1. ICMP HDD replacement kit
1. ICMP HDD REPLACEMENT KIT
Purpose of this kit
This kit contains one HDD which can be used to replace a malfunction HDD of the Barco ICMP installed
inaBarcoDPInfinium powered projector.
About this document
This document gives a brief introduction into the ICMP HDD, describes the LED status of the HDD and
describes the HDD removal and installation instructions.
The latest version of this document can be downloaded from the Barco website www.barco.com or from
the secured Barco website https://my.barco.com.
For detail information about the ICMP or Barco digital cinema projector refer to the manual of the projector
which is also available on the Barco website.
CAUTION:The HDD is not hot swappable. Switch off the projector prior to replace the
malfunction HDD.
In case only one HDD is replaced (RAID degraded mode) the ICMP automatically starts
with the RAID recovery process after the malfunction HDD is replaced. The red LED of
the HDD which has to be rebuild is blinking. This process takes about 3 to 4 hours. Once
the RAID is completed the red LED turn off.
CAUTION:It’s strongly recommended to complete the RAID recovery process prior to
start a show. This to ensure that the content is protected and that the show is not inter-
rupted.
In case more than one HDD is replaced (RAID destruction mode), all content will be lost
an the ICMP automatically creates a new (empty) RAID 5 configuration.
1.1 ICMP HDD
About ICMP HDD
The three HDDs (local storage) in the ICMP, are set up in a RAID 5 configuration. This storage technique,
that combines multiple HDD components into a logical unit, manages enough redundancy information to
continue to operate properly after the loss of one HDD.
Image 1-1
R5905769 ICMP HDD 11/02/2014 1

1. ICMP HDD replacement kit
A failed drive should be replaced as soon as possible.
CAUTION:ARAID5configuration with three HDDs allows a maximum loss of one disk.
With the simultaneous loss of more than one HDDs, data is lost and the RAID must be
completely initialized again!
About degraded mode
When a RAID array experiences the failure of one disk, it enters in degraded mode. Content storage and
playback is always available on the ICMP.
CAUTION:The loss of one disk causes no serious consequences on the ICMP. But ac-
tion must be taken quickly because the loss of a second disk will make the RAID system
inoperative. The main cause of the total loss of RAID is due in most cases to the loss of
the second disk while the first has not been rebuilt!
About “RAID recovery” process
The restoration from degraded to normal condition of the RAID 5 system is done automatically. When the
RAID controller detects a new HDD to replace the failed disk the recovery procedure starts automatically.
CAUTION:The automatic process does not work if more than one disk is lost. In that
case the RAID must be completely initialized again!
About RAID destruction
When more than one HDD is out of order, the RAID is considered as destroyed and the content is lost.
The failed HDDs must be changed and a new RAID must be created.
Exchange or re-use of a disk set
It’s possible to reuse a set of disks coming from another projector with ICMP. It is sufficient to insert three
HDDs, from a valid RAID array, and let the system explore the new RAID. The mounting order of the HDDs
and the HDD slots do not matter. Of course, it’s necessary to retrieve the KDMs corresponding to content
and the ICMP from the content distributor.
1.2 ICMP HDD status LEDs
ICMP HDD status LEDs
54
Image 1-2
2R5905769 ICMP HDD 11/02/2014

1. ICMP HDD replacement kit
Status overview PWR/ERROR and READY LEDs:
4 5
HDD I/O RAID ICMP HDD Status
Off Off HDD turned off
Blinking
Green
Off RAID normal operation (I/O activity)
Blinking
Green
Blinking Red RAID rebuilding
Off Red RAID error
1.3 Removing a HDD form the ICMP
How to remove a HDD ?
1. Switch off the projector.
2. Moving the latch towards the left.
Image 1-3
3. Push the unlock button to open the handle.
Image 1-4
4. Pull the HDD out of its slot.
R5905769 ICMP HDD 11/02/2014 3

1. ICMP HDD replacement kit
Image 1-5
To install the HDD see procedure "Installing a HDD into the ICMP", page 4 .
1.4 Installing a HDD into the ICMP
This procedure assumes that the HDD slot of the ICMP is empty. If not, see procedure
"Removing a HDD form the ICMP", page 3 .
How to install a HDD ?
1. Ensure that the projector is switched off.
2. Prepare the HDD for insertion by moving the latch towards the left and push the unlock button to open
the handle.
Image 1-6
3. Insert the HDD into the HDD slot. Ensure that the handle is sufficiently open so that the hook (reference
1) of the handle can pass the front plate of the ICMP.
4R5905769 ICMP HDD 11/02/2014

1. ICMP HDD replacement kit
1
Image 1-7
4. Push the HDD completely inside its slot, close the handle, and move the latch towards the right.
Image 1-8
5. Switch on the projector.
In case you replace one HDD (e.g. degraded mode) the ICMP automatically starts with
the RAID recovery process. The red LED of the HDD which has to be rebuilt is blinking.
This process takes about 3 to 5 hours. Once the RAID is completed the red LED turn off.
CAUTION:It’s strongly recommended to complete the RAID recovery process prior to
start a show. This to ensure that the content is protected and that the show is not inter-
rupted.
R5905769 ICMP HDD 11/02/2014 5
