Balanced Body MOTR Installation instructions

Start Your MOTR™
MOTR SET-UP AND SAFETY
1. Stand the MOTR upright with the Locking Lid at the top.
2. Remove the Lid by pressing the green button with your
thumb while gripping the handle. Then twist counter clockwise
until the Lid is loose, remove it, and set it aside.
**** It is very important that you press the button before
turning the Lid. Failure to do so will damage the Lid. ****
3. Remove the Carrying Strap
by sliding it out of the slot (a)
and unclipping it from the
bottom of the MOTR (b).
Set it aside.
4. Reach into the Roller and
remove the donut shaped
foam spacer and the loops.
Set them aside.
5. Use the Pull Out Strap to
lift the Arm completely out of
the Roller.
6. Remove the Pull Out Strap from around the VRM and set it
aside. (The Pull Out Strap, Carrying Strap, and foam spacer may also be stored
inside the roller as they will not be needed during the workout.)
7. Attach the Arm to the top of the MOTR by sliding the tabs on
the Arm into the slots on the top of the Roller, round edges down.
8. Place the Locking Lid back on the MOTR with the green button
positioned over a slot and rotate clockwise until you hear it click
into place.
9. Clip one loop to each VRM.
10. Remove the Stability Wedges from the Arm and place them
on the floor where you want the MOTR to be during the workout.
Then place the MOTR on the Stability Wedges. Adjust the
Stability Wedges so they are under the foam part of the roller
and approximately a finger’s width from each end.
11. Rotate the MOTR until the Arm is parallel to the floor.
Slot (a)
Carrying
Strap
(b)
Finger’s Width
Finger’s Width
Variable Resistance Module (VRM)
Roller
Locking
Lid
Arm
Stability Wedges (VRM)
Fig A
Fig B
Fig C
Contact Us
1-800-PILATES | [phone]
pilates.com | [e-mail]
10880 | 06.03.21

CRITICAL NOTE:
Never allow the hand straps to recoil uncontrolably. Releasing
the hand straps while under tension will damage the VRM.
BEFORE EACH USE:
»Inspect the hand straps, cords, and buckles for wear.
»Make sure the lid is securely locked so the Arm stays in place
during use.
»Verify that the VRM bolts are not loose.
»Make sure the Stability Wedges are no more than a finger’s
width from the ends of the foam.
ADJUSTING THE RESISTANCE
NOTE: It is very important that the resistance only be adjusted
when the cord is fully retracted or the VRM may be damaged.
LIGHT RESISTANCE: Both buttons OUT
MEDIUM RESISTANCE: One button IN, one button OUT
HEAVY RESISTANCE: Both Buttons IN
SAFETY AND COMFORT ON THE MOTR
»To keep the MOTR from sliding on a smooth floor place a yoga
mat under the Stability Wedges.
»To create a softer surface for sensitive clients place a yoga
mat or a Mini Mat on top of the roller.
»To lessen the risk of slipping when standing on the roller, wear
flexible shoes or socks with grip.
»To stabilize the MOTR when it is in Ballet Barre position, place
it on a non-slip surface.
CUSTOMER SATISFACTION POLICY
Returns and Warranties
For complete and current information on returns, shipping,
changes, cancellations and warranties, please visit “About My
Order” in the online store at pilates.com.
Click here for Balanced Body Patent Data.
Clic aquí para obtener datos de patentes de Balanced Body.
Cliquez ici pour consulter les données de brevet du corps
équilibré.
Fare clic qui per i dati sui brevetti di Balanced Body.
Klicken Sie hier für Balanced Body Patent Data.
Klicka här för Balanced Body Patent Data.
单击此处以获取平衡车身专利数据。
QUESTIONS?
Please call Balanced Body Technical Support at
1-800-PILATES (U.S.) or [phone] (International).
This button is ‘IN’.
Only grey visible.
This button is ‘OUT’.
White is visible.
Fig D
