B. Braun microspeed uni User manual

Aesculap Power Systems
microspeed® uni
Instructions for use
microspeed® uni motor system
Gebrauchsanweisung
microspeed® uni-Motorensystem
Mode d’emploi
¾voir www.aesculap-extra.net
Instrucciones de manejo
¾ver www.aesculap-extra.net
Istruzioni per l’uso
¾vedere www.aesculap-extra.net
Instruções de utilização
¾ver www.aesculap-extra.net
Gebruiksaanwijzing
¾zie www.aesculap-extra.net
Bruksanvisning
¾se www.aesculap-extra.net
Käyttöohjeet
¾ks. www.aesculap-extra.net
Инструкция по примению
¾смотри www.aesculap-extra.net

7
6
5 5
8
4
12
17 16 14
3
3
1 2
910 11 13
15
39

18
20 19
18
23
21 24
22
29
26 30 28
31
28
27
33
35
34
3837
32
36
25

2
microspeed® uni motor system
Aesculap Power Systems
Legend
Captions first foldout page: Control unit
1microspeed® uni control unit with cooling unit GD670
2Display and touch control field
3Release buttons
4Coolant pump
5Motor connection sockets
6Power OFF switch
7Power ON switch
8Power ON indicator
9Bottle holder
10 Bottle holder mount
11 Ventilation grate
12 Power socket
13 Fuse holder
14 Connection socket for foot control
15 Stacking cones
16 Locking screw
17 Equipotentialization connector
39 Interfaces to be used by the manufacturer only
Captions second foldout page: Foot controls, motor cables, motors
18 Foot control function button
19 Right pedal
20 Left pedal
21 microspeed® uni foot control, two pedals, GD671
22 Motor direction switch
23 Pedal
24 microspeed® uni foot control, one pedal, GD668
25 Motor release switch
26 Hand control function button
27 microspeed® uni motor cable with hand control GD673
28 Release key
29 Lever
30 Motor release switch
31 microspeed® uni motor cable for foot control GD672
32 Motors with motor-side plug connection
33 microspeed® uni mini pistol handpiece GD684
34 Upper trigger
35 Lower trigger
36 Suction control lever
37 microspeed® uni shaver handpiece GD682
38 Tube olive
Contents
1. Safe handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. Product description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1 System components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.2 Components necessary for using the product . . . . . . . . . . . . . . . 4
2.3 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.4 Mode of operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.4.1 Control unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.4.2 Control and display interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.4.3 Control fields on the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.4.4 Motor control fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.4.5 Pump control field . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.4.6 Instruction menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.4.7 Motor recognition. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.4.8 Automatic saving of device settings . . . . . . . . . . . . . . . . . . . . . . . 6
2.4.9 Overload cut-out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.4.10 Coolant pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.4.11 Motor cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.4.12 Motors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.4.13 Foot control devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.5 Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.5.1 Symbols on the control unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.5.2 Symbols on foot control, motor cable and motor . . . . . . . . . . . 12
2.5.3 Symbols in display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3. Preparation and setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.1 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.1.1 Mounting the control unit on the mobile stand . . . . . . . . . . . . 15
3.1.2 Dismounting the control unit from the mobile stand . . . . . . . . 15
3.1.3 Mains power connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4. Working with the microspeed® uni motor system. . . . . . . . . . . 16
4.1 System set-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.1.1 Connecting the accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.1.2 Connecting the foot control to the control unit . . . . . . . . . . . . 16
4.1.3 Connecting the tubing set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.1.4 Connecting the motor cable to the control unit . . . . . . . . . . . . 17
4.1.5 Connecting a motor (GD674, GD676, GD677, GD678
and GD679) to the motor cable. . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.1.6 Switching on the control unit/Automatic self-test . . . . . . . . . . 18
4.1.7 Connecting handpieces/attachments/blades . . . . . . . . . . . . . . . 18
4.2 Function checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.3 Safe operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.3.1 Setting up and operating the motors GD674, GD676,
GD677, GD678 and GD679 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.3.2 Setting up and operating
the microspeed® uni shaver handpiece GD682 . . . . . . . . . . . . . 26
4.3.3 Setting up and operating
the microspeed® uni mini pistol handpiece GD684. . . . . . . . . . 28
4.4 Settings in the Instruction menu . . . . . . . . . . . . . . . . . . . . . . . . 32
4.4.1 Submenu information on the error conditions
shown on the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
4.4.2 Submenu Device-specific settings . . . . . . . . . . . . . . . . . . . . . . . 33
4.4.3 Submenu Motor (type)-specific settings . . . . . . . . . . . . . . . . . . 35

3
5. Processing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
5.1 Processing the microspeed® uni control unit with
cooling unit GD670 and
microspeed® uni foot control devices GD668/GD671 . . . . . . . . 38
5.1.1 Cleaning/Disinfection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
5.1.2 Manual cleaning/disinfecting. . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
5.1.3 Control, care and inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
5.1.4 Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
5.2 Processing the microspeed® uni motors GD674, GD676,
GD677, GD678, GD679 and motor cables GD672 and GD673 . 39
5.2.1 Preparations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
5.2.2 Cleaning/Disinfection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
5.2.3 Mechanical cleaning/disinfecting . . . . . . . . . . . . . . . . . . . . . . . . 40
5.2.4 Manual cleaning/disinfecting. . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
5.2.5 Control, care and inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
5.2.6 Packaging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
5.2.7 Sterilization method and parameters . . . . . . . . . . . . . . . . . . . . . 41
5.2.8 Sterilization for the US market . . . . . . . . . . . . . . . . . . . . . . . . . . 41
5.2.9 Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
5.2.10 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
5.3 Processing the microspeed® uni shaver handpiece GD682 . . . . 41
5.3.1 Preparations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
5.3.2 Mechanical cleaning/disinfecting . . . . . . . . . . . . . . . . . . . . . . . . 41
5.3.3 Manual cleaning/disinfecting. . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
5.3.4 Control, care and inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
5.3.5 Packaging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
5.3.6 Sterilization method and parameters . . . . . . . . . . . . . . . . . . . . . 42
5.3.7 Sterilization for the US market . . . . . . . . . . . . . . . . . . . . . . . . . . 42
5.3.8 Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
5.3.9 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
5.4 Processing
the microspeed® uni mini pistol handpiece GD684 . . . . . . . . . . 43
5.4.1 Preparations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
5.4.2 Cleaning/Disinfection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
5.4.3 Mechanical cleaning/disinfecting . . . . . . . . . . . . . . . . . . . . . . . . 43
5.4.4 Manual cleaning/disinfecting. . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
5.4.5 Control, care and inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
5.4.6 Packaging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
5.4.7 Sterilization method and parameters . . . . . . . . . . . . . . . . . . . . . 44
5.4.8 Sterilization for the US market . . . . . . . . . . . . . . . . . . . . . . . . . . 44
5.4.9 Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
5.4.10 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
6. Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
7. Troubleshooting list. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
7.1 Malfunctions with error numbers . . . . . . . . . . . . . . . . . . . . . . . . 46
7.2 Other malfunctions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
7.3 Fuse change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
8. Technical Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
9. Accessories/Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
9.1 Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
9.1.1 microspeed® uni motors, motor cables and
foot control devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
9.1.2 Cooling unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
9.1.3 Other components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
9.1.4 Power cord. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
9.1.5 Maintenance, processing and service . . . . . . . . . . . . . . . . . . . . . 50
9.2 Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
10. Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
10.1 Classification acc. to directive 93/42/EEC . . . . . . . . . . . . . . . . . 50
10.2 microspeed® uni control unit with cooling unit GD670 . . . . . . 51
10.2.1 Factory settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
10.3 Low-speed motors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
10.3.1 Low-speed motors with micro-Line coupling. . . . . . . . . . . . . . . 51
10.3.2 Low-speed motor with mini-Line coupling . . . . . . . . . . . . . . . . 52
10.4 High-speed motors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
10.4.1 High-speed motors with Hi-Line coupling . . . . . . . . . . . . . . . . . 52
10.5 microspeed® uni shaver handpiece GD682. . . . . . . . . . . . . . . . . 52
10.6 microspeed® uni mini pistol handpiece GD684 . . . . . . . . . . . . . 53
11. Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
12. Distributor in the US/Contact in Canada
for product information and complaints . . . . . . . . . . . . . . . . . . 53
1. Safe handling
CAUTION
Federal law restricts this device to sale by or on order of a physician!
Note
For handling and operating the products that are used with the
microspeed® uni motor system, always observe the instructions for use of
the respective products. The present instructions for use only describe the
handling and operation of the “microspeed® uni motor system”.
¾Prior to use, check for proper condition and functioning of the product.
¾Observe “Notes on Electromagnetic Compatibility (EMC)”, see
TA022130.
¾To avoid damaging the product through improper setup or operation
and mitigating the warranty and liability on the part of the product’s
manufacturer:
– Use the product only according to these instructions for use.
– Follow the safety instructions and maintenance advisories.
– Only combine Aesculap products with each other.
¾Ensure that the products and accessories are operated and used only
by persons with the requisite training, knowledge or experience.
¾Keep the instructions accessible for the O.R. personnel.
¾Always adhere to applicable standards.
¾Verify that the electrical installations in the room in which the
equipment is to be used conform to IEC standards.
¾Unplug the device by pulling on the plug, and never on the power cord.
¾Do not use the control unit and motors in explosion hazard areas.
¾Prior to use, carry out sterile processing of motor(s), motor cable,
tubing, handpiece(s) and tools.
¾Operate the handpieces only at the recommended motor speeds.
DANGER
Risk of death by electric shock!
¾The user must not open the control unit under any
circumstances.
¾Connect product only to mains with protective circuit.

4
microspeed® uni motor system
Aesculap Power Systems
2. Product description
2.1 System components
2.2 Components necessary for using the product
• microspeed® uni control unit with cooling unit GD670
• Power cord
• Motor
• Motor cable
(when using a motor with a motor-side plug connection)
• Foot control
(when using a motor cable without hand control, or the shaver
handpiece)
• Bottle holder
(when using the coolant pump)
•Tubingset
(when using the coolant pump)
• Surgical suction device
(when using the shaver handpiece)
2.3 Intended use
The microspeed® uni motor system is a universal system with respect to
its range of applications and to the system composition and its variety of
uses.
The microspeed® uni motor system is used in orthopedics/traumatology,
neurosurgery, spine surgery, hand/foot surgery, ENT/OMF surgery, plastic
surgery and arthroscopy.
The microspeed® uni motor system can be operated as complete from the
sterile area, either through foot control or through hand control.
2.4 Mode of operation
The microspeed® uni motor system comprises the following components:
• Control unit with coolant pump, for universal application
• Two motor cables (with or without hand control)
• Various motors with different coupling types
• Pistol handpiece
• Shaver handpiece
• Two foot control devices
2.4.1 Control unit
Control unit 1has been designed for a mains voltage rating of 100 V to
240 V/50 Hz to 60 Hz. The mains voltage is transformed so that the motors
run at safety low voltage.
Control unit 1is equipped with two motor connection sockets 5for
connecting two (different) motors, and with one foot control connection
socket 14 (on rear panel).
The following devices can be connected to control unit 1at the same time:
•Twomotorsand
• One foot control (GD668 or GD671).
Note
Do not connect two shaver handpieces GD682 at the same time.
Only one motor can be activated at any one time.
Motors with motor-side plug connection (GD674, GD676, GD677, GD678
and GD679) can be operated either through hand control (motor cable
GD673) or foot control GD668 or GD671 (with motor cable GD672).
Note
When two motors without hand control are connected to the control unit
(motor cable GD672), a motor can only be activated if the motor release
switch of the motor that is to be activated is in the “ON” position while the
other motor is locked (motor release switch in “OFF” position).
2.4.2 Control and display interface
Display 2shows the present device status (operating and error conditions)
at all times. The display is divided into motor control field(s) and a pump
control field. The device parameter settings can be changed by pressing
the control keys.
For information on all the symbols used in the motor and pump control
fields, see chapter Symbols in display.
Control key “Instruction menu” calls up the Instruction menu.
Designation Art. no.
microspeed® uni control unit with cooling unit GD670
Bottle holder GD412804
Instructions for use TA022089
Notes on Electromagnetic Compatibility (EMC) TA022130

5
2.4.3 Control fields on the display
Fig. 1
Legend
AMotor control field(s)
BPump control field
CInstruction menu
The display is divided into three different control fields, which are
described in the following chapters.
2.4.4 Motor control fields
Fig. 2
Legend
AStatus display and control key for releasing (symbol highlighted by
green background)/locking the pump
BActivation mode indicator: hand control or foot control
CPresent motor speed range upper limit setting
DQualitative display of the actual motor speed
EControl keys for increasing or reducing the motor speed range upper
limit
FMotor direction indicator
GOperating mode selected for the connected motor type, e.g. saw
program for motors GD678 and GD679
HConnected motor type
IMaximum selectable motor speed range upper limit for the connected
motor type or with the selected operating mode, respectively
Each motor connected to control unit 1has a motor control field assigned
to it.
Two motor control fields are opened in display 2only if two motors 32 are
actually connected to control unit 1.
Only one motor control field will be opened if only one motor is connected.
The control fields are visually identified as belonging to the respective
motor connection sockets 5.
A B
C
A
B
C
D
H
E
F
G
I

6
microspeed® uni motor system
Aesculap Power Systems
A motor control field is displayed as an active control field when the motor
assigned to the motor control field:
• is operated
• was the last motor operated.
The symbol of the connected motor type is highlighted by a green
background whenever a motor control field is released for operation.
2.4.5 Pump control field
Fig. 3
Legend
AStatus indicator symbol of coolant pump 4. The symbol is highlighted
by a green background while the pump is active. The pump can only
be activated if it has been released for operation and if the motor is
active.
BControl keys for increasing or reducing the delivery rate
CDisplay of selected dosage
The preset dose level Capplies to the motor whose settings are displayed
in the (white background) motor control field.
2.4.6 Instruction menu
Note
The Instruction menu can only be called up at the control unit.
This control key is pressed to call up the Instruction menu. In the
Instruction menu, information about the error conditions output to the
display and device settings such as the user language and the volume of
the acoustic alarm/notification signal can be changed.
Motor-type specific adjustments and settings can be carried out here, too:
• Slow-down and speed-up ramps for each motor type
• Oscillating or tapping mode (for pistol handpiece GD684)
• Oscillation frequency and speed-up ramp in oscillating mode (in
Shaving mode of operation of shaver handpiece GD682)
• Reset: to restore the factory settings
2.4.7 Motor recognition
Control unit 1recognizes the motor type connected to one of the motor
connection sockets 5of control unit 1and displays the type in the
respective motor control field of display 2. The most recent settings for this
motor type at the same motor connection socket are shown on display 2.
The settings can be changed within the motor-specific setting ranges,
either on the display or through hand or foot control (in the Device
settings menu), see chapter Technical specifications.
The motor control field of the most recently activated motor is always
brightly highlighted, whereas the motor control field of the motor that is
not the one that was most recently activated or locked is displayed with
a gray background. When only one motor is connected to control unit 1,
the corresponding control field is highlighted, if this motor is not locked.
Saw program (only for low-speed motors GD678 and GD679)
In this program the maximum motor speed is limited to 16,000 1/min. The
settings most recently used with the saw program (motor speed range
upper limit, dose level for coolant pump 4) are recalled automatically.
2.4.8 Automatic saving of device settings
The most recent settings for this motor type at this motor connection
socket (speed range upper limit, delivery rate, etc.), are called up
automatically as soon as the same motor type is recognized again as
connected at the same motor connection socket of control unit 1after a
motor change.
Note
After each device start-up both the coolant pump and motor type-specific
special functions such as the saw program (for GD678 and GD679) or the
oscillating or tapping mode (for GD684) are always inactive (even if they
had been released or activated before). All parameters are reset when the
operating key "Factory setting" in the Instruction menu is pressed.
A
B
B
C

7
2.4.9 Overload cut-out
To protect the connected motors against thermal destruction, the system
features a separate motor temperature monitoring device. For this
purpose, a temperature module is integrated in the device.
•1stLevel:
As soon as the temperature module indicates a motor temperature
above 75 °C and below 90 °C, an acoustic warning is sounded and the
message “Temp. Motor” flashes on the display. Any further overload
causes control unit 1to switch to level 2.
• 2nd Level:
As soon as a motor temperature in excess of 90 °C is detected, the
motor is switched off and the message “Error 7 – Motor overheated” is
shown on display 2.
After a cooling-down period the motor can be activated again.
Alternatively, the temperature module is reset, and work can be continued
as soon as the overheated motor has been replaced. We recommend
keeping a replacement motor on standby.
2.4.10 Coolant pump
Note
The coolant pump only works when a motor is running!
At power-on of the control unit, coolant pump 4 is always deactivated
(even if it had been released for operation at an earlier time).
The microspeed® uni control unit 1is fitted with a coolant pump 4. This
coolant pump serves exclusively for cooling or irrigating the tools. The
delivery rate at the highest dose level is approx. 80 ml per minute. The
coolant pump can be activated either in the respective motor control field
or through the appropriate hand or foot control device. The delivery rate
can be selected via the pump control field or through the Device settings
menu, see chapter Submenu Device-specific settings.
Exception: When using pistol handpiece GD684, the pump can be
activated, and the delivery rate can be changed, only via the appropriate
control fields on the control unit.
Any one of 21 dosage settings can be selected. At dosage settings 1 to 5,
coolant pump 4operates in intermittent mode. The pump can be switched
on and off, and the delivery rate can be changed, even while the motor is
active. Once the motor was active for more than two seconds, a special
drive control prevents further coolant from dripping out.
2.4.11 Motor cable
Note
A motor cable is needed to connect motors (with motor-side plug
connection) GD674, GD676, GD677, GD678 and GD679 to the control unit.
The microspeed® uni motor system comprises one motor cable for foot
control (GD672) and one motor cable with hand control (GD673). Both
motor cables can be used in connection with all motors with a motor-side
plug connection. Either of the two motor cables can be connected at any
of the two motor connection sockets 5.
Notes
The choice of motor cable depends on the application and which handpiece
is to be used.
For using saws GB128R, GB129, GB130R and motor cable with hand
control GD673, we recommend guiding the saw with both hands for
optimal handling. If single-handed saw guidance is required, use motor
cable GD672 with a foot control device.
WARNING
Risk of injury due to uncontrolled movement of skin
abrading handpiece GB280 in conjunction with a motor
cable with hand control GD673!
¾Use skin abrading handpiece GB280 only with motor
cable GD672 and foot control.

8
microspeed® uni motor system
Aesculap Power Systems
microspeed® uni motor cable for foot control GD672
Fig. 4
Legend
30 Motor release switch
Note
This motor cable can only be used in connection with a foot control.
The motor coupled to this motor cable can only be activated if motor
release switch 30 is in the “ON” position. When two motor cables GD672
are used at the same time, a motor can be activated only if it has been
released (motor release switch 30 in position "ON") while the other motor
is deactivated (motor release switch 30 in position "OFF").
microspeed® uni motor cable with hand control GD673
Fig. 5
Legend
25 Motor release switch:
Position "ON": Motor released for operation
Position "OFF": Motor locked against operation
26 Hand control function button:
Short actuation: Switching on/off the coolant pump
Pressing for more than three seconds (with the motor inactive):
Change to Device settings menu, siehe Kapitel Changing the settings
in the Device settings menu through hand control
29 Lever:
Actuator for motor speed setting
Note
This motor cable can not be used in connection with a foot control.
The motor coupled to this motor cable can only be activated if the motor
release switch is in its “ON” position.
30 2629 25

9
2.4.12 Motors
Motors with motor-side plug connection
Note
A motor cable GD672 or GD673 is required for connecting motors with
motor-side plug connection to the control unit!
Depending on the field of application, there are five different motor types
available, with the three Aesculap standard coupling systems Hi-Line,
micro-Line (Intra coupling system to DIN 13940/ISO 3964) and mini-Line.
Each motor can be operated in right or left (clockwise or
counterclockwise) rotation mode. When a motor is running in left-
rotation mode, control unit 1issues an acoustic signal.
For the performance data and parameters to be set for the individual
motor types, see chapter Technical specifications.
Motor types GD678 and GD679 offer the option to select a saw program.
In this program the maximum motor speed is limited to 16,000 1/min.
Motors with fixed motor cable GD682 and GD684
Note
The motors are directly connected to the control unit. An additional motor
cable is not required!
For the performance data and parameters to be set for the individual motor
types, see chapter Technical specifications.
microspeed® uni shaver handpiece GD682
Fig. 6
Legend
36 Suction control lever:
Lever for continuous regulation of the suction power
38 Tube olive:
Connection to the surgical suction device via a suction tube
Notes
Always observe the instructions for use of blades TA011579.
Only use Aesculap blades.
Shaver handpiece GD682 can only be used with foot control GD671 and a
surgical suction device (e.g. GF200 or GF210).
Shaver handpiece GD682 can be used if:
• a motor with motor cable GD673 is connected at the second motor
connection socket, or
• a pistol handpiece GD684 is connected at the second motor connection
socket, or
• a motor with motor cable GD672 is connected at the second motor
connection socket and the motor release switch of that cable is in its
“OFF” position, or
• only one shaver handpiece GD682 is connected to control unit 1.
There are two types of blades available for shaver handpiece GD682:
reamer and shaver blades.
Control unit 1recognizes whether the coupled blade is a reamer or a
shaver blade. The respective mode of operation (reaming or shaving) is
indicated on the display.
An acoustic signal is issued whenever a blade of a different type is
inserted. At the same time the respective symbol is displayed in the
appropriate control field.
With a reamer blade inserted, left-rotation and right-rotation modes are
avilable, but not the oscillating mode. The maximum speed is limited to
8,000 1/min. The symbol for the "Reaming" operating mode is displayed in
the control field.
With a shaver blade inserted, right-rotation and left-rotation operating
modes are available. The maximum speed is limited to 5,000 1/min. The
symbol for the "Shaving" operating mode is displayed in the control field.
36 38

10
microspeed® uni motor system
Aesculap Power Systems
microspeed® uni mini pistol handpiece GD684
Fig. 7
Legend
34 Upper trigger
35 Lower trigger
Note
The pistol handpiece can be locked against inadvertent actuation by gently
pressing and turning the upper trigger by 90°.
The pistol handpiece cannot be used with foot control.
Pistol handpiece GD684 is fitted with the Aesculap mini-Line coupling
system.
A protective sleeve is supplied with the handpiece. This sleeve serves to
protect against injury and damage when inserting Kirschner wires.
There are two operating modes of pistol handpiece GD684:
• Standard operation
• Oscillating or tapping mode
If control unit 1recognizes a pistol handpiece GD684 connected, the
pistol handpiece will operate in the Standard mode (factory setting). The
device parameter settings (speed range upper limit, delivery rate, pump
status) can be changed only via the touch control field of control unit 1.
Oscillating or tapping mode can be selected via the Instruction menu. The
symbol for “Oscillating or tapping mode” is displayed in the respective
motor control field. Oscillating or tapping mode is activated though the
upper trigger. An acoustic notification signal is sounded and “Oscillating
or tapping mode active” flashes in the respective motor control field. In
this mode of operation, the speed range upper limit cannot be changed via
the touch control field on control unit 1.
The oscillating or tapping mode can be deactivated again by pressing the
upper trigger. After each power-up of the control unit and connection of
the pistol handpiece, oscillating or tapping mode is always deactivated
and needs to be activated anew via the pistol handpice. The preselected
setting in the Instruction menu is saved and remains in memory even
through subsequent system restarts.
Standard operation:
Right and left rotation mode (when in left-rotation mode, control unit 1
issues an acoustic signal).
Motor direction switch/trigger for left rotation 34, see Fig. 7:
• Pressing lower trigger 35 while holding down upper trigger 34 makes
the pistol handpiece operate in left-rotation mode.
• The motor direction is changed by pressing trigger 34 with trigger 35
already actuated.
Motor speed control trigger 35:
• Actuator for motor speed setting (motor speed proportional to
actuator travel).
• If only trigger 35 is pressed, the pistol operates in right rotation mode.
Oscillating or tapping mode:
Activating or deactivating the operating mode, see Fig. 7:
• This mode of operation is activated (and deactivated) by pressing and
holding upper trigger 34 for three seconds.
Working in “Oscillating or tapping mode”:
• The pistol handpiece is operated in tapping mode by pressing lower
trigger 35 within the first half of the total trigger travel. The motor
speed is proportional to the actual trigger travel.
Tapping mode means: Clockwise rotation by a certain angle (forward step)
followed by counterclockwise rotation (backward step) by a smaller angle.
• The pistol handpiece is operated in oscillating mode by pressing lower
trigger 35 within the second half of the total trigger travel. The motor
speed is proportional to the actual trigger travel.
Oscillating mode means: Clockwise rotation by a certain angle followed by
counterclockwise rotation by the same angle.
The pistol handpiece is operated in left-rotation mode by pressing lower
trigger 35 at the same time as upper trigger 34.
34
35

11
2.4.13 Foot control devices
Notes
The microspeed® uni motor system includes two different foot controls
(GD668 and GD671).
Only one foot control can be connected to control unit GD670 at any time.
microspeed® uni foot control, one pedal, GD668
Fig. 8
Legend
18 Foot control function button:
Short actuation: Switching on/off the coolant pump
Actuation for more than three seconds (with the motor inactive):
Changing to Device settings menu, see chapter Changing the settings
in the Device settings menu through the foot control
22 Motor direction switch:
Selection of right or left rotation
23 Pedal:
Actuator for motor speed setting
microspeed® uni foot control, two pedals, GD671
Fig. 9
Legend
18 Foot control function button:
Short actuation: Switching on/off the coolant pump
Actuation for more than three seconds (with the motor inactive):
Change to Device settings menu, see chapter Changing the settings in
the Device settings menu through the foot control.
19 Right pedal:
Actuator for motor speed setting in right rotation
20 Left pedal:
Actuator for motor speed setting in left rotation
18
23
22
20
18
19

12
microspeed® uni motor system
Aesculap Power Systems
2.5 Symbols
2.5.1 Symbols on the control unit
2.5.2 Symbols on foot control, motor cable and motor
Adhere to instructions for use
Type BF application component
Input from irrigation bottle (coolant pump)
Outlet to handpiece (coolant pump)
Pumping direction (coolant pump)
Equipotentialization connector
Fuse
Alternating current
Foot control
Marking of electric and electronic devices according to
directive 2002/96/EC (WEEE), see chapter Disposal.
Foot control function button
(Foot control GD668, GD671, motor cable GD673)
Motor direction switch
Selection of left or right rotation
(Foot control GD668)
Pedal for left/right rotation
(according to the motor direction set through the motor
direction switch, foot control GD668)
Pedal for right rotation
(Foot control GD671)
Pedal for left rotation
(Foot control GD671)
Oscillating operation when both pedals are pressed
(only allowed in "Shaving" mode in conjunction with
shaver handpiece GD682 , foot control GD671)
Class AP anesthetic test
(EN 60601-1)
(Foot controls GD668 and GD671)
Enclosure protection type to DIN EN 60529
(Foot controls GD668 and GD671)
Release
(Motors GD674, GD682 and GD684)
Motor speed control
(Motor GD684)
Right/left rotation switch
(Motor GD684)
Oscillating or tapping mode:
(Motor GD684)
Protection against inadvertent activation
(Motor GD684)
IPX8

13
2.5.3 Symbols in display
Display symbols in the motor control fields
(Set) motor speed range upper limit
(example: 20,000 1/min)
Motor speed in 1/min
Qualitative display of the actual motor speed (for shaver
handpiece GD682: actual tool speed)
Symbol displayed on gray background in motor control
field if the respective motor is not activated
Qualitative display of the actual motor speed (for shaver
handpiece GD682: actual tool speed);
active while motor is operated
Motor direction indicator for right rotation
when the motor is inactive or when right rotation was
not selected through foot control GD668;
in an inactive motor control field, this symbol is displayed
on a gray background
Motor direction indicator for right rotation
active when the motor is operated or in standby, provided
this motor direction was selected and foot control GD668
is connected to the control unit
Motor direction indicator for left rotation
when the motor is inactive or when left rotation was not
selected through foot control GD668;
in an inactive motor control field, this symbol is displayed
on a gray background
Motor direction indicator for left rotation
active when the motor is operated or in standby, provided
this motor direction was selected and foot control GD668
is connected to the control unit
Hand control
active if connected hand control is recognized
Foot control
active if connected foot control is recognized and at least
one motor is not operated through a hand control device
No response when foot control is pressed down
active if neither a foot control nor a hand control device
is recognized as connected
GD676 microspeed® uni Hi 150 motor (high-speed motor;
150 W; coupling system: Hi-Line (XS) connected
If the motor can be activated (is released), the symbol is
highlighted by a green background
GD677 microspeed® uni Hi 100 motor (high-speed motor;
100 W; coupling system: Hi-Line (XS) connected
If the motor can be activated (is released), the symbol is
highlighted by a green background
GD678 microspeed® uni micro 150 motor (low-speed
motor; 150 W; coupling system: micro-Line)
If the motor can be activated (is released), the symbol is
highlighted by a green background
GD679 microspeed® uni micro 100 motor (low-speed
motor; 100 W; coupling system: micro-Line)
If the motor can be activated (is released), the symbol is
highlighted by a green background
GD674 microspeed® uni mini 100 motor (low-speed
motor; 100 W; coupling system: mini-Line) connected
If the motor can be activated (is released), the symbol is
highlighted by a green background
GD682 microspeed® uni shaver handpiece connected
If the motor can be activated (is released), the symbol is
highlighted by a green background
GD684 microspeed® uni mini pistol handpiece (coupling
system: mini-Line) connected
If the motor can be activated (is released), the symbol is
highlighted by a green background
Operating mode "Reaming"
(only in connection with shaver handpiece GD682, if no
shaver tip is recognized)
Operating mode "Shaving"
(only in connection with shaver handpiece GD682, if a
shaver tip is recognized)
Oscillating or tapping mode (only in connection with
pistol handpiece GD684)
Displayed when oscillating or tapping mode was released
in the instruction menu, but not activated through the
pistol handpiece

14
microspeed® uni motor system
Aesculap Power Systems
Display/Control key symbols in the motor control fields Display symbols in the pump control field
Control key symbols in the pump control field
Control key symbols within the display
Oscillating or tapping mode active:
(only in connection with pistol handpiece GD684)
Displayed when oscillating or tapping mode was released
in the Instruction menu and is activated through the
pistol handpiece (by holding down the upper trigger for
three seconds)
Increasing the motor speed range upper limit
Reducing the motor speed range upper limit
Status indicator/control key of the saw program
This symbol indicates that the saw program, which can
only be selected in connection with motors GD678 and
GD679, is inactive
Status indicator/control key of the saw program
This symbol indicates that the saw program, which can
only be selected in connection with motors GD678 and
GD679, is active
Motor direction indicator when left rotation was not
selected, and control key for selecting left rotation
The control key symbol is only displayed, and a motor
direction can only be selected if hand control GD673 is
connected
Motor direction indicator when left rotation was
selected, and control key for selecting left rotation
The control key symbol is only displayed, and a motor
direction can only be selected if hand control GD673 is
connected
Motor direction indicator when right rotation was not
selected, and control key for selecting right rotation
The control key symbol is only displayed, and a motor
direction can only be selected if hand control GD673 is
connected
Motor direction indicator when right rotation was
selected, and control key for selecting right rotation
The control key symbol is only displayed, and a motor
direction can only be selected if hand control GD673 is
connected
"Pump OFF" indicator and control key for activating the
pump
The symbol is displayed in the respective motor control
field
"Pump ON" indicator and control key for activating the
pump
Active when, in connection with the selected motor, the
pump is switched on via the function button (hand or
foot control) or by actuating this field. The symbol is
displayed in the respective motor control field.
"Pump inactive" indicator
Symbol as displayed with the motor inactive, i.e. when
the pump has not been activated in the pump control
field
"Pump active" indicator
is active when the pump released in connection with the
selected and activated motor is activated
Display of selected dosage
is always active
Increasing the delivery rate
Reducing the delivery rate
Selecting the secondary control level
Instruction menu,
can only be activated when no motor is active

15
3. Preparation and setup
Non-compliance with these rules will result in complete exclusion of any
responsibility and liability on the part of Aesculap.
¾Observe the following regulations when setting up and operating the
product:
– the national regulations for installation and operation
– national regulations on fire and explosion protection.
– operating advisories acc. to IEC-/VDE regulations.
The following advice is given on the basis of the presently applicable
IEC-/VDE regulations:
The foot control circuit is ignition-safe and approved for operation in
medical environments acc. to IEC 601/VDE 0750.
3.1 Preparation
Note
The control unit can be mounted on an Aesculap mobile stand for
microspeed® uni (adjustable height) GA411 or on an Aesculap mobile stand
for surgical devices GD416M.
Other Aesculap devices must not be stacked on top of the control unit.
3.1.1 Mounting the control unit on the mobile stand
Note
Follow the instructions for use of the mobile stand.
Fig. 10
Legend
ADevice support
15 Stacking cones
16 Locking screw
Only one device may be mounted on the mobile stand at any time, always
taking into consideration the stability of the mobile stand.
¾Remove the caps from stacking cones 15.
¾Remove the device feet, using a screwdriver.
¾Move stacking cones 15 to the correct mounting positions by turning
locking screw 16 counterclockwise as far as it will go, using a
screwdriver.
¾Position the device on the mobile stand in such a way that front edge
sits flush with device support A and stacking cones 15 sit in the
corresponding holes in device support A.
¾Secure the device by turning locking screw 16 clockwise as far as it
will go.
¾Gently lift the device to check if it is securely attached to device
support A.
The device is now mounted on the mobile stand.
3.1.2 Dismounting the control unit from the mobile stand
¾Use a screwdriver to turn locking screw 16 counterclockwise as far as
it will go.
¾Lift off the device.
¾Reattach the device feet either by hand or with a screwdriver.
The device is now dismounted from the mobile stand.
3.1.3 Mains power connection
The voltage of the mains power must correspond to the voltage indicated
on the type plate of the device.
¾Plug in the power cord at power cord socket 12.
¾Plug in the mains plug at the building mains power socket.
WARNING
Fire and explosion hazard!
¾Do not use the control unit and motors in explosion
hazard areas.
16 15 A

16
microspeed® uni motor system
Aesculap Power Systems
4. Working with the microspeed® uni
motor system
4.1 System set-up
4.1.1 Connecting the accessories
Note
Follow the instructions for use of individual accessories!
Note
micro-Line drill pistol (GB200) and arthroscopy handpiece (GB801) must
not be used with this product.
Combinations of accessories that are not mentioned in the present
instructions for use may only be employed if they are specifically designed
for the intended application and do not compromise the performance and
safety characteristics of the products.
Depending on the motor type, all handpieces and tools of this range can
be coupled through the three Aesculap standard coupling systems Hi-Line
(or Hi-Line XS), micro-Line (handpieces for drilling, reaming, sawing and
shaping, with Intra coupling system acc. to DIN 13940/ISO 3964) and
mini-Line.
For other accessories, see chapter Accessories/Spare parts and brochure
no. O22711, Aesculap Power Systems.
4.1.2 Connecting the foot control to the control unit
Note
Only necessary when using motor cable for foot control GD672 or shaver
handpiece GD682.
The foot control can not be used in combination with motor cable with
hand control GD673 and/or pistol handpiece GD684.
Fig. 11
Legend
AFoot control connector
BLocking pins
CLocking clips
DArrows
14 Connection socket for foot control
¾To connect the foot control connector Ato control unit 1:
Fully plug in the foot control connector Aat the connection socket for
foot control 14 (in rear panel of the unit).
Locking clips Caudibly engage in locking pins B, see Fig. 11.
¾To disconnect the foot control device from control unit 1:
Simultaneously compress locking clips C(see arrows D) and unplug
connector A.
WARNING
Risk of infection and contamination!
¾Prior to first operation, carry out sterile processing of
the motors, motor cable, tubing, handpiece and tools.
¾Make certain that the packaging of sterile products is
undamaged.
WARNING
Risk of injury caused by inadvertent activation of the
motor!
¾Secure motors that are not actively operated against
inadvertent activation through foot or hand control.
A
B
B14 D
D
C
C

17
4.1.3 Connecting the tubing set
Note
The tubing set is sterile! Sterile separation is carried out at the tubing.
Fig. 12
Legend
AArrows
BArrows
3Release buttons
4Coolant pump
¾To open coolant pump 4: Simultaneously press release buttons 3.
¾Insert tubing: Insert the pump tube with the tube nipple into the recess
(arrows B).
¾Close coolant pump 4: Push together the pump housing until it clicks
into position (arrows A). When doing this, ensure that the pump
enclosure is completely closed, both at the inlet (from the irrigation
bottle) and at he outlet (to the handpiece).
¾Insert bottle holder 9for the sterile fluid bottle into bottle holder
mount 10.
¾Insert the spike into the sterile fluid bottle.
¾Mount the sterile fluid bottle at bottle holder 9.
4.1.4 Connecting the motor cable to the control unit
Note
The motor cable and the motor are sterile! Sterile separation is carried out
at the motor cable.
Fig. 13
Legend
AMark (motor connection socket)
BPlug
CMark (plug)
DArrows
5Motor connection socket
¾To connect plug B: Align plug Bin such a way that mark Con the plug
is aligned with mark Aon motor connection socket 5.
¾Fully insert plug Bin the motor connection socket.
¾To disconnect plug B: Hold plug Bin the marked places (arrows D) and
unplug it from motor connection socket 5.
3
3
4
AA
B
B
CAUTION
Damage to, or destruction of, the motor cable caused by
pulling the cable!
¾Always pull at the plug, never at the cable.
A
C B
DD
5

18
microspeed® uni motor system
Aesculap Power Systems
4.1.5 Connecting a motor (GD674, GD676, GD677, GD678
and GD679) to the motor cable
Fig. 14
Legend
AMark on motor cable
BMark on motor
CArrows
28 Release key (x2)
32 Motor
¾To couple motor 32: Install motor 32 on the motor cable, making
certain that mark Bon the motor is aligned with mark Aon the motor
cable.
Motor 32 will audibly engage in its proper position.
¾To uncouple motor 32: Compress both release keys 28 at the points
indicated by arrows C. (The motor will be pushed away slightly from
the motor cable.)
This completes the uncoupling of motor 32.
4.1.6 Switching on the control unit/Automatic self-test
¾Switch on control unit 1at mains power ON switch 7.
Power ON indicator 8 will be illuminated.
Control unit 1 always performs a self-test when the unit is switched on.
During this test the microspeed® uni start picture is displayed.
If any malfunction is detected, an error message will be displayed, see
chapter Malfunctions with error numbers.
4.1.7 Connecting handpieces/attachments/blades
Note
For using saws GB128R, GB129, GB130R and motor cable with hand
control GD673, we recommend guiding the saw with both hands for
optimal handling. If single-handed saw handling is required, use motor
cable GD672 with a foot control.
28
A
32
B 28
C
C
WARNING
Risk of injury due to uncontrolled movement of skin
abrading handpiece GB280 in connection with motor cable
with hand control GD673!
¾Use skin abrading handpiece GB280 only with motor
cable GD672 and foot control.
WARNING
Risk of injury and material damage due to inappropriate use
of handpieces or attachments!
¾Always follow the safety advice and information given in
the instructions for use of the handpieces and
attachments.
¾Do not exceed the specified maximum motor speed.
WARNING
Risk of injury caused by loose milling heads when operating
high-speed motors in left rotation mode!
¾Do not use screw-coupled milling heads.
CAUTION
Damage to motor and handpiece!
¾Couple/uncouple handpieces only with the motor
inactive.
