ously lit.
0: Simple configuration
(initial value)
1: Standard configuration
2: High function configuration
• Items marked in the tables are displayed in standard and/or high function configuration.
• To change a user level, refer to Changing the user level in the lower right part of this page.

8
1-12-2 Kawana, Fujisawa
Kanagawa 251-8522 Japan
URL
: https://www.azbil.com
(11)
Specifications are subject to change without notice.
PV input range table
[Thermocouple] [RTD]
C0 1
set value
Sensor
type
Range
(°C)
Range
(°F)
C0 1
set value
Sensor
type
Range
(°C)
Range
(°F)
1 K -200 to +1200 -300 to +2200 41 Pt100 -200 to +500 -300 to +900
2 K 0 to 1200 0 to 2200 42 JPt100 -200 to +500 -300 to +900
3 K 0.0 to 800.0 0 to 1500 43 Pt100 -200 to +200 -300 to +400
4 K 0.0 to 600.0 0 to 1100 44 JPt100 -200 to +200 -300 to +400
5 K 0.0 to 400.0 0 to 700 45 Pt100 -100 to +300 -150 to +500
6 K-200.0 to +400.0 -300 to +700 46 JPt100 -100 to +300 -150 to +500
9 J 0.0 to 800.0 0 to 1500 51 Pt100 -50.0 to +200.0 -50 to +400
10 J 0.0 to 600.0 0 to 1100 52 JPt100 -50.0 to +200.0 -50 to +400
11 J -200.0 to +400.0 -300 to +700 53 Pt100 -50.0 to +100.0 -50 to +200
13 E 0.0 to 600.0 0 to 1100 54 JPt100 -50.0 to +100.0 -50 to +200
14 T -200.0 to +400.0 -300 to +700 63 Pt100 0.0 to 200.0 0 to 400
15 R 0 to 1600 0 to 3000 64 JPt100 0.0 to 200.0 0 to 400
16 S 0 to 1600 0 to 3000 67 Pt100 0 to 500 0 to 900
17 B 0 to 1800 0 to 3300 68 JPt100 0 to 500 0 to 900
18 N 0 to 1300 0 to 2300
[DC voltage/DC current]
19 PL II 0 to 1300 0 to 2300
20
WRe5-26 0 to 1400 0 to 2400 C0 1
set value
Input type Range
21
WRe5-26 0 to 2300 0 to 4200
23
PR40-20 0 to 1900 0 to 3400 84 0 to 1 V The scaling and decimal
point position can be
changed variably in a
range of –1999 to +9999
24 DIN U -200.0 to +400.0 -300 to +700 86 1 to 5 V
25 DIN L -100.0 to +800.0 -150 to +1500 87 0 to 5 V
88 0 to 10 V
89 0 to 20 mA
Initial value 90 4 to 20 mA
*1 • Accuracy for No. 17 (B thermocouple) is as follows. 260 °C or less: ±5 %FS. 260–800 °C: ±1 %FS.
The PV values under 20 °C are not shown. However, if ROM version 1 (i
d02) of the instrument
information bank is 2.04 or earlier, the indicated low limi value is -180 °C.
• Accuracy for No. 23 (sensor type PR40-20) is as follows. 300 °C or less: undefined. 300–800 °C:
±5 % FS. 800–1900 °C: ±2 % FS. However, if ROM version 1 (i
d02) of the instrument information
bank is 2.26 or earlier, No. 23 cannot be selected.
*2 PL II thermocouple is a range, which has been added to the units manufactured from July, 2003.
*3 The decimal point for thermocouples can be displayed if the ROM version is 2.26 or later.
List of alarm codes
Alarm
code
Failure name Cause Corrective action
Input failure
AL0 1PV input failure
(Over-range)
Sensor burnout, incorrect
wiring, incorrect PV input
type setting
Check the wiring.
Set the PV input type
again.
AL02 PV input failure
(Under-range)
Sensor burnout, incorrect
wiring, incorrect PV input
type setting
AL03 CJ failure Terminal temperature is
faulty (thermocouple).
Check the ambient
temperature.
PV input failure
(RTD)
Sensor burnout, incorrect
wiring
Check the wiring.
AL 11CT input failure
(Over-range)
(CT input 1 or 2,
or both)
A current exceeding the
upper limit of the display
range was measured. The
number of CT turns or the
number of CT power wire
loops is incorrectly set, or
wiring is incorrect.
• Use a CT with the cor-
rect number of turns
for the display range.
• Reset the number of
CT turns.
• Reset the number of CT
power wire loops.
• Check the wiring.
Unit failure
AL70 A/D conversion
failure
A/D converter is faulty. Replace the unit.
AL95 Parameter failure Power is shut-down while
the data is being set, or
data is corrupted by noise.
• Restart the unit.
• Set the data again (set
data for AL95/97 and
adjustment data for
AL96/98.
• Replace the unit.
AL96 Adjustment data
failure
Power is shut-down while
the data is being set, or
data is corrupted by noise.
AL97 Parameter failure
(RAM area)
Data is corrupted by noise.
AL98 Adjustment data
failure (RAM area)
Data is corrupted by noise.
AL99 ROM failure ROM (memory) is faulty. • Reset the unit.
• Replace the unit.
Handling Precautions
• If ROM version 1 (i
d02) of the instrument information bank is
2.04 or earlier, CT input failure (AL 11) is not displayed.
Event type
Operation
type
Set
value
Direct action
:
shows that the ON/OFF is changed at this value.
: shows that the ON/OFF is changed at a point
that "1U" is added to this value.
Reverse action
:
shows that the ON/OFF is changed at this value.
: shows that the ON/OFF is changed at a point
that "1U" is added to this value.
No event 0 Always OFF Always OFF
PV high
limit
1ONHYS
Main setting
PV
ON HYS
Main setting
PV
PV low limit 2
Main setting
PV
ON HYS
Main setting PV
ON
HYS
PV high/low
limit
3
Main setting
* Sub-setting *
PV
ON HYS ONHYS
Main setting * Sub-setting *
PV
ONHYS HYS
Deviation
high limit
4ONHYS
SP + Main setting
PV
ON HYS
SP + Main setting
PV
Deviation
low limit
5
SP + Main setting PV
ON HYS
SP + Main setting
PV
ONHYS
Deviation
high/low
limit
6
Main setting Sub-setting
SP
PV
ON HYS ONHYS ONHYS HYS
Main setting Sub-setting
SP
PV
Deviation
high limit
(Final SP
reference)
7ONHYS
SP + Main setting
PV
ON HYS
SP + Main setting
PV
Deviation
low limit
(Final SP
reference)
8
SP + Main setting PV
ON HYS
SP + Main setting
PV
ONHYS
Deviation
high/
low limit
(Final SP
reference)
9
Main setting Sub-setting
SP
PV
ON HYS ONHYS ONHYS HYS
Main setting Sub-setting
SP
PV
Heater 1
burnout/
Over-current
16
CT1 at output ON
Main setting
*
Sub-setting *
ON HYS ONHYS ONHYS HYS
Main setting *
Sub-setting *
CT1 at output ON
OFF before measuring the CT1 current value OFF before measuring CT1 current value
Heater 1
short-circuit
17 ON
HYS
Main setting
CT1 at output OFF
ON HYS
Main setting
CT1 at output OFF
OFF before measuring CT1 current value OFF before measuring CT1 current value
Heater 2
burnout/
Over-current
18
CT2 at output ON
Main setitng *
Sub-setting *
ON HYS ONHYS ONHYS HYS
Main setting *
Sub-setting *
CT2 at output ON
OFF before measuring CT2 current value OFF before measuirng CT2 current value
Heater 2
short-circuit
19 ON
HYS
Main setting
CT2 at output OFF
ON HYS
Main setting
CT2 at output OFF
OFF before measuring CT2 current value OFF before measuring CT2 current value
Alarm
(status)
23 ON if alarm occurs (alarm code AL01
to 99).
OFF in other cases.
OFF if alarm occurs (alarm code AL01
to 99).
ON in other cases.
: initial value
*: If the main setting is greater than the sub-setting, operations are performed with the
main setting and sub-setting automatically swapped.
Event types other than the above:
Operation type Set
value
Operation type Set
value
Operation type Set
value
SP high limit 10 Loop diagnosis 1 20 During AT (status) 27
SP low limit 11 Loop diagnosis 2 21 During SP ramp 28
SP high/low limit 12 Loop diagnosis 3 22 Control action (status) 29
MV high limit 13 READY (status) 24 ST setting standby (status) 30
MV low limit 14 MANUAL (status) 25 Timer (status) 32
MV high/low limit 15
1st edition: Mar. 2007 (W)
3rd edition: Apr. 2019 (B)© 2007–2019 Azbil Corporation. All Rights Reserved.
