Badger Meter ModMAG M Series User manual

User manual
ModBusMap_M1000R (September 2018)
M-Series®M1000
MODBUS Memory Map

Page 2
September 2018
CONTENTS
Inhalt
OVERVIEW................................................................................................................................................................ 3
WIRING.................................................................................................................................................................3
SECURITY.............................................................................................................................................................. 4
REGISTER NAME .....................................................................................................................................................4
REGISTER ADDRESS ................................................................................................................................................ 4
REGISTER TYPE ...................................................................................................................................................... 5
SUPPORT FUNCTION CODES .................................................................................................................................. 5
IMPORTANT ......................................................................................................................................................... 5
M1000 MEMORY MAP BY REGISTER ADDRESS ......................................................................................................... 6
TROUBLESHOOTING............................................................................................................................................... 13

September 2018
Page 3
RS-Interface
M1000-24
Dig. Out- and
Input
Analog Output
Solid State
Relay
OVERVIEW
M-Series M1000 supports MODBUS RTU communications. Physical layers are: RS-232, RS-422, RS-485, USB CDC, Ethernet (if
assembled).
The tables to follow identify the MODBUS registers and attributes that exist in the M-Series M1000 flow meter. Each register
has attributes that are also specified in the tables.
WIRING
Wiring diagram for RS232, RS422; RS485
M1000 External device
Interface mode selection and termination of the bus
RS232, RS485 and RS422 with ModBus®RTU.
Mode can be configured by DIP switches also termination ON or OFF.
M1000-23
Auxiliary power
USB
Coil detector
Electrodes
detector
Display
Ethernet (in
process)
RS-Interface
DIP switch

Page 4
September 2018
SECURITY
Security identifies the required security level of the register in order to be successfully written. This attribute does not apply
to the readability of the register and registers listed with ADMIN, SERVICE or USER are unprotected if the meter is not
secured (that is, Admin pin is not programmed.)
• READ-ONLY –Typically, read-only registers. This means only the flow meter firmware has the privilege to update the register.
• FACTORY –Includes registers that can only bewritten by the factory
• ADMIN –Registers that require admin level access
• SERVICE –Registers that require service level access
• USER –Registers that require user levelaccess
All registers can be protected by enabling security on the flow meter. Once the flow meter is secured, all registers are
write-protected unless remote privilege is granted. All read accesses to registers are still accepted when the flow meter is
secured. Obtaining remote privilege for write operations requires a sequence of MODBUS actions to take place. Remote login
process is encrypted to ensure protection of the login pins.
1. Read the random value register (Address 0x012B).
2. Perform necessary calculations (contact Badger Meter for details).
3. Write the remote login register (Address 0x012F).
It is advised that a support application is written to perform this process and embedded within the main application software
used to access the flow meter.
REGISTER NAME
When applicable, describes the parameter so it can be associated within the display menu items. Please note, not all registers
are directly modifiable via the menu manager. Also, some registers are not accessible via the menu manager.
REGISTER ADDRESS
Register Address defines the physical address that is required to be transmitted over the MODBUS RTU serial link. Some third-
party applications require the use of logical addressing when communicating over MODBUS. The logical address determines
the MODBUS function code that is transmitted over the serial link.
logical address range 4xxxx is supported. Logical address range 4xxxx issues the Read Holding Register function code 0x03. All
logical addresses start at index 1 (example, 40001).
For example, suppose the application requires logical addressing and is targeting to access the “Flow Rate [User Units]”
register. The physical address for this register is 0xF1 or 241d. This register can be read from logical address 40242. The
logical address is calculated by adding the physical address to the logical start address (40001).
• 40001 + 241 = 40242 (Issues function code 0x03 –Read Holding Register)

September 2018
Page 5
REGISTER TYPE
Register Type identifies the number of registers the parameter requires. Each register is 16 bits. Supported Register
Types include:
Register Type
Description
Number of
MODBUS
Registers
HEXADECIMAL[x]
Unsigned Character (16 bits)
x
UCHAR8[x]
Unsigned Character Array
x/2
UINT16
Unsigned Integer (16 bits)
1
UINT64
Unsigned Integer (64 bits)
4
UINT32
Unsigned Integer (32 bits)
2
FLOAT32
Floating Point (32 bits)
2
For FLOAT32 register types, these registers make use of IEEE-754 floating point standard. For example, 1 .0 is transmitted as
0x3F800000. MODBUS serial link will transmit the most significant byte first, 0x3F, followed by 0x80, 0x00, 0x00.
SUPPORT FUNCTION CODES
Following table identifies the MODBUS function codes (commands) available to access the register. Supported MODBUS
function codes include:
MODBUS Function Code
Description
0x03
Read Holding Register
0x10
Write Multiple Registers
IMPORTANT
Write function codes update only the working register located in volatile memory. Any sequence of writes must be
followed by a write of value 0x01 to the “Command Action Request Register”, address 0x0125. Otherwise changes will
be lost if the flow meter is power cycled or reset.
It is not possible with read function code 0x03 to read blocks of registers. Read multiple registers in one transmission is
not allowed.

M-Series® M1000 MODBUS Memory Map
Page 6
September 2018
M1000 MEMORY MAP BY REGISTER ADDRESS
Register
Address
Register Name
Register Type
Security
Stored in
non-volatile
memory
0x0000
Product Code
4 : M1000R
UINT16
Read-
Only
0x0001
HW Name
UCHAR8[16]
Read-
Only
0x0009
FW Name
UCHAR8[32]
Read-
Only
0x0019
Application Version
UCHAR8[20]
Read-
Only
0x0023
Compile Date
UCHAR8[32]
Read-
Only
0x0033
Compile Time
UCHAR8[32]
Read-
Only
0x0043
Identification Number
UCHAR8[10]
Factory
Yes
0x0048
OTP Boot Checksum
UCHAR8[6]
Read-
Only
0x004B
Flash OS Checksum
UCHAR8[6]
Read-
Only
0x006F
Detector Diameter
1 : 6mm - 1/8inch
2 : 8mm - 1/4inch
3 : 10mm - 3/8inch
4 : 15mm - 1/2inch
5 : 20mm - 3/4inch
6 : 25mm - 1inch
7 : 32mm - 1 1/4inch
8 : 40mm - 1 1/2inch
9 : 50mm - 2inch
10 : 65mm - 2 1/2inch
11 : 80mm - 3inch
12 : 100mm - 4inch
13 : 125mm - 5inch
14 : 150mm - 6inch
15 : 200mm - 8inch
16 : 250mm - 10inch
17 : 300mm - 12inch
18 : 350mm - 14inch
19 : 400mm - 16inch
20 : 450mm - 18inch
21 : 500mm - 20inch
22 : 550mm - 22inch
23 : 600mm - 24inch
24 : 700mm - 28inch
25 : 750mm - 30inch
26 : 800mm - 32inch
27 : 900mm - 36inch
28 : 1000mm - 40inch
29 : 1050mm - 42inch
30 : 1200mm - 48inch
31 : 1400mm - 54inch
32 : 1600mm - 64inch
33 : 1800mm - 72inch
34 : 2000 mm - 80
inch
UINT16
Factory
Yes

User manual
September 2018
Page 7
Register
Address
Register Name
Register Type
Security
Stored in
non-volatile
memory
0x0071
Detector Factor
FLOAT32
Factory
Yes
0x0075
Detector Offset [m/s]
FLOAT32
Factory
Yes
0x0079
Amplifier Factor
FLOAT32
Factory
Yes
0x007D
Detector Current [mA]
FLOAT32
Factory
Yes
0x0081
Power Line Frequency [Hz]
0 : 50Hz
1 : 60Hz
UINT16
User
Yes
0x0082
Excitation Frequency
1 : 3.125/3.75 Hz
2 : 6.25/7.5 Hz
3 : 12.5/15 Hz
4 : 2.083/2.5 Hz
5 : 1.042/1.25 Hz
6 : 0.833/0.833 Hz
UINT16
Service
Yes

Page 8
M-Series® M1000 MODBUS Memory Map
September 2018
Register
Address
Register Name
Register Type
Security
Stored in
non-volatile
memory
0x0083
Flow Unit
0 : LPS-liter/sec
1 : LPM-liter/min
2 : LPH-liter/hour
3 : M3S-cu.meter/sec
4 : M3M-cu.meter/min
5 : M3H-cu.meter/hour
6 : F3S-cu.ft./sec
7 : F3M-cu.ft./min
8 : F3H-cu.ft./hour
9 : GPS-gal./sec
10 : GPM-gal./min
11 : GPH-gal./hour
12 : MGD-mega gal/day
13 : IGS-UKG/sec
14 : IGM-UKG/min
15 : IGH-UKG/hour
17 : OPM-oz./min
18 : BPM-barrel/min
UINT16
User
Yes
0x0084
Totalizer Unit
0 : L-liters
1 : HL-hectoliters
2 : M³-cubic meters
3 : Ft³-cu. feet
4 : USG-US gallons
5 : MG-mega gallons
6 : MG-mega gallons
8 : Oz.-fl. ounces
9 : Aft-acre feet
10 : bbl-barrel
UINT16
User
Yes
0x0086
Full Scale Velocity [m/s]
FLOAT32
Factory
Yes
0x008E
Low Flow Cutoff [%]
FLOAT32
Admin
Yes
0x0090
Full Scale Flow [User Units]
FLOAT32
Factory
Yes
0x0092
Flow Direction
0 : UniDirectional
1 : BiDirectional
UINT16
Factory
Yes
0x0094
Digital Input: Function
0 : None
1 : Remote Reset
2 : Positive Zero Return
3 : Batch Reset
4 : ADE
UINT16
Service
Yes
0x0095
Analog Output Range
1 : 4 - 20 mA
2 : 0 - 20 mA
3 : 0 - 10 mA
4 : 2 - 10 mA
UINT16
Service
Yes
0x00A3
Output #1: Mode
0 : Normally Open
1 : Normally Closed
UINT16
Service
Yes

User manual
September 2018
Page 9
Register
Address
Register Name
Register Type
Security
Stored in
non-volatile
memory
0x00A4
Output #1: Function
0 : Off
1 : Flow Alarm
2 : Empty Pipe Alarm
3 : Error Alarm
4 : Pulse Forward
6 : Pulse Reverse
8 : Preset Batch Output
9 : Direction
10 : Verification Test
11 : Ade
12 : Loopback
UINT16
Service
Yes
0x00B0
Output #2: Mode
0 : Normally Open
1 : Normally Closed
UINT16
Service
Yes
0x00B1
Output #2: Function
0 : Off
1 : Flow Alarm
2 : Empty Pipe Alarm
3 : Error Alarm
4 : Pulse Forward
6 : Pulse Reverse
9 : Direction
10 : Verification Test
12 : Loopback
UINT16
Service
Yes
0x00E9
Flow Velocity [M/S]
FLOAT32
Read-
Only
0x00ED
Flow Rate [M3/S]
FLOAT32
Read-
Only
0x00F1
Flow Rate [User Units]
FLOAT32
Read-
Only
0x010B
Scale Factor [%]
FLOAT32
Service
Yes
0x0114
Menu Language Setting
0 : English
1 : German
2 : Czech
3 : Spanish
4 : French
5 : Russian
6 : Italian
UINT16
User
Yes
0x0115
Analog Input Measure Value
FLOAT32
Read-
Only
0x0119
Analog Input Measure Counter
UINT16
Read-
Only
0x011A
Empty Pipe Actual Resistance [Ohms]
FLOAT32
Read-
Only
0x0124
Empty Pipe Mode
0 : Off
1 : On
UINT16
Admin
Yes
0x0125
Command Action Request
UINT16
Admin
0x0126
Analog Output Calibration Point A
[mA]
FLOAT32
Factory
Yes
0x0128
Analog Output Calibration Point B
[mA]
FLOAT32
Factory
Yes

Page 10
M-Series® M1000 MODBUS Memory Map
September 2018
Register
Address
Register Name
Register Type
Security
Stored in
non-volatile
memory
0x012A
Flow Simulation
0 : 0.0%
10 : + 10.0%
20 : + 20.0%
30 : + 30.0%
40 : + 40.0%
50 : + 50.0%
60 : + 60.0%
70 : + 70.0%
80 : + 80.0%
90 : + 90.0%
100 : +100.0%
65408 : Off
65436 : -100.0%
65446 : - 90.0%
65456 : - 80.0%
65466 : - 70.0%
65476 : - 60.0%
65486 : - 50.0%
65496 : - 40.0%
65506 : - 30.0%
65516 : - 20.0%
65526 : - 10.0%
UINT16
Service
0x012B
Random Value
UINT32
Read-
Only
0x012E
Alarm Mode
0 : Meter error has no
influence on analog output
1 : Meter error drives
output 2 mA below min
2 : Meter error drives
output 2 mA beyond max
UINT16
Service
Yes
0x0155
Digital Input: Status
UINT16
Read-
Only
0x0201
Empty Pipe Counter
UINT16
Read-
Only
0x0202
Pulse: PulsesPerM3
FLOAT32
Service
Yes
0x0204
Pulse: Width
UINT16
Service
Yes
0x0205
Out Low
UINT16
Service
Yes
0x0206
Out High
UINT16
Service
Yes
0x0207
Totalizer T1Plus
FLOAT32
Read-
Only
0x0209
Totalizer T1Minus
FLOAT32
Read-
Only
0x020B
Totalizer T1BiDir
FLOAT32
Read-
Only
0x020D
Totalizer T2Plus
FLOAT32
Read-
Only
0x020F
Totalizer T2Minus
FLOAT32
Read-
Only
0x0211
Totalizer T2BiDir
FLOAT32
Read-
Only

User manual
September 2018
Page 11
Register
Address
Register Name
Register Type
Security
Stored in
non-volatile
memory
0x0216
Totalizer ActualUnit T1Plus
FLOAT32
Read-
Only
0x0218
Totalizer ActualUnit T1Minus
FLOAT32
Read-
Only
0x021A
Totalizer ActualUnit T1BiDir
FLOAT32
Read-
Only
0x021C
Totalizer ActualUnit T2Plus
FLOAT32
Read-
Only
0x021E
Totalizer ActualUnit T2Minus
FLOAT32
Read-
Only
0x0220
Totalizer ActualUnit T2BiDir
FLOAT32
Read-
Only
0x0222
Pulse: Pulses Per ActualUnit
FLOAT32
Service
Yes
0x0224
Empty Pipe Treshold Resistance
FLOAT32
Admin
Yes
0x0226
Date Time
DATETIME
Service
Yes
0x0232
Fault
HEXADECIMAL
Read-
Only
0x0233
Port
HEXADECIMAL
Read-
Only
0x024A
Serial Interface
0 : None
1 : Irda
2 : Serial
3 : M-Bus
4 : Hart
5 : RS 485
UINT16
Service
Yes
0x025B
Internal Disk Size [byte]
UINT64
Read-
Only
0x025F
Internal Disk Free Space [byte]
UINT64
Read-
Only
0x0263
Dataloger period
1 : 1 Minute
15 : 15 Minutes
61 : 1 Hour
66 : 6 Hours
72 : 12 Hours
84 : 24 Hours
UINT16
Service
Yes
0x0265
MBUS Manufacturer
UINT16
Factory
Yes
0x0266
MBUS Product Code
UINT16
Factory
Yes
0x0267
Filter Median
UINT16
Service
Yes
0x0268
Filter Moving Average
UINT16
Service
Yes
0x0269
Filter Display
UINT16
Service
Yes
0x0270
MBUS Primary address
UINT16
Service
Yes
0x0271
ADE Control
0 : Off
1 : On
UINT16
Service
Yes
0x0272
ADE Protocol
1 : Protocol v.1
2 : Protocol v.2
3 : Protocol v.3
UINT16
Service
Yes

Page 12
M-Series® M1000 MODBUS Memory Map
September 2018
Register
Address
Register Name
Register Type
Security
Stored in
non-volatile
memory
0x0273
ADE Dial
0 : 4 Dial
1 : 5 Dial
2 : 6 Dial
3 : 7 Dial
4 : 8 Dial
5 : 9 Dial
UINT16
Service
Yes
0x0274
ADE Resolution
1 : 10000
2 : 1000
3 : 100
4 : 10
5 : 1
6 : 0.1
7 : 0.01
8 : 0.001
9 : 0.0001
UINT16
Service
Yes
0x0275
Polarization voltage [v]
FLOAT32
Read-
Only
0x0279
Analog Output K
FLOAT32
Read-
Only
0x0281
Analog Output Q
FLOAT32
Read-
Only
0 : M1000 mode
1 : M7600 mode
UINT16
Service
Yes

September 2018
Page 13
User manual
TROUBLESHOOTING
MODBUS transmissions can be rejected for various reasons:
• Write request received with an invalid value (out-of range value).
• Write request received to a secured meter.
• Invalid register address supplied in modbus serial request.
• Invalid number of registers supplied in modbus serial request (too many or too few).
• Invalid function code supplied in modbus serial request.
• The following error response codes arereturned.
Error Response Code
Reason
0x01 –Illegal Function Code
Request received with invalid function code.
0x02 –Illegal Data Address
Read/Write request received with invalid number of registers.
Read/Write request received with address not supported.
Write request received to a read-only register.
0x04 –Device Failure
Write request received with invalid value.
0x21
Write request received to a protected parameter (secured device).
MODBUS transmissions may not be responded to for various reasons:
• Bad CRC –Verify serial link is properly shielded.
• Framing / Parity Errors –Verify serial communication settings match for both the flow meter and application software.
• Wrong port address –Verify the flow meter is properly programmed with the correct node address.
• Duplicate port addresses on serial link –May cause collisions when multiple meters respond at the same time.
• Wrong serial wiring –verify wiring is appropriate.
• For RS485, lack of termination on end devices or lack of biasing by MODBUS Master. Flow meter does not provide RS485 biasing. This is
assumed to be accomplished by the MODBUS Master.
