Bali AutoView User manual

Owner’s Manual
AutoView™ Motorized Shades

2
Please be sure to read and remove the securing tape and label before operating your motorized shade.
About Your Motorized Shade
Motorized shades offer a convenient solution to everyday challenges. They provide instant privacy,
glare reduction, and eliminate the need to manually adjust shades. Motorized shades also eliminate
dangerous cords and create a comfortable and energy efcient environment. Your shades feature
Z-Wave Radio technology, Z-Wave is an advanced radio platform which operates up to 65 ft and
eliminates the need to aim the remote at the shade.
About your Motorized Shade .............................................................................................................................................. 2
Basic Shade Control ............................................................................................................................................................ 3
Control Features .................................................................................................................................................................. 3
Home Button — Single-Channel Remote ........................................................................................................................... 3
LED (Light) Locations and Battery Status ........................................................................................................................... 4
Program Buttons ................................................................................................................................................................. 5
Adjusting Your Shade’s Default Lower Limit (optional) ........................................................................................................ 6
Adjusting Your Shade’s Default Upper Limit (optional) ....................................................................................................... 6
Adjusting Your Shade’s Home Position (optional) ............................................................................................................... 7
Adjusting the Home Position on a Group of Shades (optional) ............................................................................................ 8
Reversing Motor Direction .................................................................................................................................................... 9
Adding Remotes and Creating Groups .............................................................................................................................. 10
Adding a New Remote When the Only Remote Controlling the Shade is Lost .................................................................. 10
Adding a New Single-Channel Remote as a Group Control .............................................................................................. 11
Adding Secondary Remotes for Individual Shade Control Using a Single-Channel Remote as Primary ........................... 12
Reasigning a Two-Button Remote as a Group Control ...................................................................................................... 13
Adding Secondary Remotes to a Group of Shades for Individual Control Using a Two-Button Remote as Primary ........ 14
Adding Z-Wave®Shades to a Home Automation Hub.........................................................................................................15
Associating Secondary Remotes to Shades........................................................................................................................16
Network Reset .................................................................................................................................................................... 17
Local Reset — Motor ......................................................................................................................................................... 17
Local Reset — Remotes ..................................................................................................................................................... 17
Z-Wave Information ............................................................................................................................................................ 18
FCC Class B Notice ........................................................................................................................................................... 18
Battery Information for Shades ............................................................................................................................................18
Notes ....................................................................................................................................................................................19
Table of Contents
Remove securing tape and position motor
RF antenna wire and power cable away
from roller tube (see A) or outside of headrail
(see B) depending upon product type.
Avoid crimping or damaging the antenna
and power lead during installation process.
NOTE: RF antenna should be visible
(exposed outside headrail) for greatest
RF range. In some cases, RF antenna
wire may need to be repositioned for
optimal performance.
RF Antenna Wire
Power cable
B. Cellular, Pleated,
Classic Roman
Power cable
RF Antenna Wire
ATTENTION! IMPORTANT INSTALLATION INFORMATION
¡ATENCIÓN! INFORMACIÓN IMPORTANTE SOBRE LA INSTALACIÓN
A. Solar, Roller,
Soft Shade, Natural Shade
A. Solar, Roller,
Soft Shade, Natural Shade

3
Basic Shade Control
Control Features
Home Button — Single-Channel Remote
Upon rst power up, you will see a green light illuminate on the headrail or motor end of the shade. This will happen
whenever power is rst applied or restored after an outage. Press the UP or DOWN button to operate the shade.
Note: You can press and release the opposite directional button to stop the shade while it is in motion.
How to operate your shade with the two-button remote or optional single-channel remote.
button: Acts as a STOP button while shade is in
motion. It can also be programmed as a quick way to
bring shades to your preferred intermediate position.
Press and release while your shade is at rest to bring
your shade to your position.
Press and release while the shade is in motion to stop
the shade.
Press and release
the UP button
to fully open the
motorized shade
Press and release
the DOWN button
to fully close the
motorized shade
Your controls have been preprogrammed to control your shade. The upper and lower limits and
position have already been set. If you are not satisfied with the default upper, lower, or position
of your shade, see steps in the following sections of this manual.
UP Button
DOWN Button
HOME Button
(Intermediate/Favorite)
Momentary Movement: Press and hold the directional buttons (UP or DOWN) to operate shade for ne-tuning. The
shade will only travel while the button is depressed. Releasing the directional button will stop the movement.
Jog: A jog is a brief up and down movement of the shade. This guide references that your shade will jog as you program
and adjust it.

4
LED (Light) Locations and Battery Status
LED Light Bar
Light indicator
on the front of
the controls
Shade LED
Light indicator on
the shade end
Remote LED Indications
If the battery within the remote is completely discharged, there will be no
LED feedback when a button is pressed. Always replace battery as a rst
solution if the LED does not light with a button press.
Replacement battery: #CR2430 Lithium Coin
Shade LED Indications
The shade LED is located on the end of your shade and provides
additional valuable feedback. Avoid excessively bright conditions for
better visibility. If there is no operation or LED indication when a
command is sent to the shade motor, replace the batteries.
Replacement batteries: Eight AA Lithium per battery case; larger shades
may require multiple battery cases.
LED Action When Definition
Green ashing only After button press Remote battery
is good
Amber ash after
green ash sequence After button press Remote battery is low
Red ash after green
ash sequence After button press Remote battery require replacement
LED Action When Definition
Amber ashing After motor operation Shade batteries are
at approximately 20%
Red ashing After motor operation Shade batteries
require replacement

5
Program Buttons
Cellular, Pleated,
and Roman
Located on the headrail
Single-Channel Remote
BACK VIEW BACK VIEW
Two-Button Remote
Program
Button
Remote Program Button
The recessed button on the back of the two-button or optional single-channel remote is used for various programming
functions outlined in this guide.
Shade Program/Operation Button
The button located on the headrail or motor end can be used to operate the shade if the remote is misplaced or to
conrm various programming functions.
Solar, Roller, Natural
Shade, and Soft Shades
Located on the motor end
Solar, Roller, Natural
Shade, and Soft Shades
Located on the motor end

6
Adjusting Your Shade’s Default Upper Limit (optional)
Adjusting Your Shade’s Default Lower Limit (optional)
1. Press and release DOWN
button. Allow the shade to
reach its default lower limit.
1. Press and release UP button.
Allow the shade to reach its
default upper limit.
The lower limit of your shade is factory preset to a closed position matching the ordered length. You may want to
adjust the lower limit to accommodate window hardware or other obstructions.
The upper limit of your shade is factory preset to an open position which protects the shade from damage
while maximizing the view. If you desire the shade to have an upper limit at a lower position when fully opened,
follow these steps.
*PRODUCT SAFETY NOTE: When adjusting the upper limit on cellular or pleated shades, do not
raise the product too high. This can make the product too tight, which can cause the motor to fail
and/or break/fray the internal cording. When installing a solar or roller shade in a fascia or
cassette valance, be sure the hem bar does not lift into the fascia or cassette, as this could cause
the hem bar to get stuck and/or damage the fabric.
NOTE: All programming steps are associated with a time-out feature to preserve battery life.
*PRODUCT SAFETY NOTE: Be careful not to exceed the ordered product length, which may
result in a damaged product. If your shade will not lower to your desired lower limit, contact a
customer service representative for assistance.
NOTE: All programming steps are associated with a time-out feature to preserve battery life.
2. Once the shade stops, press
and hold UP and DOWN
buttons simultaneously until
LED light on the remote turns
amber (about three seconds),
then release both buttons.
The shade will jog and the
LED on the remote will ash
green. The LED on the shade
will alternately ash green
and red.
2. Once the shade stops, press
and hold UP and DOWN
buttons simultaneously until
LED light on the remote turns
amber (about three seconds),
then release both buttons.
The shade will jog and the
LED on the remote will ash
green. The LED on the shade
will alternately ash green
and red.
3. Adjust your lower limit by
using UP or DOWN to move
your shade to your desired
lower limit.* The shade will only
move while UP or DOWN is
being pressed.
3. Adjust your upper limit by
using UP or DOWN to move
your shade to your desired
upper limit.* The shade will
only move while UP or DOWN
is being pressed.
4. When the shade is stopped at
your new desired lower limit,
press and hold UP and DOWN
buttons simultaneously until
the LED on the remote turns
amber (about three seconds),
then release both buttons. The
shade will jog and the new
lower limit will be set.
4. When the shade is stopped at
your new desired upper limit,
press and hold UP and DOWN
buttons simultaneously until
the LED on the remote turns
amber (about three seconds),
then release both buttons. The
shade will jog and the new
upper limit will be set.
Hold
Hold
Hold
Hold
Hold
Hold
Hold
Hold

7
Adjusting Your Shade’s Home Position (optional)
If your shade system includes an optional single-channel remote, it has been preprogrammed to control your shade(s).
The default position (intermediate position) is preset to mid-length of your shade. To change the position, follow
these steps.
NOTE: If the single-channel remote controls multiple shades as a group, refer to the next section.
NOTE: Always adjust the upper and lower limits before adjusting your position. After adjusting the upper or lower
limits, the position will reset to the new mid-length position.
1. Use the UP or DOWN button to put the shade in
motion. When the shade reaches your desired
position, press and release to stop the shade.
2. To set your position, press and hold the
button until the LED on the remote turns amber (about
three seconds), then release the button. The shade will
jog and the new position will be set.
A time-out can occur during programming the remote or motor. When no buttons are pressed within
a predetermined amount of time (about 20 seconds), the remote or motor will revert back to a user
state. Simply repeat programming steps if the remote or motor has timed-out.
Hold

8
Adjusting the Home Position on a Group of Shades (optional)
If your shade system includes an optional single-channel remote as a group control, it has been preprogrammed to
control your shades. The default position (intermediate position) of all shades is preset to mid-length. To change the
position on multiple shades, follow these steps.
NOTES:
• Always adjust the upper and lower limits before adjusting your position. After adjusting the upper or lower
limits, the position will reset to the new mid-length position.
• You are required to access the motor head to adjust the position.
1. Press and release the button to bring the
group of shades to their preprogrammed
position. (Fig. 1)
2. In order to adjust the position of each
shade, you must rst target the individual
shade you want to adjust. To do this, press
and release the program button on the back
of the single-channel remote (one tap). The
LED on the remote will ash green. (Fig. 2)
3. Then on the shade that you want to adjust,
press and hold the program button on the
headrail/motor end until the LED begins to
ash green (about three seconds) and
release. The shade will jog. (Fig. 3)
4. Using the two-button remote that controls the
shade, adjust the shade to the new desired
position. (Fig. 4)
5. Using the single-channel remote, press and
HOLD the button until the LED turns
amber (about three seconds), then release
the button. The shade will jog and the
position of the target shade is now reset.
(Fig. 5)
6. Repeat process for additional shades to
adjust the new desired position.
Fig. 1
Fig. 4
Fig. 2
Fig. 5
1x
Fig. 3
Hold
Hold
A time-out can occur during programming the remote or motor. When no buttons are pressed within
a predetermined amount of time (about 20 seconds), the remote or motor will revert back to a user
state. Simply repeat programming steps if the remote or motor has timed-out.

9
Each shade is preprogrammed from the factory to operate up and down corresponding to the appropriate buttons on
your remote(s). However, if the directions are inadvertently reversed, follow these steps to return the shade to
proper operation.
Reversing Motor Direction
1. Move the shade to a position between the
upper and lower limits. Press and release a
directional button to set the shade in motion.
Press the opposite directional button to stop
the shade. (Fig. 6)
The shade will jog and the LED on the motor
will begin to alternately ash green and red,
and the LED on the remote will ash green.
Shade direction has now been reversed;
however, the upper and lower limits have
been maintained.
2. Press and hold UP and DOWN buttons
until the LED light turns amber (about three
seconds), then release buttons. (Fig. 7)
3. Press and hold the UP and DOWN buttons
until the LED turns amber (about three
seconds), then release buttons. (Fig. 8)
Fig. 6
Fig. 8
Fig. 7
Hold
Hold
Hold
Hold
A time-out can occur during programming the remote or motor. When no buttons are pressed within
a predetermined amount of time (about 20 seconds), the remote or motor will revert back to a user
state. Simply repeat programming steps if the remote or motor has timed-out.

10
Adding Remotes and Creating Groups
Adding a New Remote When the Only Remote Controlling the Shade is Lost
1. Press and hold the program button on the
headrail/motor end. The LED will ash green
then amber (about seven seconds). When the
shade jogs once, release the button and the
LED will turn solid amber and turn off. The
motor is now ready to be associated to a new
remote. (Fig. 9)
2x
Your motorized shades are preprogrammed from the factory with the appropriate pairing and grouping between remotes
and shade motors. However, there are several scenarios when additional programming steps are required. The next
sections explain how to accomplish the most common scenarios you might encounter. If the appropriate scenario is not
included, please contact a customer service representative prior to attempting any adjustments.
If you no longer have your remote, or the remote has been damaged and no longer works, follow these steps.
2. Using a paper clip or a similar item, press and
release the programming button located on
the back side of the new remote twice in rapid
succession (two taps). The LED on the remote
will alternately ash amber and green. (Fig. 10)
3. Press and hold the program button on the
headrail/motor end, and release when the
LED ashes green (about three seconds). The
shade will jog and all LEDs will turn off. The
shade will now operate from the newly added
remote. (Fig. 11)
A time-out can occur during programming the remote or motor. When no buttons are pressed within
a predetermined amount of time (about 20 seconds), the remote or motor will revert back to a user
state. Simply repeat programming steps if the remote or motor has timed-out.
Fig. 9
Fig. 11
Fig. 10
Hold
Hold
Hold
Hold

11
Adding a New Single-Channel Remote as a Group Control
1. Exclude each of the other individual remotes from
the shade they control.
A. Press and hold the program button on the
back of the remote until the LED stops
ashing. The LED will ash green, amber, red,
and then turn off (about 15 seconds).
(Fig. 12)
B. Press and hold the button on the headrail/
motor end until the LED begins to ash red
(about seven seconds) and release. The shade
will jog, conrming exclusion. (Fig. 13)
2. Include the new group remote as the
primary control.
A. Press and release the program button on the
back of the remote twice in rapid succession
(two taps). The LED on the new group remote
will alternately ash amber and green to
identify inclusion mode. (Fig. 14)
B. Press and hold the program button on the
headrail/motor end until the LED ashes
green (about three seconds), and release. The
shade will jog and all LEDs will turn off. The
shade will now operate from the newly added
remote. (Fig. 15)
Repeat this process for each motor to be added to
this group.
Go to page 12 to add secondary remotes for
individual shade control.
If a group control was not selected at the time of purchase and is being added to an existing motorized shade, follow the
steps below.
NOTE: Individual shade control will be restored with the original two-button remote only after it has been reassociated
with the shade as a secondary remote. (See next page)
Fig. 12
Fig. 14
Fig. 13
Fig. 15
Hold
Hold
Hold
2x
A time-out can occur during programming the remote or motor. When no buttons are pressed within
a predetermined amount of time (about 20 seconds), the remote or motor will revert back to a user
state. Simply repeat programming steps if the remote or motor has timed-out.

12
A time-out can occur during programming the remote or motor. When no buttons are pressed within
a predetermined amount of time (about 20 seconds), the remote or motor will revert back to a user
state. Simply repeat programming steps if the remote or motor has timed-out.
Adding Secondary Remotes for Individual Shade Control Using a Single-Channel Remote
as Primary
When adding individual control to shades that are part of a newly formed group, the remote will now be referred to as the
secondary control.
2x
1. Joining a secondary remote to the primary remote.
A. Starting with the primary control, press and
release the program button on the back side
of the current remote twice in rapid
succession (two taps). The LED light will
alternately ash amber and green to identify
inclusion mode. (Fig. 16)
B. Press and hold the program button on the
secondary remote control until the LED light
ashes green (about three seconds), then
release the button. Both the primary and
secondary remote LEDs will ash green and
then turn off, conrming inclusion. (Fig. 17)
2. Associate secondary control to the motor.
A. Press and release the program button on the
back side of the secondary control once
(one tap). The LED will ash green to identify
association mode. (Fig. 18)
B. Press and hold the program button on the
target shade headrail/motor end until the LED
light ashes green (about three seconds), then
release button. The LED on the secondary
control will turn green and the shade will jog.
Both the primary (group) and secondary
(individual) controls will now operate the
shade. (Fig. 19)
Repeat this process on all shades you want to
individually control.
Fig. 16
Fig. 17
Fig. 18
Fig. 19
1x
Hold
Hold

13
A time-out can occur during programming the remote or motor. When no buttons are pressed within
a predetermined amount of time (about 20 seconds), the remote or motor will revert back to a user
state. Simply repeat programming steps if the remote or motor has timed-out.
Reassigning a Two-Button Remote as a Group Control
This process is followed when the end user desires to reassign a two-button remote to control a group of shades.
You must rst select which remote you would like to be the group controller, then exclude all other individual
two-button remotes.
NOTE: This two-button remote will no longer perform as an individual shade controller.
2. Include two-button remote as the primary
controller of a group of shades.
A. Press and release the program button on the
back of the remote twice in rapid succession
(two taps). The LED on the new group remote
will alternately ash amber and green to
identify inclusion mode. (Fig. 22)
B. Press and hold the program button on the
headrail/motor end until the LED ashes
green (about three seconds), and release. The
shade will jog and all LEDs will turn off. The
shade will now operate from the newly
added remote. (Fig. 23)
Repeat this process for each shade to be added to
this group.
Go to page 14 to add secondary remotes to
shades in the group for individual control.
Hold
2x
1. Exclude the two-button remote from the shade
they control.
A. Press and hold the program button on the
back of the remote until the LED stops
ashing. The LED will ash green, amber, red,
and then turn off (about 15 seconds).
(Fig. 20)
B. Press and hold the button on the headrail/
motor end until the LED begins to ash amber
(about seven seconds) and release. The shade
will jog, conrming exclusion. (Fig. 21)
Repeat this process to exclude each individual
remote, except the one designated as the new
group control.
Go to page 14 to add secondary remotes to
shades in the group for individual control.
Fig. 22
Fig. 21
Fig. 23
Fig. 20
Hold
Hold

14
A time-out can occur during programming the remote or motor. When no buttons are pressed within
a predetermined amount of time (about 20 seconds), the remote or motor will revert back to a user
state. Simply repeat programming steps if the remote or motor has timed-out.
Adding Secondary Remotes to a Group of Shades for Individual Control Using a Two-Button
Remote as Primary
When adding individual control to shades that are part of a newly formed group, the remote will now be referred to as the
secondary control.
Hold
1. Join a secondary remote to the primary remote.
A. Starting with the primary control, press and
release the program button on the back side
of the current remote twice in rapid
succession (two taps). The LED light will
alternately ash amber and green to identify
inclusion mode. (Fig. 24)
B. Press and hold the program button on the
secondary remote control until the LED
ashes green (about three seconds), then
release the button. Both the primary and
secondary remote LEDs will ash green, then
turn off, conrming inclusion. (Fig. 25)
2. Associate secondary control to the motor.
A. Press and release the program button on the
back side of the secondary control once (one
tap). The LED will ash green. (Fig. 26)
B. Press and hold the program button on the
target shade headrail/motor end until the LED
ashes green (about three seconds), then
release button. The LED on the secondary
control will turn green and the shade will jog.
Both the primary (group) and secondary
(individual) controls will now operate the
shade. (Fig. 27)
Repeat this process on all shades you want to
individually control.
Fig. 24
Fig. 25
Fig. 26
Fig. 27
2x
Hold
1x

15
Adding Z-Wave®Shades to a Home Automation Hub
Your shades and controls feature built-in Z-Wave radio technology. This allows the shades to be controlled directly by
many popular home automation hubs. The process of including the shades and controls into a Z-Wave smart home
network starts with rst disassembling the current shade/control network. This is referred to as the exclusion process.
After the current shade/control network is disassembled, a new network is created with the home automation hub
through the inclusion process. Finally, after all shades and controls are included in the smart home network, the remote
controls can be added back to the shades for local control through the association process. These steps are outlined
below and on the next page.
Fig. 28
Fig. 29
1. Exclude all remotes from the shade network by
performing a local reset on each remote.
Press and hold the program button on the back of the
remote until the LED stops ashing. The LED will ash
green, amber, red, and then turn off (about 15 seconds).
(Fig. 28)
Repeat this process to exclude each individual remote.
2. Exclude each shade from the network by performing a
network reset.
Press and hold the program button on the shade until
the shade jogs once (about seven seconds), then
release the button. (Fig. 29)
NOTE: Shade limits are not lost. All controllers will be
removed from the shade’s memory.
3. Include each shade and remote in the home
automation hub’s network.
A. Initiate device enrollment from the home
automation hub’s user interface. Refer to the
home automation hub’s instructions for enrolling
new Z-Wave devices. In some cases, the
shades/remotes may be enrolled as “Other Z-Wave
Supported Device” or within the “Lighting Devices”
product sections.
NOTE: Inclusion of both the shades and remotes
is required for proper operation when using a
home automation hub.
B. Press and hold the button on the shade end until
the LED begins to ash green (about three
seconds) and release. If inclusion is successful,
the shade will appear as a found Z-Wave device
in the home automation system user interface.
Repeat this step for each shade and remote being
added to the home automation system. (Fig. 30)
Refer to Associating Secondary Remotes to Shades on
the next page. This is required for local control by
the remotes.
Fig. 30
Hold
Hold
Hold

16
Associating Secondary Remotes to Shades
Association is the setting up of a secondary remote in the network to operate specic shade(s). A secondary remote can
be associated to any number of shades.
NOTE: The shade and remote must be included in the home automation hub’s network for this association step.
Fig. 31
Fig. 32
1. Join a secondary remote to shade(s).
A. Press and release the program button on the back of
the remote once (one tap). The LED will ash green
to identify association mode. (Fig. 31)
B. Press and hold the button on the headrail/motor
end until the LED begins to ash green (about three
seconds) and release. The LED on both the motor
and the remote will turn solid green, then turn off and
the shade will jog, conrming association. (Fig. 32)
Repeat this process on all shades you want to
individually control.
NOTE: A primary remote can be identied by double
tapping the program button on the remote.
If allowed to include or exclude, it is a primary
remote. If not, it is a secondary remote.
Identication is as follows:
Double tap (inclusion mode):
Alternating amber/green = primary remote
Solid red LED = secondary remote
1x
A time-out can occur during programming the remote or motor. When no buttons are pressed within
a predetermined amount of time (about 20 seconds), the remote or motor will revert back to a user
state. Simply repeat programming steps if the remote or motor has timed-out.
Hold

17
Network Reset
Local Reset — Motor
Local Reset — Remotes
1. Press and hold the button on the headrail/
motor end until the shade jogs once (about
seven seconds), then release the button. The
LED will go from solid green to ashing green,
and then to ashing amber.
NOTE: Shade limits are not lost. All controllers will
be removed from the motor’s memory.
1. Press and hold the button on the headrail/
motor end until the shade jogs twice (about
15 seconds), then release the button. The LED
will go from solid green to ashing green to
ashing amber, and then to rapid ashing red.
NOTE: Factory limits are set in the motor at about
2" to 4" apart. All controllers will be
removed from the motor’s memory.
1. Press and hold the programming button until
the LED stops ashing. LED will ash green,
amber, red, and then nally turn off (about
15 seconds).
NOTE: Local reset must be performed on both the
controllers and motors. All motors will be
removed from the remote’s memory.
Use these procedures only if a complete network reset is required.
Contact customer service to understand if you need to perform these steps.
Hold
Hold
Hold
Hold

18
Z-Wave is a wireless mesh-networking protocol for reliable, intelligent home control
of all Z-Wave compatible devices. Z-Wave devices can act as repeaters to create a
mesh-network to ensure reliable communication regardless of the manufacturer or
type of device. This product can be included and operated in any Z-Wave network
with other Z-Wave certied devices from any other manufacturer. Z-Wave devices
such as lamp modules, fan controllers, thermostats, dimmer switches, and many
other types of home control devices are available from a wide range of
manufacturers. The Z-Wave Alliance (www.z-wavealliance.com) provides a list of
manufacturers of Z-Wave compliant devices. Z-Wave was created by Sigma
Designs and more details on the technology can be found at www.z-wave.com.

This product can be included and operated in any Z-Wave network with other
Z-Wave certied devices from other manufacturers and/or other applications. All
nonbattery-operated nodes within the network will act as repeaters regardless of
vendor to increase reliability of the network.

The current product controls may establish two Association Groups. Association
Group #1 is a dedicated lifeline for secondary controls, primarily used for battery
status reports, central scene cc, local reset cc. Association Group #2 is dedicated
to slave shades nodes, with a maximum of 12 slave nodes. Normal shade control
command will use Association Group #2.
FCC Class B Notice
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/television technician for help.
Modifications: Any modications made to this device that are not approved by Oracle may void the authority granted to the
user by the FCC to operate this equipment.
Advance technical information available by contacting customer service.
Battery Information for Shades
Use only eight AA Lithium batteries, which are available through most hardware stores, pharmacies, and home centers.
CAUTION: Batteries must be installed as shown below. Failure to do so could result in injury and will invalidate your warranty.
Do not mix type, brand, or old with new. Do not recharge, disassemble, heat (above manufacturer’s specied temperature), or
incinerate. Keep batteries out of reach of children and in original packaging until ready to use. Dispose of batteries properly.
Correct battery orientation and proper battery disposal must be followed.

19
Notes
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________

Bali is a brand of Springs Window Fashions, the Best Experience Company
Visit us at: Baliblinds.com
or contact motorization technical support at [email protected]
1-800-221-6352
79084-00 (02/17) IMR 17-4694
springswindowfashions.com • Middleton, WI 53562
