PARTS LIST (INCLUDED):
Description Part Number Qty.
Ankle Velcro (pair) 101-001 1
Cotton Loop (pair) 101-005 1
Long Web (pair) 101-026 1
Thigh Velcro (pair) 101-020 1
Wool Fuzzy (pair) 101-022 1
Roll down bar 710-010 1
Belly Strap 210-034 1
T-Pin GEN9892 2
Red Trapeze Spring SPR9001 2
Yellow Trapeze Spring SPR9002 2
Blue Trapeze Spring SPR9004 2
Long Yellow Trapeze Spring SPR9006 2
Long Purple Trapeze Spring SPR9461 2
Black Trapeze Spring SPR9005 2
Safety Strap 210-021 1
Push Through Bar Connector TRP0021 1
Push Through Bar (PTB) TRP0047 1
Trapeze Bar w/Springs and Sling 950-059 1
Vertical Slider TRP6002 1
Horizontal Slider TRP6003 1
1/8" Cotter Pin 216-000 4
3-16" Allen Wrench GEN9280 1
ASSEMBLE THE TRAPEZE CANOPY
1. Using the provided allen wrench, loosen the set screws in
each of the eight flange connectors mounted to the outside
of the Reformer frame. Insert the provided cotter pins into
the 1/8 holes near the bottom ends of each vertical tube. Pick
up the vertical tube assemblies and place the tube ends into
the flanges. The cotter pins will automatically set the tubing
height. Be careful that the cotter pin doesn’t scratch the vinyl
or wooden frame. The tubeset with the push-through bar
goes at the head end of the machine (the end with the vinyl
flaps). The eyebolts on each tubeset should face the
other end.
2. Now set the canopy top onto the four vertical tubes. You will
need help with this. The end of the canopy frame with the
black safety strap goes over the push-through bar. Be certain
all four corner fittings fit securely over the tubes.
3. Using the allen wrench, tighten the set screws in the corner
fittings and in the flanges around the reformer frame.
Supporting the push-through bar, remove the T-pins one at a
time and re-insert them so that they enter from the outside
of the tubes. If either pin binds, some adjustment of the
vertical tubes is needed. Simply loosen the set screws and
rotate the tubes until both pins slide in and out freely. Be sure
to re-tighten all set screws. Remove the cotter pins from the
tubes and save for future use.
INSTALLING THE PUSH THROUGH BAR (PTB)
CONNECTOR
The Push Through Bar Connector is installed by backing the
T-Pins out until they are flush with the PTB. Then hold the
Connector between the legs of the PTB so the T-Pins go into
both ends when fully installed.
WEEKLY MAINTENANCE
Inspect springs for separations, and replace if needed. Inspect
snaps on springs and make sure the retractors operate smoothly.
Replace them if worn or do not operate freely. Make sure that
there are no indentations on the inside of the hooks.
Inspect all nuts, eyebolts and setscrews for tightness. Tighten or
replace if necessary.
Check to see if quick release T-pins operate correctly. Does the
ball at the end of the pin protrude? Does the ball retract when
the button is pressed? If not, replace the pin.
WARNING: This machine is potentially dangerous, and Balanced
Body Inc. assumes no liability towards use or misuse. If you are
not fully aware of the safety issues and use of this machine, do
not use it. Use only with qualified instructor supervision.
QUESTIONS?
Call Balanced Body at 1-800-PILATES (1-800-745-2837) or
+1 916-388-2828.
ASSEMBLY PODCAST
You can also see the Trapeze Table assembly podcast located on
the Instructions & Safety page of our Web site, pilates.com.
