Installing the Balanced Body®Allegro 1B
with Riser Konnector™
The Konnector is compatible with Balanced Body Allegro
Reformers with removable shoulder rests with Twist Lock posts
ONLY. If you aren’t sure whether this system will work with your
equipment, please contact Balanced Body at 1-800-PILATES (US
and Canada), or +1-916-388-2838 (all other countries).
To view the installation podcast, please visit
www.pilates.com/instructions
PARTS LIST (INCLUDED):
ITEM PART NO. QTY
Konnector Rope 210-073 1
Tri-Loops (Grey) 210-061 2
Tri-Loops (Black) with pulleys 210-060 2
Pulley Block Riser Assembly 624-005 2
Lower Mount Allegro Assembly 624-006 2
Under Carriage Mount Assembly 624-004 2
Twist Lock Flanged Cap 616-401 2
1/4”-20x4.25 Socket Head Screws GEN9575 2
1/4-20 Nylock nut GEN9021 2
1/4” Flat Washer GEN9305 4
5/32” Allen wrench GEN9282 1
3/16” Allen wrench GEN9280 1
7/16” Wrench 616-113 1
Spacer, Black, 1.5” Diameter** ALL0516 4
** ”If your machine has legs disregard these spacers. If you
machine has rubber feet, unscrew each foot. Install the spacer
on top of the threaded rubber foot. Screw the foot/spacer
assembly back on machine so spacer is between the machine
and rubber foot.
WARNING: Using the existing shoulder posts with a Konnector
system can cause the loops to fall off the posts during use
which may cause injury.
REMOVE ROPES, POST AND SHOULDER BRACKETS
1. Remove the rope from the cam cleats, carriage and pulleys.
They are no longer needed.
2. Unthread each post from the shoulder rest bracket by hand
and completely remove them from the shoulder rest bracket.
You will no longer need them. Remove the shoulder rest
bracket from the carriage. Repeat on the other side.
3. Using the provided Allen key and 7/16” wrench, remove the
four nuts and washers from the bolts as shown in Figure A.
WARNING: If you are only using some of the loops, the
unused loops MUST be stored on the flanged shoulder
posts.
1 2 3 4
Figure A
Contact Us
1-800-PILATES | +1-916-388-2838
pilates.com | info@pilates.com
400-452 | 10.30.18
INSTALL THE CARRIAGE PULLEY BRACKETS
4. Bolt the two
carriage pulley
brackets to the
underside of the
carriage using
existing hardware
and nuts just
removed. Make
sure the pulleys
are facing towards
the headrest as in
Figure B. Tighten
nuts securely. If
the bolts do not go into the Nylon of nut, it is okay to remove
the washers.
5. Install the shoulder rests back onto the carriage by sliding
them into the slots and away from the carriage pad.
6. Install new flanged shoulder posts onto the protruding
threads of the shoulder rests. Turn the flanged shoulder posts
clockwise to tighten. Hand tighten so the shoulder rest does
not move. Repeat on the other side. See Figure C.
INSTALL RISERS
7. Remove the pulleys from your existing risers by loosening the
nuts on the back of the risers.
8. Using the provided 5/32” Allen wrench, loosen the middle
screw and washer on each riser block and remove them. Slide
the riser block down on the riser posts and secure them using
the just removed screw and washer. See Figure D. Repeat for
the other riser.
INSTALL LOWER PULLEY MOUNTS
9. Install the lower mounts to the inside frame head end cross
rail using the 1/4-20 bolts on the inside of the frame, nuts
and washers as shown in Figure E.
INSTALL ROPE AND LOOPS
10. Place the black loops with pulleys on the shoulder posts. See
Figure F.
11. Thread one end of the rope through both pulleys under the
carriage and pull the ends evenly toward the risers. See Figure
G.
Figure B
Figure E
Figure C
Figure D
Figure F
Loop Pulley
Figure G
2
12. Take one end of the rope and thread up through the lower
mount pulley. Continue threading the rope up through the
upper, inner pulley on the riser block and pull toward
the carriage. See Figure H.
13. Thread the rope through the pulley attached to the black Tri-
Loop with pulley on the same side of the Reformer as the riser
and pull back toward the riser. See Figure I.
14. Thread the rope through the upper, outer pulley on the riser
block and pull back toward the carriage. See Figure J. See
Figure K for a detailed view of the riser pulley block rope
routing.
15. Using a Soft-Touch connection, see Figure L, secure each
end of the rope to a grey Tri-Loop on the same side of the
Reformer as the riser.
16. Repeat steps 12-15 for the other side of the Reformer.
Figure H
Figure I
Figure L
Figure J
Figure K
3
IMPORTANT SAFETY NOTE: Use of the Konnector system in a manner for which it is not intended may result in equipment damage
and/or injury to the user. Intense cardio work utilizing jarring movements may overload the system. Balanced Body is not responsible
for injuries caused by equipment misuse.
Questions? Call Balanced Body Technical Support at 1-800-PILATES (US and Canada), or +1-916-388-2838 (all other countries).
WARNING: Using the existing shoulder posts with a Konnector system can cause the loops to fall off the posts during use which
may cause serious injury.
Contact Us
1-800-PILATES | +1-916-388-2838
pilates.com | info@pilates.com
400-452 | 10.30.18
